Showing 44 items
matching prototype tramcar
-
Melbourne Tram Museum
Photograph - Colour Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1972
... Prototype tramcar... plus seat and foot controls for the prototype tramcar 1041....Trams tramways Preston Workshops Prototype tramcar tram ...Colour photograph of cab showing control panel installed plus seat and foot controls for the prototype tramcar 1041.trams, tramways, preston workshops, prototype tramcar, tram 1041 -
Melbourne Tram Museum
Photograph - Illustration/s, Melbourne & Metropolitan Tramways Board (MMTB), early 1970's
... Prototype tramcar... drawing or illustration of prototype tramcar (later 1041), has...Trams tramways MMTB Prototype tramcar Preston Workshops ...Photocopy onto a foolscap sheet of paper of a pencil drawing or illustration of prototype tramcar (later 1041), has destination of Mont Albert, route 42. Not signed. Possibly prepared by one of the MMTB draftsmen at Preston Workshops for use in publications.trams, tramways, mmtb, prototype tramcar, preston workshops, tram 1041 -
Melbourne Tram Museum
Photograph - Set of 2 Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar... of the frame at Preston Workshop for prototype tramcar 1041. Shows...Trams tramways 1041 Prototype tramcar New Tramcars Tramcar ...Series of 2 black and white photographs of the construction of the frame at Preston Workshop for prototype tramcar 1041. Shows the first frame positioned with the main bogie centre beam cross member. See Reg Item 2521 for other photos of the frame under construction.Some photos have pencil marks on rear.trams, tramways, 1041, prototype tramcar, new tramcars, tramcar bodies, preston workshops, tram 1041 -
Melbourne Tram Museum
Photograph - Colour photograph - mounted, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar... of orange in the printing of prototype tramcar 1041 with Parliament...Trams tramways 1041 Prototype tramcar Spring St Parliament ...Block mounted colour photograph - faded or excessive amount of orange in the printing of prototype tramcar 1041 with Parliament House in the background. Montaged photo of the tram onto the scene - destination of East Preston not to scale, driver - a "cardboard cutout" - no conductor, though the seat is shown. No tramcar number. Front of tram with headlight and marker lights not as built but as shown in some drawings and the model.trams, tramways, 1041, prototype tramcar, spring st, parliament, tram 1041 -
Melbourne Tram Museum
Photograph - Set of 4 Black & White Photograph/s and Colour Print/s, Melbourne & Metropolitan Tramways Board (MMTB), Aug. 1973
... Prototype tramcar... photographs of Prototype tramcar 1041, at Preston Workshops just prior...Trams tramways 1041 Preston Workshops Prototype tramcar ...Set of two black and white photographs and two colour photographs of Prototype tramcar 1041, at Preston Workshops just prior to its formal launch. .1 - At the entry to the workshops showing route 88 and "city". IN the background is a tram stop shelter in St Georges Road. .2 - In Miller St - shows the PCC bogies .3 - as for .1 .4 - as for .1, but on a different track and angle. .1 and .2 on Kodak paper.On the rear of the photograph has in pencil. .1 - "1041-entrance-Preston - MMTB". .2 - "1041-Miller St - Preston - MMTB". .3 - "1041-Preston 2- MMTB". .4 - "1041-Preston 2- MMTB" - has various trimming marks and notes on front and rear of the photograph. Some have MMTB stamps on rear.trams, tramways, 1041, preston workshops, prototype tramcar, miller st, route 88, pcc, tram 1041 -
Melbourne Tram Museum
Photograph - Set of 3 Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar... of the body or frame of prototype tramcar 1041 in the body shop...Trams tramways Prototype tramcar New Tramcars Tramcar ...Set of 3 black and White Photographs of the construction of the body or frame of prototype tramcar 1041 in the body shop of the Preston Workshops. .1 - "1041-frame construction - Preston - MMTB" - shows the frame of the tram being built, the drivers cab are yet to be fabricated. .2 - "1041-frame construction2 - Preston - MMTB" - shows the completed frame and painted. Printed on Kodak paper .3 - "1041-frame construction3 - Preston - MMTB" - shows the end view of the tram looking along the tram with the draft gear apparent. See also Reg Item htd4539 for earlier frame photos.On the rear of the photograph has the MMTB stamp and Reference number on some. A caption is in pencil on the top of each photograph, reflected in description.trams, tramways, prototype tramcar, new tramcars, tramcar bodies, preston workshops, tram 1041 -
Melbourne Tram Museum
Photograph - Set of two Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), 31/01/1973 12:00:00 AM
... Prototype tramcar... of the body or frame of prototype tramcar 1041 at Preston Workshops...Trams tramways 1041 Prototype tramcar New Tramcars Tramcar ...Set of 2 black and White Photographs of the construction of the body or frame of prototype tramcar 1041 at Preston Workshops. .1 - "1041-traverser-31 Jan 1973 - Preston - MMTB". showing the tramcar body on temporary workshop bogies on a traverser. the side panelling is largely completed but the drivers cabs are yet to be panelled. On the rear has a noted in ink. "Started 17 May 1972 / Progress @ 31/Jan. 1973" / i.e. 8 months. Photo possibly taken 31/1/1973. .2 - "1041-on-PCC trucks - Preston MMTB" - As above but in the yard at the workshops. Two copies held.On the rear of the photograph has the MMTB stamp and Reference number on some. A caption is in pencil on the top of each photograph, reflected in description.trams, tramways, 1041, prototype tramcar, new tramcars, tramcar bodies, preston workshops, traverser, tram 1041 -
Melbourne Tram Museum
Photograph - Set of 5 Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar... installed on prototype tramcar 1041. .1 - "Underfloor wiring MMTB...Trams tramways 1041 Prototype tramcar Electrical Equipment ...Set of 5 black and White Photograph electrical equipment installed on prototype tramcar 1041. .1 - "Underfloor wiring MMTB" showing one part of the wiring on the tram. .2 - "Accelerator Unit - MMTB" - showing the complex unit on the floor of the workshops prior to installation. .3 - "Accelerator Unit - MMTB2" - showing the unit installed on the underfloor along with other equipment. .4 - "Underfloor wiring 2-MMTB" - showing the complex wiring on the tram including the accelerator unit. Has a date on the rear14/3/73 in ink on the top left hand corner. .5 -"Accelerator Unit install MMTB" - showing the Accelerator unit installed and other adjacent equipment. Printed on Kodak paperOn the rear of the photograph has the MMTB stamp and Reference number on some. A caption is in pencil on the top of each photograph, reflected in description.trams, tramways, 1041, prototype tramcar, electrical equipment, controllers, tram 1041 -
Melbourne Tram Museum
Photograph - Set of 7 Colour Print/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar...Trams tramways MMTB Prototype tramcar 1041 Riversdale Rd ...Set of seven black and white prints of prototype tram 1041, during its first days of commissioning and testing in the city and on the Wattle Park route. All printed on Kodak paper. .1 - at Preston workshops, showing City, route 088 .2 - ditto .3 - ditto - 2nd copy added from donation of Geoff Warburton added 10/10/17. .4 - In Riversdale Road, Wattle Park, showing W. Park Elgar Rd, route 070. .5 - ditto, but showing special and route 000 - trees behind the tram had been faded out. .6 - turning out of Bourke St into Spring St with destination of E. Brunswick, route 96. Has been painted with words "Welcome Board" and "Enter here" on front door. Has the Windsor hotel in the background. Second trolley retriever fitted as well. .7 as for .5 but at a different location. 2nd copy of .3 added 10/10/17.4 - notes to remove pole, ext and I HT and grating on rear along with a sketch of the tram outline and number 16. .6 - on rear "9 3/4 x 6 1/8" .7 on front of the photo "9 3/4" x 6 1/4" in felt pen. .3 - second copy "1041-Preston-3-MMTB" in pencil on rear.trams, tramways, mmtb, prototype tramcar, 1041, riversdale rd, wattle park, preston workshops, tram 1041 -
Melbourne Tram Museum
Document - Report, Melbourne & Metropolitan Tramways Board (MMTB), "The All-Electric Tramcar", 1961
... Prototype tramcar... Prototype tramcar Has a lable on the first page, "Plan & EPA Library ...Report - blue Rexene cloth heavy card covers, dark blue glued end sheets, fully sewn bound, with some 9 sections, with many sheets folded and appropriate paper spacing allowed for in the binding. Report titled "MMTB The ALL-ELECTRIC TRAMCAR" with MMTB logo in gold block on front cover and on the side of the report. About 150 pages. Report prepared by Frank R. Kirby Chief Engineer, December 1961. Has a table of Contents, Appendices, figures, tables and photographs. Report looks at the development of All Electric Tramcars in Europe and North America, the cost of maintenance of Melbourne's trams, operating costs, conductors, seated conductors, passenger handling, reliability, speeds, maintenance and capital costs.Has a lable on the first page, "Plan & EPA Library M0036918", Front cover stamped in red "Secretary's Files"trams, tramways, mmtb, pcc, germany, europe, all electric trams, prototype tramcar -
Melbourne Tram Museum
Photograph - Set of 10 Black & White Photograph/s - Mockup of all electric tram Preston Workshops, Melbourne & Metropolitan Tramways Board (MMTB), c1972
... Prototype tramcar...Trams tramways Prototype tramcar Tramcar Bodies Preston ...Series of 10 black and white photographs of the construction of the prototype or mock-up model of the prototype for tram 1041 at Preston Workshops c1971. See Reg Item 2502 and 7370 for other photos. .1 - external view shows the centre door and the mock-up construction. .2 - external view showing small entry door - at the back of the tram? .3 - Front entry door. .4 - internal view showing conductors desk and seats .5 - internal view showing conductors desk, ticket machine and microphone. .6 - another view looking along the tram length. .7 - same photo. .8 - Drivers seat showing the mock-up pedals and drivers console. .9 - ditto - different view. .10 - close up of the drivers pedals mock-up box. The photos could have been taken at different stages of the design process and after layout changes had been made.Item 6 has MMTB stamp and "P25/1/1016""trams, tramways, prototype tramcar, tramcar bodies, preston workshops, 1041 mock-up, interiors, tram 1041, pcc class, gibson ticket machines -
Melbourne Tram Museum
Photograph - Set of 2 Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar...Trams tramways 1041 Prototype tramcar New Tramcars Tramcar ...Series of 2 black and white photographs of the finishing off and testing of tram 1041. .1 - Internal view with conductors desk and workmen possibly installing the glazing sections or cleaning the tram. .2 - weights laid out on the floor to simulate a full passenger load for braking tests.trams, tramways, 1041, prototype tramcar, new tramcars, tramcar bodies, preston workshops, testing, interiors, tram 1041 -
Melbourne Tram Museum
Photograph - Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1973
... Prototype tramcar...Trams tramways MMTB Prototype tramcar 1041 Preston ...Black and white print of prototype tram 1041 at Preston Workshops - mounted onto a heavy white cardboard sheet, prior to the painting of the dark brown section on the lower side of the tram c1973.trams, tramways, mmtb, prototype tramcar, 1041, preston workshops, tram 1041 -
Melbourne Tram Museum
Photograph - Colour Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), 1973
... Prototype tramcar...Trams tramways Prototype tramcar Nicholson St MMTB On rear ...Colour print of prototype tram 1041 in Nicholson St, near the Victoria Parade intersection with tram 1038 in the background. Tram 1041 has the destination of East Brunswick, route 96. 1038 has the destination of East Preston. Presumed to be MMTB official photograph soon after 1041 issued to traffic - August 1973. Printed on Kodak paper.On rear in ink "Prototype tram built at Preston W/Shops "The first Z".trams, tramways, prototype tramcar, nicholson st, mmtb -
Melbourne Tram Museum
Document - Personal Papers, Melbourne & Metropolitan Tramways Board (MMTB), "Principle Dimensions of Tram Body Work" and "ASEA Truck", 1975
... Prototype tramcar...Trams tramways Z class New Trams W7 class 1041 Prototype ...Set of two personal papers hand written on approx. A5 sheets, ,1 - "Principle Dimensions of Tram Body Work" - lists various dimension including ceiling clearance height, door sizes, step for Z class trams, 1041 and the W7. .2 - "ASEA Truck" - 8 sheets stapled in the top left hand corner, describing the various dimensions, systems, mass, braking, motor, gear boxes, wheels, suspension systems, motor alternators, trolley pole head, foot controllers and the ASEA Tramiac unit.trams, tramways, z class, new trams, w7 class, 1041, prototype tramcar, bogies, trucks, asea, brakes, tram 1, tram 1041 -
Melbourne Tram Museum
Document - Report, Melbourne & Metropolitan Tramways Board (MMTB), "1041 Prototype Tram", 21/03/1974 12:00:00 AM
... Prototype tramcar...Trams tramways MMTB Prototype tramcar 1041 New Tramcars ...Report - three foolscap sheets, titled "1041 Prototype Tram" outlining the basis of the construction of the prototype tram. Gives information on the trucks, control equipment, body frame, interior, doors and windows, heating and ventilation, lighting, destination equipment and other equipment. Notes the construction of the new trams by Commonwealth Engineering and the basis for the design from those of Gothenburg Sweden. Dated 21/3/1974trams, tramways, mmtb, prototype tramcar, 1041, new tramcars -
Melbourne Tram Museum
Photograph - Set of two Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1972
... Prototype tramcar...Trams tramways Preston Workshops Prototype tramcar tram ....1 Black and white photograph of control panel, for 1041 at Preston Workshops .2 Black and White photographs (2 copies) of cab showing control panel installed plus seat and foot controls Printed on Kodak Paper.MMTB stamp on rear of all copy 1 od .2 has A "ASEA PAGE 3" and printing dimensionstrams, tramways, preston workshops, prototype tramcar, tram 1041 -
Melbourne Tram Museum
Photograph - Set of two Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), c1972
... Prototype tramcar...Trams tramways 1041 mock-up Preston Workshops Prototype ...Set of 2 Black and white photographs of control panel, seat in cab of prototype mock-up at Preston Workshops Printed on Kodak Paper. See also Reg Item htd4540 and 7370 for other photos.trams, tramways, 1041 mock-up, preston workshops, prototype tramcar, pcc class, tram 1041 -
Melbourne Tram Museum
Photograph - Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), Aug. 1973
... Prototype tramcar...Trams tramways 1041 Preston Workshops Prototype tramcar ...Black and white photograph of the Transport Minister inspecting prototype tram at Preston Workshops prior to its completion. The trolley pole, numbers and other equipment is yet to be fitted. Outside the tram are Ken Hall and D. H. Eakins. Photo by the Herald and Weekly Times Ltd - has their copyright stamp on the rear. Printed on stippled paper. Not dated, prior to its launch in August 1973.On the rear of the photograph has in pencil. "K. T. Hall - D. H. Eakins - 1041 - Preston - HWT Copyright / Minister of Transport V. Wilcox inside"trams, tramways, 1041, preston workshops, prototype tramcar, minister for transport, tram 1041 -
Melbourne Tram Museum
Photograph - Colour Print/s, Melbourne & Metropolitan Tramways Board (MMTB), Aug. 1973
... Prototype tramcar...Trams tramways 1041 Preston Workshops Prototype tramcar ...Colour print of the conductors desk or console in 1041, showing seat, microphone, change machine, desk and internal seating of 1041, cAugust 1973. shows interior view of the car.On the rear of the photograph has in pencil. "1041 - conductors console -MMTB"trams, tramways, 1041, preston workshops, prototype tramcar, interiors, conductors, tram 1041 -
Melbourne Tram Museum
Photograph - Prototype tram PCC 1041, Public Transport Corporation (PTC), 1973
... Prototype tramcar... Provides publicity photographs of the prototype PCC tram 1041 ...Provides publicity photographs of the prototype PCC tram 1041, that lead to the construction of the Z class trams.Yields information about prototype tram 1041Set of four colour prints and one black and white print of prototype tram 1041 on Riversdale Road, with Wattle Park in the background, second half of 1973, during commissioning and testing phase. .1 - tram showing special and route 000 - has been printed so that the background above the tram has been partly faded. Both printed on Kodak Paper. .2 - tram showing W. Park - Elgar Rod, route 070 - two copies .3 - similar to .2, at different location with park in background. Printed on Kodak paper. .4 - same as .1 - Has PTC copyright stamp on rear and number 3953 - better colour. .5 - black and white print - with PTC stamp and number 3953.tramways, trams, mmtb, prototype tramcar, tram 1041, riversdale road, wattle park -
Melbourne Tram Museum
Photograph - Black & White, David Menzies, Tram 1041 & cable tram set 1 at Preston Workshops, Dec 1974
... prototype tramcar... tram 1041 cable trams prototype tramcar mmtb preston workshops ...Black and white print of PCC Class Tram 1041 & cable tram set 1 at Preston Workshops Dec 1974 See also items 1036 and 72 for other photographs of this event.Demonstrates the prototype all electric tramcar alongside the first cable tram set of 1885Black and White photograph - printed on plain paper with photographers stamp on rear.Has stamp of David Menzies on rear.tramways, trams, tram 1041, cable trams, prototype tramcar, mmtb, preston workshops, tram 1, pcc class -
Melbourne Tram Museum
Photograph - Black & White, David Menzies, Tram 1041 at Malvern Depot, 1974
... prototype tramcar... of Special. Demonstrates the prototype all electric tramcar ...Black and white print of PCC Class Tram 1041 at Malvern Depot with the front door open showing the entry. Has the destination of Special. Demonstrates the prototype all electric tramcar at Malvern Depot.Black and White photograph - printed on plain paper with photographers stamp on rear.Has stamp of David Menzies on rear. and in ink "1041 Malvern Depot"tramways, trams, tram 1041, prototype tramcar, malvern depot, pcc class, mmtb -
Melbourne Tram Museum
Photograph - Black & White Photograph/s, David Menzies, c1974
... Prototype tramcar...Trams tramways Cable Trams Prototype tramcar MMTB Preston ...Black and white photograph of prototype 1041 and the cable tram set 1 side by side at Preston workshops c1974. Photograph by David Menzies. See also Reg Item 72.Has stamp on rear "D. Menzies 237 Wattletree Rd, Malvern, Vic 3144"trams, tramways, cable trams, prototype tramcar, mmtb, preston workshops, tram 1041, pcc class, tram 1 -
Melbourne Tram Museum
Newspaper, The Sun, "New Tram takes the rails", 27/08/1973 12:00:00 AM
... Prototype tramcar... Trams tramways Prototype tramcar 1041 Launch Preston Workshops ...Newspaper Clipping - from The Sun 27/8/1973 titled "New Tram takes the rails" about the launch of the prototype tram 1041 the previous day. Notes the launch with the Premier Mr. Hamer, the Transport Minister Mr Wilcox and quotes drive John Newland. Has a photograph of the tram showing Special.trams, tramways, prototype tramcar, 1041, launch, preston workshops, tram 1041 -
Melbourne Tram Museum
Magazine, Australian Electric Traction Association (ATEA), "New Trams for Melbourne", "Electric Traction May 1973", Apr. 1975
... Prototype tramcar... 1041 Prototype tramcar Electric Traction tram 1 tram 1041 ...Single page foolscap document photocopied titled "New Trams for Melbourne". Gives details of the Z class trams, equipment, safety features, dimensions and details of builder and suppliers, along with a comparison table between W7 class trams, Prototype 1041 and the Z class See also Reg Item for the 2254 for a draft document headed "New Trams for Melbourne" See Reg Item 86 for the newspaper item for the launch of the tram on 30/4/1975 .1 Electric Traction - May 1973 - with a cover photo of 1041 and an article detailing the tram written by John Prideaux, photos by Len Millar. Published by the AETA.trams, tramways, z class, launch, press release, new trams, w7 class, 1041, prototype tramcar, electric traction, tram 1, tram 1041 -
Melbourne Tram Museum
Document - Personal Papers, John Prideaux, "Details of the Comeng Trams", 1975
... Prototype tramcar... Trams tramways Z class New Trams W7 class 1041 Prototype tramcar ...Handwritten draft on ruled Foolscap folio sheet, folded in half and written on three of the four sides, titled "Details of the Comeng Trams". Could have been written by John Prideaux for the AETA Electric Traction. Gives details of the tram, designer, seating, doors, ASEA Equipment, motors, control equipment, braking, resilient wheels, testing. The final page is about the history of the East Preston and East Brunswick Routes.trams, tramways, z class, new trams, w7 class, 1041, prototype tramcar, bogies, trucks, asea, brakes, comeng, electric traction, aeta -
Melbourne Tram Museum
Pamphlet, Minister of Transport, "Melbourne's Pollution Free Public Transport", "Modern Trams", 1973
... Prototype tramcar... Trams tramways Public Transport Prototype tramcar Z class ...Pamphlet, full colour of semi gloss quarto paper, folded into three, providing an image and details and features of new trams (Z class trams) and new Hitachi Silver trains. Issued by the Ministry of Transport. Printed by the Victorian Railways with the VR Print number of 374-73. Features Tram 1041 and a Silver train with a Show Grounds destination. Second copy added 28/11/2016.trams, tramways, public transport, prototype tramcar, z class, hitachi silver train -
Melbourne Tram Museum
Postcard, Nu-color-Vue, 1041 and Cable Tram set No. 1, c1974
... Prototype tramcar... Trams tramways Cable Trams Prototype tramcar MMTB Preston ...Colour postcard with serrated edges of 1041 and Cable Tram set No. 1 outside a building at Preston Workshops, c1974. Produced by Nucolorvue Productions for the TMSV, NCV1095. Has details of the photograph on the rear, TMSV Logo, Publisher details and Printed in Australia. Photograph by David Menzies. Two copies held See Also Reg Items 120, 1036 and 3320 72.1 - 2nd copy of postcard - on rear - Has 33 cent stamp, postmarked for the Centenary of Cable Car Services, 11/11/1985 with a grip included and stamped "100 years of Melbourne trams carried on Commemorative official trip from Flinders St, Melbourne to Richmond Town Hall, November 11, 1985" in blue ink in the bottom right hand corner. See Reg Item 5784 for a colour slide.trams, tramways, cable trams, prototype tramcar, mmtb, preston workshops, centenary, stamps, tram 1041, tram 1 -
Melbourne Tram Museum
Newspaper, The Herald, “New trains, trams hope”, 5/10/1971 12:00:00 AM
... Prototype tramcar... Prototype tramcar 1041 tram 1041 Newspaper clipping titled: “New ...Newspaper clipping titled: “New trains, trams hope” – Herald Tues 5/10/71 Photo and text of new tram Experimental new colours, orange, yellow, green Passengers will board through the front door and leave through the centre exit. Driver separated from passengers by a low bulkhead and rails, same style as buses. Conductor will be seated at front entrance. Trams will be heated. Acting chairman of Tramways Board, F D Snell said plans for new trams were complete. “Ready to go as soon as we get the money”. Tram fleet of 700 is planned to be replaced by 600 of improved version. About 900 new trams will be needed by 1985 according to Metropolitan Transport Plan. Each new tram is expected to cost about $65,000.trams, tramways, new trams, livery, metropolitan transport plan, prototype tramcar, 1041, tram 1041
