Document - GE-T2-6480, Melbourne Electric Supply Co. (MESCo), Cross-section of permanent-way using 90lb Girder Rail, 21/02/1923

  • Cross-section of permanent-way using 90lb Girder Rail.

  • /

    Cross-section of permanent-way using 90lb Girder Rail.

Historical information

Produced by Melbourne Electric Supply Company Limited (MESCo), Geelong Branch, 21/01/1923, for the Geelong Tramways.

Significance

Print of a document showing in very good detail a cross-section of tramway with drainage. Shows how the sleepers were embedded into aggregate to form the tramway.

Physical description

MESco (Geelong Tramways) document GE-T2-6480; "Cross-section of permanent-way using 90lb Girder Rail.". Drawn 23/02/1923. Beige paper copy of original dyeline print.

Inscriptions & markings

Copy of original dyeline print.
