Historical information

Providing GA drawings of the following:
R3076 - A class
R5963 - A class
R3078 - C class
R3077 - G class
R7416 - L class
R3093 - T class
R4382 - T class
R3756 - U class
R2459 - W2 class
R3071 - W3 class
R3812 - W4 class
R4678 - W5 class
R4646 - Sw2 class
R5818 - SW5 class
R4771 - SW6 class
R6408 - SW6 class
R2462 - X class
R2463 - X1 class
R3080 - X2 class
R2464 - Y class
R2465 - Y1 class
R8332 - PCC class

The number for each class of tram is given on the index sheet. The S class and CW5 class have been omitted. Possibly assembled in the early 1950s, given the tram plans used.
See items 4714 & 5639 for other sets of drawings.

Significance

Yields information about the MMTB fleet including scrapped trams and their General Arrangement.

Physical description

Album or set of 23 blueprints secured with two brass clips with a cloth cover strip.
