Map - 5712/10, Scheme A, City of Bendigo, Bendigo Trust Tram Project, Proposed Curve, High Street into Violet Street. Scheme A, 01/11/1972

  • City of Bendigo Tramway, Proposed 500' Radius Curve.

  • /

    City of Bendigo Tramway, Proposed 500' Radius Curve.

Historical information

Produced by City of Bendigo, signed by the City Engineer J.L. Hicks, 1948.

Significance

Print of a drawing showing in very good detail, a drawing of a proposed track curve at High Street into Violet Street in Bendigo. Document was initialed by J.R. Graves dated 1/11/1972.

Physical description

City of Bendigo document 5712/10; "Proposed Curve, High Street into Violet Street. Scheme A.". Drawn 01/11/1972. Original dyeline print.

Inscriptions & markings

Original dyeline print.
