Tramcar component - window lifter - cast brass fitted with a leather piece to enable a person to lift the window. Fitted to cable car trailers. Included are two brass slotted head screws. Appears to have a silicon seal around the brass stud on the rear. Collected as a sample - see history of object.trams, tramways, cable trams, windows, trailers, components

Tramcar component - possibly locking key - made from two pieces of cut steel and welded together and finished. A known unknown! Kym Smith advised - "11/6/2020 - It looks familiar, but I can’t recall exactly. I think is used as a locking pin to hold an internal panel in place, possibly the internal panels/frames that are on the interior side of the sliding doors, with the pin going through the top sill into the internal frame?" and 13/6 " I remember somewhere seeing a panel that has pins in the bottom that locate in holes in the floor, then the panel is pushed into place and the securing/locking pin used to hold it in place, with the panel having a square saddle that the pin goes through. I’m wondering if it is a kick panel under a seat? "trams, tramways, tramcars, components

Brass door roller from a former Melbourne cable car trailer - numbered 2 222 - probably No. 2 end of trailer No. 222. Consists of a large cast section for attachment to the top of the door, roller wheel and axle. Cable trams commenced in 1885 and by 1891 there were 350 sets. (see reference) See p79 of "Mind the Curve", John D.Keating re number of tram built by 1891.melbourne, cable trams, door roller, tramcar component

Made by Duncan and Fraser for fitting to horse-drawn tramcars and possibly other products of their Adelaide workshops. See 565 and 8744 for other examples.Demonstrates Duncan and Fraser's workshop practice of putting their name on some fittings.Duncan and Fraser, Adelaide SA window lifter or bracket to enable a horse tram window to be lifted in the window frame. Cast brass, about 40mm in diameter with a right angle lug to enable a person to lift the window. Words "Duncan & Fraser" cast around the outside of the device and the words "Adelaide S.A." cast into the centre. Has been drilled with three countersunk holes. Has brown paint on the lifting portion. On the rear, possibly the letters "5L", scratched into the metal. If this is the case, could have indicated the fifth left hand window as an identification of location. Given to the BTM 1995 by Doug Prosser, of the TMSV, said to be from Ballarat Horse Tram No. 1 horse trams, duncan & fraser, window furniture, tramcar component, tramcars, tramways

Bell portion of a tramcar conductor's bell. Approximately. 100mm diameter, about 35mm deep with a raised or bossed hole at the top 4.5mm at the top. Bell possibly cast or pressed brass, appears to have been damaged or repaired due to excess brass in portion of the bell and on the underside where signs of brass welding are apparent. If from a horse tram, would have most likely been made by Duncan and Fraser of Adelaide SA. Given to the BTM 1995 by Doug Prosser, of the TMSV, said to be from Ballarat Horse Tram No. 1. horse trams, duncan & fraser, conductors bell, tramcar component

Made by Duncan and Fraser for fitting to horse-drawn tramcars and possibly other products of their Adelaide workshops. See also items 2172 and 8744 for other examples.Tramcar component, Duncan and Fraser, Window lifter Cast brass window lifter, with raised letters - "DUNCAN & FRASER" on outside &"ADELAIDE S.A." inside circle. Has three mounting holes & rolled top edge to give a finger hold. Of type used on horse trams.DUNCAN & FRASER ADELAIDE S.A.windows, duncan & fraser, ballarat, tramways, tramcars, horse trams, window furniture, tramcar component, btm, ballarat tramways

Cast Aluminium Zinc?? alloy? Step plate for the use on tramcar steps - with raised "dimples" to provide a non slip surface. Has not be drilled with the holes for positioning the tramcar. one has number 758 on rear, the second 3758. Two number held.trams, tramways, tramcar component, preston workshops, castings, tram 829

Cast steel and machined Self Lapping air brake handle stamped "CAR 19". Could have been allocated to Freight car 19 or 19W.trams, tramways, brakes, tramcar component, preston workshops

Cast brass and machined handle used on tramcars fitted with air operated sliding doors.trams, tramways, sliding door tramcars, tramcar component, preston workshops

Made by Duncan and Fraser for fitting to horse-drawn tramcars and possibly other products of their Adelaide workshops. See also items 565 and 2172 for other examples.Demonstrates Duncan and Fraser's workshop practice of putting their name on some fittings.Cast brass window lifter, with raised letters - "DUNCAN & FRASER" on outside &"ADELAIDE S.A." inside circle. Has three mounting holes & rolled top edge to give a finger hold. Of type used on horse trams.DUNCAN & FRASER ADELAIDE S.A.tramways, tramcars, horse trams, duncan & fraser, window furniture, tramcar component, btm, ballarat tramways

Made by John Stephenson & Co. for fitting to the windows of the tramcars that they built such as horse cars or possibly cable cars. Very similar in style to that used by Duncan and Fraser for their tramcars.Demonstrates John Stephenson & Co's workshop practice of putting their name on some fittings.Set of 3 Cast brass window lifter, with raised letters - "JOHN STEPENSON & CO" on outside & "NEW YORK" inside circle. Has three mounting holes & rolled top edge to give a finger hold. Of type used on horse trams.tramways, tramcars, horse trams, window furniture, tramcar component, btm, ballarat tramways, john stephenson

Cartridge fuse - Tramcar Component - black Bakelite? with brass ends, possibly containing a powder given the weight and a fuse wire. Has remnants of a paper label around the centre. No details of the of the manufacturer or date. Type used for a compressor fuse. At one end has a diamond with a vertical bar through the centre and 10 stamped into the brass end - possibly a 10Amp fuse and possibly the manufacturer's symbol.fuse, tramcars, electrical engineering, electrical equipment

Hand brake pawl, possibly from a cable or horse tram, smaller than an electric tram version consisting of a cast or forged pawl with a forged, turned and threaded bolt, steel washer and nut. Components have been removed from very rotten wooden floor. Possibly c1900tramcars, brakes, handbrakes

The penel was recovered by the restorer of MESCo/SECV Geelong tram No. 2 and provided information about the paint scheme and layout. The Geelong tramway system closed in March 1956, No. 2 making its last run in January 1956. The body was subsequently sold to Phil Shoppee, a farmer at Murradoc on the Bellarine Peninsula. The farmer had used the tram body as a feed store, with this part placed up against a water tank or similar. This prevented it from being painted over. The panel shows the methodology of securing it to the tram body and the location of the lining and the emblem. The SECV logo or emblem dates from the formation of the SECV in 1921. The panel dates from the 1950s, possibly from a repaint after the side entry gates on the car were replaced by hinged doors in the mid-1950s. See reference.Yields information about the location of the lining and logo on the tram body and colours. One of the few original SECV logos formed from gold leaf in the Museum's collection.Sheet steel - treated - SEC green paint with a gold leaf SECV logo or emblemtrams, tramways, geelong, tram 2, secv tramways, logos, secv, emblems

Strip of aluminium cut and punched with three location holes or sections along the top edge - "Z3 Side Destination - Example Flip Piece". Z3's entered service in 1979. See Reg Item 3704i5 for an actual sample and 3704i4 for the destination equipment."Z3 Side Destination - Example Flip Piece" written in felt tip pin.trams, tramways, z3 class, mmtb, destination indicators

Bell cord - for a grip car bell - consisting of a wooden turned handle fitted with a screw at the bottom, a length of sash cord and a cast iron end to which the rope has been glued or fastened into.trams, tramways, cable trams, grip tram, gripmen, bell

Destination indicator equipment that was fitted to a C class tram - dot matrix style, set to the word "CITADIS" with inbuilt control equipment and computer control plugs. Installed within a metal box, with detailed wiring, plastic components and electrical components. Has a loose wire with two pin plug in the bottom left hand corner of the unit. Three labels on the rear control unit - no formal manufacturer name - perhaps DUHAMEL and other ID items.trams, tramways, destination indicators, c class, citadis, transport equipment

Set of six destination indicator equipment that was fitted to Z, Z3 and B class trams. .1 - dot matrix type destination sign fitted to the side of a B class tram - set at Preston Depot - serial number 232636 - Luminator type, back cover loose, 180H x 1300W x 100D. See images 3704i1a to e. .2 - dot matrix type route number fitted to the front of a tram, type fitted to B2 class tram, set at 86D, serial number 273644 - Luminator type, marked "163 No", 240H x 350W x 135D. See images 3704i2a to d. .3 - flipper type, side destination type, marked "ex 53" (Z class tram), made in Italy by Boselli has yellow label 37/702S, serial number 40A1603, set to St Kilda Beach and stamped 136 on one flange. 120H x 330W x 165D. See images 3704i3a to c .4 - flipper type, destination box, with markings "B'Wick Flaps", with labels "New" "Universal A flaps" made in Italy by Boselli, serial number 40A6623, set to St Kilda Junc". 210H x 1000W x 1900. See images 3704i4a to d. .5 - flap from an above type box, half of "Richmond" and "South Melb Depot", 970W x 80H. See images 3704i5a to b .6 - controller box, marked "No. 105" on rear, serial number 202311 Luminator, numeric pad, illuminated display and five control buttons made by gulton Luminator division fitted to a B2 tram. See images 3704i6a to b .7 - dot matrix destination sign fitted to the front of a B2 class tram, set to "Not in Service", Serial number 502626 Luminator, 220H x 1300W x 165D, See images 3704i7a to e. Source of items 3 and 4 name based on drawings held by the Museum for the destination signs fitted to Z class trams. Refer to drawing R11-982 as an example. Luminator made by Luminator Technology Group Texas - see https://www.ltgglobal.com/ access 12/7/2019. Imagetrams, tramways, destination indicators, z3 class, transport equipment, z class, b class

Glass chimney from a Melbourne Cable tram oil headlamp - base partly broken and top broken off and damaged - four fragments from original. Has a note that the lamp was restored by Alf Twentyman, later take by Norm Maddock for the Stanhope St Museum. Written by Robert Green Feb. 2015. The chimney has dirt marks on the inside. Item contained within a small box with packing and then a larger Torino Comfort shoe box with further packing and a note about the object.trams, tramways, cable trams, lights, headlights

A souvenir from one of the last trams to Port Melbourne. Both the South Melbourne and Port Melbourne cable lines closed on this date. The South Melbourne line was converted to electric traction; the Port Melbourne line was replaced by a bus service. See item 7595 for another bell cord from the same event.Has a close association with the closure of the Port Melbourne cable tram line.Bell cord - for a grip car bell - consisting of a wooden turned handle fitted with a screw at the bottom, a length of sash cord and a cast iron end to which the rope has been glued or fastened into and a hook that went on the underside of the bell itself. On the wooden handle is a label - "Cable tram cord taken from the last tram to run in Port Melbourne"trams, tramways, cable trams, grip tram, gripmen, bell, port melbourne, last tram, closure

Bell - conductors - cast brass circular with a square hole in the centre, polished on one side and rough cast on the inside. Part of a conductors bell.trams, tramways, bell, conductors, tramcars, equipment

Written on the handle in pencil "The dear old "PM" cable trams passed away March 13, 1937" - a souvenir from one of the last trams to Port Melbourne. Both the South Melbourne and Port Melbourne cable lines closed on this date. The South Melbourne line was converted to electric traction; the Port Melbourne line was replaced by a bus service. See item 5556 for another bell cord from the same event.Has a close association with the closure of the Port Melbourne cable tram line.Bell cord - for a grip car bell - consisting of a wooden turned handle fitted with a screw at the bottom, a length of sash cord and a cast iron end to which the rope has been glued or fastened into.On the wooden handle a note has been written in pencil.trams, tramways, cable trams, grip trams, bell, port melbourne, last trams, closure.

Set of destination indicator equipment that was fitted to Z3 and A class trams. Each item consists of various electronic parts contained within a metal case that could have been cabled together. Equipment manufactured by (Carl) C. Brose of Wuppertal Germany and maintained by Font Electronics of Melbourne - some items have the manufacturers details on them along with the details of the maintenance company and serial numbers etc. Photo .1 - shows the set of equipment as placed on display in the training room. .1 - set of two route number boxes, three individual controlled blinds, driven by a motor and control gear. Has a Fluro light fitted internally. See images .2 to .5 .2 - Small side destination indicator, with driven blind, electronic equipment with motor on the underside of the box - for use in Z class trams - see images .6 to .9 .3 - as for .2, but with motor mounted right side, used in A class trams, see images .10 to .12 .4 - set of two control panels with selection equipment for selecting the destination (by number) and route number with indicators and start button - see image .13 to 14 .5 - set of two long main rolls indicators, with control gear and Fluro light internally, driven by an internal electric motor - see images 17 and 18 .6 - set of two linking mechanism for the various boxes with large cables cut off for each of the four tram boxes. Would have been control panel item .4 - see image 15 and 16. See e-mail from Simon dated 17/11/2014. See reg Item 4617 for a small side destination roll.trams, tramways, destination indicators, a class, z3 class, transport equipment

1 - cast brass hanger with a screw hole on each side and a formed opening for the bell cord to pass through. 2 - as for .1, but with the letters "J S" on top of the formed opening - John Stephenson and Co of New York. These items were from the three recovered cable tram bodies that the BTPS / BTM dismantled over the yearsSet of two brass bell cord supports from Melbourne cable trams..bell cord, john stephenson, cable trams, mto co, mmtb

Black and White photograph of a interior saloon step plate of a Bendigo single trucker, advising that it was built by Duncan and Fraser of Adelaide. Photo by George Bishop 12/1971.On the back of the photos in ink on a label "Step plate indicating tram builder Duncan and Fraser Adelaide SA. Photographed December 1971, Bendigo Victoria" and "Photo G. Bishop" in penciltramways, trams, bendigo, duncan fraser, tramcar component

Black and White photograph of a interior sign or notice in a Bendigo tram - advising passengers that it is the Conductors duty to issue a check for every fare received and that it must be produced on demand. Photo by George Bishop 12/1971.On the back of the photos in ink "presumably Bendigo December 1971 SEC trams" and "Photo G. Bishop" in penciltramways, trams, bendigo, signs, tickets, tramcar component

Black and White photograph of a very faded and damaged SEC emblem / logo / coat of arms on the side of a Bendigo tram. Photo by George Bishop 12/1971.On the back of the photos in ink on a label "State Electricity Commission of Victoria coat of arms photographed December 1971 Bendigo" and "Photo G. Bishop" in pencil.tramways, trams, bendigo, signs, secv, logos, tramcar component

Framed logo - PMTT monogram or emblem - Saloon door glass (see donation document) that has been framed in a walnut finished frame with gold edge and further glazing. Was a broken part in one corner - bottom right hand. At the base three photographs have been provided - one of the original Malvern Tram depot building, PMTT No. 44 bogie car and the interior of a saloon of a PMTT tram. Has paper back with a hanging strip on the rear. Very heavy.trams, tramways, pmtt, windows, interiors, tramcars, tramcar component

Trolley Wheel - cast brass, fitted with a cylindrical bush in the centre. Used on Melbourne trams until the late 1950's when changed for trolley skids to bring the power from the overhead into the tram. Fitted to the end of a trolley pole with another cast item known as a hasp. Has been used. Used by Ballarat and Bendigo trams.trams, tramways, tramcar component, overhead, trolley wheels, trolley poles
