Technical drawing - blue print, Details of Timber Truck Ironwork, 17.07.1912

Physical description

DWR-00286 Details of Timber truck ironwork, Victorian Hardwood Company, Powelltown, 1919.
Blue Print.

Inscriptions & markings

Victorian Powell Wood Process Ltd
details of timber truck ironwork
scale 1 1/2" -3" = 1 foot Sheet No 17
11/07/12
Note:- the number off each part are for one wagon only
