Trolley wire sample from the overhead at the former South Melbourne depot mounted with two nails from the rear on a white painted wooden block, with the label "Tramway Trolley Wire from South Melbourne Depot 1925-1997" The label has been printed onto a manila coloured sheet and nailed to the side of the block. The wire has a width of approximately 9mm. Understood to have been made by the TMSV following closure of the depot late 1997.trams, tramways, trolley wire, south melbourne depot, closure

Print of drawing number VB4/7184C "Diagrammatic Arrangement of Feeders and Trolley Wire", marked up in colour showing the various feeder and trolley wire arrangements for the central part of Ballarat and the Gardens line. Shows the detailed switch locations that enable the overhead to be isolated or changed when electrical work was being undertaken on the overhead that required it to be isolated. Shows how the various sections were fed from the power station. Revision C issued 2-9-1958.Yields information about the arrangement of the power supply to the trams from the power station and changes made to the system about 13 years prior to closure. Dyeline print on white paper of Drawing - "Diagrammatic Arrangement of Feeders and Trolley Wire" - VB4/7184Ctramways, ballarat, secv, trolley wire, feeder cables, overhead, power station, electrical engineering, electrical switching

Samples of both types of trolley wire used in Melbourne during the 1960s. See item 4084 for a tender document with dimensions. Size - 81.3mm2 or .126 inch squared and 129mm2 or .2 inch sq.Demonstrates the two types of trolley wire used in Melbourne during the 1960sCopper, cadmium copper hard drawn grooved trolley wire - two samples of each type.trams, tramways, mmtb, trolley wire, samples, overhead

Short ear (3 screw) with worn trolley wire bent at either end. Ear - brass, with clamp on fitting used to hold trolley wire in position and steel bolt, steel spring washer. Trolley wire cut about 40mm on either side. One side has pulled out of ear - has no groove on one side. Shows how ear has worn while in service. Screws could not be removed while attached to wire. See original worksheet for sketch. Images added 3-12-2016ballarat, overhead, trolley wire, fittings

Carbon typed copy of a technical procedure - 4 pages -"Graphical Location of Trolley Wire" giving the guide on how to locate trolley wire on curves and junctions, gives formulas, positioning at frogs, notes regarding various cars and trolley wire height. Consists of four pages with a blue print drawing. Each page has been scanned the blue print drawing reversed imaged as well. 4768.2 - the blue print drawing. Extracted from "Transit" Journal - April 1934. Dated 10th Jan. 1935 BTPS Number "226". "226" in ink on left hand bottom of first pagetrams, tramways, overhead, trolley wire, points

Worn piece of old trolley wire (330mm long) of 89mm2 (?) cad copper wire. Taken from an old wire joiner within depot to be used as a sample of worn wire for use in ceremony of new trolley wire hand over on 26/11/96, when Victorian Minister of Transport, Alan Brown handed over new Trolley wire (2km) to Museum. Not known where made - could be either UK or Australia. Images added 3-12-2016 See The Courier, p6, 27/11/1996, see Reg. Item No. 503.trolley wire, btm

Sample length (260mm long) of 107mm2 trolley wire supplied by Metal Manufacturers (Port Kembla Wire and Rod) - November 1996, Used in ceremony of 26/11/1996 when Victorian Minister of Transport, Alan Brown handed over the Trolley Wire (2km) to Museum. Sample supplied ex Test lab - had been tested for hardness. Wire type known as HC - high conductivity. Images added 3-12-2016 See Courier p6 of 27/11/1996 - see Reg. Item No. 503. trolley wire, btm

Piece of worn trolley wire (copper, probably cadmium copper) taken from north bound trolley wire between poles 9 and 17 (Loop and St. Aidans Drive) on 4/3/1997 during replacement operations. Is badly worn on one side. OK on the other side - slightly curve with worn side on the outside of the curve. Green (Oxidized) and sides, dark brown on top. Has been cut at either end. Images added 3-12-2016 See p14 of Section 65 of ICS Manual Tramway systems etc. London c1921.ballarat, overhead, fittings, trolley wire

Tender document - MMTB - 5 sheets - some pre-printed and some typed with hand written notes titled "Supply and Delivery of Hard Drawn Cadmium Copper Trolley Wire", for Contract No. 107. Stapled top left hand corner. Document has not been filled in and has several notations written in blue ink.trams, tramways, trolley wire, tenders

Part of a tramway overhead wiring system, supplying electricity to power the tram. Two devices bolted together; a 'Hanger' and an 'Ear'. Together these devices suspend the tramway trolley wire from the 'side bracket', or a 'span wire'.Historical EquipmentTwo devices bolted together; a 'Hanger' and an 'Ear'. The ear is a '4 screw' ear. Together these devices suspend the tramway trolley wire from a 'side bracket', or a 'span wire'. There is a short piece of trolley wire attached to the ear.68/16 stamped on one sidetramways, equipment, trolleywire

Piece of trolley wire taken from North bound wire between poles 1 & 9 - curved, worn on underside, with longer or sharper groove on inside than normal, probably due to metal flow. Has been cut from wire. See Reg. Item 514 for original wire size and notes. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Sample of trolley wire taken from overhead (South wire ear 10B) which has worn end and then suffered a fractured or break (North end), during replacement operation. Item noted as fractured when ear was disconnected from hanger. Finally fractured or parted at time of lowering wire to the ground. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Sample of trolley wire taken from overhead (South wire) ear 12C, which has worn flat under ear, with metal flow to side,- good grooves and short length past ear and worn to one side at the other end. See Reg item 514 for wire size details. See sketch on original worksheet for cross sections and colours. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Piece of partly worn trolley wire taken from North bound wire between poles 9 and 17 (Loop & St Aidans Drive) on 4/3/97, during replacement operations. Is slightly curved, and only partly worn, both grooves are still good. Has been cut from other wire. See sketch on original worksheet for colours of wire. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Framed print of SEC Drawing No. VB4 7184C, "Diagrammatic Arrangement of Feeders and Trolley Wire" for Ballarat, dated 18.9.1958. Framed in a timber brown section with black/gold lining with glass and black paper backing. Framed by N.L. Harvey & Sons, 131 Sturt St. Ballarat. Has eye hooks and metal picture hanging wire on rear to hang print. See Reg Item 4773 for an original coloured marked up print of this plan and 5173 for a scan of the print and hard copy and item 8680 for a high res scan of this drawing.trams, tramways, power supply, feeders, trolley wire, switches

Sample taken from overhead (North wire, St Aidans Dve) of new 107mm^2 trolley wire. Has been cut at either ends and has been bent at one end through about 90 degrees also slightly curved. Shining new copper colour. Has minor nicks. See original worksheet for sketch. Images added 3-12-2016 See Kembla Wire & Rod letter of 23/9/1996.ballarat, overhead, trolley wire, kembla wire & rod

Sample of trolley wire taken from overhead (South Trolley) at ear 10, which has been heavily distorted, with metal flow under ear, and abrasion marks possibly due to trolley pole "bounce". Grooving of wire varies with position of ear etc. Shows where 6 screw ear was located. Has cut marks at either end. See Reg. item 514 for details of wire size. See sketch for cross-sections and colours on original worksheet. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Piece of heavily worn trolley wire taken from south bound ear, just before ear 41B. Wire in area (on the joiner side) had failed about two months prior to replacement. Sample taken 8 December 1997 during replacement operations. Was on a curve. Two screw marks at one end from being inside a wire joiner. Heavily worn over the years with groove only one side of wire. Top of wire green (oxidised) and dark grey on underside where not contacted by wheel. Has been cut at both ends. Wire curved after taking down naturally. See item Reg No. item 514 for original wire size details. Images added 3-12-2016 See Reg. Item No. 514 ballarat, overhead, trolley wire

5686.1 - Spirit duplicated magazine, 8 quarto pages, single sided - " The Trolley Wire", Vol 2, No. 4, April 1953, stapled down along the left hand side. Has items on proposed tramway to Rockdale, map of the VR tramway to Brighton Beach, tramways and ferry connecting services in Sydney, Eastern Suburbs tramways, Sydney news, tram destination roll for Ashfield (1910), list of destination boards on Sydney steam trams. 5686.2 - Spirit duplicated magazine, 7 quarto pages, single sided - " The Trolley Wire", Vol 2, No. 5, May 1953, stapled down along the left hand side. Has notes on Tempe to Rockdale (map), tramways and ferry connecting services in Sydney, Rushcutters Bay depot track layout, opening dates of Sydney tramway extensions, Sydney news, association news and signs used on Sydney trams. 5686.3 - Spirit duplicated magazine, 7 quarto pages, single sided - " The Trolley Wire", Vol 2, No. 6, June 1953, stapled down along the left hand side. Has an editorial on Sydney transport, tramways and ferry connecting services in Sydney, Sydney news, introduction of electric trams into Sydney, Light St depot, Brisbane track layout, Sydney news, association news. 5686.4 - Spirit duplicated magazine, 9 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 7, July 1953, stapled down along the left hand side. Has notes on replacement with buses on the Ryde line, tramways and ferry connecting services in Sydney, Sydney news, Honeysuckle Depot 1887, Iron Cove or Drummoyne Bridge, Sydney news, Association and Museum news. 5286.5 - Spirit duplicated magazine, 6 quarto pages, single sided - " The Trolley Wire", Vol 2, No. 8, August 1953, stapled down along the left hand side. Has notes on the commencement of electric trams in Sydney, Iron Cove or Drummoyne Bridge, Association and Museum news, map of Sydney electric lines in 1899 and opening dates of Sydney tramway extensions. 5286.6 - Spirit duplicated magazine, 6 quarto pages, single sided - " The Trolley Wire", Vol 2, No. 9, September 1953, stapled down along the left hand side. Has notes on an electric train tour, tramways and ferry connecting services in Sydney, Sydney news, Iron Cove or Drummoyne Bridge, Association news and Newcastle news. See Reg Item 5685 for other Vol 1 issues and Reg Item 105 for Vol 1, No. 6 and Vol. 3 No. 5All copies have pencil or typed inscription of "H. H. Matthews "along top edge.trams, tramways, tramway news, history, sydney, newcastle, map

5685.1 - Spirit duplicated magazine, 4 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 3, April 1952, stapled down along the left hand side. Has items on Sydney trams, a Map of Ballarat tramways (See image i2), Newcastle News, and a discussion of the influx of transport experts into Sydney from England. 5685.2 - Spirit duplicated magazine, 7 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 4, May 1952, stapled down along the left hand side. Has notes on use of tramway power for pumping stations, map of Bendigo (see image i4), news from Brisbane, Sydney news, association news, tramcar painting letters, Newcastle Destination roll 5685.3 - Spirit duplicated magazine, 7 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 7, August 1952, stapled down along the left hand side. Has notes on Brisbane, Association news, map of the La Perouse - Botany - Mascot district, Ryde Cemetery, Sydney R 1890 runaway, North Sydney destination roll (1910) 5685.4 - Spirit duplicated magazine, 8 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 8, September 1952, stapled down along the left hand side. Has notes on Association news, (left hand side very faded), map of the Enfield's lines, Brisbane Trolley Bus system 1952, Sydney news, and Eastern Suburbs roll. 5285.5 - Spirit duplicated magazine, 9 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 10, November 1952, stapled down along the left hand side. Has notes on Brisbane, Wylde St trolley bus route in Sydney, Sydney news, association notes, Proposed lines in Sydney - Haberfield to Dobroyd, use of triple trams in Sydney, Broken Hill destination roll, Fort Macquarie depot track drawing and Newcastle news. See Reg Item 5685 for other Vol 1 issues and Reg Item 5686 for Vol. 2 issues.Vol 1, No. 4 has pencil inscription of "H. H. Matthews" in top right hand corner.trams, tramways, tramway news, history, sydney, newcastle, broken hill, brisbane, ballarat, bendigo, map

Long ear, 6 screws, ex South wire, at location 14D showing badly worn ear, broken screw head, worn wire etc. Screws faced East. Screws were partially undone on 3/3/97. Ear- Brass, Wire-Cad Copper. See original worksheet for sketch and Reg. Item 514 for wire sizes. Images added 3-12-2016ballarat, overhead, fittings, trolley wire

Demonstrates the type of equipment used in overhead electrical collection parts and has a strong association with Ballarat trams..2 - Photocopy of the record cards "Car History", 10 sheets cut to size, giving dates, repairs, accidents, notes and maintenance of the tramcar.trolley wire, overhead, electrical equipment

Sample of wire from the State Electricity Commission (SEC) Yallourn Morwell area. Shows wear on lower edge - from pantograph operation. About 75mm from one end shows marks of two screw ears, used to hold overhead into position. Images added 3-12-2016trolley wire, secv, yallourn

Trolley Wire No. 241 May 1990. Anniversaries - Newcastle and Bendigo. History and photos..tramways, bendigo

Yields information about Sydney trams in the early 1950s and demonstrates means of publishing information of the era.105.1 - Spirit duplicated magazine, 8 quarto pages, single sided - " The Trolley Wire", Vol 1, No. 6, July 1952, stapled down along the left hand side. Has items on Brisbane, with map, Brisbane news, Sydney news, Gladesville to Lane Cove proposed tramway and Western Suburbs Destination Roll, 1947 - 1950. 105.2 - Spirit duplicated magazine, 9 quarto pages, single sided - " The Trolley Wire", Vol 3, No. 5, 20th May 1954, stapled down along the left hand side. Has notes on association matters, map of tramways in the Moore Park area, Drummoyne Bridge and Iron Cove tram lines, Easter workings, Sydney news. See Reg Item 5685 for other Vol 1 issues and Reg Item 5686 for Vol. 2 issues. Scan with care.Vol 3, No. 5 has pencil inscription of "H.Matthews"trams, tramways, tramway news, history, sydney, brisbane

Has a strong association with the formation of COTMA and the work undertaken by Australasia tramway and rail heritage organisations at the time and the organisers of the first COTMA Conference in 1975.82 page A4 sized bound document - "The First Conference of Australian Tramway Museums Ballarat 25-27 April 1975" . Has a light weight card cover, with black plastic binding/spine strip. Produced by Trolley Wire 1st Conference Proceedings Contents: Acknowledgements Message from BTPS President - Maurice Calnin Convenor's Note - Bill Kingsley List of Museums Invited List of Delegates Conference Minutes of Special General Meeting COTMA Operational Guidelines Papers Wymond - Financing the Railway / Tramway Operating Museum Kahn - A history of experience Breydon - Accounting methods suitable for museum operations Prentice - Tramcar Maintenance - Museum Style Radcliffe - Buses - their preservation and relevance to tramway museums (supplement document_ Rawlings - The formation of an Association of Tramway Museums of Australasia Stamford - Museum Publications Workshops Engineering Cars and Parts Treasury Publicity Management Governments Removals Membership Special Has a red dot, taped onto the spine of the front cover.Inside front cover label "Graeme S. Breydon" and his address and on front cover in pencil, "G.Breydon".trams, tramways, cotma, ballarat, proceedings, conferences

Map titled "Geelong tramways" prepared by Ken McCarthy Feb. 1981 showing the Geelong tram system with major street names, with a service frequency chart for weekdays in 1951 and 7 small maps showing the various stages of system development from 1912 to 1940. Has an insert for the depot layout. Produced for Ken's article on Geelong Tramways in the April 1981 issue of Trolley Wire, published by the Sydney Tram Museum.Yields information about the Geelong tram system and has a close association with Ken McCarthy.A4 printed sheet - from the April 1981 issue of Trolley Wire magazine.tramways, geelong, map, trolley wire

Set of five colour photographs of Trolley Wire replacement in Wendouree Parade sent to the Editor of Trolley Wire - 2 used in the May 1997 issue of Trolley Wire. All photos by Carolyn Dean. All photos taken on 4-3-1997. All photos on AGFA paper. 1139.1 - Working on the trolley wire just to the north of Gardens Loop 1139.2 - Alan Snowball's Ute and trailer with wire reel, North Gardens area. 1139.3 - Replacing wire -group photo around behind truck - used on page 38 of Trolley Wire. 1139.4 - General photo of work with Ute and trailer in foreground and tower truck in background. Wire run out for a number of pole lengths - used on page 38 of Trolley Wire. 1139.5 - Photo of work on trolley wire replacement with tower truck. All have in black ink "4.3.97" and "Photo by / Carolyn Dean". 1139.3 has "Gardens Loop" in blue ink on top edge, and white sticker with "Photo 56 / 14.4 x 9.5cm" written on in black ink. 1139.4 - has white sticker with "Photo 57 / 14.5 and 7cm" written on in black ink.trolley wire, btm, wendouree parade, overhead
