Drawing, State Electricity Commission of Victoria (SECV), "Brake rigging dropped centre double bogie tram Brill maximum traction truck 22E, Trams Nos. 31,", Aug. 1947

  • "Brake rigging dropped centre double bogie tram Brill maximum traction truck 22E, Trams Nos. 31,"

    "Brake rigging dropped centre double bogie tram Brill maximum traction truck 22E, Trams Nos. 31,"

  • Background note

    Background note

  • "Brake rigging dropped centre double bogie tram Brill maximum traction truck 22E, Trams Nos. 31,"
  • Background note

Historical information

Drawing details brake rigging and dimensions for a Brill 22E truck. Dated 4/8/1947, prepared by the SEC Geelong branch, signed by H N Hornabrook 6/8/47 showing the layout and loads on each part of the brake system, drawing No. T1647. See item 9025 for another version.

Significance

Yields information about the brake rigging for Brill 22E trams and demonstrates the activities of the SEC Geelong office.

Physical description

Drawing - blueprint, titled "Brake rigging dropped centre double bogie tram Brill maximum traction truck 22E, Trams Nos. 31,"

Inscriptions & markings

"D1775" in ink on top sheet right hand corner.
