Manufactured by the Adelaide tramcar body builder, A Pengelley & Co to indicate or advise passengers who built the tram. Were generally located above a doorway of the tramcars.Demonstrates the method of recording who built the tramcar body Oval shaped enamelled steel plate with the words "A PENGELLEY & Co BUILDERS EDWARDSTOWN SOUTH AUSTRALIA in black on a white background. Has two 4mm diameter holes on long ends. builders plate, adelaide, tramcar, workshops, pengelley

Destination roll used to indicate to passengers the destination or route of the tram. At night the roll was back lit by two light bulbs fitted to the destination box on the tram. Item used in Geelong until 1956. Based on the hand written marking, used on a Pengelley type tram and painted in 1954. This roll is See Reg Item 2906 and 9619 for a smaller side destination roll and 4122 for a wide roll fitted to bogie tram No. 39. The Destinations have a different arrangement to that of item 4122. Item 4122 is an earlier formation based while 9618 is a later format set out to minimize the amount of movement on the roll between the various destinations introduced with changed through routing in 1954. The second image shows two rolls side by side showing the set out. This roll is on the right side or is the shorter one.Yields information and demonstrates aspects about Geelong's destination rolls used in trams up to 1956 when the system closed.Destination roll - white lettering on black background - using black paint leaving the lettering transparent at night. Uses a book binders cloth. Attached to a wooden blind roller, as used in the destination box to keep the blind tight. One loose roller that was attached to the other end of the roll. The wooden roller has a "Hartshorn's" and "Stewart Gladstone" name lables attached to it.In pencil as base of roll "Pengelley Dest End. B.G.L.M Flat, 31/7/54" tram, trams, geelong, destination roll, pengelley

Digital image of a Photograph of the interior of one of Pengelley-built trramcars that operated in Geelong. Photo by Keith Kings. Shows the door arrangements and the location of a builders plate.Yields information about Geelong tramcars that were built by Pengelley of Adelaide.Digital image of a colour slide - Keith Kings K(f)(83)trams, tramways, geelong, pengelley

Demonstrates the method of delivery of a tramcar body for Geelong from the railway station using a horse drawn jinker with the horse driver standing in the same location as a tram driver would have. Tramcar built by Pengelley of Adelaide. The tramcar bodies were delivered during 1924 and 1925.Yields information about the Pengelly built tramcars for Geelong c1924 and how tramcar bodies could be transported using a horse drawn jinker. At the time, the Geelong tram system operated by the Melbourne Electric Supply Co.Copy photograph on black plastic type backing with black edges of a Pengelley Adelaide built tramcar body for the Geelong tramway system being delivered 1924, from the Geelong Railway station.geelong, tramways, pengelley, tram bodies, horse drawn jinker

Provides information on how a tramcar body was fitted with a wheelset or truck (Brill Radiax EB1 type). Lifted on the jacks after delivery by a horse drawn jinker from the Railway Station (See Reg Item 8321) The wheel set is being pushed under the tramcar by another tramcar. Once fitted the tramcar would have been towed back into the depot and the motors etc connected. Has the Blakiston & Co. building in the background. Yields information about how tramcar bodies were lifted outside the Geelong tram depot in Brougham St in order to be made operational. Copy photograph on black plastic type backing with black edges of a Pengelley Adelaide built tramcar body on jacks being fitted with a truck or wheel set.geelong, tramways, pengelley, tram bodies, brill radiax truck, brougham st, trams

Digital image scan of a Keith Kings slide showing the interior of a Geelong Pengelley tram in particular the detail of the end seat arrangement, doors, pay as you enter sign and the location of the builders plate.Yields information about the interior of a Geelong Pengelley tram.Digital image - Keith Kings number K(f)(83),geelong, pengelley, trams, tramways, builders plate

Drawing of Melbourne Electric Supply Co. Ltd (MESCo) Geelong tramways - "Combination Car Mounted Brill E1B Special Radiax Truck" - trams 16 to 23, built by Pengelley & Co in Adelaide 1924-25. Details the tramcar elevation with dimensions, and shows the towbars. Drawing dated Jan 1985, prepared for the TMSV. Scale 1/4"=1' Second drawing is titled "Elevations of body Pengelley tram Nos. 20-23" - based on MESCo drawing GE-T9-8358. Drawing dated Jan 1985, prepared for the TMSV. Scale 1/4"=1' Yields information about the Pengelley built tramcars for Geelong.Set of Drawings printed on light brown paper with brown ink - Drawing GE-T9-8350 and GE-T9-8358trams, tramways, geelong, drawings, pengelley

Black and White print contained within the Wal Jack Bendigo and Geelong Album, see Reg Item 5003 for more details. Photo of No. 23 at the Geelong Railway Station with the station buildings in the background. Photographer unknown - handwriting is the same as other photos such as Reg item 5850.. Wal's album notes dates the photo as June 1939. Printed on Kodak Velox paper. The tram has two trolley poles and the destination of Newtown. i1 - scan of print in the album i2 - rear of image i3 - scan of negative at 3200dpi added 6/6/2020. Has the rear in ink "Geelong Tramways, No. 23 "Two man trams", built by A. Pengelley South Australia"trams, tramways, geelong, railway station, tram 23

Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 19 at Belmont terminus mid 1950's. Tram has the destination of Belmont. Photographer unknown. "G 19" and "1 -19" in pencil.tramways, trams, geelong, belmont, tram 19

Photo shows two trams at the Geelong railway station, with No 8 in front and a Pengelley tram behind. Based on three other photos by "CF" - c1948.Yields information about the Geelong tram 8Black and white photograph, plain back.Has the initials "CF" in pencil on the rear. tramways, trams, geelong, railway station, tram 8

Black and white photograph of Geelong Pengelley tram No. 19 in Railway Terrace inbound to the City area. See also Reg. Item 2800 for the tram at the station terminus. Photo shows the fence along the south side of the Railway goods yard. Photo taken 1955 or 1956.tramways, trams, geelong, railway station, railway terrace, tram 19

Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 18 at West Terminus. Tram destination part way between "East" and "West". Photographer unknown. Taken after 1951, probably near time of closure. "G 17" and "1 -17" in pencil.tramways, trams, geelong, west, tram 18

Destination roll used to indicate to passengers the destination or route of the tram. At night the roll was backlit by two light bulbs fitted to the destination box on the tram. Item used in Geelong until 1956. Based on the handwritten marking, painted in July 1946. Used on the side destinations of either the Pengelley or the trams built for MESCo trams such as Geelong No. 2. See Reg Item 2906 for another smaller side destination roll and 4122 for a wide roll fitted to bogie tram No. 39 and 9618 wide roll fitted to a Pengelley tram. Destinations have the same arrangement to that of item 2906.Yields information and demonstrates aspects about Geelong's destination rolls used in trams up to 1956 when the system closed.Destination roll - white lettering on black background - using black paint leaving the lettering transparent at night. Uses a book binders cloth. Attached to a wooden blind roller, as used in the destination box to keep the blind tight. Wooden roller has a "Hartshorns" and "Stewart Gladstone" name lable attached to it.In pencil as base of roll "Taubmans Black 4-7-46 JS" tram, trams, geelong, destination roll

The photograph shows Geelong tram No. 22 at the Geelong Railway station . Photo by Roy Field 6/49. Roy provides notes on the rear of the photo about the tram's two trolley poles, radial truck and that it was built by Pengelley. Yields information about tram 22 and the railway station terminus.Black and white photograph with details on rear.See rear image a C Roy Field stamptramways, trams, geelong, geelong railway station, tram 22

Geelong No. 16, outside Geelong depot 21/8/1955 - converted Pengelly tram. Photo by Keith Kings.Stamped on 'K.S.Kings No. K(y)(47)' on top edge. In ink on base, 'Geelong, Converted Pengelley No. 16 outside depot 1/50, f5.6, 21/8/1955'tramways, trams, geelong, pengelly, tram 16

Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 16 at the Beach terminus - Bellarine St and Corio Tce (now Brougham St). Photo taken after 1951. Dave O'Neil notes remark that the corner is virtually unchanged, except for traffic lights. "G 14" and "1 -14" in pencil.tramways, trams, geelong, beach, corio tce, tram 16

Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 19 running out of the depot / power house building into Corio Tce mid 1950's. Tram has the destination of Chilwell. Photographer unknown. Taken after 1951, probably near time of closure. "G 18" and "1 -18" in pencil.tramways, trams, geelong, depot, corio st, tram 19

Geelong No. 23, unconverted Pengelly tram, outside depot on 7/1/1956. Has two trolley poles. Showing 'EAST' destination. Photo by Keith Kings.Stamped 'K.S.Kings No. K(y)(70) TC9' on top edge. On bottom edge, 'Geelong No. 23 - unconverted Pengelley, outside depot 1/50, F4.5, 7/1/56'tramways, trams, geelong, pengelly, tram 23

Photo of Geelong Pengelley No. 16 in Pakington St. Geelong at the junction with the Newtown line. Tram is coming from Chilwell and has the destination of Station. Tracks from Newtown at bottom of photograph. Photo by Hugh Ballment, 25-5-1954. See item 9583 for a print of this image.Yields information about Geelong No. 3 in 1954.Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide."G 13" and "1 -13" in pencil.tramways, trams, geelong, pakington st, chilwell, tram 16

Black and white photograph of Geelong Pengelley tram No. 18 or 19 in Railway Terrace, changing ends at the station terminus. See also Reg. Item 2792 for a photo of the tram inbound to the city in Railway Terrace. Photo taken 1955 or 1956 and shows a number of buses in the station forecourt. Note the phone box in the right hand side of the photograph.tramways, trams, geelong, railway station, railway terrace, tram 19, tram 18

Shows the results of an accident, possible at the same time of a photograph in the collection of an AEC solid tyre truck carrying sacks of coal? See Reg Item 7750 which shows possibly the actual event on 9-2-1927.Yields information on the nature of damage following a collision with another vehicle. The body of the tramcar is preserved by the Tramway Museum Society of Victoria at Bylands See https://tmsv.org.au/gallery/fleet/geelg22.htmCopy photograph on black plastic type backing with black edges of Geelong tramcar No. 22, damaged following an accident. geelong, tramways, pengelley, accidents, tram 22, trams

Black and White photograph contained with Reg. Item 1902 - Photo Album from Keith Kings to Les Denmead 1970. Photograph of SEC Geelong, No 23 outside the depot, 7/1/1956. Tram has destination of "East" on the side. Keith Kings No. Q(u)(8) Scanning: i - image file, p - presentation file, b - back of photograph.Stamp in top left hand corner and handwritten number with "K.S. Kings No. Q(u)(8) Copyright reserved". In blue ink "Geelong / No. 23, "unaltered" Pengelley car / outside Depot / 7/1/56".trams, tramways, geelong, depot, tram 23

Yields information about the Geelong tramway system and one of the terminus and the appearance at the time.Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 18 at East Terminus Ormond and Boundary Roads. Photo shows a child walking away from the tram. Tram has the destination of East. Photographer unknown. Taken on the last day of the first closures, 8/1/1956. See also Reg Item 4389 for a print of this slide. "G 16" and "1 -16" in pencil.tramways, trams, geelong, east, closure, last day, tram 18

Destination roll used to indicate to passengers the destination or route of the tram. At night the roll was back lit by two light bulbs fitted to the destination box on the tram. Item used in Geelong until 1956. Based on the hand written marking, used on bogie tram 39. See Reg Item 2906 and 9619 for a smaller side destination roll and 9618 for a roll fitted to a Pengelley-type tramcar.Yields information and demonstrates aspects about Geelong's destination rolls used in trams up to 1956 when the system closed.Destination roll - white lettering on black background - using black paint leaving the lettering transparent at night. Uses a book binders cloth. Top edge “R.E. Fluck” stamped in black ink – twice In pencil words “Dulux” – has been crossed out Alongside “B.A.L.M. Flat Black 18-3-52” and a set of initials “Off No. 39” all in pencil Bottom edge; Initials “R E F” in black pencil? – along outside of roll. tram, trams, geelong, destination roll, tram 39

Agfachrome Professional plastic mount (blue base, white cover) reproduction slide of a colour slide of Geelong Pengelley No. 18 at East Terminus. Photo shows a crewman boarding the front end of the tram. Possibly taken on the last day of the Chilwell - East West line, 8/1/1956. See Reg. Item 476.5 for a similar photograph taken by Geoff Grant and 2610 for another copy of the slide. Photographer unknown. "G 15" and "1 -15" in pencil.tramways, trams, geelong, east, tram 18

Black and White photograph contained with Reg. Item 1902 - Photo Album from Keith Kings to Les Denmead 1970. Photograph of SEC Geelong No. 19, leaving the depot, with the main office part of the depot building in the background. A number of motor vehicles on either side of the depot entrance. Tram has destination of "Chilwell". On rear of photo is stamped "ll317A and 28.5.70", possibly indicating print manufacture dates. Keith Kings No. Q(u)(3) Scanning: i - image file, p - presentation file, b - back of photograph.Stamp in top left hand corner and handwritten number with "K.S. Kings No. Q(u)(3) Copyright reserved". In blue ink "Geelong "Pengelley" No. 19 leaving the Depot. / Note:- MESCo Ltd. name above entrance / 8/1/56".trams, tramways, geelong, mesco, depot, tram 19

Contract tender analysis for the second batch of PMTT tramcars - contract No. 44 - giving the tenderers name, price per body (combination or summer), totals for each type, delivery and remarks. Tenderers were Duncan and Fraser, Meadowbank who also offered Sydney cars as a special offer, Noyes Bros and Pengelley & Co. The contract was let to Duncan and Fraser. The trams became the G and H class type, entering service in 1913 - Destination City 5th Edition pages 53 and 54.Demonstrates a PMTT Tramcar body tender analysisTyped sheet on special size paper, ruled vertically with red lines.pmtt, tramcars, tenders, contracts, g class, h class

Photograph shows Moorabool St looking south from near Corio St Geelong. Shows the track junction with Malop St. Has Pengelley built tram 22 southbound with a Birney tram in front. The two trams are going from the Wharf to Newtown and South respectively. In the background is the State Savings Bank, The Geelong Library, Solomons store, and a building advert sign for Dr Morses Indian Root Pills. There are many motor cars, some horse-drawn vehicles, and one bus in the view. Photo, late 1920s, sourced from the La Trobe Library Melbourne.Yields information about Moorabool St Geelong late 1920s.Publish Black and white photograph with caption and source printed along bottom edge.ballarat, trams, tramways, geelong, tram 22, birney tramcars, moorabool st

Photograph shows Pengelly built tram No. 18 at the intersection of Pakington and Aphrasia Streets Geelong. The tram has the destination of Chilwell. On the left is the Chilwell Newtown fire station and the Municipal Hall. Photo taken in 1955.Yields information about Geelong tram 18 and the intersection of Pakington and Aphrasia St.Black and White photograph with details on rearTyped lable on rear "One of the Pengelley built cars of 1924-25. The sister tram of the one illustrated here has been preserved by the Tramway Museum Society of Victoria." and a stamp in the bottom left hand corner "WELT Collection, A G Culpeffer Cooke Victoria Australia, Ref 8B, Date 1955"trams, tramways, geelong, tram 18, chillwell, pakington st, aphrasia st

Yields information about Geelong Tramways and demonstrates letters between the SEC and Wal Jack.Letter, typed, two pages, from the State Electricity Commission, Geelong office to Wal Jack dated 1/10/1943 signed by T. L. Gurr, Office Manager responding to the queries of Wal's letter of 23rd Sept. Concerns Geelong Scrubber Car, Geelong trams, trams 14 and 15 being converted to single pole, conversion of combination to one-man trams, General routes before 1940, copy of current timetable (See Reg Item 5629), and confirming the name of Pengelley of Edwardstown, Adelaide. Satisfag Bond paper used for the letter for the first page Contained originally within Reg Item 5623 at the front of this note book. For items see btm5623 loose items list.pdf.trams, tramways, geelong, scrubber tram, conversion, routes
