Printed timetable for the Chicago Transit Authority "Evanston Express Service", timetable No. 30, effective September 3, 1963. Has details of the express service timetable and fares charged. On the front cover has a written note "Converted from PCC trams" - See Other Information for further details. See Wikipedia files accessed 30-10-2011.In ink "Converted from PCC trams".chicago, timetables

Wal Jack kept extensive notes on railways and tramways around the world, provided by his correspondents and research. This set of sheets lists PCC-type streetcars or trams ordered by North American cities between 1936 and 1947, including a summary of who ordered the most cars. Includes note on the builders. When compared to the reference, there are errors or differences. Bickarts were Ballarat Watchmakers and Jewellers.Yields information about type of work undertaken by Wal Jack.Four orange colour quarto sheets using Bickarts' letterhead providing lists of PCC Type trams built for North American cities.letters, wal jack, archive, usa, records, bickarts, pcc trams

Report - typed copy - 14 foolscap sheets stapled in top left hand corner. Titled "Report on Road Tests on PCC and SW6 trams to determine performance"", dated September 1950. Report is in complete, refers to the graphs which have not been included. Report looks at the current consumption using an oscillograph, on PCC 980 and newly completed SW6 959. Gives tests results, methods, location and details of the trams.trams, tramways, preston workshops, reports, specification, tramcars, pcc, tram 980, tram 959

Report - 3 foolscap typed sheets, titled , dated 24 July 1950. Document details the PCC tram for an article describing in detail the tram, the seating, floor, ceiling, strap hangers, PCC equipment, supplied St Louis Car Company, bogies, electrical equipment, controllers, general description, equipment compartments, doors, trolley pole and a list of principal dimensions. Signed A. Stephenson 24/7/50.trams, tramways, pcc, new trams, manufacturing, licence fees, agreements, bogies, controllers

Document produced by the Transit Research Corporation of New York, details the specifications for the Presidents Conference Committee (PCC) for a streetcar or tram for American cities. The MMTB researched this type of tramcar for use in Melbourne, taking out a licence for their production. This document dated 1/4/1947 with revision to 1/6/1950 would have been part of the licence agreement. Unfortunately, there were insufficient funds to build this type of tramcar. Only tram 980 which was based on a modified W6 class body was fitted with PCC equipment, later transferred to prototype PCC tram 101. See reference.Yields information about the technical specification for US PCC tramcars.Document - bound with card covers, approx 300 printed pages including folded drawings held by an Arnos type steel binding clip,On the spine with a green/white label "Specifications for PCC Car"tramways, tramcars, pcc, new trams, tramcar specifications

Set of four colour slides taken during the Monash Railway club tour on 9-8-1970 using PCC 980 from Malvern Tram Depot. The route number and destinations are for show only. Photographs by Warren Doubleday.Yields information on Monash Railway club tour, the trams used and the locations.Set of five Anscochrome colour slides, of Melbourne tram PCC 980 on a Monash Railway Club tour - 9-8-1970 .1 - PCC 980 on the depot access tracks for Malvern Tram Depot in Coldblo Road .2 - With the Malvern Tram Depot in the view .3 - In Dandenong Road at Hawthorn Road .4 - Crossing Hawthorn Road - has a tram shelter in the view. .5 - About to use the then new Nolan St (now Southbank Blvd) crossover.Has photographers slide numbers on each slide.monash railway club, tram 980, malvern depot, hawthorn road, dandenong road, nolan st, tramways, trams, pcc class

Wal Jack collected tramway and railway items for his collection. This illustration of the first production President's Conference Committee (USA Transit operators) of 1936, built for the Brooklyn & Queens Transit Corporation. See reference for the background. The tram itself is now part of the collection of The Shore Line Trolley Museum, East Have CT. Melbourne Tram 980 was built using the PCC technology.Demonstrates a Tram that would have interested Wal Jack.Printed illustration of Brooklyn & Queens No. 1001 - the first production PCC Carletter, wal jack, pcc trams, usa, brooklyn

Provides publicity photographs of the prototype PCC tram 1041, that lead to the construction of the Z class trams.Yields information about prototype tram 1041Set of four colour prints and one black and white print of prototype tram 1041 on Riversdale Road, with Wattle Park in the background, second half of 1973, during commissioning and testing phase. .1 - tram showing special and route 000 - has been printed so that the background above the tram has been partly faded. Both printed on Kodak Paper. .2 - tram showing W. Park - Elgar Rod, route 070 - two copies .3 - similar to .2, at different location with park in background. Printed on Kodak paper. .4 - same as .1 - Has PTC copyright stamp on rear and number 3953 - better colour. .5 - black and white print - with PTC stamp and number 3953.tramways, trams, mmtb, prototype tramcar, tram 1041, riversdale road, wattle park

The photograph shows the procedure for releasing the drum brakes on PCC tram 980 and where the brace (spanner) is located on the tram. Dated 24/8/1960.Demonstrates the methodology of releasing the drum brakes on a PCC car.Photograph - black and whiteHas MMTB stamp on rear and number P25/1/248 in ink.trams, tram 980, brakes, pcc class, tramways, mmtb, st. louis b3

Negatives No. 270 and 271 and colour print made by colour laser printer (stored in folder ) of Melbourne PCC tram No. 980 decorated for the Royal Visit. Two negatives very similar. No. 271 slightly closer up by corners have light coming in. Envelope describes the negatives as "Especially decorated tram from Royal visit. It was the PCC tram done up. At Caulfield on the Darling Road, Pt Ormond Line. Feb. 23, 24, 25, 26 '54". 2 views side on". Photo by Geoff Grant. Negative scanned and image updated 19/5/2020.trams, tramways, pcc, point ormond, caulfield, darling road, tram 980

Negative No. 273 and colour print made by colour laser printer (stored in folder ) of Melbourne PCC tram 980, in Coldblo Road , Malvern depot, during an AETA tour on 8/5/1954. Photo by Geoff Grant. Envelope with negative describes the scene as "980 PCC type tram. It is unconventional tram with some American ideas and components." Hi res scan of negative and image updated 19/5/2020.trams, tramways, malvern depot, pcc, coldblo road, aeta, tram 980

Duplicated quarto sheet for the Victorian Schools Railway Club Association, VSRCA, tour during 1960 using MMTB PCC tram 980. Provides details of the tramcar and its Melbourne operation. On the rear is a typed note thanking the person for the book and that it will be departing Malvern at 2pm. No date on the circular.trams, tramways, vsrca, pcc, tours

The photograph, by an MMTB photographer, shows PCC car 980. A significant tram, was the first example of an American PCC tramcar used in Australia. The technology used was very successful with many examples in North America and Europe. See the reference for the background to this type of tram.Yields information about a tramcar that was technologically advanced compared to other Melbourne tramcars at the time.Postcard - full colour, divided back.Has MMTB stamp on rear.tramways, tram 980, pcc class, trams, mmtb

Report - 9 foolscap duplicated sheets, titled , dated 13 Oct. 1938. Report looks at the background to the development of the tram, the project objectives, development history, the story, noise, design features, the trucks, use of rubber, weight, speed. Notes on his visit to Brooklyn, revenue results, safety, accidents, his visit to the Canadian Car and Foundry Co of Montreal, securing the rights for Australia, licences, royalties, terms of any agreement and finally a recommendation to enter into an agreement for the tram.trams, tramways, pcc, new trams, manufacturing, licence fees, agreements, canada

Memorandum - carbon copy - two foolscap sheets and one quarto sheet - titled "PCC Agreement", regarding the agreement between the MMTB and Transit Research Corporation of the USA regarding the licence to use PCC Equipment dated and initialled by R. J. Risson Chairman 20/1/1953. Seems to be some dispute over the holding of the licence with the TRC. Meeting attended by the former MMTB Manager (Operations) S. M. Richardson, Mr Bell Junior and Mr. Guice Acting Secretary. Notes Brisbane's work and the economic conditions in Australia at the time.trams, tramways, mmtb, pcc, new trams, agreements

Slide - set of 29 - 35mm - white plastic mount of various heritage trams at Bylands. .1 - Recovered A class ? body stored at Bylands .2 - front of 980 .3 - interior of 52? or 980? .4 - Recovered A class ? body stored at Bylands .5 - VR52 .6 - Ballarat Jelbart Roller .7 - Ex U class car as a stores delivery form. .8 - Interior .9 - Interior W3 or W2 .10 - W3 667 .11 - W3 667 .12 - W4 interior .13 - general view inside depot .14 - not used .15 - interior of 902 .16 - VR car .17 - ditto .18 - ditto interior .19 - ditto interior .20 - sign about not travelling on running boards .21 - VR car .22 - W2 .23 - interior of 844 .24 - interior of W1 427 .25 - ditto .26 - W1 427 .27 - interior of X1 467 .28 - X1 467 .29 - Grinder .30 - W3 667trams, tramways, bylands, w1 class, w2 class, w3 class, w4 class, w6 class, pcc, vr trams, jelbart, tram 667, tram 673, tram 980, tram 52, tram 902, tram 467, tram 427, tram 844

Colour slide - Kodachrome cardboard mount - of MMTB PCC 1041 and the cable tram set No 1 at Preston Workshops following MMTB workshop refurbishment work on the cable car set prior to its display outside the then Museum. Slide dated Dec 74 See also Reg Item 72 for colour postcards.On the slide in ink 'TMSV, Ron Scholten" and pencil markings.trams, tramways, preston workshops, pcc, cable trams, tram 1, tram 1041

Set of 2 colour photographs by Norm Cross: Prints not dated. 1 - PCC tram 1041 in High St Preston showing Special - c1975 2 - ditto in River St Maribyrnong, also showing Special - c1976 The tram is on display at the Melbourne Tram Museum.Demonstrates the work of Norm Cross in photographing trams and his collection.Set of 2 colour prints.trams, tramways, tram 1041, pcc class, pcc 1041, high st preston, river st

Photograph shows PCC tram 980 at the Bourke Street terminus near Spencer St. Tram has adverts for Dave Price second hand cars - High Street Northcote. In the background is the Melbourne Tramway and Omnibus Co. office building. Photo by George Bishop 1969.Yields information about the operation of tram 980 in Bourke St during 1969.Black and White Photograph of PCC 980 Bourke St at Spencer St.Details of the photograph and photographer on the rear in pencil and ink.trams, tramways, pcc class, tram 980, mtoco, mmtb, bourke st

Colour print of PCC tram 980 at the Bourke St terminus at night, showing Special. The Mail Sorting centre is in the background. The printers date of the photo show Jan. 1971. The tram was withdrawn from service in May 1971 and the bogies used under PCC car No. 1041.Yields information about PCC tram 980 and the Bourke St terminus at night.Colour print with a printers date printed on the rear.trams, tramways, pcc class, tram 980, bourke st

Negative No. 274 and colour print made by colour laser printer (stored in folder ) of Melbourne PCC tram 980, in Coldblo Road , Malvern depot, during an AETA tour on 8/5/1954. Photo by Geoff Grant. Envelope with negative describes the scene as "980 PCC type tram. Side on view of this tram on a special AETA tour to Footscray for opening of new branch to that suburb. At Malvern depot May 8, 1954." Hi res scan of negative and image updated 19/5/2020.trams, tramways, malvern depot, pcc, coldblo road, footscray, tram 980

Set of 12 photos by Hugh Ballment, unless noted, of MMTB, VR, Hong Kong KCR and MTA: HHBM173 - VR Tram 40, 26/05/1954, Brighton Beach, Tram has three roof top Robur Tea Adverts HBM174 - VR Trams 39, 54, 1950s, Elwood depot, Both trams have the destination of Elwood Depot HBM175 - VR Tram 3, 1950s, Elwood depot, Has the VR Substation in the background HBM176 - MMTB Trams W2 385, SW6 923, 26/05/1954, Swanston St, Damaged photograph. Tram 385 (South Melbourne Beach route 2A) and 923 (RAAF tram. Camberwell route 7). In the background is the Greer & Ashburnter Pty Ltd building HBM177 - MMTB Tram 31 May 1976, Bourke Street, Dark photo. Has the Palladion Theatre in the background showing Barry's Lindon. HBM178 - MMTB, c1954, Elizabeth St, Looking south from about Little Collins St with street decorations possibly for a Royal Tour positioned. Has the Hotel London and McEwans store in the view. HBM179 - MMTB Tram PCC 980, c1955, Malvern Depot, HBM180 - MMTB Trams 864, 502, c1987, Flinders St, Dark photo - see also HBM027 for a better photo. HBM181 - Photo 1950s, Melbourne from south of Yarra River, Kodak commercial slide titled "Melbourne City Skyline across the River Yarra" HBM182 - MTA Tram SW6-915, cNov 1987, Bourke Street Mall, Has Billy Guyatts, Petra Haircare, Roger David and the Royal Mail Hotel in the background HBM183 - KCR , Apr 1988, ComEng Dandenong, Tuen Mun tram HBM184 - MTA, Aug 1988, Bourke St, Spencer St junction construction. Z3 180 on Route 96 plus several other Z class trams present. Two Welding trucks onsite plus the mobile lilting crane and AEC Mk.VI meal bus further up Bourke Street Yields information about Melbourne tram operations, with 1950s to 1980s photos of Melbourne tramways.Kodachrome cardboard and plastic mounts, with notes - set of 12new tramway, vr, st kilda brighton tramway, tram 915, bourke st, spencer st, tram 40, tram 39, tram 3, tram 54, tram 985, swanston st, tram 31, tram 980, tram 864, tram 502, malvern depot, elizabeth st, hong kong, trams, brighton beach, elwood depot, w2 class, tram 385, sw6 class, tram 923, raaf, route 2a, route 7, z class, pcc class, arts trams, volvo b59, bourke st mall, route 95, comeng, z3 class, tram 180, welding truck, route 96, met bus

Negative No. 272 and colour print made by colour laser printer (stored in folder ) of Melbourne PCC tram 980, at beginning of the then new Footscray connecting line at Munitions Factory, Maribyrnong during an AETA tour on 8/5/1954. Photo by Geoff Grant. Hi res scan of negative and image updated 19/5/2020.trams, tramways, footscray, pcc, munitions factory, aeta, tram 980

Negative No. 275 and colour print made by colour laser printer (stored in folder ) of Melbourne PCC tram 980, in at the beginning of Footscray branch or connecting line to Footscray, at Munitions factory, during an AETA tour on 8/5/1954. Photo by Geoff Grant. Hi res scan of negative and image updated 19/5/2020.trams, tramways, footscray, pcc, munitions factory, aeta, tram 980

Black and white print of PCC Class Tram 1041 at Malvern Depot with the front door open showing the entry. Has the destination of Special. Demonstrates the prototype all electric tramcar at Malvern Depot.Black and White photograph - printed on plain paper with photographers stamp on rear.Has stamp of David Menzies on rear. and in ink "1041 Malvern Depot"tramways, trams, tram 1041, prototype tramcar, malvern depot, pcc class, mmtb

.1 - Photocopy of a two A4 page document titled "Australia's first "Noiseless" Tramcar" from the September 1, 1950 issue of Commonwealth Engineer. Report details the noise reducing features of PCC car 980, bogies, the car body with dimensions and its USA licence for the manufacture of such cars in the Australia. See also Reg Item 3420.11 for a similar report.trams, tramways, pcc class, pcc 980, new trams, tramcar design, bogies

Booklet - 20 pages, printed on off white paper, centre stapled within a grey cover slightly larger than the printed document, titled "The Case for Electric Road Passenger Transport". The title is printed on both document covers. The title is contained within a embossed area on the grey cover. The document looks at the case for electric transport in road use, both trolley buses and trams, current developments, including PCC cars, traffic problems, Europe, financial, passengers, reserved track, health and cleanliness. Not date, early 1950's? - has a reference to a 1951 public transport conference on page 5. On the rear page states "Issued by the British Electrical Development Association" of London."4K1" in ink on front cover and AETA stamp top of cover. AETA stamp and PR Officer 14 Kenaway St, Tusmore F3111" (Tusmore is in Adelaide).trams, tramways, public transport, uk, electrical equipment, electric vehicles, trolley buses, trams, pcc

HBM080 - MMTB Tram 980, 24/02/1954, Malvern depot, Decorated for Royal Visit, original image part double exposed, image reworked to give a repaired copy. Orignal image included. Has Keith Kings notes on the image - K(l)(i). See image HBM151 for a night photo of the tram when decorated. Yields information about MMTB tram 980, decorated for the Royal Visit in 1954.Kodachrome cardboard mounts with hand written notes on the slide and a piece of tape on the left hand side of the film.No. K(l)(i) in ink, MMTB 980 decorated for Royal visit, Malvern Depot 24/2/1954"tramways, tram 980, royal visit, decorated trams, trams, pcc class, malvern depot, mmtb

The photograph places PCC 1041 during trials showing destination 'Special'Yields information about launch of this prototypeBlack and white photograph with notes on rearIn ink 'KB KINGS 124-33. M&MTB 1041 Gertrude & Nicholson Sts, Fitzroy, 19/4/73 copy of L N Millar photo'trams, pcc 1041, 1041, gertrude st

The photograph places PCC 1041 during trials showing destination 'Special'Yields information about launch of this prototypeBlack and white photograph with notes on rearIn ink 'KB KINGS 124-32. M&MTB 1041 Gertrude & Nicholson Sts, Fitzroy, 19/4/73 copy of L N Millar photo'trams, pcc 1041, 1041, gertrude st
