Significance

Yields information about the supplier of the original track in Ballarat for electric trams and the extent of the work Hadfields undertook in providing curves, not just pointwork.

Physical description

Illustration from Hadfields Ltd of Sheffield, of the "Special Curves for the Ballarat Tramways". T Grenville St end of Sturt St. From page 9A of a catalogue publication of Hadfields held by the Wellington Tramway Museum, New Zealand. Shows the curves laid out in Hadfields yard.



btm3679i - image of the printed version.

Full size pdf copy held - filed as "Hadfields pic Ballarat Trackwork - btm3679i" on the high resolution image file.
