A bound volume of 365 pages outlining the development of the Wilson Transformer company, including illustrations, plans and photos. This book gives an in-depth history of the development of the Wilsons Transformer Company Pty. Ltd. from its inception in 1933 until 1983. In this period over 74,000 transformers have been produced from wilson electric transformer company - history, manufacturing industries wodonga, manufacturing australia

This transformer lamp system, which has a dial to transform 240 volts to a minimum of 32 volts was used by electrical technicians to inspect internal parts of the large generators (even in small confined spaces). The reason for the reduction of the 240 volts to the 32 volts was for the safety of the inspector. The SEC Victoria Hydro Scheme's electrical generators are powered by the hydro force of "stored" water at a higher altitude. The establishment of both the NSW and Victorian Hydro schemes was achieved from the mid 1900's to the 1960's. At this the point in time the need for additional power sources to quench both an industrial and domestic demand for electricity was purely an economic and not and environmental (carbon reduction) factor. This hydro scheme was instigated by "the Government of the day" as a bold move and was the major force of the World War II refugee and "technical" workforce inclusion of skilled and unskilled migration into the Australian environment. Although this mass "invasion" of workers with families was thought of in some circles as intrusive, the expansion of population post war years and its integration into the Australian rural sector, produced the multi- lingual multi-cultural diversity of later years.This transformer lamp is very significant to the Kiewa Valley as it was introduced as a very small part of the explosion of human resources into the valley. This influx of population transformed the region from that of a basically quiet rural region to one which evolved into both industrial and larger residential community. This evolution in the valley created a change, not only in the "physical" landscape but also the socio-economic expansion which permitted other "tourist" based industries into the valley. This is also a specific electronic item which was manufactured in Melbourne and not sourced from Europe or Asia. This demonstrates the fast evolution of Australian technology to a high standard compatible to that of the rest of the world.This heavy hand held electrical transformer (transforms 240 volts to 32 Volts) an has one leather handle on the top with three small (gauze filtered) air holes. It also has two 2 pin directional cable distribution (clipsal) in/out points 10amps / 240 volts. There is one glassed in volts/ac meter and one variable switch (180 to 150 voltage in settings of 10 volt increments.There are two vents (one on each of the smaller sides). There is also one three pin electrical lead coming out from the top.On one side is a manufacturer's plaque with "ELECTRONIC A & R EQUIPMENT MELBOURNE" and underneath "TYPE 1719, PRI V. 180 250" underneath "V.A. 1250" underneath "CYC 50" underneath "SEC V. 115" underneath "SEC A. 10 . 8". The label on topside "CAUTION SET SWITCH TO 250 v BEFORE CONNECTING TO MAINS THEN, WITH EQUIPMENT OPERATING, SET METER TO RED LINE.kiewa hydro electricity scheme, victorian state electricity commission, transformers

The SECV constructed the Kiewa Hydro Electric Scheme including the township of Mt Beauty. Text books were available for the workers.The books were used by the workers on the Kiewa Hydro Electric Scheme.Variety of text books some published by the SECV on the topics - 'Voltage Transformers' and 'Wiring Regulations'secv, voltage transformers, wiring regulations

Transformer with switchable voltage. Voltage ranges from 110 to 240. This means it can be in different countries. It has a 6 volt input for light/lamp. Made in 1940s. The core of the transformer is laminated steel, each layer insulated to stop from over heating. The transformer is still in working order.Transformer with switch for different voltage settings. Globe connected to unit. Universal transformertransformer, switch, voltage, light, laminated steel, insulated, switchable, universal

.1 - Book - 56 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Electrical Performance of Large Electric Generators and Motors - Continuous Maximum Rating" - C36-1927, May 1927 with a green label dated September 1932 advised that the tentative standard has been endorsed as a Standard with amendment. .2 - Book - 48 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Electrical Performance of Alternators of the Steam Driven Type" - C38-1927 - December 1927 with a green label dated September 1932 advised that the tentative standard has been endorsed as a Standard with amendment. .3 - Book - 32 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Electricity Meters" C39-1927, August 1927. .4 - Book - 28 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Pressboard for Electrical Purposes" - C40-1927, January 1927. .5 - Book - 24 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Hard Drawn copper stranded circular conductors for overhead power transmission purposes" C41-1930, August 1927, with a green label dated October 1932 advised that the tentative standard has been endorsed as a Standard with amendment. .6 - Book - 48 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard "for Indicating Ammeters, Voltmeters, wattmeters, frequency and power factor meters" - C42-1927 - December 1927, with a green label dated October 1932 advised that the tentative standard has been endorsed as a Standard with amendment. .7 - Book - 32 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Tentative Australian Standard - "Instrument Transformers" - C45-1928, June 1928. .8 - Book - 28 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Australian Standard "Liquid Starters for Electric Motors" C46-1927, December 1927. .9 - Book - 20 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Australian Standard "Star Delta switch starters for Electric Motors" C47-1927, December 1927. .10 - Book - 24 pages + grey covers, side stapled, issued by the Australian Commonwealth Engineering Standards Association, Australian Standard "Multiple switch starters for Electric Motors" C48-1927, December 1927. On top right hand corner has the date stamp of the "The Electric Supply Co. of Victoria Ltd Ballarat" trams, tramways, power station, standards, materials, electrical systems

Information from Norman F. Dalton: Ballarat had a reticulated DC supply in the early part of last century and in 1905 had sufficient generating capacity to enable the trams to be changed from horse drawn to DC electricity. The use of electricity increased with the main power station located on Wendouree Parade, near Webster Street, under the ownership of The Electric Supply Company of Victoria. AC generating plant was installed in 1925 and conversion to AC proceeded. In 1934 the company was taken over by the State Electricity Commission Victoria (SECV) and more AC generation was installed and the changeover of customers was accelerated. This is around the time that the Synchronome Frequency Checking Mast Clock was installed at the Wendouree Parade Power Station. The SECV Annual Report of 1921 states: ::Section 11 of the act directed the COmmission to enquire into the question of securing the adoption of such standards of plant and equipment of a system, frequency and pressure for the generation and distribution of electricity as will admit of the efficient interconnection of undertakings throughout the State. In 1934 when the SECV took over the Ballarat operations the question of linking with the State grid had been a planned operation for some years but due to financial considerations had hindered it and in fact would continue to do so for a further 10 years. So while the need for close frequency control for interconnection was hardly an issue, the need to keep electric clocks correct was important, particularly as this item was a frequent sales point to cover the inconvenience and sometimes expense of converting from DC to AC. The clock is a very accurate pendulum clock with provision for varying effective length during operation for precise time regulation. There are two normal time dials and one is controlled by the pendulum and the other is operated by the system frequency. When the clock was in use it was installed by the MEter and Tests Laboratory and the time was checked daily by radio time signals. The two dials were repeated in the operators control panel in the Power Station. A maximum deviation between the two dials was set in the operating instructions (eg 5 seconds) and the operator would correct this when necessary by remote manual alteration of the turbine governor set point. The clock was used to drive and regulate a system of "slave" clocks which were used to display the time in various locations around the power station. A slave clock is a simple clock which is driven by a small electric motor, its accuracy is regulated by the master clock every 30 seconds to ensure that it and all the other slave clocks in the station are on exactly the right time; slave clocks were placed in various locations, from common rooms to workshops. A master clock could potentially run thousands of slave clocks at one plant. The clock also contains a rectifier. A rectifier is a device that is used to convert AC power to more stable DC current.Two clocks in a timber case. Both are electric, one is powered by the main pendulum mechanism, the other is a self contained electric clock. The main mechanism is of the gravity arm and roller type, which sends an impulse to the slave clocks every 30 seconds. The This Synchronome Frequency Checking Master Clock was used at the Ballarat Power Station. Below the main section of the case is a smaller cabinet containing a rectifier to provide consistent DC power for the clock. The rectifier was made by the Victorian company Hilco, which was located in Burwood. There is a high chance this is not the original rectifier from this clock as there appears to be brackets to hold a larger device in the space the rectifier occupies.Front below main clock face on front of case: "Patented Sychronome Brisbane" Lower left-hand clock face: "Frequency time" Lower right-hand clock face: "Standard Seconds" Synchronous electric clock mechanism on door (Frequency time clock): >200/250 V. 50~ >"Synchronomains" Made in England >Direction indicator for clock starting switch >"To start move lever in direction of arrow and release" >"Patent applied for" Mechanism for "standard seconds" clock: >"English Made" >"Patented" >Serial number "321" >0 above right-hand pillar on front-plate Mechanism for "standard seconds" clock: >"English Made" >"Patented" >Serial number "321" >0 above right-hand pillar on front-plate Mechanism for main clock face: >"English Made" >"Patented" >Serial number "8751" >0 above right-hand pillar on front-plate Inside case, back panel, top enamel plate: >Seconds Battery + Pos. > Battery Common or - Neg. >1/2 min dials Inside case, back panel, bottom enamel plate: external seconds dial Inside case, right hand side, electrical knobs: two switches, both "A.C. mains" Pendulum rod, below suspension spring: Serial number (?) 0000005 Rectifier in bottom cabinet: >"Hilco Rectifier" >"A.C. Volts 230/240" >"Model 1060/S" >"A.C. Amperes" >"Serial No. 1060/S >"Phases 1" >"D.C. Volts 6" >"C.P.S. 50" >"D.C. Amperes 1" >"Made in Australia by Hilco Transformers McIntyre St., Burwood, Victoria." Bakelite electrical plug: makers mark Lower cabinet, RH side panel, pressed tin plate: "AC" (upside down) Brass speed adjustment, outer right RH side: "S" and "F" Ivory and wood pendulum beat ruler: >Ruler, with 0 in centre and numbers 1-5 in ascending order from centre on left and right. > "Synchronome Patent." Steel plate, back panel, inside case, right hand side: >N R A" (descending) >"2191" serial number/part number Face of main clock: "Synchronome Electric" synchronome frequency checking master clock, electricity, state electricity commission, wendouree parade power station, secv, clock, time, pendulum, electric supply company of victoria, norman f. dalton, ballarat power station, rectifier, slave clock

The unit was used at Ballarat School of Mines in the Maths, Science and Physics Departments.Grey metal unit with Dials on the front and vents at the back. Handles for carrying. Two circuit breaker switches, two DC output sockets, two AC output socketsYellow sticker - SMB - with number 116069. Engraved on back - S.M.B.. Maths / Science / Physics Sticker on cord indicating inspection of unit - 13/04/2005. Tag Number - 032725alternating current, direct current, ac, dc, electrical, ballarat school of mines, science, maths, physics, ac/dc, scientific instrument

large technical drawings .1) Transformer sub-station Job No 1 A.466 .2) Pole type transformer sub-station (SEC) A.1934-1 .3) Transformer sub-station Job No 1 C.46 Ballarat School of MInesballarat school of mines, technical drawing, transformer substation diagrams, r. downey, j. downey, a. richards

Black and White Photograph of a transformer face plate for a British General Electric transformer for use in Mercury Arc Rectifier Equipment, made 1950. Provides details of the transformer capacity, ratings and wiring diagram. Made at the EPM Works, Waterloo NSW.trams, tramways, transformer, mercury arc, substation, electrical equipment

Yields information about the construction of the BTPS sub-station at the depot.Set of 3 AGFA blue and white plastic mount 27mm square slides of work on BTPS isolating transformer and sub-station and depot storage - c1974. See btm3017 for other photographs. .1 - Frank Hanrahan working on the transformer with one his son's observing. .2 - ditto .3 - Main switch and transformer in position. Various notations by John as to the slide number and the trams in pencil and ink.tramways, trams, btps, substation, depot, electric traction, electric failure

Set of two brass manufacturing / data plates from the BTM Isolating transformer that failed Oct. 2004 and sent to ABB's Yarraville Workshop for assessment. Recovered from the transformer by ABB staff following inspection. Plates detail Manufacturer (State Electricity Commission of Victoria), ratings, connection diagrams, windings and date of manufacture (1931). These plates did not reflect the re-winding characteristics, but its original manufacturer. Transformer No. 1267. Each plate has four corner holes. Transformer acquired by the BTPS 1973 for re-winding from the SEC. See Reg. Item 3018 for transformer photographs at ABB workshops. tramways, trams, btps, substation, depot, electric traction, electric failure, sec

Versabraille system is a self-contained braille information system for use with audio cassettes for reading and writing braille. The controls include an eject button, variable audio speed and volume sliders, braille control keys for writing, editing, and audio record/playback, a 20-character braille display with text advance bar, text backup key, text access keys for chapters, pages, paragraphs or words, a place indicator, an "add new chapter" key, and a pair of buttons with unknown function. The unit takes ordinary audio cassette tapes. On the back is a 24-contact IB/P connector, a pair of connectors of unknown function, and a power connector for the included 120V power adapter. Light brown coloured plastic square object with brown covering box and transformer with cord Versa Braille system Tele Sensory Systemsbraille equipment, equipment

The second version of the Versabraille system, which appeared in 1987, reflected the change from cassette to floppy disks and an enhanced method to produce 128 standard ASCII characters. Light brown coloured plastic square object with brown covering box and transformer with cord TSIbraille equipment, assistive devices

Four page colour laser printed document presenting photos of the BTM Isolating Transformer, following its failure, at the ABB's Yarraville Workshop, on 8/11/2004. Photos taken with a digital camera. Document prepared using MS Word. Shows transformer in the partly dismantled state. Note - not all images used in the document. Two copies held. Ten digital images held on file. See Reg. Item 3230 for transformer plates. btps, substation, depot, electric traction, electric failure

Yields information about the delivery of the installation of the wooden poles around the depot fan in June 1973. Has a strong association with those involved.Set of seven black and white photographs of the delivery and dismantling of the transformer to be reworked as the isolating transformer for the depot. Date possibly 16 June 1973 - based on the list of dates in the 1972 - 73 Annual Report. Photographer Eldon Hogan. See also Reg Item 4759 for colour slide photographs.trams, tramways, btm, construction, overhead, substation

Set of eight colour slides of the delivery and dismantling of the transformer to be reworked as the isolating transformer for the depot. Date possibly 16 June 1973 - based on the list of dates in the 1972 - 73 Annual Report. Photographer Eldon Hogan, AGFA Slide, blue plastic with white plastic on reverse. See also Reg Item 4761 for black and white photos.tramways, trams, btm, construction, overhead, substation

This resistor was part of the Hydro generator control metering system which displays what electricity is produced at the underground generators. The control centre can be hundreds of meters above the generators and this resistor reduces the large current to a small voltage entering a calibrated control monitor. This resistor is highly significant to the Kiewa Valley because it represents a major construction and ongoing operational industry dealing with the supply of hydro electricity to Victoria. Although it is relatively small in size it is part of the controlling mechanism for the supply of a non polluting energy source for home and industrial use.This mainly metal and wire resistor has been built of copper and brass and designed to carry a current of 2000 Amperes. Wires are wound around a non conductive cement block which has grooves on the top and bottom ledges to hold the wires snuggle into place. At the rear there are three connection rods which have long 5mm thick screws (to fasten cable ends)On one side it is scribed "0.2 OHMS" and underneath this "10 AMPS"kiewa hydro electricity scheme, victorian state electricity commission, transformers

Set of 15 Digital Images of the aftermath of the sub-station repairs, wiring it up and the installation of the isolating transformer taken between 11/12/2004 and 18/12/2004 .1 - Garry Wood with some concrete for the substation floor .2 - Alan Snowball and Paul Mong laying the floor. .3 - Part of the Switchboard modified to position the new Isolating Transformer .4 - ditto .5 - the Transformer arrives - 15/12/2004 .6 - being positioned in the depot .7 - the manufacturers plate - Illawarra Transformers Wollongong .8 - unpacked .9 - being positioned .10 - In position .11 - the door to no where - the platform across to the store and archives yet to be built .12 - some of the equipment installed but found not to be suitable for the purpose. Was ex an PTC sub .13 - wiring it up .14 - Paul working .15 - the new control panel. trams, tramways, btm, substation, testing, isolating transformer

Newspaper clipping from The Courier, 27/12/2004 titled "Boxing Day trip down memory lane". Photo of Peter Winspur driving No. 27 across Wendouree Parade to start the resumption of services following the installation of the replacement Isolating Transformer. Article written by Monique Patterson. Article notes the 30th anniversary of BTPS/BTM Operations, transformer, fund raising and tram services.btm, substation, reopening, 30th anniversary

Steel, aluminium, plastic and copper. Transformer used to reduce current from 240 to 110 volt for use with tenetyps machine. Iten painted in non reflective grey. 6 electrical plugs on front.Label on back of item - Gordon & Joy Garbott. 64-66 Poldfett Street, Darystock. Vic 3992signals, transformer

Used in the Ballarat School of Mines and Ballarat Institute of Advanced Education Physocs Laboratories. Both are predecessor institutions of Federation University Australia. A "late model" manual beam balance, with mechanically applied milligram masses and optically displayed balance point. Built into a resowood frame cabinet. Complete with: .2) light source .3) transformer. Serial Number 98700scientific instruments, surveying, physics, ballarat school of mines, ballarat institute of advanced education, beam balance, balance

This barometer was part the hydrology and forestry groups working within the SEC Vic Hydro Scheme from the initial appraisal review long before any construction began in the 1940's. The river flows and rainfall patterns had to be established before any construction of holding dams or tunneling could commence. This barometer is very relevant to the Kiewa Valley history because it presents the high degree of professional and technical information required at the time before implementing the "Scheme" upon the virgin alpine region and its effects upon the "natural" flows of the rivers within the Kiewa Valley. Time since the start of the project has verified the use of instruments such as this barometer and the information gained from its use that the success of any large impact upon a sensitive environment requires a thorough and systematic study before implementation. Weather records were kept of temperature, wet-bulb temperature, wind direction, speed and barometric pressures. To record barometric pressure a meter was devised with a clockwork mechanism which took one week to do a revolution. A chart was fitted to a drum and had an ink pen shaped like a little shovel. The shovel was filled with ink and was checked daily. To calibrate the barometer it was sent to the Melbourne General Post Office to be compared against the one there (at sea level). After calibration it was sent back to the Bogong Camp.On plaque on top side."NEGRETTI & ZAMBRA" underneath this and in smaller print "TRADE MARK" below this "LONDON" On the bottom and in small print "HOBART DUFFPty Ltd COLLINS HOUSE MELBOURNE C1"kiewa hydro electricity scheme, victorian state electricity commission, transformers, resistors, barometers
