Copy of an article by Neville Gower, published in "Somersault", the magazine of the Signalling Record Society of Victoria, May 1988. Describes location of loops in horse drawn era compared to those of the ESCo area 1905 to 1934, with reference to changes made to ESCo Loops by SECV upon rehabilitation of the system, based upon changes on BTM's collection of staffs. Published in p54, 55, 56 and 60 of Somersault, May 1988. Copy supplied by Graeme Reynolds, printed with a dot matrix printer. Page 56 and cover page supplied by Warren Doubleday (2/1999). Was a follow up article or item by Peter Barry in the July 1988 issue and an article on Bendigo during 1989. (Information provided by David Langley editor at the time - 1/1999). See also item 988.p1 - 54 has been enhanced in black ink.trams, tramways, signals, crossing loop, esco, tramway staffs

Copy of an article by Peter Barry on the location of loops and operations of the Ballarat Tramway system. From pages 76 to 79 of the July 1988 issue of Somersault. Cover page, page 61 included. Covers running times, loop sections on Sebastopol, Lydiard St and Eastern Routes, Weekdays and Sats. and Suns., View Point, Signalling system, points where trams reversed in the section.trams, tramways, signals, crossing loop, secv, operations

Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, 52 and 53 and 4444 to 4448, , 4996 and 4497, 9037 and Reg item 934 and 988 for articles on the safeworking systems.Demonstrates aspects of Safeworking on the Ballarat Tramway system to c1936 when replaced by electric signals. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "STURT ST. SOUTH ST. " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head-on collisions. Safeworking object - known as a section staff. Not known when made, but in use, until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, 52 and 53, 2473 and 4444 to 4448 , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.Demonstrates aspects of Safeworking on the Ballarat Tramway system used to c1936 when replaced by electric signals. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "PLEASANT ST - GARDENS LOOP NTH. " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg.tramcars, tramways, staff, safeworking, tramway staffs, sec, esco

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "SOUTH ST. RUBICON ST." stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. Used a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "CARLTON ST HADDON ST LOOP " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "PLEASANT ST TO CARLTON ST LOOP " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "VICTORIA PARK LOOP / CARLTON ST LOOP" stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. The top line of words has a reddish paint inlay. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "CAR SHED LOOP / MACARTHUR ST LOOP" stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. The stamped area appears to have been polished compared to the others. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, 4496 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "DARLING ST LOOP RUBICON ST LOOP " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.Ballarat Tramways Section Staff Darling St Loop Rubicon St Looptrams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "URQUHART ST LOOP TO GREY ST LOOP " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "CARLTON ST. CAR SHED LOOP." stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. The part with the words "CAR SHED LOOP" appears to have been ground down and a previous location name taken out and replaced. Used a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath with the words "SEYMOUR ST LOOP GREGORY ST LOOP." stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. The part with the words giving the two locations appears to have been ground down and a previous location names taken out and replaced. Used a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.trams, tramways, staff, safeworking, tramway staffs, sec, signals

Demonstrates aspects of Safeworking on the Ballarat Tramway system from 1960 to c1936 when replaced by electric signs. Yields Information about the operation of Ballarat's trams and safeworking procedures. Demonstrates what can happen in use - has been run over by a tram - possibly being exchanged on the move or some other story.Cast brass item with a flat part recessed section with the words "BALLARAT TRAMWAYS SECTION STAFF" cast into the surface and a flat section underneath, flush with the outside edges in which the words "STURT ST RUBICON ST " stamped in. Has an open rounded end which forms a handle or a point where it could be hung on a peg. The staff has been run over by a tram and had the last part of the object cut off. Used as a means of authorising a tramcar to have sole use of the track between the named points to avoid head on collisions. Safeworking object - known as a section staff. Not known when made, but in use until the introduction of the electric signalling in the mid 1930's by the SEC. See also Reg Items 934 and 988 for details of use and other examples are at 1851, to 53, 2473 and 4444 to 4448, , 4996 and 4497 and Reg item 934 and 988 for articles on the safeworking systems.Ballarat Tramways Section Staff Sturt St Rubicon Sttrams, tramways, staff, safeworking, tramway staffs, sec, signals

45 No. Dept. of Road Transport and tramway staff tickets used in the 1940's to 1960's for safeworking on single lines of Maitland, Newcastle and Sydney tram lines, see attached listing for full details, descriptions etc. Printed on flimsy paper. Some of the tickets show the personal name of the Government printer. This would enable time of printing to be better determined. (48 tickets in image). Image of list added 29/9/2013 - see related documents for details.trams, tramways, nsw, sydney, maitland, newcastle, safeworking, staff tickets

Christmas Card prepared by Peter and Patti Duckett and sent to Keith Kings Printed photo on exterior with red printed ribbons, photo corners on inside with another photo and gold block print and the Duckett's address. Photographs by Peter Duckett. Item made for 1996 Christmas Card titled "Single Track Days on the East Brighton Line", featuring the story of the single track extension in 1937 for the East Brighton, route 64 line. Notes the staff system in use for Safeworking. Cover photo includes the driver of W2 class 452 bound for East Brighton, picking up the staff from another car and the inside print of tram 550 at the terminus."To Keith" in ink.trams, tramways, east brighton, route 64, safeworking, staff, crossing loop, w2 class, tram 452, tram 550

Training program "PTC - One person operation Training Program for Tram Depot Trainers" - outlining the training of the depot trainers for crews at individual depots. Has a course outline, ticketing instructions, zones, general driving, operational procedures, and working safely. Two additional documents - test questions for ticketing and general driving and safe workings procedures. Dated 11/2/1993.Yields information about training of tram depot trainers for one person operation.Document - comb bound with card and plastic covers, approx 30 A4 pages + two stapled document of test questions.driver training, one person, ticketing, safeworking

Page 9 to 10 has an article titled "Railwaymen as Tramwaymen", written by S. C. Weetman, looking at the St Kilda Brighton Electric Railway, notes Elwood Depot, Tramway Inspector, James Griffiths, number of trams, operations, drivers and conductors, maintenance, safeworking. Has a short section on the Sandringham Black Rock tramway. Photos - three photos looking out the front of the tram with the driver's arm on the controller and one of a maintenance man checking the underside of a tramcar. - See Reg Items 6414 and 6416 for prints of the original photos.Yields information about the VR St Kilda Brighton tramway system from a Railway perspective.Victorian Railways Magazine, June 1930, (52 pages, centre stapled), with a single colour cover of tradesmen at Newport Workshop feeding a round billet into a furnace.trams, tramways, vr trams, victorian railways, st kilda brighton electric tramway, sandringham, elwood depot

Yields information about the timetable tram services during the summer or 1914 - 1915, run numbers and crossing arrangements on the single line.Rolled blue print of the "Summer Timetable Oct 1st 1914 to April 30 1915", showing the run numbers crossing arrangements, for Gardens via Convent, Gardens via Ripon, Monday to Thursday and Friday, Saturday and Sunday. Also for Sebastopol and Rubicon St, Orphanage, Lydiard St - Mt Pleasant not listed. Gives roster arrangements, Safeworking or single line section staff arrangements, crossing points and other information. ballarat, rosters, shifts, timetables

Item used on the Victorian Railways Sandringham - Black Rock tram line for the short section of the single track of the line between the railway station in Station Street and the depot entrance in Bay Road. Tram drivers were required to carry this to prevent a head-on collision on the single-line section. Image 3 shows the driver placing the item in the "staff box" outside the depot. Image from the DVD "VR Tramways in the 1950s", with permission from Effectch the Producer. The Newport Railway Museum holds the other staffs for this line along with a damaged one (or two) for the same section - see photo 4 for the Black Rock to Beaumaris Section.Demonstrates an item used to safely work trams on the Sandringham - Black Rock - Beaumaris tram line.Two sections of steel intermeshed to form a cross and stamped.Stamped "No. 1 Section" and "Sandringham - Staff Box"trams, tramways, safeworking, sandringham, section staff

Yields information about on the Ballarat tramway staff's being shown at a local meeting after closure of the SEC operated Ballarat Tramway systemNewspaper cutting from The Courier, Thursday 23/9/1971, titled "Collector's item - relic of early days on trams" with Mrs Loyalo Hill and Mrs R Drury looking at one of the brass staffs or Section staff, used by ESCo and SEC up to 1936 at a meeting of the Ballarat turf Club the previous day. Notes that the staff is for the Victoria Park Loop to Carlton St loop - see item 4896 for the actual item.staff, safeworking, tramway staffs, sec, signals, esco

Negative No. N391 and black and white print made by a laser printer (stored in folder) of Ballarat tram No. 34 about to cross Grenville St from Sturt St into Bridge St. Photo has the driver setting the route to control the tram signals for Mt. Pleasant. Photo has the buildings along the north side of Sturt St in the photograph. Date of photo on folder - 5/9/1959, but this is incorrect, as the tram has been fitted with dash canopy lights and tiger stripes, post 1961. Folder and negative could have been mixed up. Original negative rescanned 24/5/2020 and image file updated. Paper folder that contained the negative had "NR8A" in red ink, "BA19" in pencil, date stamp of "5/9/1959" on front, and on rear date stamps "26 Sep 1962" and "26 Sep 1962".trams, tramways, sturt st, grenville st, signals, safeworking, tram 34

Negative No. N392 and black and white print made by a laser printer (stored in folder) of Ballarat tram No. 40 at the City terminus in Sturt St. on the south side. Tram has the destination of Sebastopol. Has the National Mutual Life Association building in the background, the Commonwealth Bank building and Prouds Jewellers. Date of photo on folder - 5/9/1959. Original negative rescanned 24/5/2020 and image file updated.Paper folder that contained the negative had "NR6A" in red ink, "BA20" in pencil, date stamp of "5/9/1959" on front, and on rear date stamps "26 Sep 1962" and "26 Sep 1962".trams, tramways, sturt st, grenville st, signals, safeworking, tram 40

Issued to employees of the VR St Kilda to Brighton electric street railway, superseding previous copies. The line closed in 1956. Note the spelling of the word "employe" with an accent over the e - an acceptable practice in Victoria at the time - a US based spelling. Book scanned into multiple parts. See Reg Item 3508 for a "Supplement to the Book of Instructions re the working of the St Kilda and Brighton Electric Street Railway, dated 1/1/1915", item 7518 for a June 1907 version, and 7580 for instructions issued in 1911.Demonstrates a Victorian Railway Rule book for electric tramways or Street Railways.Rule Book - 156 pages, five sewn sections within a green coloured Rexene heavy card with glued endpapers with the title "Victorian Railways Instructions re Working of the St Kilda and Brighton Electric Street Railway" and "1927" in gold block. Dated 1 June 1926. Has a table of contents and index - gives definitions - "trams" vs "street railways", general instructions, hand signs, working of cars, working of traffic over single and double line, staff and ticket systems, air brakes, permanent way, overhead, fares, appeals of employees against penalty and electric shock.Copy 3 has stamp of the "Westinghouse Brake Inspector" and "Lloyd Rogers" in ink on the inside front cover. On page 94 and 95 has notes in pencil about the air braking system - may have been for a following issue.trams, tramways, victorian railways, vr, st kilda brighton, rules, employees, safeworking

Instruction - 12 off white or light brown pages + white cloth card cover centre stapled titled "Supplement to the Book of Instructions re the working of the St Kilda and Brighton Electric Street Railway, dated 1/1/1915". Gives changes to a previous issued rule book, bell signals, air brake orders, operating orders, operation while running and instructions cancelled. Issued under the name of W. Stone Chief Electrical Engineer and T. B. Molomby General Superintendent of Transportation.trams, tramways, victorian railways, vr, st kilda brighton, rules, employees, safeworking

Provides a set of Instructions supplementary to the Rules and Regulations of the VR St Kilda Brighton Electric St Railway dated 1911. Not all pages have been copied. Issued under the name of W A Holmes Telegraph Superintendent. Gives instructions to crews and workers regarding emergency working, single-line working and operational instructions.Yields information about the "Rules and Regulations" - St Kilda Brighton - Electric Street Railway Document - photocopied, approx 80 pages secured along the top edge with two Arnos style clips.trams, tramways, victorian railways, vr, st kilda, brighton, employees, safeworking

Book - dark grey Rexene covers, with title - "Melbourne and Metropolitan Tramways Board - Rules, Regulations". Two sections, stapled and bound within heavy card covers, 80 pages with a typed index pasted inside rear covers, printed by Sands & McDougall, Melbourne. Authorised by W. O. Strangward Secretary 1923 and printed 1924. On first page, has number "6246" stamped onto the page. Provides the Rules and Regulations of the Board concerning Accidents, fire, general instructions, signals, uniforms, staff working, special instructions to Motormen and Conductors, tickets, safety for both Cable and Electric tramways. By-Law No. 5 provided on pages 76 to 80. On page 80 has the Seal of the Board and those who signed the document - Alex Cameron Chairman, Thos. O'L Reynolds Member and W. O. Strangward Secretary. Inside rear cover is a 12 page typed index to the rules in broken into sections for each letter of the alphabet - pages for M to O missing. Extract re Staff and ticket rules added 19-12-16 - see image i7. 2nd copy added 18-01-2022 Images revised - scanned in two parts. Copy No. 18812nd copy has "Inspector J H Cowrie" written on the inside front cover, 1st page and inside rear cover. Stamped "Malvern" in two locationstrams, tramways, mmtb, melbourne, cable trams, rules, regulations, safeworking

Yields information about ESCo tram No. 10, uniforms, passengers and the tramcar equipment.Black and white photograph, digital print, of ESCo 10 with Motorman, Conductor and two passengers standing on a step. Tram has the destination of Lydiard St Nth, track backs, rolled up canvas blinds. On the pillar nearest to the camera is hanging a Section Staff. Photo shows the painting scheme on the side in detail and front dash panel lining and numbers. Also shows the sand pipe, hand brake type, lifeguard and some of the internal signage. Photo c1010trams, tramways, esco, lydiard st, motormen, conductors, safeworking, crews, tram 10

Yields information about ESCo tram No. 2, uniforms, passengers and the tramcar equipment.Black and white photograph, digital print, of ESCo 2 with Motorman, Conductor and passengers sitting on the tram including a church minister. Tram has the destination of Gardens via Ripon St. Photo taken with a Gardens background., track brakes, rolled up canvas blinds. On the pillar nearest to the camera is hanging a Section Staff. Photo shows the painting scheme on the side and front dash panel lining and numbers. Also shows the hand brake type (geared), lifeguard, and strap hangers. Photo c1010trams, tramways, esco, lydiard st, motormen, conductors, safeworking, crews, tram 2

Railway systems have methods by which trains can proceed in safety from station to station, free from the risk of collision with other trains. These methods are generally known as "Safeworking" and they particularly apply to trains on single lines where trains run in opposite directions. The stations between these two sections are called crossing stations. A "Train Staff", a thick, round metal rod, bearing the name of the two stations is issued and these places are designated as Train Staff stations. No train is permitted to proceed through the section unless the train driver either takes the staff for the section into his possession or personally sights the staff. (Note that every station on the line is not a crossing station. These roles were performed at Barongarook, Gellibrand, Banool, Beech Forest, Wyelangta, Weeaproinah and Crowes.) Except for the period 1927-1939 when Train Section Orders were applied instead, due to declining business Train Staff and Ticket working was used throughout on the line.B/W. Driver Bill Brady holding the Train Staff in the cabin of Garratt locomotive G42, at Weeaproinah 1961 railways, bill brady, train driver, weeaproinah, train staff
