Electrical Faults on Tramcars
Workshops and Runningsheds Branch
Runningsheds Section
2 documents
1. - 9 page report from Senior Foreman RJ Tippett on procedures dealing with electrical faults on tramcars. Dated 23/5/1968
2. - 2 page report from RC Drummond, Traffic Manager, titled "Tram Car Braking on Greasy Rails". Dated 52/1/1967. (This document found within the pages of the main document)
Set of 16 floor plans of electric trams of the MMTB and the trusts from the A class of 1910 to W class of 1923. Shows floor plan, seats and a table with car numbers, loading, truck type, type of equipment, horse power, remarks and total weight. 1 - Malvern Combination - A, B, H, J classes 2 - Drop centre cars - Malvern - C, E and D classes 3 - Summer car - Malvern - F class 4 - Short saloon combination - Malvern G class 5 - Short saloon combination - Malvern K class 6 - Four motor bogie car - Malvern - L class 7 - Combination car - Hawthorn - M class 8 - Drop centre bogie car - Hawthorn - N and P class 9 - Closed bogie car - Hawthorn - O class 10 - Combination car, Preston - R and Q class 11 - Combination car, Coburg - S class 12 - Double saloon combination car - Coburg - T class 13 - Box Car Essendon U class 14 - Cross seat (toastrack) car, Essendon, V class 15 - Four motor bogie car - W class 16 - "Birney" Safety car - X class
Yields information about various classes of electric trams up to about 1923 that the MMTB absorbed from the Trusts and/or built themselves.
Folder of 16 blue prints secured with three brass clips,
tramways, tramcars, floor plans, drawings, a class, b class, c class, d class, e class, f class, g class, h class, k class, l class, m class, n class, o class, p class, q class, r class, s class, t class, u class, v class, x class, pmtt, htt, mbctt, fnptt
