Photograph - Set of five photos of SECV Depot wheel grinder, State Electricity Commission of Victoria (SECV), c1936

Significance

Yields information about the installation of the wheel grinder in the Ballarat depot during the 1935/1936 rehabilitation

Physical description

Set of 5 Black and white photo prints from collected negatives of under floor wheel grinder at the SEC Ballarat depot building, during refurbishment by the SEC during the mid 1930's.

1353.1 - General arrangement of grinding wheels, jacks, moving rails, motor control, switch and wall mounted resistor grids.

1353.2 - Close up of the grinding wheels, jacks and moving rails.

1353.3 - view looking along the pit, showing the drive motors, belts and switches

1353.4 - view looking along the pit with the outside pit covers in place and rails in place.

1353.5 - similar to 1353.1 - but showing motors and drive belts, but not wall mounted equipment.



See Reg Item 3806 for a photograph of the grinder in use.



Copy 2 - of all above photos - large format prints (203H x 253W) - added 28/7/2007, ex Alan Bradley holding of prints, received 5/2007.



See also Reg Item 3906 for a mounted set of these photographs.



Negatives scanned at 3200dpi and images updated 14/5/2020.
