Used for survery at the Ballarat School of Mines for Civil and Mining classes.A surveying level. Longitude and transverse bubbles, magnet, compass. External focussing. Twin vertical inclined hair lines. Four levelling screws. Objectove lens with dust shield. Fits tripod cat. no. 04132thodolite, surveying, ballarat school of mines, w.m. drummond, civil engineering, mining engineering, scientific instruments

8680.1 - Leather bound casing (blue in colour). Padding in lid with orange cover. Grey in the bottom with specific shapes for components to be stored. 8680.2 - Metal compass. 8680.3 - Plastic handled Ferrules metal callipers.

Military issue as part of a soldiers kit and webbing.Compass pouch, rectangular shape, green colour with folding flap cover, rear has webbing section sewn on on with slide attachment to fit a belt, hand written on front, stamped details inside flap.On front in black Texta, “ Withers 2263729”. On inside flap in black, “ 8645 - 50 - 577 - 4927 - D.....S......8/70”compass, poches, military

Used by John Burke at the State Rivers Tatura in the 1960 - 1970's.Compass: black and silver rimmed round container with removable lid. Bottom section has a clear glass with black rim covering the compass pointer and directions. Has 8 gold screws in black rim. Attached to rim is a hinged section with middle section see through. Opposite hinged section is another hinged section with sight on it. On outside rim of container under second hinged piece, is a black metal ring for holding. Bottom of the container has a flanged circle which attaches to a stand. Case: is tan leather with stitching around all edges. Two pieces, one large which holds the compass and the other is joined to bottom piece to form a lid. A leather strap is joined to the large section to hold the lid down and to make a carrying strap. Inside is red felt.compass, john burke, state rivers tatura

The belt and pouch issued to John Charles Dean No 144278 RAAF, enlisted 26.8.43 age 18 years. On discharge from the RAAF he was an LAC in 78 Sqd RAAF. Refer also 1817..1) Webbing Belt, Khaki, adjustable with brass buckles and loops, rear of belt has two webbing loops with brass buckles .2) Compass pouch with a brass stud also two brass loops on the rear..1) "144278 RAAF"uniforms airforce, webbing

Plane, Compass. With front horn shaped handle, wooden body, wooden wedge. Iron missing. Marked 48mm. Bismark plane with front horn shaped handle, wooden body, wooden wedge and curved sole. flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, plane, bismark plane

Grey hammertone cylindrical house with removable lid. Compass equipped with sighting wire and slot attachments. "Sirius" Mounting flange on bottom face with 17mm diameter female screw head. Tan leather carry case.scinetific instrument, scientific object, compass, esdale & sons

This is a book of 122 pages. It has a dark green cover with a gold compass pattern and gold printing on the front cover and spine. The pages contain printed text, maps, diagrams, graphs, colour illustrations and sepia -toned photographs.non-fictionThe history of the first 80 years of the Nestle's Companydennington nestle's factory, dennington, warrnambool, milk production, milo, nescafe production, warrnambool manufacturing

The Stars and Compass Trophy was donated by Richard Hawkins in 1998 (the Year of the Oceans) to encourage the use of traditional navigation skills by yachts at sea. See attached document for more extensive background informationnavigation, hawkins

Surveying level - long bubble level on top. Magnet, compass under telescope. No crosshairs. External focussing. Four levelling screws. No transverse level. Housed in a polished timber storage box. Fits tripod Catalogue Number 429.scientific instruments, level, dumpy

Seven boxed drafting sets containing compasses, pens and dividers. Padded lids, interiors lined with velvet, blue, black or green. .1) Belonged to Peter Fraser. .2) Belonged to Ian Hooper. .6) Belonged to Noel Cawthorn. .6 & .7) Embossed on lids "Eco O Bra / Kandidat". .1) "Koala / Series / Made in Australia".instruments, trades, drafting, containers

Map of London with also places of interest. Part of th collection of Frederick Gardner Davey DFC No 410533 RAAF. Refer cCat No 3536P for his service details.Black and white folded street map with transport routes/stations marked in orange. Cover is black and white print, features a scroll and compass design inside a B & W border, written details in black type, street index printed on inside of the cover.map, london

This is the story of those Australian Army nursing sisters who were in Malaya with the 8th Division AIF in 1941 and early 1942 and later taken prisoner by the Japanese.Hard cover in green buckram. Title on spine in faded gold lettering. Green end papers feature a map of South East Asia. Front cover embossed with the shape of a compass. 204 pages with cut edges. Illustrated with black & white line drawings.Inside on first page: “E Houlden Skene St Bendigo” Stamp in blue ink on title page: “Returned and Services League”books-military, military history-army nurses, illustrations, coolies, pow’s

A set of mathematical instruments used in geometry and other more complicated drawing processes.A set of mathematical instruments in a tin. The tin has a blue lid with red and white lettering and the drawing of an express train. This is a Helix set of mathematical instruments comprising a compass, divider, boxwood ruler, set squares, protractor, eraser, pencil and blotter used in schools.education department, teaching, equipment, george evans collection

According to Max Clarke this item was used by the surveying classes at the Ballarat School of MinesA boxed (timber) theodolite with crossbars and full-length stadia wires. The theodolite can be mounted on a metal straightedge base. The box also contains a magnetic compass with two bubble levels, a plumbing folk, and 4 brass paper clips designed to suit a plan table. On box in black paint "A 1". Inside box lid is manufacturer's label and Stadia measurement zero reference calibration.ballarat school of mines, surveying equipment, gurley, max clarke, theodolite, stadia measurement, calibration, scientific instrument

A quadrant mounted telescope with crosshairs and external focussing, with longitudinal bubble level. Mountable on a magnetic compass plate with two bubble levels. Complete with dapered-spigot base plate and slot view attachments, Housed in a polished timber box. Inside the box are two labels -A label on the inside of the box " to the School of Mines and Industries, Ballarat" To (...) Hoadley, Esq, Principal, Footscray Technical school, Footscray WII" "Sluggish Needle, 9/4/3..." "still sluggisg 1966"mining, ballarat school of mines, surveying, archibald hoadley, scientific equipment, circumferential, scientific instruments

Compass, divider, and caliper are basically instruments that have two legs pivoted to each other at the top and are concerned with small-distance measurement or transfer. The compass and divider have straight legs; the caliper has curved legs. Dividers and Calipers were known to both the Greeks and Romans, though the caliper was uncommon. A divider with a circular sector, or wing, connecting the two legs was sketched in 1245, its modern counterpart is the wing divider with a thumbscrew clamp and screw for fine adjustment. Or the marine dividers used to measure the distance a vessel has travelled by transferring the vessels distance from a map with the divider and transferring that measurement to a marine ruler to mathematical calculate the distance.Item is believed to be a replica/ copy of a 19th century map calipers used in marine navigation to determine distance travelled. Item was probably purchased between 1972-1975 to add to the marine displays at Flagstaff Hill.Stainless steel dividers used in navigation charts. Top half is alloy plated. "W & HC" and "Made in England".flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, stainless steel dividers, steel dividers, dividers

This theodolite was used by `Mr Dawson' (presumably William Tennant Dawson c.1820-1873) who `surveyed much of the area around and beyond Stratford'. It was damaged by the fire which burnt the original Roseneath home in 1921, when the Macleods were in residence. (Mrs W.T. Dawson was a Macleod). One little boy aged 3 years was given the job of saving everything on the kitchen table when the fire started at breakfast time. The theodolite was possibly in use by Dawson when he laid out St Kilda Road.This theodoite consists of a bottom plate, which is damaged and has melted metal. This rises to a ball joint, on which is pivoted another plate on which were housed four screws, of which three remain, to adjust the level. Above this is another plate, with compass markings and melted glass."Troughton and Simm's/London" in fine engraving on upper plate.surveyors, instruments

Denis Gibbons (1937 – 2011) Trained with the Australian Army, before travelling to Vietnam in January 1966, Denis stayed with the 1st Australian Task Force in Nui Dat working as a photographer. For almost five years Gibbons toured with nine Australian infantry battalions, posting compelling war images from within many combat zones before being flown out in late November 1970 after sustaining injuries. The images held within the National Vietnam Veterans Museum make up the Gibbons Collection.A black and white photograph of - With the "directional stakes" in place, Capt Tony Eaton, Kirribilli, NSW, the 1st ATF Artillery Intelligence Officer about to take a compass reading of the incoming direction of a NVA/VietCong 107mm rocket, watched by Sgt Paul Butcher (29th march 1969)photograph, capt tony eaton, 107mm rocket, 1st atf base, artillery intelligence officer, sgt paul butcher, nva/vc, luscombe airfield, gibbons collection catalogue, 1st australian task force, nva/vietcong, denis gibbons

Author Herbert Newell. Alphabets of varied fonts, headings, flourishes, plans, numerals, sketch maps, scrolls, shading, common errors, compass points. Especially designed for use in Australian Schools, offices of Lawyers, Architects, Surveyors, Engineers, Engravers, and Draughtsmen. Table of contentsThe author is a teacher of show card and ticket writing at Sydney Technical College. Book used by many students and offices. Note by the publishers provides standards for the correct form of the characters. Light brown light card cover with black ink font and border patterns. 32 Cream pages with black ink. Two staples. Hand written name on top of outline black border S. R Coleston. Price 3/9warrnambool, lettering book, angus & robertson limited, s.r. coleston, herbert newell

Denis Gibbons (1937 – 2011) Trained with the Australian Army, before travelling to Vietnam in January 1966, Denis stayed with the 1st Australian Task Force in Nui Dat working as a photographer. For almost five years Gibbons toured with nine Australian infantry battalions, posting compelling war images from within many combat zones before being flown out in late November 1970 after sustaining injuries. The images held within the National Vietnam Veterans Museum make up the Gibbons Collection. A black and white photograph of Long Tan, Phuoc Tuy Province, South Vietnam, 18/08/1969. A digger from 6th Battalion/New Zealand (ANZAC) Royal Australian Regiment, sites in the cross of remembrance using a compass whilst facing directly at the area of the bloody battle.photograph, long tan cross, phuoc tuy province, 6th battalion, 4rar nz, royal australian regiment, gibbons collection catalogue, denis gibbons, photographer, vietnam war, digger, long tan cross dedication

Collman and Tacchi shaft drawn on map corner of Dowding Street and Mt. Korong Road, California Gully, Bendigo. Mt Korong Road later became Eaglehawk Road. Hand drawn map showing the Collmann and Tacchi Shaft with No 17 Crosscut with the distances in feet and inches and the compass bearing of each leg. It is beside Mt Korong Road, near Dowding Street. Some boundary lines are drawn. Also on the map is Lansell's C and T across the road.map, bendigo, goldfields, mining reports, map of collmann and tachi shaft, collmann and tacchi shaft, lansell's c and t

The item was obtained by Donors Grandfather who served British Forces WW1 and was a RAF Sqd Leader during the surrender of Japanese Forces in Hong Kong and New Territories WW2..1) British Marching Compass brass circular shape with hinged opening, has small screws lock device on one side, brass ring on one end. .2) Brown leather case for .1). Has belt loop on rear, folding lid with brass stud for securing..1) On base, “Cruchon & Emons London, 1916 (arrow up)”compass, marching, equipment
