Drawing - 5712/11 & 12, State Electricity Commission of Victoria - Electricity Supply Department, Ballarat Tourist Tramway, Wendouree Parade Connection, 21/10/1974

  • Ballarat Tourist Tramway, Wendouree Parade Connection

  • /

    Ballarat Tourist Tramway, Wendouree Parade Connection

Historical information

Produced by R.J. Groves in 1974 for the BTPS to document the Depot Junction that was built.

Significance

Yields information about the rail bending and layout details for Depot Junction that was built in 1974 for the BTPS.

Physical description

Original print of the "Ballarat Tourist Tramway / Wendouree Parade Connection", showing the track layout as prepared, engineering dept. no 5712/11 & 12. Signed J.R. Groves, 21-10-74.

Inscriptions & markings

Original hand drawn document in pencil on tracing paper. Has a fold in top right hand corner.
