Ballarat Tramway MuseumFunctional Object - Rail Section, The North Eastern Steel Co. Ltd. Middlesborough, Rail Section 9616 Manufacturers Sample, 1903?
... Rail Section...Rail Section 9616 Manufacturers Sample...... Rail Section...Section of flanged tramway rail - saw cut from rail, polished and then nickel plated silver finished and stamped in italics - "Northampton Corporation Tramways B.S.Section No. 1C" in the head of the rail, "96lbs per yard" stamped in the base of the flange and along the foot of the rail "The North Eastern Steel Co. ...Ltd Middlesborough" and in the flangeway "1903". Rail Section 9616 Manufacturers Sample Functional Object Rail Section The North Eastern Steel Co. ...Yields information about some of the rail used in Northampton UK and demonstrates the type of rail used in tramways.Section of flanged tramway rail - saw cut from rail, polished and then nickel plated silver finished and stamped in italics - "Northampton Corporation Tramways B.S.Section No. 1C" in the head of the rail, "96lbs per yard" stamped in the base of the flange and along the foot of the rail "The North Eastern Steel Co. Ltd Middlesborough" and in the flangeway "1903".Northampton Corporation Tramways B.S Section No. 15 1993 The North Western Steel Co. Ld. Middlesbroughtrams, tramways, rail, uk, rail section -
Melbourne Tram MuseumFunctional object - Rail Section - grooved or flanged tram rail
... Rail Section - grooved or flanged tram rail......rail section...Rail possibly 96lbs/yard, used on street based tramways, rolled with a heavy check or flange for use on curves. Matches BS Section...Rail Section - grooved or flanged tram rail cut from rolled rail....Demonstrates a rail section used on street based tramways. tramways rails rail section Rail Section - grooved or flanged tram rail cut from rolled rail. ...Rail possibly 96lbs/yard, used on street based tramways, rolled with a heavy check or flange for use on curves. Matches BS Section 1C - see item 3292 of the Ballarat Tramway Museum. Demonstrates a rail section used on street based tramways.Rail Section - grooved or flanged tram rail cut from rolled rail.tramways, rails, rail section -
Ballarat Tramway MuseumFunctional object - Rail Section - sample
... Rail Section - sample......rail section...Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BALLARAT" stamped into the web of the rail " 85", stamped onto the head of the rail. with a hole drilled through the head of the rail....Functional object Rail Section - sample ...Collected by the donor near the time of the closure of the Ballarat system. Was used to provide information on the type of rail used in Ballarat and specifically for rail 85lb/yard weight.Yields information about some of the rail used in Ballarat and demonstrates the type of rail used in tramways. Demonstrates craftmanship in cutting and finishing sections of rail for tramway engineering offices, suppliers etc.Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BALLARAT" stamped into the web of the rail " 85", stamped onto the head of the rail. with a hole drilled through the head of the rail.ballarat, rail, rail section, track, tramways, steel -
Ballarat Tramway MuseumFunctional Object - Rail Section, 1930's?
... Rail Section...... Rail Section...Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BALLARAT" stamped into the web of the rail " 90A", stamped onto the head of the rail. with a hole drilled through the head of the rail....Trams tramways Rail Ballarat Rail Section "BALLARAT" stamped into the web of the rail and "90A" stamped onto the head of the rail. ...Yields information about some of the rail used in Ballarat and demonstrates the type of rail used in tramways.Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BALLARAT" stamped into the web of the rail " 90A", stamped onto the head of the rail. with a hole drilled through the head of the rail."BALLARAT" stamped into the web of the rail and "90A" stamped onto the head of the rail.trams, tramways, rail, ballarat, rail section -
Ballarat Tramway MuseumFunctional Object - Rail Section, Lorain Steel, 9mm Sawn Cut Rail, 1930's?
... Rail Section...... Rail Section...Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BENDIGO" stamped into the foot of the rail. ...Trams tramways Rail Bendigo Rail Section FRONT - 8116/yd Morain Steel Co. Lorain BACK - Bendigo Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BENDIGO" stamped into the foot of the rail. ...Yields information about some of the rail used in Bendigo and demonstrates the type of rail used in tramways and made by the Lorain Steel Co. France.Section of flanged tramway rail - saw cut from rail, smooth finished - Stamped "BENDIGO" stamped into the foot of the rail. On the other side of the rail, "81LBS PERYD", stamped onto the head of the rail. and "LORAIN STEEL CO LORAIN" stamped into the web. FRONT - 8116/yd Morain Steel Co. Lorain BACK - Bendigo trams, tramways, rail, bendigo, rail section -
Ballarat Tramway MuseumFunctional Object - Rail Section, The North Eastern Steel Co. Ltd. Middlesborough, 1900's?
... Rail Section...... Rail Section...Section of flanged tramway rail - saw cut from rail, polished and then nickel plated silver finished and stamped in italics - "Hartepool Tramways Reconstruction B.S.Section No. 1" in the head of the rail, "90lbs per yard" stamped in the base of the flange and along the foot of the rail "The North Eastern Steel Co. ...Ltd Middlesborough" Functional Object Rail Section The North Eastern Steel Co. Ltd. Middlesborough ...Yields information about some of the rail used in UK tramways, possibly Australian tramways and demonstrates the type of rail used in tramways.Section of flanged tramway rail - saw cut from rail, polished and then nickel plated silver finished and stamped in italics - "Hartepool Tramways Reconstruction B.S.Section No. 1" in the head of the rail, "90lbs per yard" stamped in the base of the flange and along the foot of the rail "The North Eastern Steel Co. Ltd Middlesborough"trams, tramways, rail, uk, rail section -
Ballarat Tramway MuseumFunctional Object - Rail Section, 9mm Sawn Cut Rail '102', 1930's?
... Rail Section...... Rail Section...Section of flanged tramway rail - saw cut from rail, finished and stamped "102" along the foot of the rail. ...Shows saw cuts. 9mm Sawn Cut Rail '102' Functional Object Rail Section ...Yields information about rails and demonstrates the type of rail used in tramways.Section of flanged tramway rail - saw cut from rail, finished and stamped "102" along the foot of the rail. Shows saw cuts.102trams, tramways, rail, rail section, btm, ballarat tramways -
Bendigo Military MuseumMemorabilia - RAIL SECTION AND CERTIFICATE, 1) est 1941-43, .2) 1984
... RAIL SECTION AND CERTIFICATE...On the rear in one corner in ink "Slice No 131". Memorabilia RAIL SECTION AND CERTIFICATE Australian Thai Chamber of Commerce ...The items were presented to Alfred Robert Maskell VX25221, 4th Anti Tank Regt in May 1984. Alf worked on the Railway during 1942-43 as a Prisoner of war in horrendous conditions. Refer 2485 for medals and service history also 1076, 2484P..1) A section of the "Thai-Burma Railway Line". A small brass plaque is attached to one edge. .2) Certificate of "Authenticity Thai- Burma Railway memento". Yellow parchment paper with gold surround with blue print. A space for "Presented to and date, signed by". A brief story on the Railway Line. On the rear in one corner in ink "Slice No 131"..1) "Rail slice Thai-Burma Railway 1942-43 Australian Thai Chamber of Commerce"memorabilia, history, railways -
Melbourne Tram MuseumDecorative object - Memento, Melbourne Cable Tramway /1885-1940 / Original Rail:, 1970's?
... ... Rail Section...Memento - comprising a section of Melbourne grooved or flanged cable tram rail sawn and then mounted on a varnished wooden board with a plastic sign mounted in front "Melbourne Cable Tramway /1885-1940 / Original Rail: Not known who made the item....Melbourne Tram Museum 8 Wallen Road Hawthorn melbourne Trams tramways Cable Trams Rail Section Melbourne Memento - comprising a section of Melbourne grooved or flanged cable tram rail sawn and then mounted on a varnished wooden board with a plastic sign mounted in front "Melbourne Cable Tramway /1885-1940 / Original Rail: Not known who made the item. ...Memento - comprising a section of Melbourne grooved or flanged cable tram rail sawn and then mounted on a varnished wooden board with a plastic sign mounted in front "Melbourne Cable Tramway /1885-1940 / Original Rail: Not known who made the item.trams, tramways, cable trams, rail section, melbourne -
Ballarat Tramway MuseumFunctional object - Section of Rail - Bendigo Battery Tram, 1890
... Section of Rail - Bendigo Battery Tram...Section of flanged steel rail, sawn, fitted with two engraved gold colour plastic signs. ...Functional object Section of Rail - Bendigo Battery Tram ...Bendigo first commenced tramway operation in 1890 using battery trams. These were not successful. The rail, approx 36lb/yard or about 38kg/m has been sawn from an original length and collected.Demonstrates a light weight section of tram rail used in Bendigo.Section of flanged steel rail, sawn, fitted with two engraved gold colour plastic signs. Engraved on the signs or plaques - "Bendigo Tramways 1890" and "Original Battery Tram Rail, No. 4"tramways, bendigo, rail, battery trams -
Linton and District Historical Society IncPhotograph, Section of Rail Line, Linton circa 1982, 1982
... Section of Rail Line, Linton circa 1982...This part of the track is stamped "5-82 VR Krupp 1888 V1". Section of Rail Line, Linton circa 1982 Photograph Photograph ...Colour photograph showing lengths of metal track. This part of the track is stamped "5-82 VR Krupp 1888 V1".railway tracks, linton railway -
Ballarat Tramway MuseumAdministrative record - Report, State Electricity Commission of Victoria (SECV), "Legend - Track gauges", 1954/55
... Gives the type of rail, its weight, gauge, location and date of measurement See item 9127 for a report on the Special Work. Some sections...Report - within a manila card folder with steel clips containing about 44 drawings on drawing paper of rail sections....Ballarat SECV trackwork rails reports Outside cover in ink "Legend Track Gauges" Report - within a manila card folder with steel clips containing about 44 drawings on drawing paper of rail sections. "Legend - Track gauges" Administrative record Report State Electricity Commission of Victoria (SECV) ...Record shows the condition of the rail head at many points throughout the Ballarat system. Gives the type of rail, its weight, gauge, location and date of measurement See item 9127 for a report on the Special Work. Some sections measured in May 1954, rest May 1955Demonstrates a detailed report into the condition and wear of the Ballarat Tramways trackwork in 1954/1955.Report - within a manila card folder with steel clips containing about 44 drawings on drawing paper of rail sections.Outside cover in ink "Legend Track Gauges"ballarat, secv, trackwork, rails, reports -
Ballarat Tramway MuseumAdministrative record - Report, State Electricity Commission of Victoria (SECV), "Condition of Ballarat Tramways special work", 30/4/1958
... Report - 8 typed foolscap sheets carbon copy within a manila card folder with steel clips containing about 50 drawings on light card sheet of rail sections....Ballarat SECV trackwork rails special work points reports tramwaysm Outside cover in ink "To accompany reprot to Manager on "Condition of Ballarat Tramways Special Work" dated 30-4-58" Report - 8 typed foolscap sheets carbon copy within a manila card folder with steel clips containing about 50 drawings on light card sheet of rail sections. "Condition of Ballarat Tramways special work" Administrative record Report State Electricity Commission of Victoria (SECV) ...Report details the condition of the special work with associated drawings of the rail head showing wear at many points around the system. Includes the size and type of the rail and the location of the rail sampled, includes curves, special work, junctions and type of equipment, Dated 30-4-1958. See item 9537 for a similar report on rails.Demonstrates a detailed report into the condition and wear of the Ballarat Tramways trackwork in 1958.Report - 8 typed foolscap sheets carbon copy within a manila card folder with steel clips containing about 50 drawings on light card sheet of rail sections.Outside cover in ink "To accompany reprot to Manager on "Condition of Ballarat Tramways Special Work" dated 30-4-58"ballarat, secv, trackwork, rails, special work, points, reports, tramwaysm -
Flagstaff Hill Maritime Museum and VillageFire fender
... Fire fender with tubular metal foot rail-metal section has one knob each end...Flagstaff Hill Maritime Museum and Village 89 Merri Street Warrnambool great-ocean-road flagstaff hill warrnambool shipwrecked-coast flagstaff-hill flagstaff-hill-maritime-museum maritime-museum shipwreck-coast flagstaff-hill-maritime-village Fire fender with tubular metal foot rail-metal section has one knob each end Fire fender ...Fire fender with tubular metal foot rail-metal section has one knob each endflagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village -
Halls Gap & Grampians Historical SocietyPhotograph - Coloured, C 1960s (?)
... Stone was transported out of quarry by rail. Some sections of track are still visible at the Quarry....Halls Gap & Grampians Historical Society Centennial Hall 117-119 Grampians Road Halls Gap grampians Stone was transported out of quarry by rail. Some sections of track are still visible at the Quarry. ...Stone was transported out of quarry by rail. Some sections of track are still visible at the Quarry.structures, train tracks, quarrying, mt difficult quarry -
Ballarat Tramway MuseumEquipment - Tram Track Materials, Pandrol Australia, Sydney
... Group of rail fittings used during 2019 track relay by Fulton Hogan between Carlton St and Depot Junction. .1 - Section of tram rail - Ri57A - cut from an 18m long rail section. ...Tramways Ballarat BTM trackwork tramway rails Pandrol Voestalpine Group of rail fittings used during 2019 track relay by Fulton Hogan between Carlton St and Depot Junction. .1 - Section of tram rail - Ri57A - cut from an 18m long rail section. ...Tramway Track materials used to reconstruct or replace Ballarat Tramway Museum track between Carlton St and Depot Junction Sept 2019. Follows the current practice in Melbourne.Demonstrates the materials used to replace BTM Tramway Track during 2019. Same materials used during the reconstruction of 2022.Group of rail fittings used during 2019 track relay by Fulton Hogan between Carlton St and Depot Junction. .1 - Section of tram rail - Ri57A - cut from an 18m long rail section. Rolled by voestalpine Railway Systems, Austria .2 - Group of three different sized Pandrol Rail insulators used between the rail and the clip. .3 - Pandrol resilient pad used between the concrete sleeper and the rail .4 - Pandrol clip used to secure the rail to the sleeper.tramways, ballarat, btm, trackwork, tramway rails, pandrol, voestalpine -
Melbourne Tram MuseumFunctional object - Section of 1906 rail - Essendon Tram Depot, Carnegie Steel Co, 1906
... Section of 1906 rail - Essendon Tram Depot...Rail used by The North Melbourne and Essendon Tramways and Lighting Co. at their Essendon Depot. Based on item 2566, originally rolled by Carnegie Steel in Pittsburg. The reference link provides the history of the company. Section...Section of rail recovered from Essendon Tram depot relay with "1906" welded to one side. ...Has a hole on the underside cut using an oxy-acetylene torch for a bolt possibly to secure the rail. Has been sawn from a salvaged section of rail. See item 2566 for a photograph of a section of rail at Essendon depot with the date and manufacturer's name rolled onto it. ...Rail used by The North Melbourne and Essendon Tramways and Lighting Co. at their Essendon Depot. Based on item 2566, originally rolled by Carnegie Steel in Pittsburg. The reference link provides the history of the company. Section taken from No. 13 road July 2005. Has rolling date welded onto one side, with location and date written in yellow paint on the foot of the rail.Yields information about the type of rail used in 1906 at Essendon Tram depot.Section of rail recovered from Essendon Tram depot relay with "1906" welded to one side. Has a hole on the underside cut using an oxy-acetylene torch for a bolt possibly to secure the rail. Has been sawn from a salvaged section of rail. See item 2566 for a photograph of a section of rail at Essendon depot with the date and manufacturer's name rolled onto it. tramways, rail, essendon tram depot, carnegie steel, nmetl -
Stawell Historical Society IncPhotograph, Jubilee Open Cut Wonga Company Cyanide Gold Recovery 1899
... Open Cut with sections of rail track bottom left. Ore cart at right of photo. ...Stawell Historical Society Inc 46 Longfield St Stawell grampians B/W photo Jubilee Open Cut Wonga Company Cyanide Gold Recovery 1899 Stawell Mining Open Cut with sections of rail track bottom left. Ore cart at right of photo. ...B/W photo Jubilee Open Cut Wonga Company Cyanide Gold Recovery 1899Open Cut with sections of rail track bottom left. Ore cart at right of photo. stawell mining -
Ballarat Tramway MuseumMemorabilia - Display panel, The North Eastern Steel Co. Ltd. Middlesborough, Standard Section of Tramway Rails
... Plywood sheet, covered in black cloth displaying 11 different British Standard Rail Sections made by The North Eastern Steel Co. ...Plywood sheet, covered in black cloth displaying 11 different British Standard Rail Sections made by The North Eastern Steel Co. ...Flanged Tramway Rails - sections from The North Eastern Steel Co. Ltd. Middlesborough - see https://www.gracesguide.co.uk/North_Eastern_Steel_Co 1 - Walthamstow & District Light Railways BS Section No. 3C - 106 lbs. per yard 1904 - Dick Kerr & Co. Contractors London. See https://en.wikipedia.org/wiki/Tottenham_Outrage 2 - Bath & District Tramways 95 lbs per yard 1903 - George Hopkins & Sons Engineers London 3 - Burton on Trent Tramways 90 lbs per yard 1903 - Messrs Kincaid, Waller & Manville, Consulting Engineers 4 - Swindon Corporation Tramways BS Section No. 4 C, 111 lbs per yard, 1904 - Messrs J G White & Co. Ltd, Contractors London 5 - Wigan Corporation Tramways BS Section No. 5, 100 lbs per yard, 1903 - Messrs J G White & Co. Ltd, Contractors London 6 - Derby Corporation Tramways BS Section No. 6, 107 lbs per yard, 1904 - Messrs J G White & Co. Ltd, Contractors London 7 - Nottingham Corporation Tramways BS Section No. 1 , 90 lbs per yard, 1903, J. G. White Ltd, London, Contractors. 8 - Swindon Corporation Tramways, BS Section No. 4, 105 lbs per yard - Messrs J G White & Co. Ltd, Contractors London, Messrs Lacy & Sillars Consulting Engineer 9 - Kalgoorlie Electric Tramways BS Section ? 96 lbs per yard. 1904 - Messrs J G White & Co. Ltd, Contractors London 10 - Leicester Corporation Tramways & Track? 100 lbs per yard 1903, I George Maybey? MICE Engineer 11 - Ipswich Tramways 90 lbs per yard, 1902, Dick Kerr & Co. Contractors London Shows the type of tramway rail and cross section produced by The North Eastern Steel Co early 1900's, the relationship to the British Standard and who used them. Provenance of the item not fully known. Possibly given to the Electric Supply Co of Victoria at the time when they would have been ordering rails for use in Ballarat. May have been collected by other parties.Plywood sheet, covered in black cloth displaying 11 different British Standard Rail Sections made by The North Eastern Steel Co. Ltd. Middlesborough , early 1900's. Each section secured with two 20mm (¾”) long, 3mm dia (1/8”) machine screws, countersunk with a slotted head from the rear. All nickel plated on both sides, engraved as to the tramway used on, date of production on the head of the rail, Designing Engineers on the web and the manufacturer on the foot of the rail. Cloth secured with staples and drawing pins on the rear. On the rear is a chalked sign, the principal one being "No Thoroughfare"Engraved as listed.tramway rails, rails, tramways, north eastern steel co, middlesborough, walthamstow, bath, burton on trent, swindon, wigan, derby, nottingham, kalgoorlie, leichester, ipswich, j g white & co, dick kerr -
Ballarat Tramway MuseumDocument - Letter/s, "Mr Jerusalem Smith", Nov. 2008
... Letter concerning "Mr Jerusalem Smith" forwarding drawings of rail Sections that could be used in horse tramways. ...Ballarat Tramway Museum South Gardens Reserve Wendouree Parade Ballarat Ballarat goldfields Trams tramways Trackwork Horse Trams City Of Ballarat Letter concerning "Mr Jerusalem Smith" forwarding drawings of rail Sections that could be used in horse tramways. ...Letter concerning "Mr Jerusalem Smith" forwarding drawings of rail Sections that could be used in horse tramways. The cross-section of the rail in the drawings have been water coloured with a blue and yellow wash. .1 - Covering Letter from Ian Armstrong of the Armstrong Collection .2 - Image of the cover of the book at Post-it note that came with the item .3 - Drawing of Gjedsted Rail. .4 - Central Webbed Rail .5 - Davies Foot Rail with fishplates shown. .6 - Davies Foot Rail with a wheel shown in the drawing. See also Reg item 4248 and 9646 for further correspondence on this matter.trams, tramways, trackwork, horse trams, city of ballarat -
Ballarat Tramway MuseumBook, The Electric Railway Improvement Co. (ERICO), "Notes on Bonding and Return Circuits", c1916
... Gives costs of welding, bonding, rail resistance, voltage drops, testing methods, electrolysis, rail expansion, rail section, sleeper track, treatment of ties (sleepers), and the monthly average price of copper from period 1885 to Dec. 1915, the power required for electric traction and a list of clients. ...Gives costs of welding, bonding, rail resistance, voltage drops, testing methods, electrolysis, rail expansion, rail section, sleeper track, treatment of ties (sleepers), and the monthly average price of copper from period 1885 to Dec. 1915, the power required for electric traction and a list of clients. ...Book, titled, "Notes on Bonding and Return Circuits" consisting of 20 pages, printed in black ink. Prepared by The Electric Railway Improvement Co. of Cleveland, Ohio, USA. Gives costs of welding, bonding, rail resistance, voltage drops, testing methods, electrolysis, rail expansion, rail section, sleeper track, treatment of ties (sleepers), and the monthly average price of copper from period 1885 to Dec. 1915, the power required for electric traction and a list of clients. Date of printing not given in document, estimated to be c1916. See also item Reg. No. 1638 for a book on equipment for welding and bonding.trams, tramways, trackwork, rail bonding, erico, welding -
Ballarat Tramway MuseumBook, Broken Hill Pty Co Ltd (BHP), "BHP - Hot rolled carbon steel sections and plates", 1967
... Was supplied free by BHP to students. Rail sections listed: 387 pound/yard crane rail 175 lb crane rail 146 lb crane rail 107 lb - 53 kg/m with fishplate and sleeper plates details 102 lb or 51 kg grooved tram rail 94 lb or 47 kg - fishplates and sleeper plates 91 lb or 45 kg NZR standard rail 82 lb or 41 kg - fishplates and sleeper plates 75 lb or 37 kg - fishplates and sleeper plates 63 lb or 30 kg - fishplates 45 lb or 22 kg - fishplates 30 lb or 15kg - fishplates 20 lb or 10kg - fishplates ...Was supplied free by BHP to students. Rail sections listed: 387 pound/yard crane rail 175 lb crane rail 146 lb crane rail 107 lb - 53 kg/m with fishplate and sleeper plates details 102 lb or 51 kg grooved tram rail 94 lb or 47 kg - fishplates and sleeper plates 91 lb or 45 kg NZR standard rail 82 lb or 41 kg - fishplates and sleeper plates 75 lb or 37 kg - fishplates and sleeper plates 63 lb or 30 kg - fishplates 45 lb or 22 kg - fishplates 30 lb or 15kg - fishplates 20 lb or 10kg - fishplates Yields information about rails and associated items produced by BHP AIS in 1967 along with other steel sections and plates. railways tramways rails BHP fishplates sleeper plates Book - 132 pages, white comb bound + blue plastic covers. ...Published by BHP 1967 gives the dimensions and properties of rails, steel sections and plates produced by Australian Iron and Steel and Broken Hill Pty Ltd. Was supplied free by BHP to students. Rail sections listed: 387 pound/yard crane rail 175 lb crane rail 146 lb crane rail 107 lb - 53 kg/m with fishplate and sleeper plates details 102 lb or 51 kg grooved tram rail 94 lb or 47 kg - fishplates and sleeper plates 91 lb or 45 kg NZR standard rail 82 lb or 41 kg - fishplates and sleeper plates 75 lb or 37 kg - fishplates and sleeper plates 63 lb or 30 kg - fishplates 45 lb or 22 kg - fishplates 30 lb or 15kg - fishplates 20 lb or 10kg - fishplates Yields information about rails and associated items produced by BHP AIS in 1967 along with other steel sections and plates.Book - 132 pages, white comb bound + blue plastic covers.railways, tramways, rails, bhp, fishplates, sleeper plates -
Ballarat Tramway MuseumFunctional Object - Length of Rail, Horse tram, 1880's
... See page 3 of item 4248 for a similar section of rail drawn in the letter....See page 3 of item 4248 for a similar section of rail drawn in the letter. Demonstrates a section of horse tram rail that was possibly attached to stringers. ...Section of horse tram rail reportedly used in Ballarat. See page 3 of item 4248 for a similar section of rail drawn in the letter.Demonstrates a section of horse tram rail that was possibly attached to stringers.Length of horse tram rail, reportedly used in Ballarat. Has been oxy cut.trams, tramways, horse trams, rails -
Phillip Island and District Historical Society Inc.Photograph, Anderson Family Homestead, 1960
... Side aspect of Glen Isla from street, wooden rail fence, double story section of building on right. To left single story building....Phillip Island and District Historical Society Inc. phillip-island-and-the-bass-coast Side aspect of Glen Isla from street, wooden rail fence, double story section of building on right. To left single story building. local history photography photographs slides film buildings historic glen isla homestead phillip island coloured photograph mrs emma anderson jacobs Side view of Glen Isla Homestead Anderson Family Homestead Photograph ...Side aspect of Glen Isla from street, wooden rail fence, double story section of building on right. To left single story building.Side view of Glen Isla Homesteadlocal history, photography, photographs, slides, film, buildings, historic, glen isla homestead, phillip island, coloured photograph, mrs emma anderson jacobs -
Glenelg Shire Council Cultural Collection
Photograph - Photograph - Main Breakwater construction, Portland, 31/05/1957
... Post & rail fencing across section. Car on road in foreground....Post & rail fencing across section. Car on road in foreground. ...Port of Portland Authority ArchivesBack: 31.5.57port of portland archives, main breakwater construction, harbour development -
Ballarat Tramway MuseumDocument - Report and drawing, State Electricity Commission of Victoria (SECV), "Ballarat Tramways - Tracks", October 1962
... Refers to a drawing with 7 rail cross sections, titled "Ballarat Tramways typical prfiels of tram rails" - see image 2, for VB4/40. ...Refers to a drawing with 7 rail cross sections, titled "Ballarat Tramways typical prfiels of tram rails" - see image 2, for VB4/40. ...Document or report dated October 1962, outlining the history of the Ballarat Tramways tram tracks, rail replacement, extensions, type of construction, present condition, eg Sebastopol, notes on photos which are not included within the report, including point castings and crossings, issues and recommending that the track is rehabilitated. Refers to a drawing with 7 rail cross sections, titled "Ballarat Tramways typical prfiels of tram rails" - see image 2, for VB4/40. See item 9936 for a similar drawing for Bendigo Tramways.Yields information about the condition of the Ballarat Tramways track in Oct. 1962Document - memo - typed carbon copy on 3 foolscap sheets and dyeline printed drawing.tramways, trackwork, ballarat, reports, track materials, stringer tram tracks, tram track construction, drawings, rails, profiles -
Melbourne Tram MuseumDocument - Report, East Doncaster Progress Association, "East Doncaster Progress Association - Public Transport Survey - Report", mid 1960's
... Includes comparisons between MMTB bus services and possible rail services. Section 2 - copy of questions on questionnaire, includes many comments....Includes comparisons between MMTB bus services and possible rail services. Section 2 - copy of questions on questionnaire, includes many comments. ...Report contained within a light brown card folder, containing many loose sheets, titled "East Doncaster Progress Association - Public Transport Survey - Report". About 50 pages, printed with a spirit duplicator. Not dated, possibly mid to late 1960's. Report stapled centrally along top edge., secured by a piece of adhesive tape. Includes comparisons between MMTB bus services and possible rail services. Section 2 - copy of questions on questionnaire, includes many comments.AETA stamp on front and inside sheet and "4E8" in ink on front cover.trams, tramways, doncaster, railways, mmtb, aeta -
Ballarat Tramway MuseumLetter - Woods Gilbert Rail Planing Machine, Woods Gilbert, 1917
... Set of documents Edgar Allen & Co of Sheffield promoting and providing information about the Woods Gilbet Rail Planing machine. 1 - letter dated June 1917, sent from the South Australian Hotel in Adelaide to Mr Pringle, of ESCo from the travelling representative of the company, a letter on Edgar Allen & Co letterhead with a list of various articles on the machine, and a letter from Woods Gilbert of their Melbourne office, dated Jan. 1917 2 - A 30 page printed booklet contained within a green cover titled "Rail Planing Machines" with Mr Pringle's name written on it in the top right-hand corner. 3 - Photograph of the rail planing machine with "1916 type rail grinding machine" on rear in pencil along with the Company stamp. 4 - Drawing of the Milling Trolley prepared by Atlas Co of Engineers Melbourne 5 - drawing - Cardiff-rail-section Woods-Gilbert 6 - photograph - Woods-Gilbert Recording instrument on a postcard by Kodak Magazine extracts: 7 - Woods-Gilbert Tramway and Railway World-12 Oct 1916 - page 1 of 2 8 - Woods-Gilbert Tramway and Railway World 12 Oct 1916 - page 2 of 2 9 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 10 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 11 - Woods-Gilbert Tramway and Railway World - 12 Apr 1917 page 1 of 2 12 - WoodsGilbert Tramway and Railway World - 12 Apr 1917 page 2 of 2...Ballarat Tramway Museum South Gardens Reserve Wendouree Parade Ballarat Ballarat goldfields Set of documents Edgar Allen & Co of Sheffield promoting and providing information about the Woods Gilbet Rail Planing machine. 1 - letter dated June 1917, sent from the South Australian Hotel in Adelaide to Mr Pringle, of ESCo from the travelling representative of the company, a letter on Edgar Allen & Co letterhead with a list of various articles on the machine, and a letter from Woods Gilbert of their Melbourne office, dated Jan. 1917 2 - A 30 page printed booklet contained within a green cover titled "Rail Planing Machines" with Mr Pringle's name written on it in the top right-hand corner. 3 - Photograph of the rail planing machine with "1916 type rail grinding machine" on rear in pencil along with the Company stamp. 4 - Drawing of the Milling Trolley prepared by Atlas Co of Engineers Melbourne 5 - drawing - Cardiff-rail-section Woods-Gilbert 6 - photograph - Woods-Gilbert Recording instrument on a postcard by Kodak Magazine extracts: 7 - Woods-Gilbert Tramway and Railway World-12 Oct 1916 - page 1 of 2 8 - Woods-Gilbert Tramway and Railway World 12 Oct 1916 - page 2 of 2 9 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 10 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 11 - Woods-Gilbert Tramway and Railway World - 12 Apr 1917 page 1 of 2 12 - WoodsGilbert Tramway and Railway World - 12 Apr 1917 page 2 of 2 Yields information about the Woods Gilbert Rail planing machines for repair of rails and removal of corrugations. tramways trams ESCo rail planing woods - Gilbert track rails tramway rails Maintenance Equipment Set of 12 documents with letters, pamphlet, photo, drawing and magazine cuttings. ...Set of documents Edgar Allen & Co of Sheffield promoting and providing information about the Woods Gilbet Rail Planing machine. 1 - letter dated June 1917, sent from the South Australian Hotel in Adelaide to Mr Pringle, of ESCo from the travelling representative of the company, a letter on Edgar Allen & Co letterhead with a list of various articles on the machine, and a letter from Woods Gilbert of their Melbourne office, dated Jan. 1917 2 - A 30 page printed booklet contained within a green cover titled "Rail Planing Machines" with Mr Pringle's name written on it in the top right-hand corner. 3 - Photograph of the rail planing machine with "1916 type rail grinding machine" on rear in pencil along with the Company stamp. 4 - Drawing of the Milling Trolley prepared by Atlas Co of Engineers Melbourne 5 - drawing - Cardiff-rail-section Woods-Gilbert 6 - photograph - Woods-Gilbert Recording instrument on a postcard by Kodak Magazine extracts: 7 - Woods-Gilbert Tramway and Railway World-12 Oct 1916 - page 1 of 2 8 - Woods-Gilbert Tramway and Railway World 12 Oct 1916 - page 2 of 2 9 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 10 - Woods-Gilbert Tramway and Railway World Nov 1916 - page 1 of 2 11 - Woods-Gilbert Tramway and Railway World - 12 Apr 1917 page 1 of 2 12 - WoodsGilbert Tramway and Railway World - 12 Apr 1917 page 2 of 2Yields information about the Woods Gilbert Rail planing machines for repair of rails and removal of corrugations.Set of 12 documents with letters, pamphlet, photo, drawing and magazine cuttings.tramways, trams, esco, rail planing, woods - gilbert, track, rails, tramway rails, maintenance equipment -
Melbourne Tram MuseumPhotograph - Set of 12 Black & White Photograph/s, Melbourne & Metropolitan Tramways Board (MMTB), 1966
... Series of 12 black and white photographs of the trackwork on the MMTB system. .1 - demolished track at a junction .2 - section of rail showing the flangeway missing .3 - junction plates between different weight railway . .4 - wood blocked track showing broken joint and failure .5 - ditto .6 - V crossing ,7 - ditto at a wooden sleepered crossing with puppy dog spikes. .8 - crossing possibly between tram and rail .9 - H crossing rail showing broken joints and wear .10 - ditto .11 - section of rail pumping - waterlogged .12 - damaged joint, pumping, broken joint plate....Melbourne Tram Museum 8 Wallen Road Hawthorn melbourne Trams tramways Trackwork Rails Points Crossover Track Materials Track Repairs Series of 12 black and white photographs of the trackwork on the MMTB system. .1 - demolished track at a junction .2 - section of rail showing the flangeway missing .3 - junction plates between different weight railway . .4 - wood blocked track showing broken joint and failure .5 - ditto .6 - V crossing ,7 - ditto at a wooden sleepered crossing with puppy dog spikes. .8 - crossing possibly between tram and rail .9 - H crossing rail showing broken joints and wear .10 - ditto .11 - section of rail pumping - waterlogged .12 - damaged joint, pumping, broken joint plate. ...Series of 12 black and white photographs of the trackwork on the MMTB system. .1 - demolished track at a junction .2 - section of rail showing the flangeway missing .3 - junction plates between different weight railway . .4 - wood blocked track showing broken joint and failure .5 - ditto .6 - V crossing ,7 - ditto at a wooden sleepered crossing with puppy dog spikes. .8 - crossing possibly between tram and rail .9 - H crossing rail showing broken joints and wear .10 - ditto .11 - section of rail pumping - waterlogged .12 - damaged joint, pumping, broken joint plate.trams, tramways, trackwork, rails, points, crossover, track materials, track repairs -
Ballarat Tramway MuseumDocument - Engineering Standards, The Engineering Standards Committee, "British Standard - Tramway Rails and Fish Plates - Standard Sections and Specification - July 1903", 6/05/2006 12:00:00 AM
... Book - 10 pages + 13 drawings sheets of rail cross sections contained within separate printed covers (colour fleck), titled "British Standard - Tramway Rails and Fish Plates - Standard Sections and Specification - July 1903". ...Book - 10 pages + 13 drawings sheets of rail cross sections contained within separate printed covers (colour fleck), titled "British Standard - Tramway Rails and Fish Plates - Standard Sections and Specification - July 1903". ...Book - 10 pages + 13 drawings sheets of rail cross sections contained within separate printed covers (colour fleck), titled "British Standard - Tramway Rails and Fish Plates - Standard Sections and Specification - July 1903". Side stapled and then bound with a green tape on left hand side. Gives details of the standards of the materials, rolling, payment, conformity, testing, marking holes for both rails and fishplates. Drawings for 13 different weight rails, straight and curves, 90lb/yard to 116 and a drawing of the BS tyre profile for tram car wheels and how it interfaces with a rail. On rear cover, both sides gives a list of standards and foreign translations up to March 1919.On top of first sheet in black ink "Ballarat Tramway Preservation Society Catalogue No 8."trams, tramways, british standards, standards, rails, fishplates
