See image 2085i4 for tender re brake blocks detailing the type of cast iron and the Brinell hardness.Demonstrates MMTB tender documents of 1923.Manila colour file marked "Specifications" containing 25 different specifications of the MMTB 1922 to 1925. Not all dated, generally foolscap sheets either pinned or stapled. Dated Tender No. For supply of: 30/6/1925 157 Steel castings Not dated Ballast Hopper trucks 1923 Steelwork for electric and cable tramway crossings Pamphlet Monier Pipes and box culverts Pamphlet Monier – septic tanks and aerators Not dated 229 Purchase of removal of cottages 101 to 107 Bouverie St Carlton Not dated Side tipping ballast trucks 18/7/1923 226 Brake shoes - see pdf file for a full scan 18/7/1923 222 Steel tramway tyres 18/7/1923 220 Concrete Mixing Plants Not dated 219 Dressed wooden poles 9/5/1923 215 Bricks 19/4/1923 214 Reinforced Concrete fencing posts 20/3/1923 213 Tramway steel wire ropes 28/3/1923 212 Painting exterior of 673 Bourke St Melbourne Not dated 210 Alterations to offices at Rathdowne St depot Not dated 202 80lb steel rails and fishplates 5/1/1923 198 GE201 Motors 6/12/1922 197 Hydraulic pit jacks 6/12/1922 195 Supply of Low tension feeder cable Not dated 194 Supply of high tension cable 4/12/1922 188 Supply of hard drawn trolley wire 6/11/1922 186 Dressed wooden poles 20/11/1922 182 Steel Poles 20/12/1922 171 Erection and completion of new car depot Glen Huntly Roadtrams, tramways, mmtb, tenders, specification, trackwork, motors, cables, poles, ballast wagons, glenhuntly tram depot, brake blocks

Agfa Colour slide, cardboard mount, by Keith Caldwell of 7 March 1960 - of the sleeper transport car No. 15 westbound in Victoria St at intersection with Brunswick St - now St Vincent's Plaza. Tram appears to be carrying old brake blocks back to Preston Workshops..1 - hand stamped "12 Mar '60"trams, tramways, st vincent's plaza, victoria parade, work trams, service tramcars, brake blocks, tram 15

Cardboard cut out (drawing) of the shape of a Radiax Truck, brake Block holder. Has the title drawn onto the shape, along with ink sketches, marks etc. Has been cut from a Sandringham to Black Rock Section poster. The first section is partly detailed.trams, tramways, brake blocks, radiax truck, sandringham, black rock

Newspaper Clipping from The Courier, Ballarat 21/7/1999 on the acquisition of the equipment from the Clyde Harding Foundry, Doveton St. Nth, Ballarat by Sovereign Hill. Features a photo of Alan Harding, Jan Penny and Richard Nicholson. Mentions the supply of brake blocks to the SEC., BTM and Puffing Billy.On base in blue ink, "Wednesday July 21 1999 The Courier pg 3"trams, tramways, harding s, foundry, brake blocks, castings

Yields information about the tramcar maintenance activities of the SEC at the depot in frequency of changing brake blocks, light bulbs, trolley rope and wheels for each tramcar.Collins Diary No. 324, 1967, red Rexene covers, sewn sections with ruled sheets providing a diary for 1967, 7 days and notes for each double page. Has "useful information" sheets at from the diary. Used by the SEC Ballarat depot to record brake block changes and light globe replacements on each tramcar. Also gives details on trolley rope and trolley wheel replacements.tram, trams, sec, ballarat, depot, brake blocks, trolley wheels

Yields information about the tramcar maintenance activities of the SEC at the depot in frequency of changing brake blocks, light bulbs, trolley rope and wheels for each tramcar.Collins Diary No. 324, 1968, red Rexene covers, sewn sections with ruled sheets providing a diary for 1968, 7 days and notes for each double page. Has "useful information" sheets at from the diary. Used by the SEC Ballarat depot to record brake block changes and light globe replacements on each tramcar. Also gives details on trolley rope and trolley wheel replacements.tram, trams, sec, ballarat, depot, brake blocks, trolley wheels

Yields information about the tramcar maintenance activities of the SEC at the depot in frequency of changing brake blocks, light bulbs, trolley rope and wheels for each tramcar.Collins Diary No. 324, 1968, red Rexene covers, sewn sections with ruled sheets providing a diary for 1969, 7 days and notes for each double page. Has "useful information" sheets at from the diary. Used by the SEC Ballarat depot to record brake block changes and light globe replacements on each tramcar. Also gives details on trolley rope and trolley wheel replacements.tram, trams, sec, ballarat, depot, brake blocks, trolley wheels

Yields information about the tramcar maintenance activities of the SEC at the depot in frequency of changing brake blocks, light bulbs, trolley rope and wheels for each tramcar.Collins Diary No. 324, blue Rexene covers, sewn sections with ruled sheets providing a diary for 1970, 7 days and notes for each double page. Has "useful information" sheets at from the diary. Used by the SEC Ballarat depot to record brake block changes and light globe replacements on each tramcar. Also gives details on trolley rope and trolley wheel replacements.tram, trams, sec, ballarat, depot, brake blocks, trolley wheels

35mm Kodak white cardboard colour slide by Keith Kings of per way works car No. 15 being used to transport brake shoes (blocks) around the depot. Being loaded at Preston Workshops. 16/4/1968Keith Kings stamp and number "21-36", with details of exposure. in ink "MMTB No. 15 (ex Q 198) being used to transport brake shoes around the depot. Being loaded at Preston Workshops.trams, tramways, work trams, brake blocks, tram 15

Yields information about the tramcar maintenance activities of the SEC at the depot in frequency of changing brake blocks, light bulbs, trolley rope and wheels for each tramcar. This book was the last to be done by the SEC in Ballarat, closure occurred on 19/9/1971.Collins Diary No. 324, blue Rexene covers, sewn sections with ruled sheets providing a diary for 1971, 7 days and notes for each double page. Has "useful information" sheets at from the diary. Used by the SEC Ballarat depot to record brake block changes and light globe replacements on each tramcar. Also gives details on trolley rope and trolley wheel replacements. The last recorded entry was 14/9/1971, for fitting of second hand shoes to 34 and 42. Inside front cover were: 1 - loose - carbon copy of a "Notice to All Traffic Staff" regarding braking - See Reg Item 3520. 2 - loose - carbon copy of run number 25, Monday to Friday - See Reg Item 3521. These are to be retained with the item, but in a separate container.tram, trams, sec, ballarat, depot, brake blocks, trolley wheels

This private late-nineteenth-century four-wheeled carriage has been built to transport a family or group of passengers with a coachman in the front seat. It can be pulled by one horse, or by two horses if the T-pole is attached. The button fittings along each side of the carriage indicate that a folding roof or hood was once attached. The frame across the front of the carriagewas likely to have been a ‘dashboard’ with a leather or wood covering to prevent water, mud and other particles from splashing onto the passengers. The rear step between the two side-facing bench seats is adjustable to allow for ladies’ long skirts. These rear seats appear to be removable, in which case the carriage could be converted to a wagon to transport goods and equipment. The carriage could have been illuminated by oil or carbide lamps placed into the lamp holders on the sides. The carriage was kept under cover for many years in an open-front sandstone building that also included living quarters and an area that may have been stable. It was at ‘Murweh’ a Warrnambool property at 203 Liebig Street. The home is now Heritage and National Trust Listed and described as a ‘gentleman’s residence’. It was built by James Wotton Shevill in the 1860s. Shevill was a councillor from 1875 to 1878, serving in 1878 as Mayor of the Borough of Warrnambool. Jeremiah Wade lived at Murweh there from 1879-1880. By 1915 F.B. Whitehead and his family were living there, and by 1930 the address was used by Mr T.J. Rome and his family. Thomas James Rome was still using that address in September 1973 after his 100th birthday. It is believed that one of the property’s owners had been an Obstetrician in Warrnambool. The current owner re-told the story that children used to hide in the back section of the carriage and smoke, hidden from the sight of onlookers. He had heard the story from a previous owner.The well-appointed horse-drawn four-wheeled carriage is likely to have first belonged to a local councillor and past Mayor of the town of Warrnambool, J.W. Shervill, whose 1860s city property was the carriage location for many years. The carriage is a rare local example of a town-based lifestyle befitting a prosperous personality of the late 19th century. It adds to the story of Warrnambool's development as a town influenced by the port, wealth gained from shipping and the home place of prominent local people such as the Councillor and later Mayor. The side-facing rear seating is unusual for a passenger carriage. It has the feature of removable rear bench seats, allowing for the dual purpose of a carriage or wagon.Carriage; the Victorian-era horse-drawn four-wheeled open carriage has a coachman’s bench seat across the front and two side-facing bench seats in the rear. There are steps at the front on each side and a centre adjustable step and the back. It has a hinged shaft, two lamp holders and a separate T-pole. The bench seats have padded backrests upholstered in green leather and each has padded armrests at the ends. A rectangular metal frame, likely to have been a dashboard, is mounted across the front of the carriage. It has two inner vertical bars. The carriage's body is painted dark green with crimson highlights on some of the panelling. Decorative oval panels with hand-painted motifs are mounted along the sides. The side panels of the carriage have metal fastener buttons attached. The iron-rimmed wheels have sixteen wooden spokes and copper cuffs on the outside of the hubs, and the rear wheels are higher than the front wheels. Wooden brake blocks are mounted onto the back wheels and are active by a metal lever at the front right side of the carriage. The undercarriage is fitted with leaf springs on each side, mounted from front to back axles. Included are: (1) The separate T-pole that allows two horses to be harnessed to the carriage (2) Leather horse winkers with metal hardware and oval brass plate on the side of each winkerMotif painted on an oval panel [a musical lyre within a blue floral wreath flanked by scrolls] flagstaff hill maritime museum and village, warrnambool, great ocean road, shipwreck coast, murweh, buggy, cart, carriage, wagon, horse-drawn vehicle, victorian buggy, four-wheeled carriage, coachman’s seat, bench seat, side-facing benches, upholstered seats, victorian decals, heritage vehicle decoration, antique hand painting, hand painted decals, motifs, iron-rimmed wheels, wooden brake blocks, leaf springs, t-pole shaft, rear step, equine carriage, 19th century vehicle, victorian transport, transport, gentleman’s vehicle, james wotton shevill, councillor, mayor, jeremiah wade, f.b. whitehead, thomas james rome, warrnambool obstruction, warrnambool genealogy, warrnambool pioneers, victorian carriage, one horse carriage, two horse carriage, horse drawn carriage

Set of two tender documents, each of two foolscap sheets for the supply and delivery of castings to the Boards repair shops (Nicholson St or Holden St?), with patterns supplied by the Board. Gives details of the quality, approx. quantity, patterns, delivery, rejection, payment, cancellation and other details. .1 - "Manufacture, supply and delivery of iron castings contract No. 96" - 70 to 85 tons /half year - tenders closed 29/4/1929. .2 - "Manufacture, supply and delivery of steel castings contract No. 96" - 50 tons / year - tenders closed 10/6/1920. 2 copies of each, either pinned or clipped with a brass clip in top left hand corner.trams, tramways, tenders, contracts, mmtb, cable trams, castings, brake blocks

Photo shows an MMTB employee at a depot or workshop adjusting the brakes on a No. 15 bogie or truck using a special spanner for the task. Another open-ended spanner can be seen on the lock nut. The brake block is a new Ferodo type made by Hardie, c1970. See item 7451 re timing of introduction of this type of brake block.Yields information about the method of adjusting brake blocks on a No. 15 truck.Black and white photo with a plain backmmtb, tramways, brakes, trucks, tramcar maintenance, no 15 truck

Demonstrates a hand written note about the coefficient of friction.Foolscap sheet - titled "Some special Co-efficient of Friction" setting out parameters for steel tyres and rails, cast iron brake blocks, velocity and types of paving. Hand writtentrams, tramways, brakes, reports, tramcars

Blank form to provide an administrative record - for each Provincial tramway branch to summarize the work done for a year end. Has sections for tram bodies, trucks, motors, brake blocks, tyres etc. Not dated.Demonstrates a SECV form for reporting on annual maintenance activities.Form - duplicated foolscap sheet titled "Maintenance report - Rolling stock"tramways, tramcars, secv, maintenance, reports

Report on W2 class tramcar No. 491, 23 pages including appendices, titled "Tramcar braking tests - Tram No. 491". Dated October 1960. Report looks at the braking characteristics of the tram using various brake blocks, including those manufactured by the VR, and the degree of chilling in the block and its impact. Testing done in Miller St Preston. Document bound within a manila cover stapled with red cloth adhesive tape on the left hand side. Carbon copy with "Testing Engineer's Copy" written on the cover.trams, tramways, preston workshops, reports, tramcars, w class, braking, tram 491

Manuscript - two typed quarto sheets - titled "Ferodoisation" written by "Dick Kerr", looking at the use of Ferodo brake shoes in Melbourne. Looks at costs, service, noise, braking, disadvantages of noise, smell, dust and braking effort. See also Reg Item 3054 - "Electric Traction - May 1969", that has an article by "Richard Kerr" - most likely the same author and the collector - Bob Prentice. With the manuscript are two photographs of the brake blocks and drawing of a wheel marked Fig 1 and Fig 2 - these are not referenced in the article.trams, tramways, mmtb, brakes, ferodo brakes shoes, braking, tramcars

Record of the monthly reports from April 1965 to July 1971, signed by the Depot Foreman S Lakey, D Irwin or acting F. Minns. Lists the number of brake blocks replaced and summarises the principal work done on the tramcars and special jobs eg replacing the destination rolls. image i2 - April 1965 to December 1966 image i3 - Jan. 1967 to December 1968 - including an entry dated 10-9-1968 with a list of depot staff, addresses and phone numbers, 17 in all. image i4 - Jan. 1969 to December 1970 image i5 - Jan 1971 to July 1971Yields information about the Ballarat Workshop activities, tramcars maintained and events on a monthly basis.Memo reporting book, with sheets headed "Departmental State Electricity Commission of Victoria" - ruled, carbon copy with heavy card covers with green tape binding. Form SF-466-12-0254. A sheet of carbon paper remains in the book as if for the next entry.ballarat, tramcars, workshop records, workshops, maintenance

A spring cart is a two-wheeled, one-horse cart, often with the driver standing up to drive it, and otherwise seated on a simple seat. Carts like this one had springs to make the ride smoother. It is a lighter version of a farm dray and is sometimes called a spring dray. Spring carts were often used on farms for carrying loads. In the towns, some businesses used a spring cart for deliveries of bread, milk and other goods. The carts would be used for travel and for families going on outings and picnics. Visitors to Flagstaff Hill Maritime Village from 1986 to 1992 would enjoy watching a Clydesdale horse named Duke as he worked around the village with his driver Pat McGowan. He would be hitched to a wagon or to this lightweight spring cart or sometimes he would pull the wagon with the cart attached as a trailer. The cart was used for maintenance, carting loads of timber or stone around the site or from town to Flagstaff Hill. Sometimes Duke and the cart would take visitors for cart rides around the Village. Pat McGowan was known for his restoration of horse-drawn vehicles including this spring cart. He already had 40 years of horse handling experience when he began looking after Duke, feeding and harnessing him and driving the horse and cart around the Village. Pat’s dog ‘Yabbie’ would often join them. In August 1992 Duke had to be put down. Warrnambool Veterinary Clinic and other fund-raisers began well-supported appeals and the beloved horse was replaced by a Clydesdale also named Duke (the second), who began work in late October 1992. He, like his predecessor, had a quiet temperament and was comfortable in the traffic. The spring card is an example of vehicles used on farms, for business delivery and for domestic transport in the late-19th and early-20th century. This cart is of note for being associated with the Clydesdale horse Duke which pulled the cart around Flagstaff Hills in the 1980s and 1990s, representing transport of that period.Spring cart; two-wheeled cart with shallow box tray and plank seat bolted across the front. Wheels have metal rims and fourteen (14) wooden spokes. A plank is bolted from side to side. A decorative metal step is on the cart's left and has acorn cut-out shapes in the plate. Both wheels have a brake block that is operated by a lever on the cart's right. The cart has eight-leaf suspension from front to back. The box tray is painted blue and has decorative pale yellow detail. Each shaft pole has has a handle fitting on it. (Horse equipment with the cart is a leather covered, straw filled collar.) flagstaff hill, flagstaff hill maritime museum and village, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, springcart, spring cart, jingle, horse-drawn cart, one horse cart, two-wheeled cart, dray, spring dray, wagon, transportation, travel, cart, duke, clydesdale, pat mcgowan, delivery cart, yabbie, cartwright, horse-drawn vehicle, transport, horse cart

Book - "Instructions re Working of the St Kilda and Brighton Electric Street Railway", dated 1 January 1915. Has an index - general instructions, hand signals, working of cars, working of traffic over single and double line, staff and ticket systems, air brakes, permanent way, overhead, fares, appeals of employees against penalty and electric shock.Demonstrates a Victorian Railway Rule book for electric tramways or Street Railways.Book - 104 pages with sewn and bound dark blue rexine covers with gold blocked title and glue end papers.On inside of front cover an inscription from Gerald Dee to Richard Gilbert dated 22/10/1999.tramways, trams, victorian railways, vr, st kilda - brighton tramway, rules, employees, safe working

Book titled "The Electric Tramcar Handbook written by W.A. Agnew. Book has dark red cloth covers, gold block titled on front only, with tipped in end papers, title page, contents pages, three introductory pages by author, 110 pages of text, five index pages and two folded sheets interspersed in book with wiring or controller diagrams. Book finished with red tinted edging. Has a index at the rear of the book. Book published by The Electrical Review Limited, London in 1905, 2nd edition. Primary contents chapters include: The Electric Circuit Electric Tramways Electric Tramcars Controllers Brakes On the Road Faults and Breakdowns. See also Reg Item 2247 for the 8th Edition.Numerous price or wage calculations on inside of rear cover.trams, tramways, tramcars, tramways, technical books, handbooks

Book titled "The Electric Tramcar Handbook" written by W.A. Agnew. Book has dark red cloth covers, gold block titled on front only, with tipped in end papers, title page, contents pages, three introductory pages by author, 127 pages of text, five index pages and six folded sheets interspersed in book with wiring or controller diagrams. Book finished with red tinted edging. Book published by The Electrical Review Limited, London in 1920, 8th edition. On the inside front cover has the stamp of the Australian Electric Traction Association and office stamp of "The Melbourne Electric Supply Company Limited" which has been crossed out. Primary contents chapters include: The Electric Circuit Electric Tramways Electric Tramcars Controllers Brakes On the Road Faults and Breakdowns.See images i2 and i3 showing notes and AETA stamp and MESCo stamp.trams, tramways, tramcars, tramways, technical books, handbooks, mesco

Newspaper clipping - two sheets - from the Herald Sun newspaper, Thursday 29/11/2001 about the tramcar and parts stored at Newport Workshops East block - includes photos. Page 1 - titled "Our rotting treasurers" has a photo of the W's lined up in the former workshop. Article written by John Masanauskas - Transport Reporter Page 4 - titled "More brakes put on W-class return" with a photo of dismantled motors and a tramcars in the background. Includes comments by Rupert Hamer, John So and John Cain.trams, tramways, newport workshops, stored trams, w class

Block mounted photograph on a metal backing sheet which has a packing between a stippled card sheet and the photograph to give a curved effect with an outer plastic cover and a mounting cord on rear. Photograph of John McMahon as MMTB conductor badge Number 772 on the rear platform of cable car trailer No. 477, with one hand on a hand brake. Shows the MMTB style conductors bag and ticket folder or holder. Has the destination sign set for "Brunswick" Photograph may be hand coloured by a studio photographer.trams, tramways, cable trams, mmtb, conductors, brunswick, tram 477

Issued to employees of the VR St Kilda to Brighton electric street railway, superseding previous copies. The line closed in 1956. Note the spelling of the word "employe" with an accent over the e - an acceptable practice in Victoria at the time - a US based spelling. Book scanned into multiple parts. See Reg Item 3508 for a "Supplement to the Book of Instructions re the working of the St Kilda and Brighton Electric Street Railway, dated 1/1/1915", item 7518 for a June 1907 version, and 7580 for instructions issued in 1911.Demonstrates a Victorian Railway Rule book for electric tramways or Street Railways.Rule Book - 156 pages, five sewn sections within a green coloured Rexene heavy card with glued endpapers with the title "Victorian Railways Instructions re Working of the St Kilda and Brighton Electric Street Railway" and "1927" in gold block. Dated 1 June 1926. Has a table of contents and index - gives definitions - "trams" vs "street railways", general instructions, hand signs, working of cars, working of traffic over single and double line, staff and ticket systems, air brakes, permanent way, overhead, fares, appeals of employees against penalty and electric shock.Copy 3 has stamp of the "Westinghouse Brake Inspector" and "Lloyd Rogers" in ink on the inside front cover. On page 94 and 95 has notes in pencil about the air braking system - may have been for a following issue.trams, tramways, victorian railways, vr, st kilda brighton, rules, employees, safeworking

The VN Commodore was available in Executive, S, SS, Berlina and Calais specification levels, although a more basic SL model (opt. code A9K) was supposedly offered to government and fleet buyers, as it was not officially listed as part of the Commodore range. Changes in the relative values of the Australian dollar, the Japanese yen, and the US dollar made it impractical to continue with the well-regarded Nissan engine of the VL. Instead, Holden manufactured their own 90-degree V6 based on an old Buick design from the US, although initially it was imported. The 5.0-litre V8 remained optional and received a power boost to 165 kW (221 hp). Both these engines used multi point GM EFI and the V6 using 3 coil-packs for ignition. Holden and HSV developed this car as the basis for racing in Group A Confederation of Australian Motor Sport events. While the minimum number of cars built to qualify in Australian Touring car Championships, with modified body kit, brakes or engine is 500, only 302 VN were built but CAMS granted an exemption allowing them to compete.Holden and HSV had worked hard to develop this car to be a serious competitor to the Skyline, Ford Sierra and the BMW which had dominated in the previous years. This was to be the Holden’s answer and coincided with the return of Peter Brock back to the Holden team from 1987.Mechanically the cars were fitted with reworked version of Holden’s 4.9 litre V8. The engine block was cast for additional strength, modified cylinder heads roller rockers and high fuel flow fuel injection was applied. Output was 215 kw at 5200revs and, though at today’s standard, that is not that much it was very impressive at that time. The drive was through a six speed ZF gearbox with a heavy duty racing clutch and a limited slip differential.Under the Hawke government's Button car plan, which saw a reduction in the number of models manufactured locally, and the introduction of model sharing, the VN Commodore was rebadged as the Toyota Lexcen, named after the late America's Cup yacht designer, Ben Lexcen. Subsequently, the Toyota Corolla and Camry were, similarly, badged as the Holden Nova and Holden Apollo.Red executive 4 door sedanHolden Lion and stone emblem grille centre, Commodore boot LHS, Lion and stone emblem boot RHS.vehicle, vn commodore, holden, car

Photograph shows part of the preserved cable grip car number 1 and trailer car number 1 in a large glass covered display case in Russell Street behind the (then) Melbourne Museum and State Library. The photograph shows the gripman's compartment with two brake levers and the central grip lever. At the top of the photo above the levers is curved metal beam to which a block and tackle were fastened to lift and lower the grip into the tunnel. At either end of the compartment is a knee high board with whole at the top that fitted into slots between the end traverse seats to stop winter drafts blowing across the gripman's feet. Yields information about cable tram componentsBlack and white photograph with note on rearIn ink "29" and "K McC"cable trams, russell street, melbourne museum, state library, draw bar, tie rod, pin, safety chain, trailer coupling
