Maldon Vintage Machinery Museum Inc Maldon, Victoria

The Maldon Vintage Machinery Museum houses a wonderful display of vintage machinery from the region and further afield, including agricultural, pastoral, forestry, mining, printing, industrial and fire-fighting equipment.

Contact Information

location
PO Box 2 Maldon VIC 3463
phone
+61 03 5472 2202

Opening Hours

The building is staffed by volunteers, and aims to be open Wednesdays from 11.00 to 3.00 and Saturdays from 10.00 to 4.00, and some Public Holidays. Please note that the Museum will NOT open when the North Central Fire Danger Ratings District has ratings of Code Red (Catastrophic) or Extreme. See the Fire Danger Ratings map at http://www.cfa.vic.gov.au/

Location

Vincents Road Maldon Victoria

A showcase of Local Machinery that forged the goldfields, the farms and the everyday life in throughout the 19th and early 20th centuries. this collection includes the first steam operated electric plant developed for Thompson's Foundry, Castlemaine along with many and varied historic machines

Significance

currently working on a National Significance assessment

There are no comments yet.

Leave a comment

167 items

Sewing Machine

Maldon Vintage Machinery Museum Inc, Maldon

Singer sewing machine with electric motor and maroon hard cover. Instruction book for No. 66 Singer Sewing Machine - greenpaper cover with red logo on front, 32 pages. Hinged wooden flap forms table when lowered. Machine housing is metal painted fawn with brown drive wheel & foot pedal. Motor is also brown. Base is cream. Cover has cream handle & brass catches. Accessories box R.N. 31.10.

Inscriptions & Markings

Motor serial No K10591526

PRINTING PRESS

Maldon Vintage Machinery Museum Inc, Maldon

Large broadsheet printing press with large and small rollers.

Inscriptions & Markings

Maker's name on front "PAYNE & SONS"

Model Truck

Maldon Vintage Machinery Museum Inc, Maldon

"Tarrengower Times" model truck registration plate TLJ 10. Flat tray, spoked wheels with pneumatic tyres, leaf springs front and rear, leather upholstery. "Century" battery behind cabin with" Century" in black on gold. Painted maroon with gold trim, gold painted headlights and radiator frame.

Inscriptions & Markings

On driver's door in gold lettering "The / Tarrengower / Times /High St. / Maldon / Est. 1858" Logo on oval plate at top of radiator.

Steam Engine

Maldon Vintage Machinery Museum Inc, Maldon

Horizontal steam engine driving a flat belt pulley. Pulley shaft at right angles to engine shaft also carries a large flywheel. A mechanical oiler mounted on the engine base is activated by the engine valve shaft. Engine cylinder and valve housing painted dark green. Engine base, pulley and flywheel painted maroon. Oiler painted mid green.

Historical information

Thought to be the world's only working example of this engine. Used for driving overhead shafts in workshops, sawmills etc. Restored by members of the MVMM. Found at the Demsters property Shelbourne.

Significance

Thought to be the only one of its kind in the world.

Inscriptions & Markings

On engine valve box cover - Light green cast iron oval plate with "Cornelius Pettet / Engineer / Edinburgh" Brass plate on oiler - "Delvac Mechanical Lubricator / Design No 18376 / Made for and supplied by / Vacuum Oil Company Pty. Ltd. / Australia"

'Romulus ' Costume

Maldon Vintage Machinery Museum Inc, Maldon

.1) Cream Shirt &.2) Charcoal grey trousers with button fly and rayon? lining down to knee level. .3) Brown leather helmet with black, cotton lining, ear flaps and chin strap with buckle fastening. Makers name indicates helmet is of German origin. .4) Brown leather belt with buckle. .5 & .6) Pair brown leather boots. Right boot has hole drilled through the sole to accommodate a supporting spike on the display manequin's base.

Historical information

The costume was worn by the character of Romulus in the movie "Romulus My Father" which was filmed in Central Victoria and used a motor bike in the Maldon Vintage Machinery Museum's collection. the film company subsequently donated the entire outfit to the museum.

Inscriptions & Markings

.4) is marked on inside surface near the buckle : "HERO/38" Left boot sports a white sticker with "hora" printed in black. Right boot has black "X" on outside top edge. Both boots have "ooded(?) /MURRAY42" moulded into leather on inner top edges.. .2) bear a stick-on label printed with "ROM 4" on inside back waistband.

Slide Rules

Maldon Vintage Machinery Museum Inc, Maldon

.1 to .4)Two SAA Conversion Slides supplied by Standards Association of Australia for converting imperial measurements to metric. .5) Plastic sleeve. .6) instruction leaflet.

Clock

Maldon Vintage Machinery Museum Inc, Maldon

Battery operated clock with a highly lacquered face with an image of half of a split casing pump casing. The image is in blue and black on a white ground centred on a circular wooden clock face. Numbers are imitation chrome plastic covered with lacquer. The second hand is red. The backing board is rectangular. The operating mechanism is centred in a housing on the back.

Inscriptions & Markings

Maker's name ("Chris Shaw") on a gold sticker at the bottom centre of the back.

Chainsaw

Maldon Vintage Machinery Museum Inc, Maldon

"Pioneer" chainsaw with green housing. Pull start, no chain. Compliance plate on back (see Below) second plate on top.

Inscriptions & Markings

Compliance plate on back "Pioneer Saws / Model / 450 / Serial No. A10778 / Division of Outboard Marine Australia Pty. Ltd. / Bankstown NSW". Cast in relief on side "Pioneer & Pine Trees".

LINO TYPE MACHINE

Maldon Vintage Machinery Museum Inc, Maldon

Lino-type casting machine with furnace for casting lead plates. Makes type used in printing. Motor made by Crompton Patison. Keyboard to select letters to be cast.

Historical information

This item was used at "The Tarrengower Times" Maldon, Vic by Ron ADAMS

Inscriptions & Markings

MODEL 78 No 17175

Miniature Water Turbine.

Maldon Vintage Machinery Museum Inc, Maldon

Miniature water turbine (pelton wheel, single jet) mounted on a wooden frame. Undershot wheel driving a pulley at one end of the shaft. Flywheel at the other end of the shaft. Small die-cast buckets, some broken and missing. Pelton wheel and flywheel painted red, wooden frame unpainted.

Inscriptions & Markings

None

Pump - Centrifugal

Maldon Vintage Machinery Museum Inc, Maldon

Painted dark grey early model Thompson centrifugal pump "Class G". Single stage pump.

Inscriptions & Markings

Thompson's Engineering & Pipe Works. Serial No. 4542. 1" x 1 1/4" Class G

Leaflets

Maldon Vintage Machinery Museum Inc, Maldon

.1) Selection criteria for a suitable pump. .2) Boiler feed pumps. Leaflets, each with photographs of a pump.

Pump - Vertical Turbine

Maldon Vintage Machinery Museum Inc, Maldon

2 stage vertical turbine pump, sectioned for display purposes. Internal parts painted green & red.

Pump - Centrifugal

Maldon Vintage Machinery Museum Inc, Maldon

Single stage double suction pump with side suction and discharge branches. Mounted on a baseplate with a motor and coupling guard. The pump set is painted grey.

Inscriptions & Markings

Brass I/D plate with Pump serial No 2038 1 1/2 Class C and other details.

Pump - Centrifugal

Maldon Vintage Machinery Museum Inc, Maldon

Painted light green with moving parts and bolts picked out in black. End suction, overshot discharge Bolted to a wooden base. V belt driven.

Inscriptions & Markings

Brass specification on sides - "Suction pump manufactured for Victorian Railways in 1930. Model H" Elaborate monogram in black on side denoting Kelly & Lewis Pumps. Brass plate with Kelly & Lewis Ltd / Centrifugal Pump / Type W.

Slide Rules

Maldon Vintage Machinery Museum Inc, Maldon

Ten slide rules, various makers. All cased. Materials vary from cases in cardboard, vinyl, leather, plastic and slide rules in wood, plastic, metal. .23) Instruction book for E. Green's Hemmi's slide rule printed in Japan in 1934.

Steam Engine

Maldon Vintage Machinery Museum Inc, Maldon

Large 4 wheeled 9 HP single cylinder (horizontal) steam engine, designed to be towed. Front wheels smaller than rear. Folding smoke stack with spark arrestor. Fire box and smoke stack painted black, boiler and steam cylinder green, wheels grey. In working order but engine is connected to an independent steam/air source to be operated for display purposes. 150 cm flywheel on LHS looking forward toward the front. Timber front turntable and back brake pad assembly. Brass water drain tap on firebox. Also other brass fittings on firebox.

Historical information

Restored by Maldon Flywheelers Association. Originally owned and used by Zemster Brothers of "Brook Mount" Shellbourne.

Significance

Known as "Aunty Jack"

Inscriptions & Markings

On brass ring near top of firebox:- "Serial No. 5672, Marshal Sons & Co. / Limited / Engineers / Gainsborough England". Metal plate on front turntable:- "Restoration of the Front Undercarriage / and retubing of the boiler by / Castlemaine Technical School / 1979". Cast in relief on wheel hubs:- "Marshal Sons & Co. Gainsborough".

Drawing Machine

Maldon Vintage Machinery Museum Inc, Maldon

"Ray & Gilbert" articulated arm type manual drawing machine as used in a drawing office. Fitted with "W & G" scale rulers. Rulers are plastic coated timber. Black arms and handle, white rulers. Mounted on a wooden drawing board.. .4) Metal adjusting spanner.

Inscriptions & Markings

.1) At mounting pivot point of drawing machine "Ray & Gilbert / Drafting Machine / Serial No. ? / Melbourne. Aust." .2) Scale rule "W & G E 18". .3) Scale rule "W & G E 12". .4) No inscriptions.

Perforating Machine

Maldon Vintage Machinery Museum Inc, Maldon

Metal and timber perforator with multiple metal pins. Operated by a hand lever on RHS. Four metal feet with holes for screwing to bench top.

French Curves

Maldon Vintage Machinery Museum Inc, Maldon

.1) Wooden box with hinged lid. 22 wooden and 3 plastic flat curved patterns loose in the box. Several are numbered. .2) 3 clear plastic curves in a pouch. Made in Italy. .3) 3 clear plastic curves in a pouch. Made in Italy. .3 .....31) Plastic curves. French curves are used in a drawing office to draw a smooth best fit line through a number of points.

Inscriptions & Markings

.25) "42 / Engineering / TB5" etched into plastic. .2 & .2) Pouches marked "LONGO Made in Italy" in gold.

Pump - Centrifugal

Maldon Vintage Machinery Museum Inc, Maldon

Single stage self priming pump. Part of housing cut away to show interior for display purposes. Grey painted with cross section edges painted black. Black knobs for removing inspection cover on front end.

Inscriptions & Markings

Nameplate on top "Primo Titan" 50mm. Thompsons Kelly and Lewis logo on end cover.

Pens, Boxed

Maldon Vintage Machinery Museum Inc, Maldon

Set of 4 German made drawing pens and 3 attachments in a green plastic box with hinged clear plastic lid and white insert to hold items separately. In original white and green cardboard box.

Inscriptions & Markings

On box "S 1184 / 4N"

Rock Drill

Maldon Vintage Machinery Museum Inc, Maldon

Oswald pneumatic rock drill. What appears to be an operating lever extending to one side. Body only, no drill bits. Unpainted.

Significance

This was the first rock drill to be made in Australia and was made in Maldon. It was used in the Carmen's Tunnel mine Maldon.

Inscriptions & Markings

Cast in relief on body "Late / R. D. Oswald / Maldon".

Petrol Engine

Maldon Vintage Machinery Museum Inc, Maldon

Single cylinder horizontal petrol engine mounted on a 4 wheeled trolley. Two flywheels, one either side, no pulley. Galvanised cylindrical fuel tank mounted on a wooden box in front. Box contains a battery and ignition coil. Trolley has cast iron wheels and is designed for pulling by hand. Painted red and grey. Probably a power source for farm machinery.

Inscriptions & Markings

On a brass plate fixed to the cylinder. "Waterloo Boy Gasoline Engine / No. 81491, HP 4 / Waterloo Gasoline Engine Co. / Waterloo Iowa / Patented / August 7 1900, Dec 3 1901, Oct 7 1907 / Other patents pending / Sold by Waterloo Gasoline Engine Co." On each side of the water tank is an oval white transfer with "Waterloo Boy" above an illustration of a small boy wearing a wide brimmed hat.

Booklets - .1) Gravel Pumps. .2) Chokeless Pumps.

Maldon Vintage Machinery Museum Inc, Maldon

Two paper covered booklets with b & w photographs of pumps made by Thompsons Castlemaine. .1) Contains performance and dimension details with some hand written details. .2) Details of specialised pump for unstrained juices in cane sugar mills.

Oil Engine

Maldon Vintage Machinery Museum Inc, Maldon

10 HP horizontal cylinder oil engine in working order. Mounted on a steel chassis with 4 wrought iron wheels. Two flywheels and one flat belt pulley. Rectangular cooling water tank and cast iron exhaust pot with vertical exhaust pipe mounted at crankshaft end. Engine painted green with pale yellow trim. Blow torch start on compression when hot bulb is of certain temperature. Mechanical water and fuel pumps.

Inscriptions & Markings

Oval brass plate fixed to cylinder "The "Blackstone" / Carter's Patent / 61892 / Quote this No. / When ordering parts / Oil Engine"

Motor Mower

Maldon Vintage Machinery Museum Inc, Maldon

"Victa" 2-stroke lawn mower with rope start. Coloured green with plastic and rubber wheels. Height adjustment on each wheel. Early model with circular base, snorkel air intake and two blades.

Significance

Early model VICTA lawn mower.

Inscriptions & Markings

Aluminium plate on front "VICTA" in silver on red background.

Wagon

Maldon Vintage Machinery Museum Inc, Maldon

4 wheeled mostly wooden wagon with rear wheels of larger diameter than front. Painted white, red and tan with some pin striping on wheels. Multiple leaf springs, 2 rear sets in double configuration. Metal and timber overhead framework for a canopy. Wooden seats along each side.

Inscriptions & Markings

No inscriptions and markings.

Sewing Machine

Maldon Vintage Machinery Museum Inc, Maldon

Hand operated sewing machine. Early model with bullet shaped bobbin. In working order. Painted matt black.

Inscriptions & Markings

Serial number on plate P022565

Pump - Centrifugal

Maldon Vintage Machinery Museum Inc, Maldon

Single stage end suction centrifugal pump set up for flat belt drive. Painted grey.

Inscriptions & Markings

Bilabong. DB85 etched into end of housing. CH12 in relief on end of circular section of housing.
