Geoffrey Kaye Museum of Anaesthetic History
Equipment - Bird Respirator Mark 7A with C.I.G. 'Ventviva' ventilator
... Anaesthesia attachment... a special anaesthesia assistor controller attachment, which... anaesthesia assistor controller attachment, which is essentially ...The Bird ventilator Mark 7 is driven by medical compressed air or oxygen. It is not suited for anaesthesia unless using a special anaesthesia assistor controller attachment, which is essentially a “bag in a bottle” device.Apparatus attached to four castor stand with attached white wall connecting tubing.anaesthesia attachment, bag in a bottle -
Geoffrey Kaye Museum of Anaesthetic History
Tecota trilene inhaler, Cyprane Ltd
The item was donated by Dr K McCaul of the Royal Women's Hospital, Melbourne, in 1966.Anaesthetic trilene was administered to the patient via rubber tubing from the Trilene inhaler, within which the anaesthetic was converted into a vapor. The cylindrical metal apparatus sits atop a flat, square stand with four black rubber feet. Item includes ports and valves for connection to a face mask and vaporising chamber, as well as mask attachment and metal pouring jug with spout.Red markings identifying the manufacturer and the measurement scale are located on both the stand and top twist dial. The base of the mask attachment piece is inscribed with the manufacturer's details: 'Cyprane Ltd'. The metal beaker is engraved with a line marked at the 15cc level. trilene inhaler, tecota, anaesthesia, beaker, mask, vaporise, obstetrics, childbirth, dr k mccaul royal women's hospital melbourne, 1966, vapor, face mask, vaporising chamber, cyprane ltd, keighley -
Geoffrey Kaye Museum of Anaesthetic History
Magill's laryngoscope, A Charles Kind, Ltd
This object is Magill's adaptation of the battery handle in the form of an "inserting tracheoscope". Introduced in 1935 for one-lung anaesthesia, it is combined with an endotracheal tube, the central part of which is a latex-covered wire spiral, and a bronchus blocker. In use, the tube was fixed to the holder and the whole apparatus inserted as a ttracheoscope. At the carina, the blocker was inserted into the bronchus and the balloon (now perished in this example) inflated. The holder was then removed leaving the endotracheal tube and blocker in place. The bronchus blocker consists of gum elastic on woven silver wire and has a suction channel opening at the tip. in other stages of development of Magill's laryngoscope, the original pattern blade was adapted to the battery handle, at first in a fixed arrangement and then with interchangeable blades of different sizes. Later still, the folding handle was introduced.This U-shaped chrome plated laryngoscope comprises an endotracheal tube used to facilitate access to the patient's airway, wire spring attachments and a cylindrical handle with provisions for battery to illuminate inside the body during use.Embossed on the central shaft of the item is 'A Charles King, Ltd', the maker's details.laryngoscope, anaesthesia, macgills, chrome, battery, a charles kind ltd -
Geoffrey Kaye Museum of Anaesthetic History
Laryngoscope, MacIntosh
Complete Macintosh laryngoscope piece with a curved large sized attached blade with light bulb and a textured handle with serrated grip for easy of use and a screw in the blade connector. The handle is also a battery deposit to supply the led light bulb. The blade has general scratches on its surface because its use. At the back of the blade is still attached the curved lamina as holder of the base with the blade in its regular use position. Several engraved and stamped inscriptions are present all over the handle and blade (see inscriptions for details). Stamped on the base of the blade, BOC Stamped on the edge of the back side blade, STAINLESS Stamped on the back side blade base, MADE IN ENGLAND Engraved at the base of the blade attachment place, MAINLAND Engraved at the edge of the serrated grip of the handle, Alfred Anaes Stamped at the base of the handle, REGD TRADE MARK / P E N L O N / MADE IN ENGLAND Stamped at the bottom of the handle base, REGD TRADE MARK / P E N L O N / MADE IN ENGLAND Engraved at the bottom of the handle base, AnaeA / ALFREDlaryngoscope, complete laryngoscope, boc, penlon, handle, alfred hospital, anaesthesia
