Drawing, Melbourne & Metropolitan Tramways Board (MMTB), "Explosive Factory Cordite Ave - Proposed Tramway Extension shown red", 1940's

  • "Explosive Factory Cordite Ave - Proposed Tramway Extension shown red"

    "Explosive Factory Cordite Ave - Proposed Tramway Extension shown red"

  • /

  • "Explosive Factory Cordite Ave - Proposed Tramway Extension shown red"

Physical description

Drawing - red ink drawn on a print showing an extension to the single track, Maribyrnong tram line to run further into the Explosives Factory.



Original print from the Commonwealth of Australia, Dept of Munitions, Factory Board drawing number W-1163 titled "Explosives - Munitions Supply Laboratories Proof at Rest - Maribyrnong" and dated April 1933.



Marked in red ink is a "Explosive Factory Cordite Ave - Proposed Tramway Extension shown red". Not dated, possibly early 1940's.



Also has pencil markings around the terminus showing an alternative loop.

Inscriptions & markings

In blue pencil both edges on the rear "Cordite Ave" and in pencil on rear "Copy to Mr ?? to file"
