DIAMOND DRILLING PROCESS. MININGFRAMED DRAWING OF DIAMOND DRILL CRESWICK. PUBLISHED IN PICTURESQUE ATLAS OF AUSTRALASIA IN 1886DIAMOND DRILL CRESWICK, VICTORIA. DESCRIPTION OF DIAMOND DRILLING PROCESSmining, equipment, diamond drilling

St. George Battery dam c1920 with Drill Hall in centre of photostawell

Large Group of Dancers in Army Drill Hall 1937 Sloane Street Stawell.stawell

Stawell Army Drill Hall. Davies-Coop Cotton Factory Staff Sloane Street during WW2stawell industry war

The Grinton Collection. The other soldiers are unknown at this point. "G. Lifeboat drill". (left in hat) Jack Grinton - "Jack Grinton No. 1043, Refer Cat No. 1280 for his service history.Photograph - framed. Photograph - black and white photograph on paper depicts a group of men wearing life jackets preparing for a life-boat drill. Frame - timber, light varnish finish, Perspex front, cardboard backing."Group 5: Quota 45 - Journey". "G. Life-boat drill".framed accessories, camera on the somme, ww1, 38th bn, grinton, hmat karmala

The item is an end panel from the box section of a "SUN' Seed & Fertilizer Drill. It was manufactured by H.V. McKay Pty. Ltd. at their agricultural machinery manufacturing plant in Sunshine Victoria. The date of manufacture is estimated to be somewhere between 1921 and 1930 because of the imprint H.V. McKay Pty. Ltd. According to the Museum Metadata Exchange (http://museumex.org/oai/mv/2749) the Sunshine Harvester Works was reformed as H.V. McKay Pty. Ltd. in 1921 and in 1930 it became H.V. McKay Massey Harris Pty. Ltd after a merger with the Canadian farm machinery manufacturer Massey Harris. The two events in 1921 and in 1930 are also confirmed by Churchward, M. (2006) at (http://collections.museumvictoria.com.au/articles/2010).This early 20th century item is a relic of the agricultural machinery manufacturing past of Sunshine Victoria. The company started by H. V. McKay no longer exists and neither do the subsequent manufacturing companies H.V. McKay Massey Harris Pty. Ltd., and the later Massey Ferguson (Aust.) Limited. Manufacturing has disappeared from this site being replaced by a shopping centre and other retail outlets, high rise apartments, law courts, police station, Vic Roads, and soon will house the new Brimbank Council offices and library.Brown rusty cast iron end panel from a Seed & Fertilizer Drill"SUN" / SEED & FERTILIZER DRILL / H.V. McKAY PTY. LTD / MAKERS / SUNSHINE / D879 agricultural machinery, sun, "sun" seed & fertilizer drill, h.v. mckay pty. ltd., d879, 1921, 1930, sunshine

Ex Museum of Victoria, Lot 2, Box 2 of 3h.v. mckays massey ferguson, sunshine harvester works, farm machinery

.1 SEPIA PHOTOGRAPH OF DIAMOND DRILL NO 7L. CLUNES. SEVEN MEN STANDING ON CONSTRUCTION AT DRILL ONE MAN SITTING ON PIPE LINE ON LEFT SIDE OF PHOTOGRAPH. .2 .3 COPY OF THE PHOTOGRAPH OF DIAMOND DRILL DIAMOND DRILL NO 7 L CLUNESphotographs, mining, diamond drill

Copy of black and white photograph of the partially demolished drill hall, laminated.On back of photograph: drill hall 1970. Caption on photograph: 1970 demolition of drill hall.williamstown high school, drill hall, 1970, demolition

This Yankee spiral-ratchet Screw Driver (screwdriver) set was a hand tool with drills, used in the making of components for the ship model Sovereign of the Seas. It is part of a collection of objects used by Jim Williams, maker of fine ship models from about 1930-1955. Most of the components for the models, as well as many of the tools, were handmade by Jim Williams. Jim’s family has donated the ship model “Sovereign of the Seas” and many tools, accessories and documents used in the making of this and other ship models have been donated to Flagstaff Hill Maritime Village. Ship model of HMS Sovereign of the Seas, scale model of 17th Century English war ship, was handmade and carved from plans, enclosed in airtight glass case. All components of that model, including even the smallest pulleys, were hand crafted using tools designed and made by Jim. Outstanding details include functional rigging and moving cannons. Please see our record 3732 of the mode Sovereign of the Seas for further details of the ship and the maker. This set is connected with the hobby and skill of ship model making that has been crafted as a leisure activity for many generations. The hobby is often chosen by serving and retired mariners who appreciate the connection with maritime history. This set was used by local Warrnambool man, Jim Williams, who was employed at Cramond and Dickson clothing store, and then at Fletcher Jones menswear for 27 years. It was used in making components for the model of the historic ship, the Sovereign of the Seas. The Sovereign of the Seas was a historic 17th century English war ship with important maritime heritage. Spiral-Ratchet Screw Driver set, also called an ‘American drill’ or hand drill. 9 parts, Yankee brand, No. 31 set. Made by North Bros. Mfc Co. Philadelphia, Pennsylvania, U.S.A.. Instructions for use are on label. Ratchet screwdriver plus 6 drill bits - sizes 1/16th to 11/64th - contained in a small round wooden tube with lid, label on outside. This Screw Driver set is part of a collection of tools and accessories once used by Jim Williams, maker of a series of ship models 1930-1955 including “HMS Sovereign of the Seas”. “WITH 6 DRILL POINTS / SIZES, 1/16 TO 11/64 includes - - with - - / “Yankee” Spiral-Ratchet Screw Driver No. 31 / Made by NORTH BROS. MFG. CO. PHILADELPHIA P [A?]- / Directions for use – First Insert Drill Point In - / Drill Chuck, and turn the – in Chuck of Screwdriver U.S.A.”flagstaff hill, warrnambool, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, jim williams, james bernard williams, ship model hobby, ship model tools, ship model making equipment, ship model making accessories, wood working tool, model making tool, screwdriver set, spiral ratchet screwdriver set, yankee screwdriver set, spiral-ratchet screw driver set, american drill, ratchet drill set, ratchet hand drill, ratchet screwdriverset, north bros. mfc co philadelphia pa, tool, sovereign of the sea, ship model, hobby, ship model tool

Part Number notes have been hand-written on the back page in pencil and blue ink.h.v. mckays massey ferguson, sunshine harvester works, farm machinery

Gunnery drill book for His majesty's Fleet 1909.Gunnery Drill Book for His Majesty's Fleet 1909royal navy, gunnery drill book, 1909

Copy of black and white photograph of still standing roof structure of drill hall, laminated.On Back of photograph: Drill hall 1970.williamstown high school, 1970, drill hall, demolition

Grainy photograph of Oswald's Improved National Rock Drill with various tools laying in front.Oswald's Improved National Rock Drillmining

Two speed breast drill by IXION of Germany. Gearing is 2:1 for low speed and 7.1 for high speed. Speeds obtained by changing over the turning handle and support handle from one side to the other(unscrew and fitted in other side). Turning handle slides over a squared shaft and is secured by a round knurled nut. Chuck will be able to take twist drills for drilling wood or meta. Has a slightly curved base which is held against breast/stomach to obtain pressure for drilling.On aluminum medallion riveted to drill - 'IXION' & 'GERMANY'trades, carpentry, mechanics, tools

EX MUSEUM OF VICTORIA LOT 2 BOX 2/3"793" IN PENCIL FRONT COVER UPPER LEFT HAND CORNERh.v. mckays massey ferguson, sunshine harvester works, farm machinery

Used to drill railway sleepers in the early 20th Century.'Jigger" - an antique steel large two piece drill used to drill railway sleepers around the early 20th Century. The 50cm drill piece can be detached and replaced and it has a handle with a knob on top to turn the drill. The drill is attached by a bolt and screw.steel, metal, tool, drills

The design of this and other similar treadle powered dental engine (or dentist drill) was in common use by dentists from the 1870’s into the 1920's. When electricity became accessible to most communities the electrically powered dental engines began to take over from the treadle power. Over the ages teeth were extracted using picks and scissors and other gouging instruments. Bow drills, hand drills and even a "bur thimble" drill were later used to prepare cavities for filling. Some drills were made bendable by attaching flexible shanks between the metal bur and the handle, giving access to the teeth at the back of the mouth. Other mechanical devices were introduced along the way, such as clockwork drills, but they were hard to handle and inefficient. Over the centuries “dentistry has been performed by priests, monks and other healers. This was followed by barbers; the barber’s chair may well have been the precursor to the dental chair. “(SA Medical Heritage Society Inc.) In 1871 James Morrison patented the first commercially manufactured 'foot treadle dental engine', the first practica dental engine although others had been introduced as early as 1790 (by John Greenwood). Handmade steel burs or drills were introduced for dental handpieces, taking advantage of the significant increase in the speed of the drill. In 1891 the first machine-made steel burs were in use. The treadle drill reduced the time to prepare a cavity from hours to less than ten minutes. In 1876 the Samuel S. White Catalogue of Dentist Instruments listed a 12 ½ inch wheel diameter dental engine, with 14 bright steel parts, for sale at US $55 In today’s market, this is the equivalent to US $1200 approx. The specifications of that dental engine are very similar to the this one in our Flagstaff Hill Maritime Village’s collection. It is interesting to note that workings of a similar treadle dentist drill were used and modified to power a treadle spinning wheel of one of the volunteer spinners at Flagstaff Hill Maritime Village. The foot treadle dental engine was a milestone in dental history. “Historic importance of treadle powered machines; they made use of human power in an optimal way” (Lowtech Magazine “Short history of early pedal powered machines”) The invention of a machine to speed up the process of excavation of a tooth lead to the invention of new burs and drills for the handpieces, improving speed and the surgical process of dentistry. They were the fore-runner of today’s electrically powered dental engines. This treadle-powered dentist drill, or dentist engine, is made of iron and steel and provides power for a mechanical dental handpiece that would be fitted with a dental tool. On the foot is painted lettering naming it "The Brentfield" and there is a fine line of light coloured paint creating a border around the name. The paint under the lettering is peeling off. The drill has a Y-shaped, three footed cast iron base, one foot being longer than the other two. A vertical frame is joined into the centre of the base, holding an axle that has a driving-wheel (or flywheel) and connecting to a crank. A slender, shoulder height post, made from adjustable telescoping pipes, joins into the top of this frame. On the post just above the frame is a short metal, horizontal bar (to hold the hand-piece when it is not in use). A narrow tubular arm is attached to the top of the stand at a right angle and can move up, down and around. There is a pulley each side of the joint of the arm and a short way along the arm is fitted a short metal pipe. A little further along the arm a frayed-ended cord hangs down from a hole. At the end of the arm is another pulley and a joint from which hangs a long, thin metal pipe with two pulleys and a fitting on the end. A treadle, or foot pedal, is joined to the long foot of the base, and joined at the toe to the crank that turns the driving-wheel. The metal driving-wheel has a wide rim. Touching the inside of the rim are four tubular rings that bulge towards the outside of the driving-wheel, away from the pole, and all meet at the hub of the axle. The axle fits between the inside of the driving-wheel and the frame then passes through the frame and is attached on the other side. The driving-wheel has a groove around which a belt would sit. The belt would also fit around a pulley on the arm, at the top of the post. The pulley is joined to a rod inside the arm and this spins the drill's hand-piece and dental tool holder. The foot pedal has a cross-hatch pattern on the heel and the ball of the foot has tread lines across it. The end of the toe and the instep areas have cut-out pattern in them. "The ____/ Brentfield / __ DE IN L___" (Made in London) painted on the long foot of the base. Marked on the drill connection is “Richter De Trey, Germany”flagstaff hill, warrnambool, shipwrecked coast, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, dentist, teeth, dental drill, dental engine, treadle drill, foot powered drill, treadle engine, orthodontics, dental surgery, james morrison, the brentfield, richter de trey, german dental fitting, london dental drill

Historic - Industrial drill - typical hand operated design used in workshops.Historic - Industrial drill - typical hand operated design used in workshops.Hand operated drill press. Bench mounted type hand drill press. drill, press, workshop, hand operated, puffing billy

Historic - Industrial drill - typical hand operated design used in workshops.Historic - Industrial drill - typical hand operated design used in workshops.Hand Operated Drill Press Bench mounted type hand drill press. puffing billy, tools, hand tools, drill press

One of two sets of stereographs donated by the O'Beirne family along with a stereoscope for viewing (Stereoscope is Registration no. 2014-51).Groups of soldiers undertaking drill training. Small group of drummers in foreground."12,927. MEMBERS OF THE AUSTRALIAN EXPEDITIONARY FORCE Undergoing Drill / Excercise at BALLARAT, VIC."stereographs, australian expeditionary force

Hand Rail Drill Out on the track in the old days, it was sometimes required to drill some holes in a piece of rail so that two rails may be joined together by a metal joiner – called a fishplate. Before the use of generators and oxy cutting, the only way to do this was with a hand drill. This is the machine operated by two people, that would drill a hole in the rail. With two to three holes to be drilled in each rail end (ie 4 or 6 holes), it was a tiring, back breaking job. And then there was usually the rail on the other side of the track to be done! Historic - Railways Permanent Way and Works - track equipment - Hand Rail DrillHand Rail Drill made of metal puffing billy, hand rail drill

Used to drill a two inch diameter hole by turning it around and pressing it into wood. Used by residents of the Kiewa Valley. A steel auger used to drill into wood. It is handheld and drills a hole two inches in diameter.wooden auger, woodworking tool

The Archimedes drill, also known as a fretwork drill, is an old type of drill which works on the Archimedian principle; the drill rotates quickly as the barrel on the stem is worked up and down. This tool provides a quick and easy way to bore holes through ordinary fret wood and other substances, smaller versions are used in jewellery making where precision drilling is required. There were numerous different sized Archimedes drills made from various materials, usually a combination of wood and steel, some being all steel and some including brass parts. The fancier versions of these drills included parts made from Rosewood, Ebony, Ivory and decorative brass parts. Some of the later Archimedes drills had technological improvements such as a ratchet device and the inclusion of fly-weights. The ratchet device allows the drill to revolve continuously in the cutting direction. The fly-weights give momentum to maintain the speed of the drill during the upward stroke of the hand. Most old examples such as the subject item have no makers names.A vintage drilling tool that gives a snapshot into how holes were drilled by hand into small or delicate objects during the Victorian era. Tools from this time are today regarded as collectable items eagerly sought by collectors of antique tools.Archimedean drill with wooden grip and butterfly nut on chuck.Noneflagstaff hill, warrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, archimedean drill, drill, fretwork tools, wood working tools

The Archimedes drill, also known as a fretwork drill, is an old type of drill which works on the Archimedian principle; the drill rotates quickly as the barrel on the stem is worked up and down. This tool provides a quick and easy way to bore holes through ordinary fret wood and other substances, smaller versions are used in jewellery making where precision drilling is required. There were numerous different sized Archimedes drills made from various materials, usually a combination of wood and steel, some being all steel and some including brass parts. The fancier versions of these drills included parts made from Rosewood, Ebony, Ivory and decorative brass parts. Some of the later Archimedes drills had technological improvements such as a ratchet device and the inclusion of fly-weights. The ratchet device allows the drill to revolve continuously in the cutting direction. The fly-weights give momentum to maintain the speed of the drill during the upward stroke of the hand. Most old examples have no makers names.A vintage drilling tool, the item therefore could have been used in various industries or professions where precise drilling is required. Archimedean drill with Rosewood hand, brass grip and fittings Noneflagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, archimedean drill
