Drawing, State Electricity Commission of Victoria (SECV), "Tramcar tail lamp installation relay modification", 15/11/1949

Historical information

Set of two drawings (BA-T8-8100/1 and BA-T8-8100B) showing the installation of tail lights on SEC tramcars and modifications to the battery/trolley pole relay and battery. Both are dated 15/11/1949 and signed by the Manager Ballarat Branch. The actual relay used later was a Post Office type relay contained within a wooden box.

Significance

Yields information about the modifications proposed to the tramcars to provide a rear tail light and lights when at a terminus.

Physical description

Drawing - dyeline print on plain paper
