"No 2 end brake lever"
Can you reuse this media without permission? No (with exceptions, see below)
All rights reserved
This media item is licensed under "All rights reserved". You cannot share (i.e. copy, distribute, transmit) or rework (i.e. alter, transform, build upon) this item, or use it for commercial purposes without the permission of the copyright owner. However, an exception can be made if your intended use meets the "fair dealing" criteria. Uses that meet this criteria include research or study; criticism or review; parody or satire; reporting news; enabling a person with a disability to access material; or professional advice by a lawyer, patent attorney, or trademark attorney.
Please acknowledge the item’s source, creator and title (where known)
Have a question? Contact Ballarat Tramway Museum
Drawing titled "No 2 end brake lever" showing a part of a Brill 21E truck, shows the positioning of the holes for other parts of the brake rigging. Would have been used at the depot or the SECV Workshop for the drilling of a plate. Item undated.
Yields information about the position of the drill holes on a brake lever fitted to single truck trams.
Hand drawn drawing in pencil on plain quarto sheet.
