This pressure gauge was still in use in our Liebig Street Water Tower until the mid 1970's. This water tower was built around 1893. The gauge was mounted on a wall and measured the head pressure.Used in the Warrnambool Liebig Street Water TowerGauge cased in brass surround painted a rust colour, glass cover with bevilled edge on front, gauge has white face with black lettering and numbers. The gauge is very heavy.Bourdon's / Pressure Gauge Hampson & Halliday Engineers, Footscraywater supply, warrnambool

Used to lay out Machine work, or to set up pieces on a planer, radial drill, milling machine or boring machine. To set the Scriber the spindle swivels down or up into any position where it is clamped by the knurled nut. There is a fine screw adjustment for the Scriber point (note: this is not original Scriber supplied with this instrument). The base on this Surface Gauge can be set on cylindrical work, using the ‘V’ groove in the base, or by pushing down the two gauge pins. It can be brought square with an edge or T slot. Metal gauge toolgauge, tool, trade, brown and sharp manufacturing company

The Ballarat School of Mines was the first of its type in Australia. The Albert Street frontage was the 'working end' of the campus with the mining laboratory, gauge tower and caretakers cottage. All the structures in the foreground have been demolished to make way for the Flecknoe Building and the M.B. John Building. The gauge tower is also depicted in the 1881 Annual Report.Original double mounted and framed architectural plan for the Ballarat School of Mines Gauge Tower. The plan includes sections and elecation. Some areas have been coloured, and the drawing is at a scale of four feet to one inch. Verso in ink "Gauge Tower School of Mines" Signed left "H.R. Caselli architect 4.11.80henry caselli, henry richards caselli, architectural plan, ballarat school of mines, gauge tower, buildings, architect

Souvenirs of service in RAN Naval Vessels.Souvenirs of service in RAN Naval Vessels.HMAS Napier and HMAS Doomba1. Wooden Life Saving Ring with Temperature Gauge H.M.A.S. Napier 1940 -194. Signed by ship mates on reverse. 2. Wooden Life Saving Ring with Temperature Gauge H.M.A.S. Doomba 1940 -1941 Round Wooden life Saving Rings 1. H.M.A.S. Napier 1940 - 1941 white with Blue color ribbon painted Top, Bottom, Left and right Temperature Gauge in Fahrenheit 20 to 120 Degrees. 2. H.M.A.S.Doomba white with Blue color ribbon painted Top, Bottom, Left and right, Temperature Gauge in Fahrenheit 20 to 120 Degrees.hmas napier souvenir, hmas dooma souvenir

Appendix, maps, p.49non-fictionThe report refers to the need to change the main trunk lines in Australia to standard gauge including from narrow gauge between Fremantle and Kalgoorlie in Western Australia (with a new bridge over the Swan River)railroad gauges -- australia -- history., royal commissions - australia

The Fred Rochow Railways Collection incorporates photos related to the operation of the Wodonga Railway Station including different types of trains and railways staff C. 1930 – 1990. It was donated to the Wodonga Historical Society by Fred Rochow, a railwayman who spent many years based in Wodonga. He joined the Victorian Railways on 17th June l947 and retired in 1988. For some time, he was a member of the Australian Federated Union of Locomotive Enginemen and served a term as a member of the Trades Hall Council. He had an extensive knowledge of the struggles that took place to achieve better conditions for railway workers. Fred worked for many years as a fireman and then worked his way up the ranks to driver, experiencing many changes from the days of steam locomotives through to diesel trains, locomotives and even the modern XPT train. He worked throughout Victoria at different stages of his career, with his final working years focused on the northeast of Victoria and the Albury to Melbourne line. After his retirement, Fred continued to share his love of steam miniature trains with the community. S Class Locomotives - The eighteen members of the S Class were ordered in two batches by the Victorian Railways from Clyde Engineering for express passenger and freight workings, with the final eight locomotives ordered specifically to work the North-East standard gauge line. Many were named after prominent Victorians.This collection has local and statewide significance as it captures images of trains, locomotives and personnel who operated the railway services in Wodonga and throughout Northeast Victoria. The railways played a critical role in opening up Victoria and connecting Australia for trade, business, social communication and transport.The first standard gauge passenger train from Sydney to Melbourne pulled by Locomotive S314. This was made possible when part of Australia's gauge problem was solved with the construction of a new standard gauge line. The new line was a 317 km long line running from Albury, NSW, parallel to the existing broad gauge line to Melbourne, connecting Australia's two largest cities by standard gauge. S314 entered service on 24 April 1961 and was named after Sir John O'Shannassy who was the second Premier of Victoria. The S314 pulled the first passenger train to travel straight through from Sydney to Melbourne on 13 April 1962. On the morning of 7th February 1969, the southbound Southern Aurora collided head-on with a northbound goods train near Violet Town, Victoria. The Locomotive S314 was hauling the goods train and was destroyed by the impact of the collision. On front of locomotive "S314" On banner below Coat of Arms "FIRST STANDARD GAUGE PASSENGER TRAIN / SYDNEY - MELBOURNE/ APRIL 13 - 1962"railways wodonga, fred rochow, walker rail motor vehicles, wodonga to tallangatta rail service

Report - 42 pages, + 6 maps, printed on foolscap and folded map sheets, edge stapled titled "Report of the Royal Commission on the matter of Uniform Railway Gauge" - dated 12/10/1921. Looks at the Australian railway system and makes recommendation for a uniform gauge for the rail system, technical issues, change of gauge, rollingstock, costs and existing system maps.Has in top right hand corner a stamp "Received Nov. 18, 1921"trams, tramways, railways, gauge

Shuttle gauge, used by a loom tuner for shuttles in a box loom.Fred Murgatroyd Shuttle gauge used by a loom tuner for shuttles in a box loomtextile machinery weaving textile mills, murgatroyd, mr fred, textile machinery, weaving, textile mills

From the 9th April until the 8th July 1896 the Victorian Parliamentary Standing Committee on Railways, chaired by Mr. Cameron with members from both houses, took evidence on three narrow gauge extensions from broad gauge railway stations in the area, the Beech Forest Extension from Colac, the McDonald's Track Extension from Warragul, and the Drouin and Poowong East Extension from Drouin.Minutes of Evidence, Beech Forest Narrow-Gauge Extension. Minutes of Evidence, McDonald's Track Narrow-Gauge Extension. Minutes of Evidence, Drouin and Poowong East Narrow-Gauge Extension. Victorian Parliamentary Papers; Melbourne (Vic); April-July, 1896. 60 p. (VPARL1896-97 No 42)

A history of narrow gauge railways in VictoriaHard cover book with glossy coloured photographs on front and back cover of narrow gauge steam trainsnarrow gauge railways, victoria, dandenong ranges

The Gauge Tower was designed by architect Henry Richards CaselliReproduction of an architectural drawing of the Ballarat School of Mines Gauge Tower as reproduced in a Ballarat School of Mines Annual report.henry caselli, henry richards caselli, ballarat school of mines, gauge tower

A marking gauge is used to scribe marks onto the timber of a woodworker's job.Gauge, wooden; block section of a marking gauge. Inscription impressed into wood.Stamped "JB" on two ends.flagstaff hill maritime museum and village, warrnambool, great ocean road, woodworking tool, marking gauge, hand tool

Black box containing a Matrix Braille writing machine, with a paper spool attached to the feeding mechanism. The front portion of box is hinged and lifts up to reveal keyboard. Top half of box lifts to reveal Braille writer which is bolted to a wooden base that can be lifted out. The base is secured with a metal latch. Machine has black keys and the wooden case has black leather-like covering, hinged lid, metal clasps, and leather handle on the side. "Model G, Matrix, Coventry Gauge & Tool Company, Ltd., No. 792, For The Royal National Institute for the Blind, London W.I." is stamped on the front,Black vinyl-covered case containing black metal writer and paper spool"Model G, Matrix, Coventry Gauge & Tool Company, Ltd., No. 792, For The Royal National Institute for the Blind, London W.I." is stamped on the front.braille equipment, royal national institute for the blind

Black box containing a Matrix Braille writing machine, with a 24mm-wide paper spool attached to the feeding mechanism. Corner of box is hinged and lifts up to reveal keyboard. Top half of box lifts to reveal Braille writer which is bolted to a wooden base that can be lifted out. The base is secured with a metal latch. Machine has black Bakelite keys with rubber pads beneath make this a "silent" machine; wooden case has black leather-like covering, hinged lid, metal clasps, and leather handle on the side. "Model G, Matrix, Coventry Gauge & Tool Company, Ltd., No. 1183, For The Royal National Institute for the Blind, London W.I." is stamped on the front,Black vinyl-covered case containing black metal writer and paper spool"Model G, Matrix, Coventry Gauge & Tool Company, Ltd., No. 1183, For The Royal National Institute for the Blind, London W.I." is stamped on the front.braille equipment, royal national institute for the blind

The Ballarat School of Mines was the first of its type in Australia. The Albert Street frontage was the 'working end' of the campus with the mining laboratory, gauge tower and caretakers cottage. All the structures in the foreground have been demolished to make way for the Flecknoe Building and the M.B. John Building. Harry Brew, the well known Ballarat School of Mines caretaker, lived in the small weatherboard building to the right of the photograph. He was appointed to the staff at the Ballarat School of Mines in 1936.Printed copy of an architectural plan for the Ballarat School of Mines Gauge Tower as printed in the 1879 Ballarat School of Mines Annual Report.henry caselli, henry richards caselli, architectural plan, ballarat school of mines, gauge tower

The third in the historical series outlining the narrow gauge Victorian Railways line from Colac to Crowes, and then Colac to Beech Forest, in the Otways between 1954 and 1962 when the line closed. Victorian Railways Narrow Gauge "G" Class; "Garratts in the Otways" Part Three. A photographic profile - 1954-1968. Emile D. Badawy (ed.). 2001; Train Hobby Publications; Studfield (Vic). ii, 48 p.; illus. Soft cover. ISBN 1 876249 41 2colac; beech forest; crowes; victorian railways; narrow gauge; garratt; emile d. badawy;

The first in an historical series showing the Victorian Railway narrow gauge line from Colac to Crowes, and then from Colac to Beech Forest, in the Otways from 1954 until 1962 when the line closed.Victorian Railways Narrow Gauge "G" Class. "Garratts in the Otways" Part One. A photographic profile - 1954-1962. Emile D. Badawy (ed.); John Sargent (ed.). 1998; Train Hobby Publications; Studfield (Vic). ii, 48 p.; illus., maps. Soft cover.colac; beech forest; crowes; victorian railways; garratt; narrow gauge; emile d. badawy; john sargent;

Gauge for steam pressure, made by John Tompson Woverhampton.flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, john tompson woverhampton, gauge

Marking gauge. Manufactured by Stanley. A marking gauge, also known as a scratch gauge, is used in woodworking and metalworking to mark out lines for cutting or other operations. The purpose of the gauge is to scribe a line parallel to a reference edge or surface. The gauge consists of a beam, a headstock, and a scribing or marking implement, typically a pin, knife, pen or wheel. The headstock slides along the beam, and is locked in place by various means: a locking screw, cam lever, or a wedge.Manufacturer's namemarking gauge, stanley -- tool manufacturer, measuring tools

This gauge was used in the making of components for the ship model Sovereign of the Seas. It is part of a collection of objects used by Jim Williams, maker of fine ship models from about 1930-1955. Most of the components for the models, as well as many of the tools, were handmade by Jim Williams. Jim’s family has donated the ship model “Sovereign of the Seas” and many tools, accessories and documents used in the making of this and other ship models have been donated to Flagstaff Hill Maritime Village. Ship model of HMS Sovereign of the Seas, scale model of 17th Century English war ship, was handmade and carved from plans, enclosed in airtight glass case. All components of that model, including even the smallest pulleys, were hand crafted using tools designed and made by Jim. Outstanding details include functional rigging and moving cannons. Please see our record 3732 of the mode Sovereign of the Seas for further details of the ship and the maker. This gauge is connected with the hobby and skill of ship model making that has been crafted as a leisure activity for many generations. The hobby is often chosen by serving and retired mariners who appreciate the connection with maritime history. This gauge was used by local Warrnambool man, Jim Williams, who was employed at Cramond and Dickson clothing store, and then at Fletcher Jones menswear for 27 years. It was used in making components for the model of the historic ship, the Sovereign of the Seas. The Sovereign of the Seas was a historic 17th century English war ship with important maritime heritage. Gauge; marking gauge, wooden. Wooden handle threaded through hole in wooden block, adjusted along the handle by tightening a wing-nut screw. The end of the handle has a pointed pin fitted for scoring a mark on the work surface to mark timber before cutting. This gauge is part of a collection of tools and accessories once used by Jim Williams, maker of a series of ship models 1930-1955 including “HMS Sovereign of the Seas”.flagstaff hill, warrnambool, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, jim williams, james bernard williams, ship model hobby, ship model tools, ship model making equipment, ship model making accessories, wood working tool, model making tool, drawing instrument, gauge, tool, sovereign of the sea, ship model, hobby, ship model tool

Marking Gauge. Manufactured by Marples of Sheffield, England. Also known as a scratch gauge, it is used in woodworking and metalworking to mark out lines for cutting or other operations. The purpose of the gauge is to scribe a line parallel to a reference edge or surface. The gauge consists of a beam, a headstock, and a scribing or marking implement, typically a pin, knife, pen or wheel. The headstock slides along the beam, and is locked in place by various means: a locking screw, cam lever, or a wedge.Maker's namemarking gauge, measuring tools, marples of sheffield

West Otways Narrow Gauge; The story of the Beech Forest 2ft 6in gauge railway and its connecting tramways; Norman Houghton; Light Railways v.XII, no.45, Spring 1973; soft cover; 52p.; illus. mapsPrinting - Kemera Press, Caulfield, Vic.west otways; narrow gauge; beech forest; 2ft 6in narrow gauge; tramways; colac; gellibrand; the ridge; crowes;

Beech Forest. Narrow gauge locomotive No.5A, 1902. Seven men (unknown), five on train, two on ground.beech forest; locomotive no.5a; railway; narrow gauge;

INSULATED wagon. Built in 1899 and numbered 1, it was the only one of its type built Service History : NTT In October 1899 a bogie insulated van was built and placed into traffic. In 1926, the class was relettered to NT. Obtained by the Puffing Billy Preservation Society By 1969, the vehicle was in the Menzies Creek Museum. Currently Located at Belgrave Station The NT is an insulated van. The wooden body (both sides and roof) was insulated with cowhair. It had two swinging doors either side in the middle, as have the NU vans. The van was painted white, in an attempt to reflect the summer heat. There was only one built for the narrow gauge lines. Vehicle Length 25 feet 2 inches ( 7671 mm) Coupled Length 27 feet 4 inches (8330 mm) Width 6 feet 3 inches (1905 mm) Weight 7 tons Capacity 10 tons Built 1899 Number Built 1 In use none To be restored 1Historic - Victorian Railways - Narrow Gauge Rolling Stock - Insulated Wagon 1NT Victorian Heritage Register (VHR) Number H2187 Puffing Billy Locomotives and Rolling Stock Collectiontimber constructed body wall cavity filled with horse hair for insulation The NT is an insulated van. The wooden body (both sides and roof) was insulated with cowhair. It had two swinging doors either side in the middle, as have the NU vans. The van was painted white in an attempt to reflect the summer heat. There was only one built for the narrow gauge.1nt1nt, puffing billy, insulated van

Construction of the Colac-Beech Forest railway line commenced in 1900 and the first activities were the work gangs and their camps. About 100 men were engaged in laying and ballasting the track while others formed the earthworks and the building of culverts and bridges. The first camp was established eight kilometres from Colac, the second 12 km south, and the remainder spaced at similar distances as the work progressed. The camps were served by butchers and bakers from Colac that visited them as many times each week to satisfy the mens' requirements. Many of the men had their families with them. They all lived in tents that consisted of a wooden floor around which the canvas cover was built. A calico partition divided the eating and sleeping quarters, and all cooking was done in camp ovens or at open fires.B/W. 158mm x 203mm. Near Colac, a narrow gauge construction camp comprising 21 workmen, a horse, and two tipping trays.construction camp; railways; colac;

The Ballarat School of Mines was the first School of Mines in Australiasia, and had a model mining laboratory which provided testing for a fee.Quarter leather bound book with an alphabetical listing of names, and certificates and stubbs for Ballarat School of Mines Vacuum and Pressure-gauge Testing Apparatus Certificates.ballarat school of mines, vacuum and pressure-gauge testing apparatus certificate book, certicates, stubbs, vacuum testing, pressure gauge testing, m.b. john, berry united gold mining company, birthday company, britannia united gold mining company, cambrain company, dry diggings gold mining company, dimboola flour mill, first chance gold mining company, great northern extended consols rutherglen, h.v. mckay, lady brassey company, llanberris no. 1, llanberris no 2, mcvitty and company, phoenix foundry, e. rowlands, south woah hawp, tinworth and party, victoria corish united, william's fancy company, woah hawp canton gold mining company, woah hawp no. 2, andrew andreson, bourdons, frederick martell, lonie and dingle, cornish gold mines daylesford, j.d. williams, jane brad, clunes, wendouree asylum, electric hydralic dredging party, east jubilee gold mining company, j.e. cowley, john mann, normanby north company, new imperial gold mining company, ballarat brewing company, yarrowee dredging company, a. mckirdy, daylesford, pearce brothers, canadian, hepburn mineral spring company, \e. balhausen, ronaldson borthers and tippett, ballarat woollen mills, cathacart central gold mining company, j.b. robinson

NKS Type Gangers Trolly - Victorian Railways 2'6" gauge trolley - a KS series Section Car oftern called the Kasey Jones The narrow gauge version of the broad gauge KS series cars. They were classed NKS with two stroke motors. These cars were built by the Spotswood Workshops, with castings coming from the Newport Workshops. KS is lighter car capable of carrying 4 men or sevenhundredweight Trolly 9 was built for the State Electricity Commission of Victoria for use on their metre gauge railway of Yallourn. It was sold to a preservation group at Walhalla and regauged to 2 foot 6 inch. It came to the Puffing Billy Railway in the early 1980s.Historic - Victorian Railways Narrow Gauge - Track Patrol Vehicle used by the State Electricity Commission of Victoria for use on their 900mm gauge railway of Yallourn. And then at Walhalla Railway where it was regauged to 2 foot 6 inchMotorised small rectangular trolly made of wood and wrought iron - currently stored dismantled Engine Type: 1 Cyl. reversible Fuel: 2 stroke Transmission: Belt driveNKS 9puffing billy, puffing billy museum, trolley, narrow gauge, 2'6" gauge, victorian railways, state electricity commission of victoria - yallourn., trolly
