Physical description

Set of three A3 size photocopies of a drawing held by the Public Records Office Victoria of the Ballarat ESCo Tramway Depot, dated 2/8/1912. Drawn at a scale of 1/16" = 1', shows building layout, track layout, overall dimensions, a proposed extension to hold eleven trailers, a front elevation showing pits, extension (drawn at 1/8" = 1'). On the current tracks, shows the individual track capacities - 26 trams.

Drawings copied by Alan Bradley for archives and research.

Subjects

Identifier

2976

Date made

2000

Production methods

Photocopied

Materials

Paper

Measurements

Width: 420 mm, Height: 297 mm
