Document - GE-T7-7630, Melbourne Electric Supply Co. (MESCo), Brill Radix (E1B Special) Truck Shewing Details of Brake Rigging, 21/03/1930

  • Brill Radix (E1B Special) Truck Shewing Details of Brake Rigging.

  • /

    Brill Radix (E1B Special) Truck Shewing Details of Brake Rigging.

  • Brill Radix (E1B Special) Truck Shewing Details of Brake Rigging.

Historical information

Produced by Melbourne Electric Supply Company Limited (MESCo), Geelong Branch for the Geelong Tramways. Drawn 21/03/1930.

Significance

Retraced from original document showing in good detail, three views of the Brill Radiax Truck (E1B Special) with specific shewing details of the brake rigging.

Physical description

MESco (Geelong Branch) document GE-T7-7630; "Brill Radix (E1B Special) Truck Shewing Details of Brake Rigging.". Drawn 21/01/1930. Redrawn from the original dyeline print.

Inscriptions & markings

Redrawn from the original dyeline print.
