Produced by the SEC (Geelong Electric Tramways) to document the trackwork at the junction of Aberdeen and Pakington streets in Geelong.Yields information regarding the construction details for the trackwork at the junction of Aberdeen and Pakington streets.SEC drawing no GE-T1-6234, "Trackwork at Junction of Aberdeen St. and Pakington St.". Drawn 25/03/1947. Beige paper copy of original dyeline print. Copy of original.provincial tramways, geelong tramway, state electricity commission of victoria

Black and white photographRingwood Railway Station. 1999 trackwork

Photo shows the installation of new special work or junction at High St and Brighton Road at Carlisle St St Kilda 17/3/1974. The work was part of the major road widening project of High Street between St Kilda Junction and Carlisle St with the trams relocated into their own reservation. The track was raised 18 inches or about 450mm above the previous road level. The track was brought into use on Monday 18/3/1974.Yields information about the installation of a new junction in 1974 and the methods used.Photograph - Trackwork High St St KildaDetailed description on rear. K S Kings stamp and photo number 130-20. tramways, high st, carlisle st, trackwork, brighton road, junctions

Photograph shows a group of about 15 men laying track at the corner of Victoria Parade and Nicholson St as part of the Bourke St reconstruction project 1955, looking south west. Note the rail in the foreground is of the bolt on check type. Yields information about the installation of the special work at Victoria Parade and Nicholson St during 1955. Black and white photograph with notes on the rear.In pencil - "Special trackwork in position at intersection of Victoria Pde & Nicholson St. Bourke St reconstruction"mmtb, trackwork, victoria parade, nicholson st, special works, track construction, rails, tramways

Colour photographs of the upgrading of North Port Station trackworkstransport - tramways, north port station

Set of two colour slides showing the intersection of St Kilda Road, City Road and Sturt Street. City Road at the start of work to lower City Road under St Kilda Road. The tracks along Sturt Street had been diverted by Nolan Street (now Southbank Blvd). The photo shows that only one of the tracks had been brought into use, the other still under construction. Photography by Warren Doubleday.Yields information on the start of the works to lower City Road under St Kilda Road 1-8-1970Set of two Anscochrome colour slides, of trackwork to place City Road under St Kilda Road. .1 - SW6 959 on St.-Kilda Road deviation - shows the Arts Centre and the scale of the deviation. The former tracks into City Road and Sturt Street can be seen in the foreground. .2 - SW6 878 - shows the Arts Centre, YMCA building the intersection with City Road and Sturt Street Has photographers slide numbers on each slide.trackworks, sturt st, sw6 class, tram 959, tram 878, tramways, track, city road, st kilda road, trams

Yields information about depot trackwork from Wendouree Parade prior to its closure in 1971.Black and white photograph of the SEC depot entry trackwork from Wendouree Parade looking towards the depot. Photo c1971. trams, tramways, depot, secv, wendouree parade, trackwork

Produced by the SEC (Geelong Electric Tramways) to document proposed widening of trackwork at Aphrasia St in Newtown and relocation of trackwork between Pakington and Pleasant St.Yields information regarding the construction details for proposed trackwork in Newtown and between Pakington and Pleasant streets.SEC drawing no GE-T1-6247, "Proposed widening of Aphrasia St - Newtown. Relocation of Track between Pakington St. and Pleasant St.". Drawn 12/09/1947. Beige paper copy of original dyeline print. Copy of original. Original had piece missing on right side and tape repair on bottom edge.provincial tramways, geelong tramway, state electricity commission of victoria

The photograph shows the demolition or removal of the cable tram track at an un-identified location, showing the removal of the yokes and track where two cable lines crossed over each other. Shows the former cable tram yokes that supported the slot rails and some details of the cable tunnels and pits. The man in the bottom left could be cutting the yokes with an oxy-acetylene cutting torch. In the view are at the top of the photo some rails can be seen. There were a number of points where the cable tram crossed other electric or cable tram lines. Given the small work site and men involved the location could potentially be either Johnston Street and Smith Street or Johnston St and Nicholson Street. The 1955 Annual Report notes that work commenced following the completion of the Queen's visit in March 1954 and that all work was done by day-labour. Photographer is possibly Keith Kings.Yields information about the extent of work need to convert the former Bourke St group of Cable tram lines to Electric trams, the people, the extent of the original construction and the methods used to undertake the work.Photograph - Black and White - demolishing cable tram trackwork where two cables crossed over each other, 1954/55.trams, tramways, cable trams, workmen, mmtb, demolition, track work, conversion, smith street, fitzroy, johnston street, nicholson street

Set of three colour photographs of testing the installation of screw spikes in the depot trackwork prior to the Wendouree Parade trackwork. Photos taken on 8/3/2003, printed on AGFA paper. 2554.1 - Gary Wood, John Shaw and Alan Snowball as a group. 2554.2 - Screwing a spike in with motorised impact tool. 2554.3 - Using an electric impact tool.trackwork, screw spikes, depot fan

Yields information about activities at the SEC Ballarat depot and derailments there.Set of 2 colour slides - Agfa blue and white plastic slide mounts of cleaning track at the SEC depot junction. .1 - cleaning Trackwork at the SEC depot junction with a tram in the background - slide not in focus. .2 - ditto, with the depot toilet block in the background - shows the many derailment marks in depot Trackwork. Photo from the collection of Lilian Butler. ballarat, tramways, trams, sec, depot junction, derailments, trackwork

Prepared by the City of Brisbane for the design of trackworkYields information on the design of trackwork.Set of nine City of Brisbane Tram Track drawings .1 - PPW91 - Standard Crossover left hand - 4'6" between tracks .2 - PPW2450 - Data for British Standard Crossings .3 - PPW 241 - Data for British Standard Lateral Switches .4 - PPW 463 - Concrete Track Construction is 102.73lb rail. .5 - PPW 501 - ditto for AS 82lb rail and other rails .6 - Not numbered - Concrete roads when using T rail sleepers .7 - PPW 575 - 150' radius RH crossover - 5' between tracks .8 - PPW 576 - 150' radius RH Crossover - 4'6" between tracks .9 - PPW 577 - 150' radius LH Crossover - 5' between tracks - 14/12/1948trackwork, points, switches, bcc transport, tramways

Photograph shows MMTB Scrubber 8 in Malvern Road following trackwork. Photo 11/71Yields information about MMTB Scrubber tram 8 being used to clean the rail head.Colour slide - Kodak cardboard mountHas in pencil slide number "18/71/35"tramways, scrubber tram, tram 8, malvern road

Produced by the SEC (Geelong Electric Tramways) to document curved trackwork at corner of Mercer St & Latrobe Terrace.Yields information regarding the construction details for curved trackwork at corner of Mercer St & Latrobe Terrace.SEC drawing no GE-T1-6217, "Curve at corner of Mercer St & Latrobe Terrace.". Drawn 12/09/1947. Beige paper copy of original dyeline print. Copy of original. Document signoff in bottom righthand corner.provincial tramways, geelong tramway, state electricity commission of victoria

Set of 3 pamphlets or hanging notices to around tram handrails, cut out advised of the changes to services due to tramway or other works. .1 - Route 96 - 30 May to 7 June 2016 - for the reconstruction of Acland St. .2 - Route 96 - 9 Dec to 20 Dec. 2017 - for trackwork - Clarendon St Jtn and St Kilda. .3 - Route 86 - 2 June to Monday 4 June 2018 - for trackwork between Parliament and Clifton Hill Interchange.trams, tramways, clarendon st, route 86, route 96, trackwork, acland st, bus replacement, notices and information, tram 3521

Series of 3 black and white photographs of:- .1 - construction of the trackwork for the new Maribyrnong River Bridge, has the temporary track on the left hand side of the photograph. Has the Express Freight Transport building in the background. .2 - as above, appears that the track on the northern side is almost completed. An Inspector is standing watching the work. This work was completed mid 1967. .3 - construction of trackwork possibly the curve from Gordon St to run alongside now River St. This work was undertaken during 1954.Some photos have pencil marks on rear.trams, tramways, trackwork, rails, track materials, track repairs, sleepers, equipment, maribyrnong river bridge, bridges, gordon st, river st, footscray

Set of two 35mm Kodak white cardboard colour slide by Keith Kings of 5/5/1968 .1 - construction of new curves from Fitzroy St and High St into St Kilda Road. Shows the old junction trackwork and road height differences. Note the temporary tram stop. .2 - ditto, shows the trackwork for High St behind the hotel and the Junction Hotel with a large Dunlop sign and Rothmans cigarette advert. See Keith's slide notes.Keith Kings stamp and number "23-27 and 23-28", with details of exposure. .1 - St Kilda Jtn by pass work. installing new turnout for Fitzroy St. In new track, New level is lower. Old curves replaced after a day's work to all normal service to resume during weekdays. .2 - St Kilda Bypass work. Installing new turnout for Fitzroy St. In new track looking south. Old Jtn out of photo to the left. New concrete track ready at rear on right. Hotel (which will remain in the middle of everything!!)trams, tramways, st kilda junction, fitzroy st, st kilda rd, trackwork, high st

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork at the Geelong Railway Station.Yields information regarding the location of trackwork around the Geelong Railway station.Geelong Tramways drawing, "Plan of Geelong Railway Station and Approaches.". Drawn 1920s. Beige paper copy of original dyeline print.Copy of original.provincial tramways, geelong tramway, melbourne electric supply co. ltd., geelong railway station

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork across the Barwon Bridge.Yields information regarding the construction details for the trackwork across the Barwon Bridge.Geelong Tramways drawing no GE-T1-6202, "Sketch plan showing proposed track over the Barwon Bridge.". Drawn 06/04/1922. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd., barwon river

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork at the Geelong Railway Station.Yields information regarding the location of trackwork around the Geelong Railway station.Geelong Tramways drawing, "Plan of Geelong Railway Station and Approaches." Drawn 1920s. Original drawing on tracing paper. Original drawing on tracing paper.provincial tramways, geelong tramway, melbourne electric supply co. ltd., geelong railway station, mesco

Set of 2 colour slides showing the completed depot extension building and trackwork that was underway at the time of the photo on 26/8/1980.Yields information about the construction of the BTPS Depot extensions and the trackwork being built to service it.Set of 2 Kodak colour slides in cardboard mounts.Have photographer's reference number written on the slide.btps, depot extensions, trackwork,

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork details of the Ormond Road loop.Yields information regarding the construction details for the new loop trackwork at Ormond Road in Geelong.Geelong Tramways drawing no GE-T1-6235, "New position of Ormond Road loop.". Drawn 20/09/1932. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork at corner of Malop St & Mercer St.Yields information regarding the construction details for the trackwork curve at corner of Malop St & Mercer St.Geelong Tramways drawing, "Curve at corner of Malop St & Mercer St.". Drawn 05/05/1926. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork for Car Shed tracks 4 & 5.Yields information regarding the construction details for the trackwork for a single junction for Car Shed tracks 4 & 5.Geelong Tramways drawing no GE-T1-6213, "Single junction for Car Shed tracks 4 & 5.". Drawn 27/09/1923. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork drainage between Myers St and Boundary Road.Yields information regarding the construction details for the trackwork drainage between Myers St and Boundary Road.Geelong Tramways drawing, "Drainage of East Geelong Track between Myers St and Boundary Road.". Drawn 21/03/1923. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork for the Ryrie St duplication and temporary cross-over.Yields information regarding the construction details for the trackwork for the Ryrie St duplication and temporary cross-over using 80lb Tee Rail.Geelong Tramways drawing no GE-T1-6211, "Ryrie St duplication. Temporary cross-over using 80lb Tee Rail.". Drawn 16/04/1923. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork details at corner of Latrobe Terrace and Glenleith Avenue.Yields information regarding the construction details for the curved trackwork at corner of Latrobe Terrace and Glenleith Avenue in Geelong.Geelong Tramways drawing no GE-T1-6218, "Curve at corner of Latrobe Terrace and Glenleith Avenue.". Drawn 22/07/1920. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork details at corner of Garden St and Ormond Rd.Yields information regarding the construction details for the curved trackwork at corner of Garden St and Ormond Rd in Geelong.Geelong Tramways drawing, "Curve details at corner of Garden St and Ormond Rd.". Drawn 27/01/1922. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.

Produced by the Geelong Tramways (Geelong Branch of Melbourne Electricity Supply Company Limited) to document the trackwork details for the proposed Loop in High St. Belmont.Yields information regarding the construction details for the proposed loop in High St. Belmont.Geelong Tramways drawing no GE-T1-6231, "Proposed Loop in High St. Belmont.". Drawn 09/01/1930. Beige paper copy of original dyeline print. Copy of original. provincial tramways, geelong tramway, melbourne electric supply co. ltd.
