Set of 16 floor plans of electric trams of the MMTB and the trusts from the A class of 1910 to W class of 1923. Shows floor plan, seats and a table with car numbers, loading, truck type, type of equipment, horse power, remarks and total weight.
1 - Malvern Combination - A, B, H, J classes
2 - Drop centre cars - Malvern - C, E and D classes
3 - Summer car - Malvern - F class
4 - Short saloon combination - Malvern G class
5 - Short saloon combination - Malvern K class
6 - Four motor bogie car - Malvern - L class
7 - Combination car - Hawthorn - M class
8 - Drop centre bogie car - Hawthorn - N and P class
9 - Closed bogie car - Hawthorn - O class
10 - Combination car, Preston - R and Q class
11 - Combination car, Coburg - S class
12 - Double saloon combination car - Coburg - T class
13 - Box Car Essendon U class
14 - Cross seat (toastrack) car, Essendon, V class
15 - Four motor bogie car - W class
16 - "Birney" Safety car - X class
Yields information about various classes of electric trams up to about 1923 that the MMTB absorbed from the Trusts and built themselves.
Folder of 16 blue prints secured with three brass clips,
tramways, tramcars, floor plans, drawings, a class, b class, c class, d class, e class, f class, g class, h class, k class, l class, m class, n class, o class, p class, q class, r class, s class, t class, u class, v class, x class, pmtt, htt, mbctt, fnptt
