Significant to mining history of Bendigo.Black and white photograph: headframe of Napoleon Gold Mine, partly constructed. Two men standing bottom left of headframe. Hill and bushland in background of image. Written in pencil on back of photographs in pencil: 'Napoleon 5.1.35''napoleon gold mine, mullock, headframe

Significant to mining history of Bendigo.Black and white photograph : Napoleon Gold Mine main shaft 1934. Image shows landscape view, some earth workings on site. Five men walking on different parts of site. Trees in background. Written in pencil on back of photograph in pencil: 'Napoleon main shaft site 23/8/34''napoleon gold mine

Significant to mining history of Bendigo.Black and white photograph : Napoleon Gold Mine main shaft 1934. Shed under construction on right hand side, horse with cart near centre. Bushland and mullock heaps on left hand side. Written in pencil on back of photograph in pencil: 'Napoleon main shaft 18/9/34''napoleon gold mine

Significant to mining history of Bendigo.Black and white photograph : landscape view of Old Napoleon gold mine site showing the early stages of the development of the mine. Mullock heap on left hand side with inclined temporary trestleway leaning on side of heap. Written in pencil on back of photograph in pencil: 'Old Napoleon 6.12.34''napoleon gold mine, mullock

The Napoleon (BML) gold mine (1932) was located beside McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer)Significant to mining history of Bendigo.Black and white photograph of a stamper head being lowered into position on the battery site of the Napoleon Reef Gold Mine. A wooden gantry supports the battery head as it being lowered, a man is standing on top of the stamper head. Concrete foundations are visible in immediate background. napoleon gold mine, napoleon reef gold mine

Significant to mining history of Bendigo.Black and white photograph: Napoleon metal headframe under construction. Mine shed in foreground and background. Kiosk sub-station (electricity supply) on right hand side of photo.Written in pencil on back of photographs in pencil: 'Napoleon 16.1.35''napoleon gold mine, headframe

Significant to mining history of Bendigo.Black and white photograph: winder metal bedplates in position; winder inside corrugated iron shed. Concrete footings on right hand side. Written in pencil on back of photographs in pencil: 'Napoleon winder bedplate in position 4/5/35'. napoleon gold mine, winder, bedplate

Significant to mining history of Bendigo.Black and white photograph: winder metal bedplates in position with winding wheel far end installed. Winder inside corrugated iron shed, metal framing on right hand side of image. Written in pencil on back of photograph : 'Napoleon winder during erection 14/6/35'. napoleon gold mine, winder, bedplate

Significant to mining history of Bendigo.Black and white photograph: six workmen positioning the metal sinking cage over the Napoleon shaft. Cage is suspended by ropes from the cross beams of the headframe. Two railway tracks leading to shaft, presumably to transport the sinking cage to site. Workman on left hand side has a hammer inserted on his belt.Written in pencil on back of photograph : ' Cage being put in Napoleon shaft 9/3/35'. napoleon gold mine, sinking cage, shaft

Significant to mining history of Bendigo.Black and white photograph: Mine cage being maneuvered into position within headframe and over shaft by three workmen. Rope attached to bottom front of cage to assist in steadying the cage.Written in pencil on back of photograph : ''... (illegible) cage in Napoleon main shaft 31/8/35'.napoleon gold mine, safety cage

Significant to mining history of Bendigo.Black and white photographs: winder. Winder inside corrugated iron shed. Two winder wheels, metal framework on right hand side. (a) Winding wheels erected 1/7/35, three men inspecting various aspects of the machinery. (b) Winder in shed, side view with two men putting on winder ropes. Written in pencil on back of photographs : (a) 'Napoleon winder 1/7/35. (b) Napoleon winder putting on ropes 30.8.35. napoleon gold mine, winder, bedplate

Significant to mining history of Bendigo.Black and white photographs: metal headframe on Napoleon mine site on left/centre of image, corrugated iron mining sheds in background and right of image. Top section of headframe still under construction. Power line in background. Written in pencil on back of photograph : Napoleon main shaft 5/2/35. napoleon gold mine, winder, bedplate

Significant to mining history of Bendigo.Black and white photograph: concrete winder foundations within corrugated iron shed. Leaning on wall in background circular 'lifebuoy' shape white object with 'London, Henley' written around the edge.Written in pencil on back of photograph : ' Main winder foundation 28/4/35'napoleon gold mine, mine machinery, winder, foundations

Significant to mining history of Bendigo.Black and white photograph: two sections of trestle way, power poles in foreground. Rock pile almost directly directly under trestleway. Wall of mine shed right hand side Low forested hills in far background.Written in pencil on back of photograph : 'Napoleon trestles completed and first truck tipped 14/9/35'. Further date unattributed 17.9.35'napoleon gold mine, trestleway, ore

The Napoleon (BML) gold mine (1932) was located near McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer) 'Napoleon BML Mines No Liability have issued a report for the fortnight ended September 5, where it states that the development scheme has been formulated and necessary equipment is being ordered. The Napoleon main shaft, (about 1700 feet south of the old Napoleon shaft) will be a four compartment shaft (17ft 6 inches by ft 2 inches inside the timber). aLevels will be opened at approximately 100 ft vertical intervals and cross-cuts extended approximately 125 ft each side of centre country to explore a cross-section across the anticline opposite to the shaft. At every fifth level, main drives will be extended north to connect with the old Napoleon shaft and south approximately 1800 ft. At the latter point, another cross-section of the anticline will be explored by rising and cross-cutting. The old Napoleon will be unwatered and on the 500ft and 1000 ft levels main drives will be driven to connect with main levels from the Napoleon main shaft to the south as well as being driven north 1800 ft where another cross-section of the anticline will be explored. Cross-sections further north and south may be developed as desired and also at intermediate points if necessary. Clearing and grading of the main shaft site are now in progress and the erection of the office and store building is proceeding. The design of engine room, change house and machine shops is now in hand and erection will proceed as soon as working plans and specifications are prepared.' The main shaft has been commenced at 3ft and advanced 10 ft. to 13 ft. https://trove.nla.gov.au/newspaper/article/10975478?searchTerm=napoleon%20bml (The Argus, 8th. September 1934, 'Mining' page 18) Significant to mining history of Bendigo.Black and white photograph of a stamper head being lowered into position on the battery site of the Napoleon Reef Gold Mine. A wooden gantry supports the battery head as it being lowered. Three large concrete foundations are visible in immediate background, two of which have stampers already in position, the third stamper is being lowered onto the final foundation. In immediate foreground, 'boxing' is erected for future concrete pours. napoleon gold mine, napoleon reef gold mine

The Napoleon (BML) gold mine (1932) was located beside McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer)Significant to mining history of Bendigo.Black and white photograph. Image shows flat, open landscape with four large eucalypt trees in centre of image. Four men working with shovels on left hand side of image, one man with wheelbarrow and dog alongside. Wooden framed structure on right hand side. Written in pencil on back of photograph: ' Battery excavations started 22/9/36' and 'excavations started'.napoleon gold mine, napoleon reef gold mine

Share register, green cover and buff spine and corners. 'Share register' and " Napoleon Reef Gold Mine Co. NL" printed on spine. Alphabetical index of shareholders in front of book. Dates from 1940 - 1941 on entries.business, mining, napoleon reef gold mine nl

Significant to mining history of Bendigo.Black and white photograph: manifold being installed at Napoleon gold mine. Written in pencil on back of photograph : ' Installing manifold at Napoleon 28/4/35'napoleon gold mine, manifold, mine machinery

Napoleon mine was in Woodward Road, Golden Square.Horwood Collection. Air Compressor at Napoleon Gold Mine, Woodward Rd, Golden Square. Markings: Napoleon? Golden Square. Air compressorKodakmine, gold, napolean, horwood collection. air compressor at napoleon gold mine, woodward rd, golden square

Significant to mining history of Bendigo.Black and white photograph: framework for ore bins at Napoleon (BML) Gold Mine, being erected alongside head frame at mine site. Trestle way visible in extreme top of image. Written in pencil on back of photograph : 'Erecting ore bins at Napoleon 27/8/56'napoleon gold mine, anticline

Significant to mining history of Bendigo.Black and white photograph: pump machinery in underground at Napoleon (BML) Gold Mine. Image shows machinery, with steel control box at far left hand side. Safety rail in front of machinery. Rock wall behind. Written in pencil on back of photograph : '....(illegible) pump No. 10 plat Napoleon 15/9/36 ''napoleon gold mine, plat, pump

Significant to mining history of Bendigo.Black and white photograph: sinking winch machinery supported on concrete block, underground at the Napoleon (BML) gold mine. Two men, one standing at back of machinery left hand side, and one standing on concrete platform operating a pulley.Written in pencil on back of photograph : '....(illegible) sinking winch No. 10 plat Napoleon 15/9/36''napoleon gold mine, sinking winch, plat

The Napoleon (BML) gold mine (1932) was located beside McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer)Significant to mining history of Bendigo.Black and white photograph: landscape view of mine sheds. Battery shed fully completed with trestleway to another shed. Trees in background. Written in pencil on back of photograph: 'completed battery 5/12/36'napoleon gold mine, napoleon reef gold mine

The Napoleon (BML) gold mine (1932) was located beside McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer)Significant to mining history of Bendigo.Black and white photograph: battery shed under erectionWritten in pencil on back of photograph: 'battery erection 17/1`1/36' and 'cracker station building' napoleon gold mine, napoleon reef gold mine

The Napoleon (BML) gold mine (1932) was located beside McDougall Road, Golden Gully, between Martin and Hattam Street. It had a depth of 921 feet. It was one of the latest and most lavish of Bendigo's mines. Plant and equipment were electrically driven. The four-compartment shaft, extra large by goldfield's standards, measured 17 feet 6 inches by 5 feet 2 inches and was cement lined below 900 feet instead of being red gum boxed as was the usual practice. The workshop was equipped to carry out all repairs for the equally lavish BML mines on the Nell Gwynne and Carshalton reefs. (The Gold Mines of Bendigo, Book 2, Arthur Victor Palmer)Significant to mining history of Bendigo.Black and white photograph: battery under construction, concrete bottom blocks being 'boxed' up .Written in pencil on back of photograph: 'another new daring creation' and ' boxing the foundation 7/10/36'.napoleon gold mine, napoleon reef gold mine

Yellow document, receipt 683 issued by Central Napoleon Gold Mining Company, Comonwealth Bank Chambers, Charing Cross, Bendigo, 11 May 1937, to C.O. Pieper, for 100 shares in the mine. Receipt signed by J. J. Stanistreet, Manager.bendigo, mining, central napoleon gold mine

Significant to mining history of Bendigo.Black and white photograph: metal mine cage at level in Napoleon mine. Man standing on right hand side looking directly at cage, with both arms raised. Lengths of timber and rock rubble on floor of level. Written in pencil on back of photograph : 'Nap. main shaft 22/6/36 opposite No. 10 plat' napoleon gold mine, mine machinery, plat, shaft

In structural geology, an anticline is a type of fold that is an arch-like shape and has its oldest beds at its core, whereas a syncline is the inverse of an anticline. A typical anticline is convex up in which the hinge or crest is the location where the curvature is greatest, and the limbs are the sides of the fold that dip away from the hinge.Significant to mining history of Bendigo.Black and white photograph: rock formation, anticline with an archlike shape in centre of image. Written in pencil on back of photograph : 'Napoleon anticline Golden Square'.napoleon gold mine, anticline

Significant to mining history of Bendigo.Black and white photograph: base of head frame with mine at top of shaft. Rail trcks in foreground.Written in pencil on back of photograph : 'Napoleon main shaft 2/9/35''napoleon gold mine, anticline
