Black and white photo of a H crossing overhead that suits both trolley poles and pantographs..1 - On the rear in ink - "Newly hung o/head crossing suits panto's and poles"trams, tramways, overhead, mmtb, trolley poles, pantographs

Cased Medal and Clasp plus miniature and ribbon .Approved in 1982 for officers and other ranks who had completed 15 years service with a clasp issued for each 5 years extra service.Pantographed to D. P. Wilkie A225020

Print of an e-mail file titled "Conversion Dates of A1 class tramcars from pole to pantograph", sent to Warren Doubleday by Hugh Waldron by e-mail 27/3/2017. List dated Oct. 1995 Lists the tram number, last day in service with pole, first day with pantograph and the three which were converted back to a pole for a period.trams, tramways, a class, trolley poles, kew depot, pantographs

Set of 4 black and white photographs of MMTB trialling overhead fittings for pantographs on the West Preston line. .1 - dummy fitting of where two overhead trolley wires cross each other at 90 degrees .2 - cross frog and signal contactor .3 - Section insulators with pantograph pan depression bars .4 - ears fitted to a curve section with a short dropping sections. Handwritten note (filed with photos) giving photo numbers, location and that sent to ET. Not dated as such. Electric Traction magazine issues for June and August 1977 - see image i5 an it advises of the pantograph trials and changes made. W2 546 had been fitted during May 1977 with a pantograph and a closed circuit camera.trams, tramways, mmtb, west preston, overhead, electrical engineering, electric traction, pantographs

Set of four photographs of W2 class tram 546 set up as a pantograph test car, used between 4/77 - 7/86, taken at Preston Workshops by Norm Cross.Yields information about the testing of pantographs on tram 546 at Preston Workshops and the prelude of their rollout on the A2 class tram.Set of 4 colour photos, with rounded corners.trams, tramways, tram 546, pantographs, preston workshops

Drawings shows on a street plan of Melbourne, tram routes, route numbers location of cross overs, and track availability of pantograph only, pole only and dual running. Dated 5/6/1996Demonstrates a PTC document for detailing overhead availability and cross overs.Drawing - Document - folded A3 sheettramways, ptc, pantographs, trolley poles, overhead, cross overs, route numbers, tram routes

Set of three photocopies of instructions for Alstom Preston Service Centre. .1 - "Pantograph Lock Down Procedure" - 1 A4 sheet - describes the procedure for locking the pantograph down and then moving it within the workshops safely - dated 10/10/2003. .2 - "Citadis Bogie Removal Procedure" with sub title "on PWS jacks" - 2 pages - dated 08/04/2004. .3 - "Citadis Preventative Maintenance Tasks" - 7 page A4 document - listing the A, B and C exams for C class trams, prepared by United Group Rail. .4 - as for .3, but printed on A3 sheets, stapled.in pencil on top of .1, "Copy only to John Prideaux" On rear of .1 in ink "Citadis Maint (Mileage graded) "A". "B" and "C" service. c2007.trams, tramways, preston workshops, maintenance, c class, pantographs, bogies, citadis

Document issued drivers at Malvern Depot 1999 giving instructions regarding Pantographs fitted to Z1 and Z3 class trams. Has notes on failures, switches, overhead damage and cut-off markings. The 3rd page has a copy of the "Modern Class - Run out" instructions dated 4/99.Demonstrates instructions issued re Panotograph trams and their operation.Document - 3 A4 pages stapled in top left hand corner printed.tramways, swanston trams, malvern depot, pantographs, instructions, z1 class, z3 class

Document or report - 6 A4 pages, photocopied - titled "Scope of works for Z1/Z2 tram upgrades" giving listing of work recommended for the upgrade of Z class trams. Gives cost per car and total cost - based on 114 trams. Document undated - assumed mid 1990's. Includes pantograph conversion.Sheets 2,3 and 5 has comments in ink.trams, tramways, z class, overhauls, bogies, pantographs, preston workshops

Pamphlet or Catalogue - 16 A4 pages + card cover - full colour centre stapled titled "Austbreck" providing a detail over view of the company, its products and locations. c2000 Company provides pantographs, overhead traction systems for rail and tram, crane trolley systems, design and project management. Includes brush holders, isolation systems and insulation.trams, tramways, overhead, electrical engineering, trolley wire, pantographs, electrical equipment

1 - Issue 1 - March 2007 - with photo of the Police Tram (2109) - Welcome message from the CEO Dennis Cliche, Good Friday appeal, Burwood highway works, new sub-stations at Coburg, Royal Park, Brunswick depot, Camberwell depot, East Preston, Essendon, Bundy Clock, Glenhuntly, Kew Depot, Malvern, Southbank,, Safety, events, Lunar Festival .2 - issue 2 - June 2007 - 18 pages, Malvern Depot (a green depot), Paul Matthews profile, trackwork at Glen Huntly and Essendon depots, Depot news, Joyce Barry tribute, Hawthorn depot museum, fund raising. .3 - issue 3 - Octr. 2007 - 16 pages - fund raising - Melbourne city romp, Des Davies retirement, CPR rescue of a collapsed driver, depot news, retirements and a chemical and fire incident on the Vermont South line. .4 - issue 4 - Jan. 2008 - 12 pages - fundraising, family events, depot news, retirements, TramTracker Jake .5 - issue 11 - Winter 2010 - 16 pages - St Kilda Road Superstops, Michel Mason - CEO, Malvern depot centenary, Transformation, new maps on trams, fundraising, the leadership team, depot news, uniforms, South Caulfield Junction upgrade. .6 - 20 pages issue 12, Summer 2010, published soon after Keolis took over operations of Yarra Trams. The first 10 pages, look at Trams on the Fringe, Feedback, Football trams, staff matters, and features a story on page 10 of the Hawthorn Tram Depot museum and Driver Shaun McCarthy wearing the brown uniform in front of tram 1041. Fully Scanned. The second ten pages are reversed (upside down) and titled "Le Pantographer", featuring a Bordeaux tram on the cover. Provides details of Keolis operations such as Lyon, Bordeaux, Lille, Le Mans, Caen, Angers, Dijon and other operations. .7 - issue 6 - Spring 2008 - Meerkats, fleet operations, training, Art Alive, Kew depot - new inspection pits, Long Lay Malvern, Did You Know campaign, and looking for Cricket players - part scanned. .8 - issue 13 - Autumn 2011 - Michel Masson CEO, visit of French Media, Ron Scholten Retirement, photo of Geoff Dean of Camberwell, - part scanned. .9 - issue 5 - June 2008 - Tram works Swanston and Flinders, tram 111, cricket .10 - issue 8 - Autumn 2009 - Good Friday appeal, public transport ombudsman, Malvern centenary, my friend Mike .11 - issue 9 - Spring 2009 - Chris Cairns safety campaign, route 48, Myki, Tramtracker, Jake.Demonstrates Yarra tram staff newslettersEleven issues of Yarra Tram's internal newsletter "The Pantograph", all A4, center stapled. Issues not fully scanned, unless noted.trams, tramways, keolis, yarra trams, fohtd, hawthorn, uniforms, coburg, substation, royal park, burwood highway, fund raising, bundy clock, environment, glenhuntly depot, essendon depot, malvern depot, south caulfield, tram 2109, tram 84, route 48, tram 111, good friday

Official Metropolitan Transit Photograph of A class No. 267. Taken at Preston workshops. Tram fitted with pantograph. Taken c1990.melbourne, metropolitan transit, a class, tram 267

Report - News - four A4 sheets - titled "New Trams", reviewing and reporting on the extension of Contract 3000, A class trams, in particular the fitting of pantographs, changes to the overhead, phasing out of trolley poles. Reports on the Contract 4000, construction of 130 articulated trams, - letter of intent to Comeng. AEG and Siemens equipment, Duewag trucks. Construction of the trucks/bogies, MTA Preston Workshops work and additional manpower needed. Appears to be possibly a report to the workshop stafftrams, tramways, a class, b class, comeng, new trams, pantographs, duewag, preston workshops

This pantograph was in the desk drawer in the study.A wooden drawing tool for reducing and enlarging.walsh st miscellaneous, robin boyd

Donated to Museum by an autistic young man, who as a boy would play at the museum toy tram tables. He donated it so that other young boys could play with it. Ha a strong association with the donorToy Tram in style of a Japanese tram, with 'friction' motor. Is dark green in colour with a wide cream band around windows; grey roof; silver pantograph; grey wheels; black chassis. Has eyes on front that move from side to side. Has '6125' on all sides (probably tramcar number) and '27' on front and rear (probably route number). Has plastic pantograph on roof.tramways, toy, models

Official Metropolitan Transit Photograph of Articulated tram No. 2001. Taken at Preston workshops at dusk with outdoor inspection pit in foreground. Tram fitted with pantograph. Taken c1990.melbourne, metropolitan transit, articulated trams, tram 2001

Black and white copy negative of a photo of MMTB Birney 218 in Power St, soon after entering service in1923. Has the Bow Pantograph or Bow Collectors.trams, tramways, x class, birney, power st, bow pantograph, bow collector, tram 218

Photo shows X class Birney No. 218 in Power Street soon after delivery. It is fitted with a bow pantograph.Yields information about X class tram No. 218Black and White photograph on plain paper.In ink on rear "Birney 218, Power St Hawthorn" Has TMSV Sales stamp on rear.tramways, tram 218, power st, x class, birney, new trams

Shows the type of trolley pole base that was used on W, Z, and some A class trams prior to replacement by pantographs.Shows a MMTB TRolley pole base used on W class tramcars.Black and White photograph the MMTB Type trolley pole base with lines and markings drawn on it in ink as part of an printed illustration. Second copy does not have marks.trams, tramways, mmtb, trolley poles, trolley pole bases

Set of 14 colour prints of Z and Z3 trams being built and equipment at Preston Workshops and Comeng Dandenong, c1979. .1 - Two pantographs of different types laid on top of each other. .2 - ASEA trucks or bogie one marked 115 .3 - Jacobs truck or bogie for a Z3 tram .4 - Z class roof sections stored at Comeng yard .5 - Z class fronts being finished off .6 - Z or Z3 class cars bodies being built at Comeng .7 - Z cab interior showing control panel .8 - Z cab being built .9 - Z class underside or underframe .10 - Interior of Z class being built .11 - ditto .12 - as for .8 .13 - Z3 front .14 - Z class being built. Printed on Kodak Papertrams, tramways, preston workshops, z class, z3 class, pantographs, bogies, tramcar bodies, tramcar manufacture, tramcar trucks, tram 115

Gives tram allocations for Brunswick, Camberwell, East Preston, Kew, Glenhuntly, Essendon, Malvern and South Melbourne. Also provides notes on tram with poles and pantographs.Yields information about tramcar allocation between various depots and workshops.Set of five double sided A4 photocopied sheets titled "PTC Allocation of tramcars as at 01 December 1994", trams, tramways, tramcars, ptc, lists, depots, depot allocation

Provided by the tramcar body builder, Duncan & Fraser on the inside of the saloon above the doorway.Demonstrates Duncan and Fraser's method of identifying the tramcar builder.Oval shaped metal plate, engraved (pantograph duplication) with words "DUNCAN & FRASER LTD. ADELAIDE" around outside & word "BUILDERS" in centre. Then words have been filled with black paint. Has two holes in sides for mounting.tramways, trams, builders plate, duncan & fraser, ballarat, btm, ballarat tramways

Provided by the tramcar body builder, Duncan & Fraser on the inside of the saloon above the doorway.Demonstrates Duncan and Fraser's method of identifying the tramcar builder.Oval shaped metal plate, engraved (pantograph duplication) with words "DUNCAN & FRASER LTD. ADELAIDE" around outside & word "BUILDERS" in centre. Then words have been filled with black paint. Has two holes in sides for mounting.tramways, trams, builders plate, duncan & fraser, ballarat

Cardboard, punched out, folding model tram - Melbourne C class tram, numbered 3001. Has a pantograph attachment as well. Tram in the first Yarra Trams colour scheme. Has various destination signs and fleet numbers. Produced by Transit Graphics of Canberra for Yarra Trams. Three copies held. 1246.1 - postcard size model tram - with pantograph only. On rear has an paragraph about Melbourne being a most liveable city and that Yarra Trams are truly Melbourne all over. Produced by Avantcard with phone and website. Added 12-01-16. Two copies held.trams, tramways, c class, yarra trams, models, tram 3001

Cardboard, punched out, folding model tram - Melbourne Z3 class tram No. 185, in M tram (Moving Melbourne), National Express Group livery. Has separate parts for two route number boxes and pantograph. Produced by Transit Graphics in 2003.trams, tramways, models, z3 class, national express, mtram

Produced by Tin Treasures, Toy City, Greater Noida, Uttar Pradesh. Painted in Melbourne City Circle tram colours, numbered tram 957, fitted with a Bank of Melbourne and "Take a Break with V/Line" roof advertisements. Based on the manufacturer's website, the roof advertisements are not original.Demonstrates a toy clockwork model City Circle tram.Painted tin plate model - fitted with a pantograph and two advertising signs. Equipped with a fixed bogie at one end driven by a windup clockwork geared motor and a swivelling bogie at the other with metal flanged wheels. Has the manufacturer's label on the underside - Tin Treasures.trams, tramways, toys, models, city circle tram, tram 957

Model wide body W class tram, made from metal painted green and cream fitted with a pantograph and a trolley pole which has been broken off, No.15 trucks. No details as to who or where the model was made, has a label on the bottom that it is not a toy.trams, tramways, models, w class

Instruction - three pages photocopied A4 dated 4-12-1984 and 11-12-1984 with a sketch titled "Articulated Tram - Warning on Roof", about the possibility of electrocution about the area near the pantograph and the section of roof between the two parts not being insulated.trams, tramways, b class, construction, electrical engineering, insulation, articulated trams
