Black and white print of PCC Class Tram 1041 & cable tram set 1 at Preston Workshops Dec 1974 See also items 1036 and 72 for other photographs of this event.Demonstrates the prototype all electric tramcar alongside the first cable tram set of 1885Black and White photograph - printed on plain paper with photographers stamp on rear.Has stamp of David Menzies on rear.tramways, trams, tram 1041, cable trams, prototype tramcar, mmtb, preston workshops, tram 1, pcc class

Black and white print of PCC Class Tram 1041 at Malvern Depot with the front door open showing the entry. Has the destination of Special. Demonstrates the prototype all electric tramcar at Malvern Depot.Black and White photograph - printed on plain paper with photographers stamp on rear.Has stamp of David Menzies on rear. and in ink "1041 Malvern Depot"tramways, trams, tram 1041, prototype tramcar, malvern depot, pcc class, mmtb

Black and white print of PCC class tram 1041 running a Special in Dandenong Road on part of the former Caulfield loop. This track was removed during Feb. 1983. In the rear on the railway embankment can be seen a string of wagons, probably an empty Briquette train to the Latrobe Valley.Yields information about the use of tram 1041 and the Caulfield Loop.Black and White photograph - printed on plain paper with photographers stamp and notes on rear.Has stamp of David Menzies on rear. and in ink "1041 Caulfield Loop"tramways, trams, tram 1041, caulfield, dandenong road, mmtb, pcc class, tours

Provides publicity photographs of the prototype PCC tram 1041, that lead to the construction of the Z class trams.Yields information about prototype tram 1041Set of four colour prints and one black and white print of prototype tram 1041 on Riversdale Road, with Wattle Park in the background, second half of 1973, during commissioning and testing phase. .1 - tram showing special and route 000 - has been printed so that the background above the tram has been partly faded. Both printed on Kodak Paper. .2 - tram showing W. Park - Elgar Rod, route 070 - two copies .3 - similar to .2, at different location with park in background. Printed on Kodak paper. .4 - same as .1 - Has PTC copyright stamp on rear and number 3953 - better colour. .5 - black and white print - with PTC stamp and number 3953.tramways, trams, mmtb, prototype tramcar, tram 1041, riversdale road, wattle park

Magazine cutting from the May 1974 issue of a Building in Plastics News, full title not shown, with a photo or tram 1041, noting that it has been extensively constructed in FRP (Fibre reinforced Plastic or fibre glass) supplied by General Plastics Pty ltd from a custom formulated resin. Two copies held. See Reg Item No. 3660 for actual image.trams, tramways, 1041, tramcar bodies, tramcar construction, tram 1041

The photograph shows PCC Class tram No. 1041 when newly built in St Georges Road Thornbury on a test trip early in 1973. Has the destination of Special. The tram is in its original colour scheme. The tram was built in 1973 - see reference for the tram's story. In the background is a Shell service station.Yields information about tram 1041 when new in 1973.Colour print with photographers stamp on the rear.Has the stamp of A E Twentyman Collection on the rear.trams, tramways, pcc class, tram 1041, st georges road, thornbury, mmtb

Quarto duplicated sheet titled "Tram No. 1041", giving instructions on opening door, fault finding, circuit breakers, motor cut outs, and what to do.trams, tramways, training, faults, doors, 1041, tram 1041

Set of 11 colour slides of PCC car 1041 taken during its early operations around Melbourne. Where the slide has a printed date, it is listed. 1 - Collins St, between Elizabeth St and Swanston St, route 47, Depot - Sept. 1973 2 - Batman Ave in Swanston St, route 15, with W2 383 alongside - Sept. 1973 3 - Elizabeth St terminus with Flinders St station in the background - route 19, North Coburg - Sept. 1973 4 - Arriving Batman Ave terminus, route 70, - Sept. 1973 5 - ditto 6 - Bourke St Mall, route 96 East Brunswick - during a trial closure of Bourke St between Elizabeth Street and Swanston Street , given the seats outside Buckley's store - Nov. 1973 7 - Night photo - TMSV slide - MP166 8 - turning from Glenferrie Road into High St - route 6 Glen Iris - a very tight turn - TMSV slide 9 - Wattle Park terminus, route 70 - 1974 10 - Flinders St -route 74 near William St with the railway viaduct in the background. 1974 11 - Interior photo - Ron Scholten - 1973Yields information about PCC car 1041, a prototype all electric tramcarSet of 11 Kodachrome colour slides, cardboard mounts.tramways, pcc class, tram 1041, collins st, elizabeth st, batman ave, st kilda rd., glenferrie road, wattle park, flinders st, interior, bourke st, route 19, route 70, route 74, route 15, route 47, w2 class, tram 383, route 6, route 96, trams

Photograph of track on Spring St in front of Parliament House with an enlarged photograph of a tram model resembling PCC 1041 (but not bearing its number) positioned and glued onto photograph to simulate its future operation. The model displays the destination "route 88 East Preston".Yields information about planning and publicity for introduction of PCC 1041 and Z class tramcars. Black and white photograph with no note on rearpcc, 1041, tram model, simulation, future opertion, parliament house, route 88, east preston

Photograph of track on St Kilda Rd near Shrine of Remembrance with an enlarged photograph of a tram model resembling PCC 1041 (but not bearing its number) positioned and glued onto photograph to simulate its future operation. The model displays the inaccurate destination "route 15 City". (The correct destinations at that time were "15 Moreland" or "16 City".)Yields information about planning and publicity for introduction of PCC 1041 and Z class tramcars. Black and white photograph with no note on rearpcc, 1041, tram model, simulation, future opertion, route 15, city, moreland, shrine, st kilda rd

Black and white print of prototype tram 1041 at Preston Workshops - mounted onto a heavy white cardboard sheet, prior to the painting of the dark brown section on the lower side of the tram c1973.trams, tramways, mmtb, prototype tramcar, 1041, preston workshops, tram 1041

Carinya postcard looking east from Queen St with PCC class tram 1041 westbound to Spencer St. Has the McEwans building in the view along with a multistory car park.Yields information Bourke St and the use of PCC class tram 1041, the forerunner of the Z class tram.Postcard - by Carinya Postcards with rounded corners, address block, Number LV028trams, tramways, bourke street, pcc class, tram 1041, mcewans

Card features PCC Class tram 1041 in Bourke St at a tram stop on route 96 to East Brunswick. The tram entered service during August 1973, so presumed this card was printed in 1973. The tram is on display at the Museum at Hawthorn depot.Demonstrates a MMTB Christmas Card issued with a photo of prototype tram 1041.Card printed - 8 pages glued - colour photograph and gold front with MMTB logo. Two copies held.tramways, mmtb, tram 1041, pcc class, christmas, greeting cards, bourke st, route 96

Series of 2 black and white photographs of the finishing off and testing of tram 1041. .1 - Internal view with conductors desk and workmen possibly installing the glazing sections or cleaning the tram. .2 - weights laid out on the floor to simulate a full passenger load for braking tests.trams, tramways, 1041, prototype tramcar, new tramcars, tramcar bodies, preston workshops, testing, interiors, tram 1041

Newspaper Clipping - from The Sun 27/8/1973 titled "New Tram takes the rails" about the launch of the prototype tram 1041 the previous day. Notes the launch with the Premier Mr. Hamer, the Transport Minister Mr Wilcox and quotes drive John Newland. Has a photograph of the tram showing Special.trams, tramways, prototype tramcar, launch, preston workshops, tram 1041, pcc class, plenty road, east preston

Black and white photograph of tram 1041 is in 1973 after the brown skirt paint was applied but before the extra lower windows were installed in the front doors. Location - traveling east in Swan Street outside the Olympic Swimming pool. Image used in Reg Item 2984. 2nd copy added 26/8/2020Has on the rear "MMTB stamp on rear. 2nd copy has PTC copyright stamp on rear and MMTB stamp.trams, tramways, 1041, new trams, prototype tramcar, tram 1041

Photograph of the reserved track in Queens Way, St Kilda with an enlarged photograph of a tram model resembling PCC 1041 (but not bearing its number) positioned and glued onto photo to simulate its future operation. The model displays "route 64 E Brighton".Yields information about planning and publicity for introduction of PCC 1041 and Z class tramcars. Black and white photograph with brief note on rear"2 B/6 3 Tram Prints"pcc, 1041, queens way, tram model, simulation, route 64, e brighton, future operation

Colour photograph from a 1979 John Sands published calendar, titled "Australia in Colour" of tram 1041 running a Toorak, route 8 service with the Shrink of Remembrance in the background. Photo taken summer 1973/74, possibly a publicity photo as the tram has yet to be repainted with the brown band along the bottom of the body, but the trolley retriever has been repositioned so the rope was out of the direct view of the driver.trams, tramways, colour schemes, livery, 1041, shrine of remembrance, st kilda rd, tram 1041

Colour photograph of tram 1041 crossing under the railway at Royal Park, with a Hitachi silver train passing overhead, front car appears to be 8M. Photograph Official VR / MMTB, c1973, when both vehicles relatively new. Train has destination of Gowrie and 1041, route 55, West Coburg. .1 - 3/4 view of tram with just one carriage of the train in the view. .2 - ditto, but with the whole train in the view.trams, tramways, mmtb, vr, hitachi silver train, 1041, tram 1041

Set of two personal papers hand written on approx. A5 sheets, ,1 - "Principle Dimensions of Tram Body Work" - lists various dimension including ceiling clearance height, door sizes, step for Z class trams, 1041 and the W7. .2 - "ASEA Truck" - 8 sheets stapled in the top left hand corner, describing the various dimensions, systems, mass, braking, motor, gear boxes, wheels, suspension systems, motor alternators, trolley pole head, foot controllers and the ASEA Tramiac unit.trams, tramways, z class, new trams, w7 class, 1041, prototype tramcar, bogies, trucks, asea, brakes, tram 1, tram 1041

Newspaper clipping titled: “The things that happen to Hamer” – Herald 19/4/73 Photo and text, tram # 1041 breakdown, pushed by tram # 1035, VIP test ride on prototype $120,000 tram Transport Minister Wilcox stunned and Premier Hamer not amused. Standing on corner of Gertrude and Nicholson Sts Fitzroy at 9.57, surrounded by 30 reporters, waiting for first VIP test ride on new prototype tram. Tramways officer tells Mr Kirby that tram has broken down in Smith St, “bloody electronics have blown up”. Tram arrived at rendezvous point at 10:12, but VIPs had gone. Number 1041 shunted at Nicholson St and headed back to Preston workshops.trams, tramways, prototype tramcar, testing, gertrude st, nicholson st, spring st, preston workshops, tram 1041, tram 1035

Containing full colour photographs of Adelaide, Melbourne, Ballarat, Melbourne, Fremantle, Sydney, Brisbane, Perth, Geelong, Launceston and Dunedin. Provides dates for holidays, school holidays and phases of the moon. Produced by Topmill Pty Ltd and distributed by Gordon & Gotch Pty Ltd. Has photos of Melbourne trams SW5 810, PCC 1041, Melbourne tram strike in Swanston St and W2 223. Photos by Arthur Perry, Les Horsburgh, Ken Smith, Warren Doubleday and Barrie Hitchens. Demonstrates production of calendars featuring tram photographs, containing many historic photographs of closed tramway systems.Wall Calendar - heavy card covers, 16 gloss art pages inside, titled "Trams - 2004" with a punched hole along the top edge to enable wall use.Has a $9.95 price label.tramways, trams, melbourne, adelaide, perth, fremantle, ballarat, geelong, launceston, brisbane, tram 810, tram 1041, tram 223

Report - three foolscap sheets, titled "1041 Prototype Tram" outlining the basis of the construction of the prototype tram. Gives information on the trucks, control equipment, body frame, interior, doors and windows, heating and ventilation, lighting, destination equipment and other equipment. Notes the construction of the new trams by Commonwealth Engineering and the basis for the design from those of Gothenburg Sweden. Dated 21/3/1974trams, tramways, mmtb, prototype tramcar, 1041, new tramcars

Series of 10 black and white photographs of the construction of the prototype or mock-up model of the prototype for tram 1041 at Preston Workshops c1971. See Reg Item 2502 and 7370 for other photos. .1 - external view shows the centre door and the mock-up construction. .2 - external view showing small entry door - at the back of the tram? .3 - Front entry door. .4 - internal view showing conductors desk and seats .5 - internal view showing conductors desk, ticket machine and microphone. .6 - another view looking along the tram length. .7 - same photo. .8 - Drivers seat showing the mock-up pedals and drivers console. .9 - ditto - different view. .10 - close up of the drivers pedals mock-up box. The photos could have been taken at different stages of the design process and after layout changes had been made.Item 6 has MMTB stamp and "P25/1/1016""trams, tramways, prototype tramcar, tramcar bodies, preston workshops, 1041 mock-up, interiors, tram 1041, pcc class, gibson ticket machines

Set of seven black and white prints of prototype tram 1041, during its first days of commissioning and testing in the city and on the Wattle Park route. All printed on Kodak paper. .1 - at Preston workshops, showing City, route 088 .2 - ditto .3 - ditto - 2nd copy added from donation of Geoff Warburton added 10/10/17. .4 - In Riversdale Road, Wattle Park, showing W. Park Elgar Rd, route 070. .5 - ditto, but showing special and route 000 - trees behind the tram had been faded out. .6 - turning out of Bourke St into Spring St with destination of E. Brunswick, route 96. Has been painted with words "Welcome Board" and "Enter here" on front door. Has the Windsor hotel in the background. Second trolley retriever fitted as well. .7 as for .5 but at a different location. 2nd copy of .3 added 10/10/17.4 - notes to remove pole, ext and I HT and grating on rear along with a sketch of the tram outline and number 16. .6 - on rear "9 3/4 x 6 1/8" .7 on front of the photo "9 3/4" x 6 1/4" in felt pen. .3 - second copy "1041-Preston-3-MMTB" in pencil on rear.trams, tramways, mmtb, prototype tramcar, 1041, riversdale rd, wattle park, preston workshops, tram 1041

Single page foolscap document photocopied titled "New Trams for Melbourne". Gives details of the Z class trams, equipment, safety features, dimensions and details of builder and suppliers, along with a comparison table between W7 class trams, Prototype 1041 and the Z class See also Reg Item for the 2254 for a draft document headed "New Trams for Melbourne" See Reg Item 86 for the newspaper item for the launch of the tram on 30/4/1975 .1 Electric Traction - May 1973 - with a cover photo of 1041 and an article detailing the tram written by John Prideaux, photos by Len Millar. Published by the AETA.trams, tramways, z class, launch, press release, new trams, w7 class, 1041, prototype tramcar, electric traction, tram 1, tram 1041

Spirit duplicated timetables for tram tours - handwritten Special Table" or timetable for a charter tram tour and an associated booking form. .1 - Booking Form for the CSIRO Div of Mining Chemistry? Social Club's, "3rd Annual Mobile Luncheon Engagement", photocopied onto a foolscap sheet. Printed for Tuesday 4-12-1973. .2 - Spirit duplicated timetable for tram tours - handwritten Special Table" or timetable for a charter tram tour and an associated booking form, printed on pink card, for John Gardner (CSIRO), dated Friday 14/12/73, Tram 104. .2 - ditto, for 4-6-1975 - Drv. Newland, Cond Armstrong, car 1041 - as above.trams, tramways, charters, special trams, tours, tram 1041, tram 104

Slide - set of 15 - 35mm - white plastic mount of the trams currently (2018) housed at the Melbourne Tram Museum. .1 - W7 1040 at Hawthorn .2 - X2 676 at Preston Workshops .3 - W5 774 at Preston Workshops .4 - W1 431 .5 - W 380 .6 - W2 510 at Preston .7 - 1041 - copy of MMTB Official Photo at Wattle Park when formally launched by the MMTB .8 - Y1 613 at Preston Workshops .9 - V214 .10 - L104 - showing route 67, Carnegie .11 - T180 at Hawthorn .12 - S164 at Preston Workshops .13 - HTT 8 .14 - X217 at Hawthorn .15 - Y469 at Preston Workshops Photographed by Mike Ryan c1998trams, tramways, mmtb, w class, w1 class, w2 class, w5 class, 1041, x2 class, v class, x class, s class, t class, y class, tram 1040, tram 676, tram 774, tram 431, tram 510, tram 1041, tram 613, tram 469, tram 8, tram 180, tram 164, tram 217

Wall Calendar - heavy card covers, 12 gloss art pages inside, titled "Trams - 2005" containing full colour photographs of Melbourne, Flinders St Station, Ballarat, Adelaide, Kilmore Horse tramway, Brisbane, Sydney (runaway tram), Melbourne track cleaners, Wellington, Wanganui and Bendigo. Has a punched hole along the top edge to enable wall use. Provides dates for holidays, school holidays and Pension payment days and phases of the moon. Produced by Topmill Pty Ltd and distributed by Gordon & Gotch Pty Ltd. Photos by William Scott, A. W. Perry, Ken Smith, Ben Parle and Graeme Jones.trams, tramways, ballarat, bendigo, melbourne, adelaide, sydney, brisbane, kilmore, wellington, wanganui, tram 470, tram 866, tram w7, tram w6, tram w9, tram 653, tram 1041, tram 61-, tram 374, tram 104, tram 1000, tram 676, tram 103, tram 937, tram 53, tram 676

Photo Album - titled "TAP - Part D - 1041, Z, A and B class trams – sheets D1 to D16 ", from Transit Australia Publishing. Photos used in the Destination City and other publications series. For a detailed list of photographs see htd4603i.pdf. For individual photo images see: \dbtext\hawthtramcoll\photo collections\TAP-Part D, images TAP244 to TAP268. TAP244_4-DecoratedTram_WilliamSt_ChrisMarsh_11Feb1989.jpg TAP245a_67-1022_EastPreston_Nov1982_PTC.jpg TAP245_46_NicholsonSt_IanHammond.jpg TAP246_112_BourkeSt_HughBallment_Jan1993.jpg TAP247_2111_BourkeSt.jpg TAP248_1041_MMTB.jpg TAP249_1_MacarthurSt_MMTB.jpg TAP250_112_KooriHeitage_PTC.jpg TAP251_116_HighSt_MMTB.jpg TAP252_134_BurwoodHwy_IanHammond.jpg TAP253_231_VictoriaPde_c1991_HughWaldron.jpg TAP254_265_StKilda-light-rail_DavidKeenan.jpg TAP255_266_StKilda_light-rail_IanHammond.jpg TAP256_271_PortMelbourne_light-rail_DavidKeenan.jpg TAP257_2001_PrestonWorkshops_DaleBudd.jpg TAP258_2007_BourkeSt_AndrewFoy_3Jan1989.jpg TAP259_2096_NormCross.jpg TAP260_2096_NormCross.jpg T AP261_2100_PlentyRd_RayMarsh.jpg TAP262_2132_ComEng_PTC.jpg TAP263_Sketch-all-electric-car-1041_MMTB.jpg TAP264_25_BurwoodHwy.jpg TAP265_233_PrestonWorkshops_PTC.jpg TAP266_267_PortMelbourne_30Oct1988_IanCooperCollection.jpg TAP267_2003_Bundoora_DaleBudd.jpg TAP268_2007_SouthMelbourne_31Oct1988_FritzVanDam.jpgtrams, tramways, transit australia, destination city, tramcars, depots, pcc, z class, a class, b class, tram 4, tram 46, tram 67, tram 1022, tram 112, tram 2111, tram 1041, tram 1, tram 116, tram 134, tram 231, tram 265, tram 266, tram 271, tram 2001, tram 2007, tram 2096, tram 2100, tram 25, tram 233, tram 2003, tram 2007
