Showing 56 items
matching tramcar design
-
Ballarat Tramway Museum
document - Correspondence, Melbourne and Metropolitan Tramways Board (MMTB), 1963 - 1965
... Tramcar Design... to Mr. John Grimwade dated 29 April 1965, concerning tramcar..., concerning tramcar design and deputy chairman (Mr. Kirby) forthcoming ...990.1 -Typed letter from Chairman of M&MTB (Robert (Bob) Risson to Mr. John Grimwade dated 18 April 1963, concerning an letter in the Age written by J. Grimwade about Trams and Motor Cars. Written on M&MTB letterhead, with "Dear John" and author's signature "Bob Risson" handwritten in. Has been folded into four for posting. On quarto size paper, with watermark "Loganvale / Parchment / Made in Britain". Gives M&MTB phone numbers, postal and street address and telegraphic address on letterhead. 990.2 - Typed letter from Chairman of M&MTB (Robert (Bob) Risson to Mr. John Grimwade dated 29 April 1965, concerning tramcar design and deputy chairman (Mr. Kirby) forthcoming overseas trip. Written on M&MTB letterhead, with "Dear John" and author's signature "Bob" handwritten in. Has been folded into six for posting. On quarto size paper, with a watermark "? / RAG ? / Made in Australia". Gives M&MTB phone numbers, postal and street address and telegraphic address on letterhead, different design to 990.1, including phone number. Above the "Dear John" an imprint from of another sheet of paper, has been imposed on the sheet - grease mark? about 15 in diameter. 990.3 - Copy of interoffice memo from Deputy Chairman (Mr. Kirby) on yellow paper, dated 27 April 1965, replying to Chairmans memo of 26 April 1965, about the design of new trams, with steps inside the doorways. Signed by Mr. Kirby. Has been folded for mailing. Has left hand edge partly folded in. 990.4 - Copy of interoffice memo from Chairman (R. Risson) to Deputy Chairman, about a suggestion by Mr. Grimwade about running boards and the width of trams. Notes Chairman's view that the policy of running boards was deliberate in order that cars collided with them first rather than the tram body. On blue paper. Signed by the Chairman. Has been folded for mailing. Item 990.2 to 990.4 stapled in top left hand corner.Signatures and names tram, trams, melbourne, footboards, tram steps, mmtb, tramcar design -
Melbourne Tram Museum
Document - Report, The Commonwealth Engineer, Electrical Engineer, The Electrical Engineer and Merchandiser, Noiseless Tramcar - first Australian Vehicles - Bogies fitted have special noise reducing features, 1917 - 1951
... Tramcar Design... - "Modern Tramcars for Melbourne - Design for reduction of noise... W5 class SW5 class PCC Class Tramcar Design Electrical ...Set of 12 reports, photocopied onto heat sensitive paper from various magazines. Documents match the image numbers. .1 - 2 pages, from The Commonwealth Engineer, 1/10/1917 - "New Cars for the Melbourne Brunswick and Coburg Tramways", written by Straun Robertson. .2 - 2 pages, from The Commonwealth Engineer, 1/3/1919 - "Double Bogie Combination Tram Car - St Kilda Brighton Electric Line". .3 - 2 pages - Electrical Engineer - 15/6/1924 - "One Man cars for Melbourne and Geelong Vic. The Brill Birney Safety Car" .4 - 1 page - Electrical Engineer - 15/11/1925 - "Standard Car for Melbourne Tramways" - has sketch of W2 369. .5 - 2 pages - Electrical Engineer - 15/8/1927 - "New Bogie car for Melbourne Tramways" Y class. .6 - 2 pages - Electrical Engineer -15/3/1936 - "Tramcar of New type for Melbourne - Large car for Two-man or One-man operation" - Y1 class .7 - 3 pages, The Electrical Engineer and Merchandiser - 15/3/1932 - "Modern Tramcars for Melbourne - Design for reduction of noise and construction with electrical Welding" W3 class. .8 - 2 pages, The Electrical Engineer and Merchandiser - 15/11/1933 - "New Tramcars for Melbourne" - has sketch of the W4 class tram. .9 - 3 pages, The Electrical Engineer and Merchandiser - 16/12/1935 - "Melbourne's Lates Tramcars, comfortable Accommodation and modern traction equipment" - W5 class .10 - 3 pages - The Electrical Engineer and Merchandiser - 15/3/1939 - "Improved Type Tramcar - advanced truck design, pneumatically operated doors, special lighting, acceleration 3pmh per sec." SW5 class. .11 - 3 pages - The Electrical Engineer and Merchandiser - 15/9/1950 - "Noiseless Tramcar - first Australian Vehicles - Bogies fitted have special noise reducing features - motor drive through bevel gears, dynamic braking" - PCC 980 (See also Reg Item 5601 for a similar report) .12 - 1 page - handwritten on the rear of a copy of item 11 - Editorial from the Oct. 1951 issue of same magazine looking at the rate of acceleration. Reprint of .7 added 30/7/2019, from papers ex Robert Green - in poor condition, has been folded, both left and right hand edges in multiple tears. The photos are good. Measures 282H x 220W.trams, tramways, mmtb, mbctt, new tramcars, vr, bogie trams, birney, x class, w2 class, y class, y1 class, w3 class, one man trams, w4 class, w5 class, sw5 class, pcc class, tramcar design, electrical engineering -
Melbourne Tram Museum
Document - Report, Melbourne & Metropolitan Tramways Board (MMTB), "MMTB Planning Branch - Maximum Capacity of a Double Track Tramway", Jun. 1968
... Tramcar Design...Trams tramways MMTB Tram Stops Swanston St Tramcar Design ...Report - 9 foolscap sheets - titled "MMTB Planning Branch - Maximum Capacity of a Double Track Tramway", dated June 1968 looking at the capacity of Swanston St in peak hours compared to an underground tramway with bogie or articulated trams. Compares different types of trams - SW6 to PCC, headways, time intervals, size of tram stops, traffic lights and comments. 2nd copy - original document - card covers, red binding on the left hand side - with three diagrams,2nd copy has "Lees" in top right corner.trams, tramways, mmtb, tram stops, swanston st, tramcar design, tramcar operations, traffic lights -
Melbourne Tram Museum
Newspaper, The Age, "Trackless and with rubber wheels, it may be our next generation trams", 2/05/2021 12:00:00 AM
... Tramcar Design... class Z class A class UGL Tramcar Acquisition Tramcar Design ...Newspaper clipping titled: “Trackless and with rubber wheels, it may be our next generation trams” by Timna Jacks Newspaper clipping from the Age 02/05/2021 Rubber wheels, electric batteries and no overhead wires could be the future for Melbourne’s trams. By 2025, 100 new trams will be designed and built due to a $1.5 billion government injection to fund 100 ‘‘next-generation trams’’, replacing A and Z-Class trams. Two manufacturers have been shortlisted to design and build the trams: French rail manufacturer Alstom and a joint venture comprising Spanish rail maker CAF and UGL. At 25 metres long – about eight metres shorter than the newest E-Class trams – the trams will carry 150 passengers, fewer than the E-Class, which carry 210 people. Despite the smaller size, seating will remain proportionally comparable with the E-Class, with 48 people or a third of passengers getting a seat on the new fleet. The new fleet will be the first in Melbourne to be partly powered by on-board batteries.trams, tramways, yarra trams, keolis downer, caf, rolling stock, e class, z class, a class, ugl, tramcar acquisition, tramcar design, tramcar manufacture -
Melbourne Tram Museum
Document - Report, Norm Cross, "Notes on M&MTB Y and Y1 class tramcars", Nov. 1970
... Tramcar Design... Acquisition Tramcar Design Tramcar Construction Report - typed ...Report - typed - quarto sheet - two sheets, stapled titled "Notes on M&MTB Y and Y1 class tramcars" written by Norm Cross in November 1970. Looks at the history of Y469, and Y1's 610 to 613 including notes on the design, use, construction issues, depots, changes over the life and the use of 613 by the VR on the Sandringham to Black Rock line.trams, tramways, y class, y1 class, tram numbering, tramcar acquisition, tramcar design, tramcar construction -
Ballarat Tramway Museum
Document - Display Board with mounted signs, Peter Lambert, 23/04/2020 12:00:00 AM
... Tramcar Design... Aidans Drive Gardens Depot Tramcar Design Carlton St World War I ...Set of 12 A3 proofs, colour, for comment in a large envelope with notes on the outside written by Dave Macartney of the almost final versions of the 12 panels that were installed in Shelters through a Public Records Office of Victoria grant during March 2020. Designed by Peter Lambert Design. 1 - Depots backed by Victoria St 2 - Tram Types - backed by the Mt Pleasant Line 3 - Beginnings backed by the Lydiard St Line 4. - Conductors backed by the Sebastopol line 5 - Carlton St backed by Trams in the City 6 - The Gardens backed by The Gardens lines. The final version for the two at St Aidans drive were changed following Council consultation into a different sized panel but with the same content. Image files are those from Peter Lambert that went to the panel makers. Panels by The Sign Shop The image files are not opened by this program. trams, tramways, displays, interpretation, pro, grants, st aidans drive, gardens, depot, tramcar design, carlton st, world war i -
Melbourne Tram Museum
Document - Folder, Melbourne & Metropolitan Tramways Board (MMTB), "MMTB General Data of Tramcars", compiled to c2005
... Tramcar Design...Trams tramways Drawings Tramcars Cable Trams Tramcar Design ...Set of 60 A3 sheets, comprising a folder of GA Drawings – from Keith Kings, held with black plastic semi elastic black clip or retaining strip. All drawings have been scanned (about 50% were already scanned, e.g. the first sheet) and placed on the Depot Tramcar Mechanical component listing. Order of drawings as received has been retained and listed as follows. R1146 – General Data of Tramcars – 24-9-1924 R11-927 – SW6 and W6 – Advertising Panel Location R11-928 – W7 Advertising Panel Location R9529 – Class W7 GA List of Tramcar GA Arrangement Drawings dated 13/12/1974 Cover sheet – “Melbourne and Metropolitan Tramways Board – Electric Tramcars Index - lists Class, numbers and Drawing Nos. R1266 – Cable Train – Dummy and 4 wheel trailer R3799 – Cable train – Dummy & 4 wheel trailer R3422 – Cable train – dummy & Bogie trailer PMTT 161 – Combination Car R3076 – Class A – Combination Car Dropped ends PMTT – 163 - Bogie car with dropped centre compartment PMTT – 700 – Bogie Car with dropped centre compartment and longitudinal rattan saloon seats R3078 – Dropped Centre bogie car – Maximum Traction R4571 – Dog Transport Car – class C converted PMTT 162 – Summer car (old type) – F class PMTT 164 – Summer car – G class R3079 – Class L R7416 – Class L PMTT 160 – Bogie Closed Car – (O class) R9787 – Class G – All night tram style R3077 – Class G – All night tram style R8999 – Class A tramcar Coburg type Original – S class R5963 - Class A tramcar Coburg type Original – S class (modified) R3093A - Class T R4382 – Class T arrangement for one-man operation Car 178 R3756A – class U R2461 – class W – W class converted to W2 R2460 – class W1 R2459 – class W2 R4646 – class SW2 R9525 – class SW2 R3071 – class W3 R3812 – class W4 R4678B – class W5 R9601 – class CW5 R5818 – class SW5 R12-052 – Class W5 – sliding door conversion R4771A – class SW6 (reversible seats) R6408A – class SW6 (Tubular Fixed Seats) R8617 – class SW6 and W6 R9529 – class W7 R10-129 – Class VR car R8332 – PCC type car R2462 – class X R1811 – types of electric cars – class X Safety car R2463 – class X1 R3080 – Class X2 R2464 – class Y R2465 – class Y1 R10-946 – All electric tram – 1041 R11-333 – class Z1 and Z2 trams R11-387 – class z outside dimensions R11-563 – Class Z tram (101-115) R11-580 - class Z3 tram R12-062 – Class A tram T4000-12 – double ended 6 axle articulated LRV – a possibly arrangement R6928 – PCC Car – double end operation R9980 – Freight car 17 – former V class passenger car See Reg Item 5639 for a similar document.trams, tramways, drawings, tramcars, cable trams, tramcar design, preston workshops, mmtb -
Melbourne Tram Museum
Drawing, Melbourne & Metropolitan Tramways Board (MMTB), "Proposed SW6 car (with front entrance)", 1965
... Tramcar Design...Trams tramways Drawings Tramcars SW6 class Tramcar Design ...Drawing - MMTB R9622, produced on an A3 sheet, titled "Proposed SW6 car (with front entrance)", also drawing No. X127. Drawing dated in drawing Register as 22/8/1965. See also Reg Item 4620 from a modified version used by Transit Australia Publishing.trams, tramways, drawings, tramcars, sw6 class, tramcar design -
Melbourne Tram Museum
Document - Folder, Public Transport Corporation (PTC), "MMTB Electric Tramways", c2000
... Tramcar Design...Trams tramways Drawings Tramcars Tramcar Design Preston ...Set of 41 A4 sheets, photocopied with the title "MMTB Electric Tramways", providing GA drawings of the following: R1146 – General Data of Tramcars – 24-9-1924 PMTT 160 - PMTT Bogie closed car (O class) PMTT 161 - PMTT Combination car PMTT 162 – Summer car (old type) – F class PMTT 163 - PMTT Bogie car PMTT 164 – Summer car – G class PMTT – 700 – Bogie Car with dropped centre compartment and longitudinal rattan saloon seats R2461 – class W – W class converted to W2 R2460 – class W1 R2459 – class W2 R2462 – class X R2464 – class Y R2463 – class X1 R2465 - class Y1 R3071 - class W3 R3076 - class A R3077 - class G R8617 - class Sw6 and W6 R3078 - Class C R3080 – Class X2 R3093A - Class T R3812 - class W4 R4382 - class T - arrangement for one man operation R4646 - class Sw2 R4678B - class W5 R4771A - Class SW6 R5818 - class SW5 R5963 - class A - One man Coburg type R6928 - PCC Car - double end operation (based on a USA drawing) R7416 - class L R8332 - PCC Type car (980) R8999 - Class A tramcar Coburg type original R9601 - class CW5 R9529 - class W7 R9622 - Proposed SW6 car with front entrance R9980 - Freight car 17 R10-129 - class VR R11-333 - Class Z1 and Z2 trams R11-387 - class Z 0 outside dimensions R11-580 - class Z3 tram R12-052 - class W5 sliding door conversion R12-062 - class A tram Articulated tram - class B2trams, tramways, drawings, tramcars, tramcar design, preston workshops, mmtb -
Melbourne Tram Museum
Document - Report, Melbourne & Metropolitan Tramways Board (MMTB), "Information - Tram 980 (PCC Equipment)", Feb. 1964
... Tramcar Design... Specification Tramcar Manufacture Tramcar Design Maintenance tram 980 ...Report - carbon typed copy - 43 foolscap sheets bound within a brown card folder, stapled, with signs of an adhesive tape binding on the outside. Titled "Information - Tram 980 (PCC Equipment)", dated February 1964, prepared by the MMTB Engineering Department Testing Department Report No. I 5/1/144. Signed by W. Hines 6/2/64, report prepared by CLF. Provides a synopsis of the report, purpose of investigation, design, operational history, time in workshops, maintenance program, schedule speeds, riding qualities, has appendices with design modification, list of time in workshops, PCC tramcars maintenance program, workshops maintenance of ten typical trams, MMTB Tramcar Schedule speeds. Includes photographs of the failure of the main body transom and the replacement one, and two graphs. Second copy added 31-5-2016 from donation of Geoff Warburton. This copy - has red binding tape.trams, tramways, testing, pcc, preston workshops, reports, specification, tramcar manufacture, tramcar design, maintenance, tram 980 -
Melbourne Tram Museum
Document, Melbourne & Metropolitan Tramways Board (MMTB), Untitled - "SW6 class", May. 1939
... Tramcar Design... Controllers Tram Equipment Tramcar Design Has a note in pencil about ...Report - 7 quarto typed sheets - untitled, but gives a detailed description of the design basis and construction of the SW6 class tram. Dated May 1939. Details the design after Bell's overseas trip the previous year. Details dimensions, seating, ventilation, seating, doors, structure, construct, timber, materials, door engines, cab equipment, PA system, interior appearances, flooring, colours, lighting, conductor's bell / signals, trucks, bolster, wheels, brake shoes, braking, motors, acceleration, performance, controllers, contactors, compressor. Gives a detailed list of the specifications.Has a note in pencil about a typographical error on the bottom of the sheet.trams, tramways, sw6 class, specification, tramcars, tram controllers, tram equipment, tramcar design -
Melbourne Tram Museum
Drawing, The Met, "Step Heights", c1984
... Tramcar Design... Trams tramways Drawings Tramcars Class Tramcar Design Drawing ...Drawing - A2 sheet, "Step Heights", listing all vehicles in use c1984, including A and B class data in both inches and mm. Drawing No. X1540.trams, tramways, drawings, tramcars, class, tramcar design -
Melbourne Tram Museum
Drawing, Transit Australia Publishing, "Siemens Combino Three Section Tram (Melbourne Class D1)", "Siemens Combino Three Section Tram (Melbourne Class D2)", Nov. 2002
... Tramcar Design... Trams tramways Drawings Tramcars D class Tramcar Design Set ...Set of two drawings of the Melbourne Siemens Combino Trams, class D1 and D2, produced by Transit Australia, November 2002, based on plans from Siemens Transportation. Side and end elevations and floor plans with leading dimensions. .1 - "Siemens Combino Three Section Tram (Melbourne Class D1)" .2 - "Siemens Combino Five Section Tram (Melbourne Class D2"trams, tramways, drawings, tramcars, d class, tramcar design -
Melbourne Tram Museum
Drawing, Transit Australia Publishing, "Melbourne Citadis 302", Nov. 2001
... Tramcar Design... Trams tramways Drawings Tramcars C Class Tramcar Design Drawing ...Drawing of the produced by Transit Australia, November 2001 of the Citadis 302 tramcar by Alstom Transport France. Side and end elevations and floor plans with leading dimensions. .1 - "Siemens Combino Three Section Tram (Melbourne Class D1)" .2 - "Siemens Combino Three Section Tram (Melbourne Class D1"trams, tramways, drawings, tramcars, c class, tramcar design -
Melbourne Tram Museum
Newspaper, Mr. Melbourne Day by Day, "Mr. Melbourne Day by Day", 20/02/1926 12:00:00 AM
... Tramcar Design... Trams tramways Tramcars Cartoons Tramcar Design Passengers ...Newspaper cutting from The Sun, 20/2/1926, glued to an A4 sheet with a cartoon from "Mr. Melbourne Day by Day", observing a lady passenger climbing aboard a W class tram, commenting about the high steps involved in boarding tramcars.trams, tramways, tramcars, cartoons, tramcar design, passengers -
Melbourne Tram Museum
Drawing, concept drawings for tramcars by the MMTB, 1940's to 1970's
... Tramcar Design... Trams tramways MMTB New Tramcars Tramcar Design PCC W6 class Z ...Series of 12 concept drawings for tramcars by the MMTB, c 1940's printed on white paper or where noted ink on mylar paper - original drawings. .1 - Proposed single truck car - three doors with some window shading. .1A - ink on mylar of the same drawing - with different window shading and paper copy. .2 - as above with no window shading .3 - as above with shaded windows .4 - a SW6 style car with two centre doors with shaded windows. .4A - ink on mylar of the same drawing - with different window shading. .5 - as above with two partly shaded windows .6 - "Proposed box car" - three doors with shaded windows. .6A - ink on mylar of the same drawing - with different window shading. .7 - as above with partly shaded windows - two copies .8 - Large car - PCC Stylish - two doors with partly shaded windows .8A - ink on mylar of the same drawing - with different window shading and paper copy. .9 - as for .4 with some windows fully blacked out. .9A - similar but different window shading .10 - "Proposed W5 tramcar" =- with two passenger doors and shaded windows .10A - ink on mylar of the same drawing - with different window shading and paper copy. .11 - as above but clear windows .12 - as for .7, but with half windows blacked out. .13 - ink on mylar of a Z class tram with three doors (has a sheet of A4 paper taped on top edge as backing) .14 - as above - different door layout .15 - ink of mylar of a W6 class tramtrams, tramways, mmtb, new tramcars, tramcar design, pcc, w6 class, z class -
Melbourne Tram Museum
Drawing, Commonwealth Engineering (Comeng), "General Assembly T4000 Articulated Tram", 1987
... Tramcar Design... Trams tramways MMTB New Tramcars Tramcar Design B class Comeng ...Drawing - Commonwealth Engineering - Comeng - spread over two A3 sheets titled "General Assembly T4000 Articulated Tram", showing the layout and dimensions of the proposed tram, with the option of couplers. Became the B class tram.trams, tramways, mmtb, new tramcars, tramcar design, b class, comeng -
Melbourne Tram Museum
Document - Report, Commonwealth Engineer, "Australia's first "Noiseless" Tramcar", 1950
... Tramcar Design... Trams tramways PCC Class PCC 980 New Trams Tramcar Design Bogies ....1 - Photocopy of a two A4 page document titled "Australia's first "Noiseless" Tramcar" from the September 1, 1950 issue of Commonwealth Engineer. Report details the noise reducing features of PCC car 980, bogies, the car body with dimensions and its USA licence for the manufacture of such cars in the Australia. See also Reg Item 3420.11 for a similar report.trams, tramways, pcc class, pcc 980, new trams, tramcar design, bogies -
Melbourne Tram Museum
Letter, "Scrubber Car", 1931
... Tramcar Design... Trams tramways Scrubber Tram Tramcar Design New Trams Work Trams ...Letters - comprising 9 sheets, between April and June 1931 titled "Scrubber Cars" - correspondence concerning the design of a new type of scrubber tram (would have been No. 5, and then later on No. 8) between the MMTB and MTT Adelaide. Considers block access, operation, motor sizes, refers to drawings which at the time of cataloguing are yet to be scanned.trams, tramways, scrubber tram, tramcar design, new trams, work trams, mtt, adelaide -
Ballarat Tramway Museum
Manual, Doug Prosser, "Self-Lapping Drivers Brake Valve - Type W", "Type E Relay Valve", 1998
... Valve, fitted to W3 and W4 tramcars, with design and operating... Valve, fitted to W3 and W4 tramcars, with design and operating ...779.1 - 4 page photocopy of a Westinghouse manual for a Type W Self Lapping Brake Valve, fitted to W3 and W4 tramcars, with design and operating information, drawings of parts and a graph showing its operation. Produced by Westinghouse dated 1946. 779.2 - 4 page photocopy of a Westinghouse manual for a Type E Relay Valve, working in connection with the W Self Lapping Brake Valve, fitted to W3 and W4 tramcars, with design and operating information, drawings and a list of parts. Produced by Westinghouse, dated November 1955. Copy of document made for BTM March 1998 by Doug Prosser. All sheets stapled together in corner.trams, tramways, brake valves, westinghouse, maintenance, type e relay valve -
Ballarat Tramway Museum
Book, Aberdeen Corporation Transport, "Aberdeen Corporation Transport - Experimental", Jul. 1940
... - Experimental" notes re tramcar, with design and other technical details... Transport - Experimental" notes re tramcar, with design and other ...12 page printed booklet with larger printed card cover - 5 photo pages, titled "Aberdeen Corporation Transport - Experimental" notes re tramcar, with design and other technical details - 2 staples. Provides detail of an experimental streamliner built for the Aberdeen tramways for its official launch on 12 July 1940. Alfred Smith was the General Manager. Record updated and images added 19/8/2013.trams, tramways, aberdeen trams, experimental tramcars, uk -
Melbourne Tram Museum
Newspaper, The Sun, The Herald, The Age, "Rises in Tram Fares Hits at Pensioners", "Tram Fares may increase" "Train chaos if no new station soon", Nov. 1968
... the design of tramcars - letter from J. Wunderly of Burwood... the design of tramcars - letter from J. Wunderly of Burwood ...Newspaper Clipping - set of six clippings adhered to two sides of one sheet of ruled quarto paper with punched holes on the left hand side - primarily about the increase in fares - Nov. 1968 1 - "Rises in Tram Fares Hits at Pensioners" 2 - "Tram Fares may increase" 3 - "Train chaos if no new station soon" - Flinders St station 4 - "Fares Rise next year" 5 - "Sunday trams adequate" 6 - "Change Tramways Board of the system" - about the design of tramcars - letter from J. Wunderly of Burwood. Cuttings from The Herald, The Age and Sun newspapers.trams, tramways, fares, flinders st station, sunday services, tramcars -
Bendigo Tramways (managed by the Bendigo Heritage Attractions)
Book, The Electric Tramcar Handbook, 1909
A brown hard cover reference book, designed for use by Motormen, Inspectors and Depot Workers, by W.A. Agnew.Stamped on first page; Agents for Western Australia. H.B. ALBERT & CO. Book & Music store 20 to 38 Central Arcade, Perth. -
Ballarat Tramway Museum
Memorabilia - Display Board with mounted signs, Graeme Sewell, 5/02/2004 12:00:00 AM
Varnished wooden panel fitted with 13 different tramway or railway related signs and one small image of a Melbourne Tramcar. The panel consists of two pieces of plywood glued to wooden backing boards. The signs have been fixed to the panel with brass screws - either round or countersunk. The signs are: "Passengers are not allowed in this Compartment / By-Law No. 5 Maximum Penalty - Five Pounds" "Passengers are requested to tender the EXACT FARE" "NO SMOKING" "NO EXIT" "SMOKING" "DESIGNED AND MANUFACTURED AT THE / TRAMWAYS BOARD'S WORKSHOPS / PRESTON" "TO STOP CAR PULL LEFT / HAND CORD ONCE" "Spitting in the car is STRICTLY PROHIBITED / Passengers infringing this Rule are liable to be ejected and prosecuted under the Board's By-law No. 5" "To stop car pull left hand cord ONCE / Entering or leaving this car from the wrong side is prohibited. Maximum penalty L5." "SPARE / CONTROLLER KEY" "In EXTREME DANGER / STOP THE TRAIN / by pulling CHAIN in this direction / Penalty for misuse L20" "Passengers are not permitted / to travel in this compartment." "RAILWAY MOTOR / TYPE GE 247-A / DL 2755000 SERIAL No. A2320 / AUSTRALIAN MANUFACTURE / AUSTRALIAN GENERAL ELECTRIC LIMITED / P.1022" L = pound symbol Signs collected by Graeme Sewell who assembled the Display Board during the 1980's.trams, tramways, signs, railways, tramways, passengers -
Ballarat Tramway Museum
Document - Photocopy, Boyce Pizzey and Booz Allen & Hamilton, "Final Report - New Directions for Melbourne's Tramway Heritage", 2001
Photocopied Report - 105 pages, titled "Final Report - New Directions for Melbourne's Tramway Heritage", dated Jan. 2001, prepared for the Department of Infrastructure by Booz Allen & Hamilton, Convergence Design Pty Ltd and Boyce Pizzey Strategic. Chapters are Introduction, Tramcar Collections, Other Tramway Heritage, Heritage Significance, Opportunities and Management Plan. Held by a large spring back binder. See Reg item 4264 and 4266 for associated papers. trams, tramways, melbourne, heritage, trams, museum, conservation -
Melbourne Tram Museum
Poster, Yarra Trams, "Welcome aboard your new look Yarra Trams", 2010
Poster -"Welcome aboard your new look Yarra Trams" showing an artist impression of the proposed livery design scheduled to be implemented from 2010. Tram Z2 113 - not know if this tram was actually painted in this livery. The tram was withdrawn from service during 2015.Demonstrates and artists impression of a Yarra trams colour scheme or livery.A3 size sheet printed in full colour.tramways, tramcars, z2 class, tram 113, artist impression, livery, yarra trams -
Melbourne Tram Museum
Document - Report, Melbourne & Metropolitan Tramways Board (MMTB), "Single-ended tram operations - a Feasibility study", mid 1970's
Report - 104 pages, with orange card and plastic covers, bound with a black coloured comb binder titled "Single-ended tram operations - A Feasibility study". Looks at the background for the proposal, operational issues, including loading and unloading, a CBD loop, capital costs, traffic issues, implementation, vehicle design. Report notes it has many advantages and disadvantages, but the concept was supportive that single ended vehicles should be introduced. Report not dated as such, but discusses the ordering of new tramcars in 1977/78, dated c1977. See Also Reg Item 337. On front cover is a post-it notes commenting about report - see image. See Reg Item 4388 for the contract tender document for the Z3 class trams which included the option for a single ended tram.Stamped on cover and inside page "Discarded from PTC Library 19 Oct 1989".trams, tramways, single ended tramcars, mmtb, bourke st, collins st, turning loops, swanston st, william st -
Melbourne Tram Museum
Document - Specification, Melbourne & Metropolitan Tramways Board (MMTB), "Design, Manufacture and delivery of 100 only all-electric trams", Jun. 1965
Specification or Tender Document - titled "Design, Manufacture and delivery of 100 only all-electric trams", and "Background Information and Preliminary Specification", dated June 1965. Bound into a brown foolscap card cover. Details the conditions of tender, conditions of contract, notes, specification, gives background information about Melbourne, dimensions, performance, drivers and conductors, trucks, wheels, brakes, electrical equipment, control panels and drawings. The drawings give a map of the system, typical city route, Glenferrie Road route (grade diagram), concrete track construction, min. radius curves, loading gauge, all-electric tram and mounting details for the trolley base, schedule of prices, tender form, form of contract, schedule of information to be provided by the tenderer. Comprises: 1 - Conditions of Tendering - 1 page 2 - Conditions of Contract - 4 pages 3 - Contents - 3 pages 4 - Notes for prospective tenderers - dated June 1965 5 - General nature of contract - 21 pages 6 - Appendix A - climate data - two sheets 7 - List of 14 appended drawings 8 - O.6887A - cross section of trolley wire 9 - P.13855 - Glenferrie Road, Longitudinal Section 10 - P.13856 - Wattle Park Route 11 - P.13857 - East Preston Route 12 - P13858 - Concrete track construction 13 - P13859 - Open track construction 14 - P.13860 - Paved ballast track construction 15 - P.13887 - Tram Route - locations of substations and section switches 16 - P.13888 - Minimum radius service curves to give minimum clearance between tramcars 17 - P.13889 - Grooved Rail - 102 pounds per yard and tire profile 18 - R10-301 - Loading gauge, proposed electric tramcars 19 - R9706K - Rolling stock data, tramcars 20 - R10306 - Collins Points Shifter - Wiring diagram. 21 - Schedule of data to be supplied by the tenderer 22 - notes on Automatic Points shifters - 2 sheets 23 - Tender prices and delivery periods - 2 sheets. See Reg Item 2266 for the 1972 version and 1583 for the August 1966 version. See Reg Item 4049 for associated newspaper cuttings. See file htd4667i1.pdf for scans of the drawings.In ink in top right hand corner - "Lees"trams, tramways, specification, tenders, z class, mmtb, melbourne -
Ballarat Tramway Museum
Functional Object - Builders' plate - Tramway Board's Workshop Preston, Melbourne and Metropolitan Tramways Board (MMTB), "Designed and Manufactured at the Tramway Board's Workshop Preston", about 1926
Demonstrates the method of recording who built the tramcar body.Rectangular cast brass Builders' Plate with raised edge, inner lined letters in capitals "DESIGNED AND MANUFACTURED AT THE TRAMWAY'S BOARD WORKSHOP PRESTON" Four mounting - countersunk in corners - matt dark grey background - paint?On rear in faint purple crayon "460"tramways, trams, builders' plate, melbourne, mmtb -
Ballarat Tramway Museum
Document - Form/s, Melbourne and Metropolitan Tramways Board (MMTB), "Supplementary Running Journal", 1950's
Yields information about the possible source of a similar document in Ballarat, a MMTB form for enabling ticket checking on trams, very similar in style.Single sheet of paper titled "Supplementary Running Journal", form No. 134, for filling in ticket starting numbers, for various value tickets. Also allows for transfer tickets, tramcar no, trip details examiner, inspector and punch marks. Has line for filling in date and signature at base of ticket. Used in Melbourne, max fare 6d, 1950's . Used as the model in Ballarat - See Reg Item 68, very similar in design. Item from Peter Winspur.On rear in pencil is a faded address and details - event or a passenger name who did not have a ticket?trams, tramways, mmtb, by laws, tickets, fares
