R 748 Class Steam Train Engines pulling freight in cutting. the freight trucks have material coverings. Houses can be see in the background of the photo. The photo was taken approximately in c 1962. Large black & white photo (copy) showing two steam train engine pulling freight trucks, on the railway at Stawell. This rail line is the main line between Melbourne & Adelaide. The first engine is an "R" class 748. c 1951R 748 on Engine and 1962 hand written on the back.railways

Restored by Des Tuttle. Originally owned by Ann Thom, retrieved from the property "Pleasantfield" BurramineMulti Vane windmill with a directional vaneWind engine and pump Co, Batavia Illinois

Steam Engine with 12 men and 3 young children standing along side the train engine. based on the surrounds, its presumed the photo was taken at Heatherlie Quarry. No names are known of people.Black & white copy of photo of Steam engine with 12 men and 3 young boys standing alongside the engine presumed the photo was taken at Heatherlie quarry. railways

Belliss & Morcom Ltd, Patent Self Lubricating Engine , Birmingham It was used to operate the Fairfield No. 2 Mill Paper Making machine by a rope and pulley drive.Historic - Industrial Twin Cylinder Engine - stationary engine used to operate the Australasian Paper and Pulp Co Ltd. - Fairfield No. 2 Mill Paper Making machine by a rope and pulley drive.Twin Cylinder Engine - stationary engine made of steel, wrought iron, brassBelliss & Morcom Ltd, Patent Self Lubricating Engine , Birminghamtwin cylinder, engine, stationary engine, industrial stationary engine, puffing billy, fairfield no. 2 paper mill, australian paper manufactures ltd, belliss & morcom

Six cylinder Bell 47G - 3B1 Piston Engine72011 Rev-AT Equip - 8ZJ2, AVCO Lycomingengine, sioux, bell 47g - 3b1

Black and white copy of original photograph showing two men working on a traction engine. There is a horse and cart next to it."Traction engine driving chaff cutter - Kerr's property"kerr, farming, traction engine, chaff cutting, barlow and sons

Steam Rail Engine & 9 workers standing on a Steam Engine. Martin Hayes (Snr.) driver leaning out of cabin. John McInerney left of M. Hayes and below Frank Dunn. The steam engine is under a rail bridge and in the background is a timber building. c1900.Old sepia photo on a damaged mount of 9 railway workers standing on a Steam engine c1900.Martin Hayes (Snr.)stawell railways transport

Frederick Mitchell was born c1874 at Staffordshire Flat, Redcastle, near Heathcote. His father was an engineer from Cornwall, and had a quartz crushing battery at Staffordshire Flat from 1870 to at least the 1890s. Around 1886 Frederick Mitchell was an 18 year old "Engineer and Instrument Maker". He was awarded an 'Honorary Mention' at the Australian Juvenile Exhibition 1890-1. It was donated to the Ballarat School of Mines Museum in 1892. In the early 1960s the model was transferred to the Heat Engines Laboratory. All Heat Engines laboratory was moved from the Ballarat School of Mines to the Mt Helen Campus on October 1869. The model was accommodated in the thermodynamics laboratory. It was shown working during open days. The Ballarat School of Mines Calendar for 1893, page 66 refers to this item. There is correspondence between Frederick Mitchell's grandson, F.W. Mitchell; E.J. Barker, Director of the Ballarat College of Advanced Education; and Graham Beanland, Ballarat School of Mines.A working model of a vertical oscillating twin cylinder steam engine with fly wheel, mounted on a wood base board and covered in glass. Usually stored under a wood-framed glass cover. steam, model, engine, frederick mitchell, flywheel, ballarat school of mines museum

City of Stawell Diesel Engine 3. Diesel Rail Engine City of Stawell N467 and three carriages in cutting 4, Close up of Diesel Engine City of Stawell N467 drivers cabin window 5. Diesel Rail Engine City of Stawell N467 pulled up at Stawell StationSix Colour photographs of Orange coloured diesel rail engine stawell

8HP Blackstone Lamps Start Oil Engine engine number 71076 Engine Details Maximum operating RPM of 240. Fitted with a 3'9" Flywheel Tested on the 6th of November 1908. Shipped to Cluter buck South Australia for installation on concrete base. Recovered and restored during the 80's in South Australia Purchased privately in 2013 in Tailem Bend South Australia and transported to Victoria. Currently on loan to the Puffing Billy Museum at Menzies Creek as an operating exhibit. Blackstone & Co. was a farm implement maker at Stamford, Lincolnshire, United Kingdom. In 1896 they built lamp start oil engines. The Lamp or hot-bulb engine (also hotbulb or heavy-oil engine) is a type of internal combustion engine. It is an engine in which fuel is ignited by being brought into contact with a red-hot metal surface inside a bulb, followed by the introduction of air (oxygen) compressed into the hot-bulb chamber by the rising piston. There is some ignition when the fuel is introduced, but it quickly uses up the available oxygen in the bulb. Vigorous ignition takes place only when sufficient oxygen is supplied to the hot-bulb chamber on the compression stroke of the engine. Most hot-bulb engines were produced as one-cylinder, low-speed two-stroke crankcase scavenged units Historic - Industrial - single cylinder, horizontal, 4 stroke, hot-bulb ignition oil engine Blackstone 8HP Oil Engine made from steel, wrought iron and brassOval Plate with Black Stones and Clutter Buck Brass Plaque engine number 71076blackstone, oil engine, clutter buck, black stone, puffing billy, hit and miss, engine, blackstone & co

The Davey Paxman Experimental Steam Engine was purchased as the result of a bequest from Thomas Bath. The 'substantial sum' was used to build an Engineering Laboratory. The Ballarat School of Mines Council minutes of 08 November 1901 record: - Plans for [the] proposed building were submitted ... and ... it was resolved that a temporary building for an Engineering Laboratory be put up.' This laboratory, as an existing building, is first mentioned in the Ballarat School of Mines President's Annual Report of 1901, presented on 28 February 1902, reporting 'the erection of a building 67ft long by 33 ft wide' This report also lists all the equipment that would be accommodated in the Engineering Laboratory, including the experimental steam engine and boiler. The experimental Davey-Paxman steam engine arrived in Ballarat towards the end of 1902. The Engineering Laboratory was opened on 14 August 1903 by His Excellency Sir Sydenham Clarke. This engineering laboratory remained in use till about 1945. By 1944 preparations were under way at the Ballarat School of Mines to expand existing facilities, to be ready for the influx of returned soldiers. A new Heat Engines laboratory was built, this time of brick construction, replacing the previous corrugated-iron shed. In the early stages the steam engine was used to drive an overhead transmission shaft for machinery in the adjacent workshop. Later the steam engine was moved to a space that became the Heat Thermodynamics Laboratory. At the end of 1969 the engine was relocated to the Thermodynamics Laboratory at the then Ballarat Institute of Advanced Education (BIAE) Mt Helen Campus. It was donated to Sovereign Hill in 2006. According to the research of Rohan Lamb in 2001 around five experimental steam engines were made by Davey Paxman, and three of these had similar configuration to the Ballarat School of Mines Steam Engine, however, each of these was also unique with different valve arrangements. The list, which was on a scrap of paper in a folio held in the Essex Archives, confirmed that one was sent to India. The Ballarat steam engine can be dated to late 1901 to early 1902. Zig Plavina was responsible for moving the steam engine to Mount Helen, and worked on it as a technician for many years. He observed the following: * The condenser is driven by the low pressure engine. * The following arrangements are possible: i) the high pressure engine alone, exhausting to atmosphere. Condenser not used, crankshaft flanges not coupled. ii) crankshafts coupled, mains pressure (120 psi) steam supplied to high pressure engine, partially expanded steam delivered to low pressure engine (Tandem operation). Choice available re exhaust steam: either to the condenser or to atmosphere. iii) crankshafts not coupled, reduced pressure steam supplied to low pressure engine. Exhaust steam - either to the condenser or to atmosphere. * Valve arrangement - a choice of Pickering cut-off or throttle governor. On low pressure engine - throttle governor only. Black and white photograph of an experimental steam engine which was produced for the Ballarat School of Mines. It was designed for experimental purposes, such as testing of efficiency, etc. The laboratory which housed the steam engine was lit with gas lighting. davey paxman experimental steam engine, model steam engine, davey paxman, steam, thomas bath, thermodynamics

Sloane's & Scotchman Mining Co remains with collapsed Poppet Head and Engine Mounts.Derelict mine site with engine housing brickwork and Mullock heap. mining

Engine E Class 345 Photo late 1880's to 1890's?Steam Engine in front of Station with about 12 Gentlemen in suites.Railway Station Stawell R A Leslie Art Photographerrailways

Morphett's Engine House was restored and opened to the public in 1986.Three colour digital images of Morphett's Engine House, Burra, South Australia

The Davey Paxman Experimental Steam Engine was purchased as the result of a bequest from Thomas Bath. The 'substantial sum' was used to build an Engineering Laboratory. The Ballarat School of Mines Council minutes of 08 November 1901 record: - Plans for [the] proposed building were submitted ... and ... it was resolved that a temporary building for an Engineering Laboratory be put up.' This laboratory, as an existing building, is first mentioned in the Ballarat School of Mines President's Annual Report of 1901, presented on 28 February 1902, reporting 'the erection of a building 67ft long by 33 ft wide' This report also lists all the equipment that would be accommodated in the Engineering Laboratory, including the experimental steam engine and boiler. The experimental Davey-Paxman steam engine arrived in Ballarat towards the end of 1902. The Engineering Laboratory was opened on 14 August 1903 by His Excellency Sir Sydenham Clarke. This engineering laboratory remained in use till about 1945. By 1944 preparations were under way at the Ballarat School of Mines to expand existing facilities, to be ready for the influx of returned soldiers. A new Heat Engines laboratory was built, this time of brick construction, replacing the previous corrugated-iron shed. In the early stages the steam engine was used to drive an overhead transmission shaft for machinery in the adjacent workshop. Later the steam engine was moved to a space that became the Heat Thermodynamics Laboratory. At the end of 1969 the engine was relocated to the Thermodynamics Laboratory at the then Ballarat Institute of Advanced Education (BIAE) Mt Helen Campus. It was donated to Sovereign Hill in 2006. According to the research of Rohan Lamb in 2001 around five experimental steam engines were made by Davey Paxman, and three of these had similar configuration to the Ballarat School of Mines Steam Engine, however, each of these was also unique with different valve arrangements. The list, which was on a scrap of paper in a folio held in the Essex Archives, confirmed that one was sent to India. The Ballarat steam engine can be dated to late 1901 to early 1902. Zig Plavina was responsible for moving the steam engine to Mount Helen, and worked on it as a technician for many years. He observed the following: * The condenser is driven by the low pressure engine. * The following arrangements are possible: i) the high pressure engine alone, exhausting to atmosphere. Condenser not used, crankshaft flanges not coupled. ii) crankshafts coupled, mains pressure (120 psi) steam supplied to high pressure engine, partially expanded steam delivered to low pressure engine (Tandem operation). Choice available re exhaust steam: either to the condenser or to atmosphere. iii) crankshafts not coupled, reduced pressure steam supplied to low pressure engine. Exhaust steam - either to the condenser or to atmosphere. * Valve arrangement - a choice of Pickering cut-off or throttle governor. On low pressure engine - throttle governor only.Black and white photograph of the Davey Paxman Experimental Steam Engine installed at the Ballarat School of MInes. steam engine, model steam engine, davey paxman, thomas bath, experimental steam engine

Tom Park's traction engine in 1920. It travelled the district around Lake Bolac with a team of men thrashing wheat. black and white photographtom park, engine, lake bolac

Sloane's & Scotchman Mining Co remains Poppet Head Chimney and Engine Mounts.Derelict mine site at upper main street. Engine housing brickwork and Chimney at right partly demolished.stawell mining

The Davey Paxman Experimental Steam Engine was purchased by the Ballarat School of Mines as the result of a bequest from Thomas Bath.The Davey Paxman Experimental Steam Engine was purchased as the result of a bequest from Thomas Bath. The 'substantial sum' was used to build an Engineering Laboratory. The Ballarat School of Mines Council minutes of 08 November 1901 record: - Plans for [the] proposed building were submitted ... and ... it was resolved that a temporary building for an Engineering Laboratory be put up.' This laboratory, as an existing building, is first mentioned in the Ballarat School of Mines President's Annual Report of 1901, presented on 28 February 1902, reporting 'the erection of a building 67ft long by 33 ft wide' This report also lists all the equipment that would be accommodated in the Engineering Laboratory, including the experimental steam engine and boiler. The experimental Davey-Paxman steam engine arrived in Ballarat towards the end of 1902. The Engineering Laboratory was opened on 14 August 1903 by His Excellency Sir Sydenham Clarke. This engineering laboratory remained in use till about 1945. By 1944 preparations were under way at the Ballarat School of Mines to expand existing facilities, to be ready for the influx of returned soldiers. A new Heat Engines laboratory was built, this time of brick construction, replacing the previous corrugated-iron shed. In the early stages the steam engine was used to drive an overhead transmission shaft for machinery in the adjacent workshop. Later the steam engine was moved to a space that became the Heat Thermodynamics Laboratory. At the end of 1969 the engine was relocated to the Thermodynamics Laboratory at the then Ballarat Institute of Advanced Education (BIAE) Mt Helen Campus. It was donated to Sovereign Hill in 2006. According to the research of Rohan Lamb in 2001 around five experimental steam engines were made by Davey Paxman, and three of these had similar configuration to the Ballarat School of Mines Steam Engine, however, each of these was also unique with different valve arrangements. The list, which was on a scrap of paper in a folio held in the Essex Archives, confirmed that one was sent to India. The Ballarat steam engine can be dated to late 1901 to early 1902. Zig Plavina was responsible for moving the steam engine to Mount Helen, and worked on it as a technician for many years. He observed the following: * The condenser is driven by the low pressure engine. * The following arrangements are possible: i) the high pressure engine alone, exhausting to atmosphere. Condenser not used, crankshaft flanges not coupled. ii) crankshafts coupled, mains pressure (120 psi) steam supplied to high pressure engine, partially expanded steam delivered to low pressure engine (Tandem operation). Choice available re exhaust steam: either to the condenser or to atmosphere. iii) crankshafts not coupled, reduced pressure steam supplied to low pressure engine. Exhaust steam - either to the condenser or to atmosphere. * Valve arrangement - a choice of Pickering cut-off or throttle governor. On low pressure engine - throttle governor only.davey paxman experimental steam engine, model steam engine, steam, thermodynamics laboratory, thomas bath, bequest

Postcard photo of Charlton's Power House and Engine established 1911Postcard photo of Charlton's engine to generate power for the town 1911. Unknown male standing next to engine."ENGINE" ELECTRIC Power House CHARLTONcharlton power 1911, charlton power engine 1911

For an explanation about the history of steam engine indicators, visit: http://www.archivingindustry.com/Indicator/contentback.htm [last viewed 20 May 2013]. For information about the Richards' Improved Patent Steam-Engine Indicator see John Walter's publication 'The Engine Indicator: a short history of the autographic patterns from 1800 to the present day' - available online via: http://www.archivingindustry.com/Indicator/chaptertwo.pdf Information on Casartelli, Manchester is also available online via: http://www.archivingindustry.com/Indicator/chapterfour.pdf Refer pp.21-22 [last viewed 20 May 2013]Brass steam-engine indicator 125mm tall - accompanied by four steel piston springs - and a wooden measuring ruleIndicator [a] Casartelli Manchester [b] 41 ; Ruler [a] 12 to the Inch [b] No.2 [c] Casartelli & Son Manchesterrichards improved patent steam engine indicator, casartelli manchester

Set of four photocopied plans or drawings on A3 sheet of the "Johnston St Engine House", "Northcote Engine House" and "Richmond Engine House", c2/1938. .1 - Sheet 1 - P8498 - Plan showing land and surrounding streets for the "Johnston St Engine House" .1 - Sheet 2 - P8499 - Plan showing the layout of the engine house. Has a note sheets 1 and 2 that it has been sold .2 - P8506 -Plan showing land and surrounding streets for the "Northcote Engine House" - 2 copies held. .3 - P8607 - Plan showing Richmond Engine House and adjacent streets with sub-station next doortrams, tramways, drawings, depots, property, cable trams, winding houses, johnston st, northcote, richmond, hoddle st, bridge rd

Used by winding engine driver at Magdala Mine. Painted dark reddish colour with arms bolted to frame with metal bolts., peg dowel jointed. Wooden Chair - Engine Drivers. Magdala Cum Moonlight Mine. Initials Carved on it include J Gilchrist 1911Names and initials carved into woodwork. Including J Gilchrist 30.12.1911(?) On arm W.H.A., PW and TN on back V.T., V.T., A.H, down side.stawell

Steam Train Engine in Hills cutting c 1940. Photo from "Boothey" EstateTwo identical photos of a steam engine & goods trucks heading towards Melbourne. The larger photo a copy of the smaller photo c 1940A543 printed on the back of one of the photos.railways
