KBW Slotting MachineHistoric - Industrial - Slotting MachineLarge metal KBW Slotting Machine KBWbelt driven, puffing billy, slotter, kbw, slotting machine

Although it’s unknown when these two photos were taken, the South African Pattern Mk IV Slotted Template Machine was in service from 1936 to 1952. The machine was used to cut slots and holes in an acetate film medium. This template was then used to fit several runs of aerial photography to ground control points at a desired scale with a substitution of the templates in the assembly. Radial slots on the templates from central holes representing the photograph’s principal point (centre) were placed over hollow metal studs mounted over control points on the scaled base sheet. The studs represented the intersection of radial lines through common points of detail of overlapping photos. A pricker was used to transfer from the photo-points to the templates. The slotted template methodology was later used as an essential aero-triangulation exercise in advance courses conducted at the School of Military Survey.These three photographs are of a slotted template machine used in aero-triangulation. The first two photographs were printed on photographic paper and are part of the Army Survey Regiment’s Collection. The photographs were scanned at 300 dpi. The third photograph was captured from a collection using a smart phone. .1) and .2) - Photo, black & white, 1936-1952. South African Pattern Mk IV Slotted Template Machine. .3) - Photo, black & white, 1936-1952. WO2 Bob Pratt operating the Slotted Template Machine. .1 and .2 –annotated on back “Slotted Template” .3P - annotated on front “COMPILATION SECTION SLOTTED TEMPLATE MACHINE WO2 BOB PRATT”royal australian survey corps, rasvy, army survey regiment, army svy regt, fortuna, asr, air survey, aerotrig

A time clock, sometimes known as a clock card machine, punch clock, or time recorder, is a device that recorded the time an employee entered and left the factory. In mechanical time clocks, this was accomplished by inserting a heavy paper card, called a time card, into a slot on the time clock. When the time card hit a contact at the rear of the slot, the machine would print day and time information (a timestamp) on the card. One or more time cards could serve as a time sheet or provide the data to fill one. This allowed a timekeeper to have an official record of the hours an employee worked to calculate the pay owed an employee.Metal time card rack.time sheet, time card, factory, employee, work life, punch clock, textile industry

A time clock, sometimes known as a clock card machine, punch clock, or time recorder, is a device that recorded the time an employee entered and left the factory. In mechanical time clocks, this was accomplished by inserting a heavy paper card, called a time card, into a slot on the time clock. When the time card hit a contact at the rear of the slot, the machine would print day and time information (a timestamp) on the card. One or more time cards could serve as a timesheet or provide the data to fill one. This allowed a timekeeper to have an official record of the hours an employee worked to calculate the pay owed an employee.Metal time card rack.time card, rack, employee, factory, timesheet, data, mechanical, punch clock

Inventor Biography: Percival Everitt was a Norfolk-born engineer and regarded as the father of the coin-op industry. in 1884 he patented one of his many inventions the coin-operated scales. For many people, it was their first exposure to coin-operated machines. As a young man in 1877, Everitt invented a hay and corn pitcher, a turnip thinner in 1878 and an “Automatic Travelling Anchor” in 1880. But he hit his stride in 1883 with the first postcard-vending machine over a hundred of which he distributed around London. Everitt went on to invent the one penny scale which prompted the formation of the Weighing Machine Company in 1885. Further inventions followed a blow tester in 1887 also the machine for testing a person grip in 1888 and the dispensing machine that opera glasses could be hired from in 1889 also the fortune-telling machine in 1890. He also invented a mechanism to shut coin slots when vending machines were empty, but then as now vandals posed a problem by jamming paper into the slot. Everitt sadly did not make his fortune he died suddenly in February 1893, in his late forties with £71 to his name. Penny Slot Weighing Machine: When the Australian colonies federated to form the Commonwealth of Australia in 1901 their post and telegraph departments were merged to form the national Postmaster General's (PMG) Department. The subject scale is an automatic public weighing machine, No.387, made in England by George Salter and Co. of West Bromwich. The Australasian Automatic Weighing Machine Co. Ltd in 1923 tendered for the right to place Automatic Weighing Machines on railway and tram premises throughout New South Wales subsequently for five-year terms in return for a fixed payment per machine and a portion of the revenue to the NSW Government. The company also made arrangements with the Postmaster General's Department to place machines outside post offices across the country. Weights were measured in stones and pound's up to 20 stone (127 kg) and average weights were shown separately for men, women, boys and girls by various heights in feet and inches. The subject item has had its scale change by the Eastern Scale Company to metric and it is believed to have occurred shortly after April 2000 as the company was first registered and began trading on this date. This weighing machine was originally installed by the Australasian Automatic Weighing Machine Co. Ltd at Warrnambool Post Office and was made by the firm, George Salter and Company, in West Bromwich, England to the Percival Everitt patent. Salter advertised that these machines were suitable for hotels, pleasure gardens, theaters, exhibition halls, clubs, baths and places of public resort. The company had been established in 1760 by the brothers, Richard and William Salter, manufacturing springs and pocket steelyards (spring balances). After several generations, the company was taken over by a nephew, George, and in 1884 the Salter trademark was registered to show a Staffordshire knot pierced by an arrow. The company's expanded range of products included the first coin-operated public weighing machines in the 1880s and in 1895 the first English made typewriter. When the last George Salter died in 1917, the company passed into the hands of other relatives but continued to grow before being bought out by Staveley Industries in 1973. Despite several subsequent mergers, the Salter name continues today on home ware products such as digital scales.A very rare example of a penny in the slot weighing machine imported into Australia and used in public places the item is significant as it gives a snapshot into community life at the time where the public could go and get weighed given there were no personal weighing machines or equipment that people could use at home. So if they needed to post a letter or go on a train journey they could use a machine to check their weight. Whats interesting is that this patent by Percival Everitt was the worlds first slot machine and the start of casino, arcade and other types of slot machines. Personal weighing scale metal large silver painted penny coin operated. Weight measurements are in stones and pounds. Australian Automatic Weighing Machine 60 lb Everitt Patent. flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village

The phonograph is a mechanical device for the recording and reproduction of sound and originally used a tinfoil sheet wrapped around a rotating cylinder to produce the sound. It was invented by Thomas Edison of U.S.A. in 1877 and was the model for all phonographs or gramophones made and developed throughout the 20th century. This machine is of particular interest to the Warrnambool and District Historical Society as it is an Edison phonograph and an earlier model of this phonograph was used in Warrnambool late in the 19th century to make an important recording. In 1896 Thomas Rome, an employee in a Warrnambool boot and shoe shop, purchased an Edison phonograph that could both play and record sounds. At the Warrnambool Industrial and Art Exhibition of 1896-7 visitors to the Exhibition paid a fee to listen to music on this phonograph. But Rome also recorded some local Warrnambool people singing and speaking and these recordings survive today. They are regarded as the oldest surviving recordings made in Australia. Thomas Rome later became a shoe shop proprietor in Warrnambool and was a well-known person in the town/city for a great number of years. This is an Edison Gem Phonograph. It has a black-painted wooden base, now detached from the main mechanism. The phonograph is made of metal which is now heavily rusted. It has a cylindrical turntable for playing the Edison cylindrical records and a handle with a wooden knob. The turning mechanism and belt are now broken. The name of the manufacturer and details of the patents are on a metal plate attached to the side of the phonograph. The amplifier mechanism at the top of the machine is missing. The cover of the machine is made of wood and has a wooden handle attached with a piece of metal and two metal screws. There are also two metal screws on the side of the cover. The cover has a slot on the side to allow the turning handle to be accommodated outside of the cover. The cover is much stained and spotted. ‘Edison Gem Phonograph’ thomas edison, history of sound recordings, thomas rome (warrnambool)

This 20th century business machine was used by the firm of D.H.Wood Motors of 169 Koroit Street Warrnambool. This firm advertised that it sold mainly Peugeot and Studebaker cars and Hillman and Humber cars and commercial trucks. This machine has local provenance as it came from the 20th century business of D.H.Wood Motors. It also has some historical interest as an example of a business or office machine used in the early to mid 20th century before the general use of computers. This is a grey rectangular-shaped metal box with rounded edges. The box has four metal studs on the base to keep the box stable. The box has a hinged section for the insertion of the paper dockets and a turning mechanism for removing the dockets, one at a time from a slot at the top of the machine. The dockets have a white (customer's) copy and a pink duplicate copy for the business to file. Two of the dockets have been removed from the machine to show the contents. The number of dockets in the machine is unknown. The metal surface of the machine is rubbed and rusty and the paper is stained. 'Paragon' 'D.H.Wood Motors, 169 Koroit Street, Warrnambool' 'Lamson Paragon Limited Wiz Register' vintage business machines, warrnambool

Charcoal soft covered booklet with general notices, designs, andtrademarks. Patents include a portable washing machine, Kinematograph shutter, anti-splash valves, Railway collision preventing, telephone automatic coin slot patents, trademark

This testing voltmeter recorder was last certified by SEC Vic laboratories on the 17/4/77. It was used extensively as mobile recorder placed for periods of one month at locations experiencing unacceptable fluctuations of power. These locations would cover the North East regions of Victoria. They cover voltage drops at domestic and business properties especially those that were experiencing regular fluctuations(daily) at approximately the same time of the day. As the electrical network is required to operate within a set level of voltage, fluctuations outside of this has to be investigated and necessary remedial action taken. This is especially so for rural properties where power "drainage" can occur through animal/bird and tree interference. It can also be the result of defective wiring and overloading at peek operational times (milking machines).This mobile voltage recorder is very significant to the Kiewa Valley because it highlights the difficulties that can occur in maintaining a power supply that experiences fluctuating power demands by the rural industries that it supplies. The requirement of a mobile testing apparatus to cover the various sections in the Kiewa Valley and other rural areas in the northeast region is one of necessity as electricity once connected to a rural property is a labour saving supply as generators on rural properties require a higher degree of maintenance an ultimately at a higher cost. The testing of the SEC Vic supplied electricity to rural properties,those who had previously run on generators, had to be quick and unassuming with certainty of correct supply levels.The mechanism of this voltage recorder has been installed(by the manufacturer) into its own protective wooden box. This box has a front (swing open) lockable section which permits direct access to the installed measuring equipment (for servicing and data collection). The top section of the box has two screw on terminals for access to the machine being tested. This tester has its own inbuilt ink supply facilities and a mechanical clockwork device that unwinds a roll of paper onto a second roll at a rate of 10 mm per hour. The recording chart is marked with time slots against voltage. There is a recording arm which has an ink pen at the end. Both arm and pen carry the ink supply from the ink reservoir, located on the left side of the cabinet door in specially constructed bottle holder( three small bottle capacity). To record a suspect power problem to a home or business establishment the voltmeter is connected to a power supply outlet being tested and wind the recording clockwork mechanism (gives a four week running time). Before leaving the recorder in situ the electrician checks to see if the chart is recording the correct voltage and that the clock mechanism is advancing correctly.On the front of the access "door" at the top a metal label "RECORDING AMMETER" below this "MURDAY SYSTEM" below this "ALTERNATING CURRENT" and below this the manufacturer's registered number "No. 139156" Below this is a metal tag with State Electricity Commission of Victoria Electrical Engineer's Section equipment number "338" Below these tags and above the viewing window is the manufacturer's dtails "EVERSHED & VIGNOLES Led LONDON"sec vic kiewa hydro scheme, alternate energy supplies, alpine feasibility studies temperature, rainfall, power outages

Used to lay out Machine work, or to set up pieces on a planer, radial drill, milling machine or boring machine. To set the Scriber the spindle swivels down or up into any position where it is clamped by the knurled nut. There is a fine screw adjustment for the Scriber point (note: this is not original Scriber supplied with this instrument). The base on this Surface Gauge can be set on cylindrical work, using the ‘V’ groove in the base, or by pushing down the two gauge pins. It can be brought square with an edge or T slot. Metal gauge toolgauge, tool, trade, brown and sharp manufacturing company

Australia Post Wall mounted postage stamp vending machine used to dispense stamps.Metal postage stamp vending machine. Wall Mounted. Embossed letters POSTAGE STAMPS on front. Horizontal slots for coins have been covered with plates stating NOT IN USE and OUT OF SERVICE. White metal plate with the wording STAMPS 5 CENTS. Two Key holes. Recepticle for the dispensing of stamps with a lift up lid with Embossed words LIFT. Postage Stamps; lift; post, stamps, vending machine, australia post offices, postage stamps, tatura

Bodice of a blue linen dress made by Elfriede Girschik for her daughter, Helga, in Camp 3. c1942 (early). The singer sewing machine it was made on came with her into the Camps.Blue linen bodice which has been part of a dress. The bodice has sleeves gathered at the top and slots for elastic (not there) at the lower edge. 6 handmade buttonholes down the opening at the back with 6 small buttons. Hand embroidery on the front, 2 ladybirds, sprays of yellow, blue, pink and orange flowers. The bodice has been separated from the bottom of the dress and hemmed up to make into a top.bodice, embroidery, camp 3, tatura, ww2 camp 3, internment camp handwork, helga griffin, helga girschik

This attachment was used by donor . It was a great improvement over hand made buttonholes.A Singer buttonhole attachment used about 1950s. It was attached to ordinary power sewing machines to make button holes. It includes a small metal plate to cover teeth when making button hole and a fairly long slotted screw for attaching plate.Singer 86662 completehandcrafts, equipment

Flanged Tramway Rails - sections from The North Eastern Steel Co. Ltd. Middlesborough - see https://www.gracesguide.co.uk/North_Eastern_Steel_Co 1 - Walthamstow & District Light Railways BS Section No. 3C - 106 lbs. per yard 1904 - Dick Kerr & Co. Contractors London. See https://en.wikipedia.org/wiki/Tottenham_Outrage 2 - Bath & District Tramways 95 lbs per yard 1903 - George Hopkins & Sons Engineers London 3 - Burton on Trent Tramways 90 lbs per yard 1903 - Messrs Kincaid, Waller & Manville, Consulting Engineers 4 - Swindon Corporation Tramways BS Section No. 4 C, 111 lbs per yard, 1904 - Messrs J G White & Co. Ltd, Contractors London 5 - Wigan Corporation Tramways BS Section No. 5, 100 lbs per yard, 1903 - Messrs J G White & Co. Ltd, Contractors London 6 - Derby Corporation Tramways BS Section No. 6, 107 lbs per yard, 1904 - Messrs J G White & Co. Ltd, Contractors London 7 - Nottingham Corporation Tramways BS Section No. 1 , 90 lbs per yard, 1903, J. G. White Ltd, London, Contractors. 8 - Swindon Corporation Tramways, BS Section No. 4, 105 lbs per yard - Messrs J G White & Co. Ltd, Contractors London, Messrs Lacy & Sillars Consulting Engineer 9 - Kalgoorlie Electric Tramways BS Section ? 96 lbs per yard. 1904 - Messrs J G White & Co. Ltd, Contractors London 10 - Leicester Corporation Tramways & Track? 100 lbs per yard 1903, I George Maybey? MICE Engineer 11 - Ipswich Tramways 90 lbs per yard, 1902, Dick Kerr & Co. Contractors London Shows the type of tramway rail and cross section produced by The North Eastern Steel Co early 1900's, the relationship to the British Standard and who used them. Provenance of the item not fully known. Possibly given to the Electric Supply Co of Victoria at the time when they would have been ordering rails for use in Ballarat. May have been collected by other parties.Plywood sheet, covered in black cloth displaying 11 different British Standard Rail Sections made by The North Eastern Steel Co. Ltd. Middlesborough , early 1900's. Each section secured with two 20mm (¾”) long, 3mm dia (1/8”) machine screws, countersunk with a slotted head from the rear. All nickel plated on both sides, engraved as to the tramway used on, date of production on the head of the rail, Designing Engineers on the web and the manufacturer on the foot of the rail. Cloth secured with staples and drawing pins on the rear. On the rear is a chalked sign, the principal one being "No Thoroughfare"Engraved as listed.tramway rails, rails, tramways, north eastern steel co, middlesborough, walthamstow, bath, burton on trent, swindon, wigan, derby, nottingham, kalgoorlie, leichester, ipswich, j g white & co, dick kerr

An antique machine made forged steel pulley block with a hook at the top which moves sideways. It has a slot on the cylindrical section for the rope or chain. It is an old farm tool from the 19th or 20th century.MAKERS PATENT SNATCHpulleys, tools, lifting equipment, pulley blocks, steel

This Cash Register was used for the sale and production of lift tickets, lessons and packages during the 1990s at Falls Creek. The employees who operated the machine were called 'Ticket Tarts'. This item is significant because it was a critical part of the everyday operation of the chair lifts at Falls Creek.A large square cash and ticket machine with buttons and slots for the production of lift tickets. Long cable connected to the back. snow, ski season, ski pass, ski lessons, ticketing, sales

Projector was used at Christ Church Anglican Church Mitcham (now All Saints Mitcham) for showing film strips to the congregation, Sunday School and youth groups.Early 'Shelton' film strip projector in a steel grey painted and hinged metal case with carrying handle. Projector has been finished in a 'hammered' meta paint with a large transformer as its base. It is a 240 volt projector. The film strip is manually rolled through the slots of the projector to show each frame separately. Project lens is adjustable for focus and it has a small angle of adjustment foe aligning the image on the screen.Shelton Projector Made in Australiaphotography, projectors

A cartoon of the 1930s titled "The Clancy Kids" of a boy dropping his pennies down the cable tram slot. Calls on Mr Timmie to help who responds with a comment regarding a vending machine. If you dropped a coin or a small item down the slot, there was no way of retrieving it.Demonstrates the peril of cable tram slots and lost items. Reproduction of a cartoon onto a display paper.tramways, cable trams, cartoon, cable slot, pennies

J. Mann and Sons was first established as a farm produce store in 1921. The range of products was extended in the 1930s and included groceries and hardware, as well as the first petrol bowser in Wodonga outside the store. After WWII, the premises were extended and the range of products continued to increase. In the 1960s the Mann Family opened a new supermarket in Wodonga, in addition to the hardware business, providing steel, plumbing and industrial supplies, and they employed over 100 people at one stage. With changes in the retail industry, the Mann Family sold the main hardware business to Bunnings and the steel and rural produce business to the Kelly brothers in 2006. Paragon, trading at various times as Lancom Paragon, Moore Paragon, Paragon Printing and the South Pacific Print Group, was also based in Wodonga from 1958 until 2010. It began as Lamson Paragon in 1958 but was destroyed by a fire causing £150,000 damage. The factory resumed operations on 24 June 1959.with 30 staff and by 1973 employed 120 and used 80 tons of paper per week. Further develp[ment took place to the factory in 2 stages. In 1977 Moore Corporation of Toronto took over control of the London based parent company Lamson Paragon necessitating a change of name of the Australian company to become Moore Business Systems Australia Limited. After many successful years of operation including expansion to a staff of 240 people, changes to business operations and the loss of several large contracts led to the company entering voluntary administration in March 2010.This machine and docket has local provenance as it came from the 20th century business of J. Mann & Son in Wodonga..The machine was manufactured by Paragon, also operating as Lamcon Paragon and Moore Paragon, which were a major manufacturer in Wodonga from 1958 until 2010.This is a grey rectangular-shaped metal box with rounded edges. The box has four metal studs on the base to keep the box stable. The box has a hinged section to enable paper dockets to be inserted. It also has a turning mechanism for removing the dockets, one at a time from a slot at the top of the machine. The machine includes a docket from Mann Mitre 10 Wodonga operated by J. Mann & Son Pty. Ltd. The dockets provided a duplicate copy for the company as well as the white copy for the customer. The dispenser and dockets were produced by Paragon.At top of dispenser: "Paragon" Across top of docket: "J. MANN & SON Pty. Ltd. (Incorporated in Victoria) TRADING AS: / Manns Mitre 10/ P.O. BOX 141, VIC., 3690. Phone: (060) 24 4813paragon, lamson paragon, moore paragon, mann wodonga, moore business systems australia limited
