Regulations for the Electrical Equipment of Buildings Publisher: E & F Spon Ltd Date: 1934warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, shipwrecked-artefact, book

Protective relays are one of the critical components of the elctrical power grid that serve to detect defective equipment or other dangerous or intolerable conditions and can either initiate or permit switching or simply provide an alarm to provide an alarm to provide a safer, more reliable delivery system. Used in power stations. The function of relay is to quickly remove from service any equipment that might suffer damage or otherwise affect the operation of the system. Relays protect the electrical system in 2 ways: Prevent failure or damage to electrical systems. Mitigate the effects of failure when it occurs. Switches that control other switches. Relays are used where it is necessary to control a circuit by an independent low-power signal, or where several circuits must be controlled by one signal.Used by the State Electricity Commission of Victoria for the Kiewa Hydro Electric Scheme in the power stations. Manually operated by remote control for an external circuit breaker. The relays were from a Kiewa Hydro Power Station control panel.Collection of black metal rectangular boxes (heavy) containing electrical wires forming a circuit. The longer, narrower rectangles have a bakelite knob at one end. Some of the boxes have one side of clear perspex and another has all sides of clear perspex. One is labelled "group relay". Another has windows with labels eg. 'turbine overspeed' 'emergency trip' and one has 3 steel knobs. - with 'stop', 'start'. One box is larger than the rest and has clear perspex side showing 'overcurrent relay' and workings.One has a plaque attached. Manufacture: "The English Co. Ltd. Londonpower circuits, electrical equipment, electric power control, power relays, power station, circuit breaker

Half foolscap Sheet Gestener printed notice titled "Overhead Electrical Equipment - 600V Traction System - St Kilda - Brighton Electric Street Railway" advising that the overhead and feeder between Hardwood St and Park St was taken out of service and abolished. Signed by T. R. Collier, Chief Traffic Manager, 23 Dec. 1957.trams, tramways, aeta, vr, overhead, closure, st kilda

The test rig is contained in a metal frame with sloping front panel that contains the indicator and number setting knobs. A perspex lift-up lid covers numerous valve sockets and a set of coding wheels. Both sides and back covered with perspex. Metal surfaces painted hammerton grey. Abbreviated working instructions and AVO Valve data manual.Serial Number 1961scientific instrument, ballarat school of mines, valve characteristic meter

.1 - Book - 28 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Contactor Starters for Electric Motors" C49-1927, December 1927. .2 - Book - 56 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Dimensions of insulated annealed copper conductors for electric power and light including voltage tests" C50-1928, June 1928. .3 - Book - 36 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Vulcanised Fibre for Electrical Purposes" C51-1928, May 1928. .4 - Book - 16 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Bus-bars and connections constructed of bare copper or aluminium" C52-1928, May 1928. .5 - Book - 16 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Fixed Condensers for Radio Reception Purposes" - C53-1928, February 1928. .6 - Book - 32 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard "Graphic (Recording or chart recording) ammeters, voltmeters and wattmeters." C54-1928 March 1928. .7 - Book - 20 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "5-Amp two pin wall plugs and sockets for domestic purposes (without earthing connection)" C55-1928, August 1928, .8 - Book - 24 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard "Electric Cable Soldering Sockets" C56-1929, March 1929. .9 - Book - 8 pages + brown covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Australian Standard "Graphical Symbols and Schedule of Outlets for the Electrical Equipment of Buildings" C64 and 65-1935, October 1935. .10 - Book - 24 pages + brown covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Australian Standard "Porcelain Insulators for overhead powerlines and outdoor switching Structures" C67-1939, August 1939. On top right hand corner has the date stamp of the "The Electric Supply Co. of Victoria Ltd Ballarat" for items .1 to .8, SEC stamp on .10. trams, tramways, power station, standards, materials, electrical systems

The item has come from the Ballarat School of Mines. It was possibly made at the school to demonstrate class processes - science and physics.Wooden box with Federal 240 volt meter and 3 fuse plugs. Appropriate wiring Federal on meterelectrical, fuses, ballarat school of mines, science, physics, demonstrate

What device converts AC to DC? rectifier A rectifier is an electrical device that converts alternating current (AC), which periodically reverses direction, to direct current (DC), which flows in only one direction. The process is known as rectification, since it "straightens" the direction of current. The unit was used at Ballarat School of Mines in the Maths, Science and Physics Departments.Grey metal unit with Dials on the front and vents at the back. Handle for carrying. Two switches for turning on and off. Yellow sticker - SMB - with number 116071. Engraved on back - S.M.B.. Maths / Science / Physics Sticker on cord indicating inspection of unit - 13/04/2005. Tag Number - 032735alternating current, direct current, ac, dc, rectifier, electrical, ballarat school of mines, science, maths, physics

The unit was used at Ballarat School of Mines in the Maths, Science and Physics Departments.Grey metal unit with Dials on the front and vents at the back. Handles for carrying. Two circuit breaker switches, two DC output sockets, two AC output socketsYellow sticker - SMB - with number 116069. Engraved on back - S.M.B.. Maths / Science / Physics Sticker on cord indicating inspection of unit - 13/04/2005. Tag Number - 032725alternating current, direct current, ac, dc, electrical, ballarat school of mines, science, maths, physics, ac/dc, scientific instrument

Possibly used by the State Electricity Commission of Victoria on the Kiewa Hydro Electric Scheme.Used by the SECV on the KHESRectangular wooden sign with red printing in capital letters on a white background. There is a hole in each corner enabling the sign to be hung by screws.In red: "Caution / Electrical / Equipment / Remotely/ Controlled"secv, health and safety.

When this AVOMETER was being utilised in the early 1950's it was at the "leading" edge of electrical measuring instrumentation.The first meter was produced by Automatic Coil Winder and Electrical Equipment Co. in 1923. This model was produced in the time from 1933 to 1951 when it was superseded by the most popular model, Model 8 (1951 to 2008).This AVO meter brought the measuring of three electrical power indicators i.e., amps, volts and ohms into one measuring unit. By using a "one fits all" unit, the carrying of separate measuring devices was reduced considerably. The need for a mountainous and a large area of operational requirements, such as the SEC Vic Kiewa Hydro Electricity Scheme, to minimise the weight of equipment carried by electricians and technicians was of the utmost relevance. The significance of this meter to the Kiewa Valley region relates to the impact of modern technology (at that time) upon a mainly rural environment. This equipment shows how the boost of "modern" equipment into the area because of the "Hydro Scheme" was facilitated a lot faster than would have taken under "normal" evolutionary time. The speed of information on all "new technology" had a relatively slow assimilation rate to those living in rural communities. This AVOMETER is a Model 7 MKII, production pre 1951. This meter measures electrical Amps, Volts and Ohms and has two internal batteries for its power. The main casing is made from aluminium with a bake-lite front. The front has a "window" detailing, with a needle pointer, the amount of electrical power being tested. There are two big dial switches, detailing Direct Current(DC) and Alternating Current(AC) when reading measurements of Ampere, Voltage and Ohms for power. This meter took the place of three or four meters used earlier. Modern meters (2000 onwards) have become digilised and are considerably lighter in weight and smaller. There are two electrical connection leads (one black and one red) each has a removable clasp and is 125cm long.Molded on the front centre panel " UNIVERSAL AVOMETER". Below this and above the left hand dial "D.C. SWITCH" .Above the right hand switch the right "A.C. SWITCH". On the left of each switch is an arrow pointing to it.The left switch is marked with a "+" and the right one with a "-". There is a "divisional 2" mark. Between and below the dials is "CUT OUT" plunger.electrical meters, electrical equipment, sec vic., state electricity commission of victoria, mt beauty, bogong village

When this AVOMETER leather case was being utilised in the early 1950's it contained the "leading" edge of electrical measuring instrumentation.The first meter was produced by Automatic Coil Winder and Electrical Equipment Co. in 1923. This model was produced in the time from 1933 to 1951 when it was superseded by the most popular model, Model 8 (1951 to 2008).This leather case which holds its AVO Meter brought the measuring of three electrical power indicators i.e., amps, volts and ohms into one measuring unit. By using a "one fits all" unit, the carrying of separate measuring devices was reduced considerably. The need for a mountainous and a large area of operational requirements, such as the SEC Vic Kiewa Hydro Electricity Scheme, to minimise the weight of equipment carried by electricians and technicians was of the utmost relevance. The significance of this meter to the Kiewa Valley region relates to the impact of modern technology (at that time) upon a mainly rural environment. This equipment shows how the boost of "modern" equipment into the area because of the "Hydro Scheme" was facilitated a lot faster than would have taken under "normal" evolutionary time. The speed of information on all "new technology" had a relatively slow assimilation rate to those living in rural communities. The use of solid leather carrying bags for transporting equipment up and down the mountains provided some form of protection against bumps and dust.This carry case for its AVO meter has an outer leather covering with an inner thick cardboard liner. The case has two mild steel buckles but stitched onto one side but no lid to fasten down. The sides are stitched together with strong tick twine. On either side there are small strap holds. On the bottom are four large chromed metal lugs acting as feet to keep the bottom from lying flat on any floor. The outside bottom has been branded "SOLID COWHIDE"Between the front two buckles is a identification plate riveted onto the cowhide "STATE ELECTRICITY COMMISSION OF VICTORIA ELECTRICAL ENGINEERING SECTION"electrical meters, electrical equipment, sec vic., state electricity commission of victoria, mount beauty, bogong village

Instruction - 5 pages - duplicated foolscap sheets - headed "MMTB Engineering Department - Workshops and Running Shed Branch" - titled "Duties of Electrical Mechanics - Runningsheds" Details electrical work to be done on tramcars at the 100 hours service; trolley pole, electrical equipment, controllers, switches, resistance boxes, line breakers, RC units, motors, governor, compressor, lighting, buzzers, door engines, wipers, brake cylinders and general body eg handrails. Dated May 1970.trams, tramways, depot, safety, workshops, electrical equipment, instructions, procedures

Book - 170 pages, 10 sections sewn and bound into heavy green card covers cloth covered with glued end pages. Title "Miscellaneous Tests on Car Equipment" for electric street car or trams written by Eugene C Parham and John C Shedd, published by McGraw Hill Book Co. of New York, dated 1910. Has a table of contents, index at the rear, and index of Rules for determining sizes of electrical equipment and tramcar horsepower and kilowatts, traction and speeds. Cover sheets, table of contents and indexes scanned to a pdf file.In a number of places "The Electric Supply Company of Victoria Limited" stamped throughout the book.trams, tramways, electrical engineering, electrical equipment, tramcars, maintenance, motors

Set of 5 black and White Photograph electrical equipment installed on prototype tramcar 1041. .1 - "Underfloor wiring MMTB" showing one part of the wiring on the tram. .2 - "Accelerator Unit - MMTB" - showing the complex unit on the floor of the workshops prior to installation. .3 - "Accelerator Unit - MMTB2" - showing the unit installed on the underfloor along with other equipment. .4 - "Underfloor wiring 2-MMTB" - showing the complex wiring on the tram including the accelerator unit. Has a date on the rear14/3/73 in ink on the top left hand corner. .5 -"Accelerator Unit install MMTB" - showing the Accelerator unit installed and other adjacent equipment. Printed on Kodak paperOn the rear of the photograph has the MMTB stamp and Reference number on some. A caption is in pencil on the top of each photograph, reflected in description.trams, tramways, 1041, prototype tramcar, electrical equipment, controllers, tram 1041

A shock of different voltages was delivered to a person using the two metal handles or two heavy soft wire combs (missing but known of) were moved across the skin. Perhaps this was an early TENS Unit. The unit came to the donor's grandfather (Roy F. Leibig - Chief Electrical Inspector of the Brunswick (Melbourne) Electric Supply) for repair and returned to his keeping once it had become obsolete (upgraded by newer machine). Donor often helped his Pa repair electrical equipment.Historical: The Resuscitator or Electric Therapy Unit was used in hospitals, possibly Mental hospitals. Provenance: The donor worked at Mt Beauty in the Kiewa Hydro Electric Scheme with the State Electric Commission of Victoria as an electrician. Black wooden smooth box with clip fastener which is screwed on - 3 screws for the base and 2 for the lid. On top of the box is a leather strap for the handle fastened by steel screwed into the box. Inside: A mask with attached strap. Tap fitting loosely into steel box. Metal cylinders and a Cardboard box. A wooden lockable case, housing electrical equipment suitable for issuing high voltage shocks.In red, middle of the side with fastener - "SPARKLETS RESUSCITATOR" Scruff marks inside the lid. A cream plastic tag is screwed on and inscribed"Manufacturers:- / SPARKLETS LIMITED / EDMONTON, LONDON, N.18 / Made in ENGLANDmedical, hospital equipment, resuscitator, tawonga district hospital, doctor

Wild Heerbrugg B8 Aviograph Stereoplotters were a very accurate piece of equipment for the extraction of topographical information from stereo air photography. This is an operating manual covering all aspects of the Wild B8 Stereoplotter. Chapters include, construction, descriptions of the optical train, electrical equipment, technical data, assembly (adjustment, instructions for use and maintenance). They were widely used throughout the Royal Australian Survey Corps from 1965 onwards. They were later upgraded with tri axis locators for capturing digital topographical data.Green hard covered operating manual covering all aspects of the Wild B8 Stereoplotter. Chapters include, construction, descriptions of the optical train, electrical equipment, technical data, assembly (adjustment, instructions for use and maintenance). There are 70 x pages of text and plans and diagrams. There are 33 x unnumbered pages of photographs, diagrams and tables. Additional photocopied pages added "P2 Relative Orientation - Semi Numerical Method." "1927" (Presumed to be the Serial Number of the B8 Stereoplotter that the manual was used with).royal australian survey corps, rasvy, fortuna, army survey regiment, army svy regt, asr

Horace Darwin, youngest surviving son of Charles Darwin, was a founding partner of the Cambridge Scientific Instrument Company in 1881 (http://www.museumoftechnology.com/cic.html).Composite object with three feet supporting two squared cylinders attached to a clamping device and metal block with four current terminals. Cylinders are covered with red leather. Metal block and clamp base appear painted.Engraved on terminal block: 'No 15548 / THE CAMBRIDGE SCIENTIFIC INSTRUMENT CO LTD. CAMBRIDGE. ENGLAND' Engraved on side of terminal block: 'To be excited from 200 volts circuit / with coils in series. Connect terminals 2 & 3.'cambridge scientific instrument company, electro magnet, electrical equipment, electrical instrumentation

The photograph shows Ballarat No. 41 northbound at Hospital Corner, Sturt and Drummond Streets, with an ESCo switch or junction box in the foreground. The tram has the destination of Lydiard St North. Photo by Mal Rowe, 22/11/1969.Yields information about the corner of Sturt and Lydiard Sts and an ESCo junction or switch box.Black and white photograph notes on rear.Mal Rowe copyright stamp with number 118,13, and "Corner Drummond St South and Sturt Street"tramcars, tramways, hospital corner, sturt st, drummond st sth, tram 41, electrical equipment, electrical switching
