Drawing, State Electricity Commission of Victoria (SECV), "Brake Rigging Brill Maximum Traction Truct No. 22E", 4/1955

  • "Brake Rigging Brill Maximum Traction Truct No. 22E"

    "Brake Rigging Brill Maximum Traction Truct No. 22E"

  • "Standard Pony Axle" - traced from MMTB drawing R3755

    "Standard Pony Axle" - traced from MMTB drawing R3755

  • "Pony Axle Box"

    "Pony Axle Box"

  • "Brake Rigging Brill Maximum Traction Truct No. 22E"
  • "Standard Pony Axle" - traced from MMTB drawing R3755
  • "Pony Axle Box"

Historical information

Set of three drawings related to the Brill 22E Maximum Traction trucks:
1 - "Brake Rigging Brill Maximum Traction Truct No. 22E" - showing the dimensions of the levers and pivot points. For the relevant Geelong drawing T1647 see item 8044
2 - "Standard Pony Axle" - traced from MMTB drawing R3755
3 - "Pony Axle Box" - traced from MMTB drawing R1112 and dated in ink 28-4-1955

Significance

Yields information about Brill 22E brake rigging and equipment.

Physical description

Set of three Drawings - dyeline print on plain paper with a brass clip in the top right hand corner.
