Showing 33 items
matching rigging equipment
-
Flagstaff Hill Maritime Museum and Village
Functional object - Deadeye, Russell & Co, Circa 1886
... rigging equipment... Clipper ship rigging equipment sailing equipment deadeye Falls ...This deadeye was amongst artefacts recovered from the wreck of the Falls of Halladale. It would have been used on the ship to attach, hold and run ropes for the ship’s rigging. The Falls of Halladale was an iron-hulled, four-masted barque, used as a bulk carrier of general cargo. She left New York in August 1908 bound for Melbourne and Sydney. In her hold was general cargo consisting of roofing tiles, barb wire, stoves, oil, and benzene as well as many other manufactured items. After three months at sea and close to her destination, a navigational error caused the Falls of Halladale to be wrecked on a reef off the Peterborough headland on the 15th of November, 1908. The captain and 29 crew members survived, but her cargo was largely lost, despite two salvage attempts in 1908-09 and 1910. The Court of Marine Inquiry in Melbourne ruled that the foundering of the ship was entirely due to Captain David Wood Thomson's navigational error, not too technical failure of the Clyde-built ship. The Falls of Halladale was built in1886 by Russell & Co., at Greenock shipyards on the River Clyde, Scotland for Wright, Breakenridge & Co of Glasgow. She was one of several designs of Falls Line of ships named after waterfalls in Scotland. The company had been founded between 1870- 1873 as a partnership between Joseph Russell, Anderson Rodger, and William Todd Lithgow. During the period 1882-92 Russell & Co. standardised designs, which sped up their building process so much that they were able to build 271 ships during that time. The Falls of Halladale had a sturdy construction built to carry maximum cargo and was able to maintain full sail in heavy gales, one of the last of the 'windjammers' that sailed the Trade Route. She and her sister ship, the Falls of Garry, were the first ships in the world to include fore and aft lifting bridges. Previous to this, heavily loaded vessels could have heavy seas break along the full length of the deck, causing serious injury or even death to those on deck. The new, raised catwalk-type decking allowed the crew to move above the deck in stormy conditions. The Falls of Halladale shipwreck is listed on the Victorian Heritage (No. S255). She was one of the last ships to sail the Trade Routes from Europe and the Americas. Also of significance is that the vessel was one of the first ships to have fore and aft lifting bridges as a significant safety feature still in use on modern vessels today. The subject item is an example of ships rigging objects used on sailing ships during the 19th and early 20th centuries to transport goods around the world the item is representing aspects of Victoria’s shipping industry and maritime history. Deadeye; wooden deadeye, three (3) holes, with metal surrounds and metal rigging cable attached. Recovered from the Falls of Halladale.Nonewarrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, shipwrecked-artefact, clipper ship, rigging equipment, sailing equipment, deadeye, falls of halladale wreck, breakenridge & co glasgow, russell & co ship builders, cargo vessel, 1908 wreck, rigging, ship rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Pulley Block, Russell & Co, ca. 1886
... rigging equipment... is an example of ship rigging equipment used on sailing ships during ...A pulley block of this size would have many applications on a ship, including lifting loads such as cargo and sails. It was recovered from the wreck of the Halladale in the 1970s by divers Gary Hansen and Peter Ronald, former Director of Flagstaff Hill. The Falls of Halladale was an iron-hulled, four-masted barque built in Glasgow, Scotland. It was used as a bulk carrier of general cargo. When the ship left New York in August 1908 it was bound for Melbourne and Sydney it’s the cargo in its hold consisted of roofing tiles, barbed wire, stoves, oil, benzene and many other manufactured items. On the 15th of November, 1908, after three months at sea and close to its destination, a navigational error caused the Falls of Halladale to be wrecked on a reef off the Peterborough headland. The captain and 29 crew members survived but most of the cargo was lost, despite two salvage attempts in 1908-09 and 1910. The Court of Marine Inquiry in Melbourne ruled that the foundering of the ship was entirely due to Captain David Wood Thomson's navigational error, not to any technical failure of the ship. The Falls of Halladale was built in1886 by Russell & Co., at Greenock shipyards on the River Clyde, Scotland for Wright, Breakenridge & Co of Glasgow. The vessel was one of several designs of Falls Line of ships named after waterfalls in Scotland. The company had been founded between 1870- 1873 as a partnership between Joseph Russell, Anderson Rodger, and William Todd Lithgow. During the period between 1882-92 Russell & Co. standardised its ship designs, which sped up their building process so much that they were able to build 271 ships during that time. The Falls of Halladale had a sturdy construction built to carry maximum cargo and was able to maintain full sail in heavy gales. It was one of the last of the 'windjammers'. She and her sister ship, the Falls of Garry, were the first ships in the world to include fore and aft lifting bridges. Previous to this, heavily loaded vessels could have huge seas break along the full length of the deck, causing serious injury or even death to those on deck. The new, raised catwalk-type decking allowed the crew to move above the deck in stormy conditions.The Falls of Halladale shipwreck is listed on the Victorian Heritage (No. S255). The vessel was one of the last ships to sail the Trade Routes from Europe and the Americas. Also of significance is that the ship was one of the first ships to have fore and aft lifting bridges as a significant safety feature that is still in use on modern vessels today. The block and pulley is an example of ship rigging equipment used on sailing ships during the 19th and early 20th centuries that transported goods around the world. It represents aspects of Victoria’s shipping industry and maritime history.A pulley block; metal frame with three sheaves. The block is in a fragile condition. It is also large and heavy. It was recovered from the wreck of the Falls of Halladale in the 1970s. warrnambool, flagstaff hill, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, flagstaff hill maritime museum and village, clipper ship, windjammer, cargo vessel, falls of halladale wreck, shipwreck, 1908 wreck, breakenridge & co glasgow, russell & co ship builders, 1886 ship, shipwreck artefact, rigging, ship rigging, rigging equipment, sailing equipment, cargo equipment, marine technology, block, ship’s block, pulley block -
Flagstaff Hill Maritime Museum and Village
Equipment - Bosun's Chair, ca. mid-20th century
... boatswains chair rigging maritime equipment bosun's seat life saving ...The bosun’s chair is a typical piece of equipment included on board a vessel in the late 19th and early 20th century. The nautical word 'bosun' is an abbreviation of the word 'boatswain' who is the person responsible for the repair and maintenance of the vessel. It could be used when rigging the sails and for rescue at sea, along with a thick rope anchored on shore or a rope between ships. It could also be used to move passengers to and from a ship as well as cargo on, to and from the vessel. A bosun's chair is a simple piece of equipment made from a short plank of wood and a sturdy piece of rope. It looks a little like a child's swing but usually has a pulley system that allows the user to adjust the length of the hanging piece of rope, and in so-doing adjusts the height above the floor or ground or sea. In modern times a harness would also be worn by the bosun’s chair user for safety reasons. Bosun's chairs are also used by window cleaners, construction workers and painters. The bosun’s chair is sometimes just a short plank, or even a canvas sling. The bosun's chair is significant for its association with maritime equipment carried on board a vessel in the late 19th and early 20th century for maintenance and safety purposes. It was occasionally used to save lives. The bosun's chair is also significant as an early version of equipment still used today. Since its invention there have been many safety features added in certain industries such as window cleaning and painting.Bosuns chair; flat smooth rectangular piece of wood, with rope passing through two holes at each end of plank and looped together above plank to form a suspended seat swing. Loops a are joined with knot work and ends are spliced together under the seat.flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, bosun's chair, bosuns chair, boatswains chair, rigging, maritime equipment, bosun's seat, life saving, marine technology, ship rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Bosun's Chair, ca. 1922
... chair rigging maritime equipment bosun's seat life saving marine ...This Bosun's char was part of the equipment on the vessel 'Reginald M. It is typical of items included on board a vessel in the late 19th and early 20th century. The nautical word 'bosun' is an abbreviation of the word 'boatswain' who is the person responsible for the repair and maintenance of the vessel. It could be used when rigging the sails and for rescue at sea, along with a thick rope anchored on shore or a rope between ships. It could also be used to move passengers to and from a ship as well as cargo on, to and from the vessel. A bosun's chair is a simple piece of equipment made from a short plank of wood and a sturdy piece of rope. It looks a little like a child's swing but usually has a pulley system that allows the user to adjust the length of the hanging piece of rope, and in so-doing adjusts the height above the floor or ground or sea. In modern times a harness would also be worn by the bosun’s chair user for safety reasons. Bosun's chairs are also used by window cleaners, construction workers and painters. The bosun’s chair is sometimes just a short plank, or even a canvas sling. The REGINALD M - The vessel “Reginald M” was a two-masted coastal ketch, owned and built by Mr. Jack (John) Murch of Birkenhead, Port of Adelaide, South Australia. Its construction took approximately 6 months and it was launched at Largs Bay in 1922. The vessel had many owners and adventures over the years until it was purchased by Flagstaff Hill Maritime Museum & Village in 1975 from the Melbourne Ferry Company at auction. It was then used as an active display until 2016. Visitors could go aboard, turn the ship's wheel, go below deck and get the feel of the captain's quarters, sailors' quarters and the storage space available. The Reginald M was a popular exhibit for young and old, until 2016.This bosun's chair is significant for its connection to the maritime history. It has been used for rigging, painting, maintenance and importantly for life saving and safety. The bonus's chair is also significant because of its connection to the history of the vessel REGINALD M, the coastal trading ketch from South Australia built in 1922 and in existence until 2016. Its flat bottom, single chine shape illustrates a very simple but robust method of construction, compared to other round bilged examples of trading vessels. The Reginald M is listed on the Australian Register of Historic Vessels (ARHV Number: HV000562.)Bosun's chair; seat is a rectangular plank of wood with a hole drilled in each corner and three reinforcing wood lengths attached below the plank. The ends of two looped thick ropes have been threaded through the holes in the plank, crossed over then spliced together. The loops of rope above the plank have been tied with light rope. A roughly made wire hook is attached at the base of one length of rope. Top surface reveals indents where the bottom wooden pieces are joined to the top and some of the metal fixtures can be seen along the edge. There are remnants of white paint on the top.flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, bosun's chair, bosuns chair, boatswains chair, rigging, maritime equipment, bosun's seat, life saving, marine technology, ship rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Bosun's Chair, ca. mid-20th century
... rigging maritime equipment bosun's seat life saving marine ...The bosun’s chair is a typical piece of equipment included on board a vessel in the late 19th and early 20th century. The nautical word 'bosun' is an abbreviation of the word 'boatswain' who is the person responsible for the repair and maintenance of the vessel. It could be used when rigging the sails and for rescue at sea, along with a thick rope anchored on shore or a rope between ships. It could also be used to move passengers to and from a ship as well as cargo on, to and from the vessel. A bosun's chair is a simple piece of equipment made from a short plank of wood and a sturdy piece of rope. It looks a little like a child's swing but usually has a pulley system that allows the user to adjust the length of the hanging piece of rope, and in so-doing adjusts the height above the floor or ground or sea. In modern times a harness would also be worn by the bosun’s chair user for safety reasons. Bosun's chairs are also used by window cleaners, construction workers and painters. The bosun’s chair is sometimes just a short plank, or even a canvas sling. The bosun's chair is significant for its association with maritime equipment carried on board a vessel in the late 19th and early 20th century for maintenance and safety purposes. It was occasionally used to save lives. The bosun's chair is also significant as an early version of equipment still used today. Since its invention there have been many safety features added in certain industries such as window cleaning and painting.Bosuns chair, rectangular slab of wood with two holes at both ends through which rope ends are threaded for support and the loops above the seat are tied with sailor's knotting to form a triangle. flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, bosun's chair, bosuns chair, boatswains chair, rigging, maritime equipment, bosun's seat, life saving, marine technology, ship rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Boat hook head, before 1977
... boating equipment boat hook head rigging Safety equipment Marine ...This boat hook head is in very good condition and has been manufactured. It would be attached to a pole or handle to give it a long reach. A boat hook is a common piece of marine equipment and many have been made by boat owners to suit their own purpose. They would also have been forged byblacksmiths and shipsmiths and have been available from ship's chandlers over the centuries. A boat hook can be used for many situations such as catching mooring ropes and chains, reaching rigging, pulling things or people out of the water, and a variety of fishing applications.This boat hook head is an example of equipment carried on vessels over hundreds of years for safety purposes and for general applications. Marine boat hook head, all brass. The body is a conical shape with a pointed end and curved, horn-shaped hook moulded into the side. The body is hollow until it reaches the hook's height. A screw hole is close to the base, in line with the hook.flagstaff hill, warrnambool, maritime village, maritime museum, shipwreck coast, great ocean road, boat hook, marine, fishing, boating, equipment, boat hook head, rigging, safety equipment -
Flagstaff Hill Maritime Museum and Village
Equipment - Gooseneck fitting, 20th century
... angle. It is a part of a ship's rigging equipment.... of a ship's rigging equipment. The gooseneck fitting is a simple ...A gooseneck fitting is a connection used between a ship's mast and a spar. It allows the spar to swivel to change its angle. It is a part of a ship's rigging equipment.The gooseneck fitting is a simple version of gooseneck fittings used on sailing vessels today.Goose neck, metal. A hollow conical fitting with two round rings joined into the top, one each side, and an axle between them. A swivel joint is around the axle. The joint has a flat ring on each side. The metal has green tarnish on much of its surface.gooseneck, rigging, mast, spar, sailing ship, flagstaff hill, flagstaff hill maritime museum, flagstaff hill maritime village, great ocean road, maritime museum, mast fitting, boom gooseneck -
Flagstaff Hill Maritime Museum and Village
Equipment - Belaying Pins, Late 19th Century
... Department of Defence. sailiing equipment nautical equipment rigging ...The pins in this collection vary in the timber used and the design. They were found in a warehouse beside Crown Casino in Melbourne, located along the Yarra River, close to the sailing ship "Polly Woodside" and not far from the docks of Port Melbourne. Some of the pins have the mark of a 'Broad Arrow' with 'D ↑ D, which signifies that they were the property of the Australian Government's Department of Defence. Belaying pins are essential equipment on a traditional sailing ship of the 19th and early 20th centuries. They are usually made of wood but some are metal. A belaying pin is used to secure the running ropes of the rigging to the ship's rails using holes drilled onto the rails for that purpose. The belaying pins are inserted into holes in the ship’s rail, drilled for that purpose. When the sail has been raised, the ropes are wrapped around the upper and lower sections of the pins in a figure-eight pattern. The shapes of these belaying pins taper from the rounded end of the handle inwards towards the bottom, which allows them to have a firm fit into the holes in the rails. The rigging rope is wound around the pins in such a way that a tug on the pin's handle pulls it out of the hole and quickly frees the rope and the sail.These belaying pins are significant for their association with sailing vessels, particularly vessels of the late 19th and early 20th centuries. They are also significant for their association with the Port of Melbourne where sailing ships docked to and from the Port of Melbourne. Some of the pins have additional significance for being connected with the Australian Government's Department of Defence.Belaying pin, wooden, simple design, wooden shaft with a wider rounded end on top third, tapering to the centre third, which is wider than a lower third. The bottom has a blunt base. Some of the pins have the three sections divided by a line around their circumferences. This collection of fifty-seven pins of varying shapes, colours and timber. Some of the pins are stained with colour, and some have been left natural Stored in a wooden crate. Some have inscriptions.Marks: (Government Defence Department Broad Arrow) "D ↑ D"sailiing equipment, nautical equipment, rigging, yards, flagstaff hill, maritime museum, maritime village, belaying pin, broad arrow, australian government, australian department of defence, sailing ship, sail -
Flagstaff Hill Maritime Museum and Village
Equipment - Belaying Pin
... Warrnambool great-ocean-road Belaying Pin Equipment Belaying pin ...Belaying pins can be metal but are often made of wood, treated or untreated, plain or with handles. A belaying pin is used to secure the running ropes of the rigging to the ship's rails using holes drilled onto the rails for that purpose. The belaying pins are inserted into holes in the ship’s rail, drilled for that purpose. When the sail has been raised, the ropes are wrapped around the upper and lower sections of the pins in a figure-eight pattern. The shapes of these belaying pins taper from the rounded end of the handle inwards towards the bottom, which allows them to have a firm fit into the holes in the rails. The rigging rope is wound around the pins in such a way that a tug on the pin's handle pulls it out of the hole and quickly frees the rope and the sail.These belaying pins are significant for their association with sailing vessels, particularly vessels of the late 19th and early 20th centuries.Belaying pin, metal, painted brown.flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, sailing equipment, nautical equipment, rigging, yards, sails, belaying pin, sailing ship -
Flagstaff Hill Maritime Museum and Village
Equipment - Belaying Pin
... Warrnambool great-ocean-road Belaying Pin Equipment Belaying Pin ...Belaying pins can be metal but are also made of wood, treated or untreated, plain or with handles. A belaying pin is used to secure the running ropes of the rigging to the ship's rails using holes drilled onto the rails for that purpose. The belaying pins are inserted into holes in the ship’s rail, drilled for that purpose. When the sail has been raised, the ropes are wrapped around the upper and lower sections of the pins in a figure-eight pattern. The shapes of these belaying pins taper from the rounded end of the handle inwards towards the bottom, which allows them to have a firm fit into the holes in the rails. The rigging rope is wound around the pins in such a way that a tug on the pin's handle pulls it out of the hole and quickly frees the rope and the sail.These belaying pins are significant for their association with sailing vessels, particularly vessels of the late 19th and early 20th centuries.Belaying Pin, metal, painted white.flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, sailing equipment, nautical equipment, rigging, yards, sails, belaying pin, sailing ship -
Flagstaff Hill Maritime Museum and Village
Equipment - Belaying Pin
... Warrnambool great-ocean-road Belaying Pin Equipment Belaying Pin ...Belaying pins can be metal but are also made of wood, treated or untreated, plain or with handles. A belaying pin is used to secure the running ropes of the rigging to the ship's rails using holes drilled onto the rails for that purpose. The belaying pins are inserted into holes in the ship’s rail, drilled for that purpose. When the sail has been raised, the ropes are wrapped around the upper and lower sections of the pins in a figure-eight pattern. The shapes of these belaying pins taper from the rounded end of the handle inwards towards the bottom, which allows them to have a firm fit into the holes in the rails. The rigging rope is wound around the pins in such a way that a tug on the pin's handle pulls it out of the hole and quickly frees the rope and the sail.These belaying pins are significant for their association with sailing vessels, particularly vessels of the late 19th and early 20th centuries.Belaying Pin, metal, painted white.flagstaff hill, warrnambool, maritime village, maritime museum, flagstaff hill maritime museum & village, shipwreck coast, great ocean road, sailing equipment, nautical equipment, rigging, yards, sails, belaying pin, sailing ship -
Flagstaff Hill Maritime Museum and Village
Equipment - Rope ladder, pre 1983
... maritime equipment rigging ropework ...This handmade rope ladder is an example of maritime equipment. It could be easily folded and stored and was useful for many purposes including fixing the ship's rigging.The rope ladder is an example of handmade maritime equipment using the shills of a ship's carpenter or sailmaker. It was simple to make, easily stored and useful for many purposes including the ship's rigging. The rope ladder is significant for being the only rope ladder in our collection of maritime equipment. Rope ladder. Handmade ladder with three wooden steps joined by thick rope lengths between them. Each step has rounded corners and a large hole near each corner. The tope is threaded and knotted to create an equal distance between the upper, centre and lower steps. flagstaff hill, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, ladder, rope ladder, handmade ladder, ship's ladder, maritime equipment, rigging, ropework -
Flagstaff Hill Maritime Museum and Village
Equipment - Rope Block, Mid-20th century
... lifting equipment stevedoring rope block rigging block sailing ...A sailing or rope block has single or multiple pulleys with one or more sheaves enclosed in an assembly between cheeks or chocks. In use, a block is fixed to the end of the line, spar or load to be lifted such as at a transport dock. A rope line is reeved through the sheaves, and through one or more matching blocks at the far end, to make up what's known as a tackle. Generally, the more sheaves in the blocks that make up a tackle, the higher its mechanical advantage. Various types of blocks are used in sailing. Some blocks are used to increase mechanical advantage and others to change the direction of a line. A ratchet block turns freely when a line is pulled in one direction but does not turn in the other direction, although the line may slip past the sheave. This kind of block makes a loaded line easier to hold by hand.This rope block is an example of rope and tackle systems used in maritime settings to lift and move cargo and machinery, often with the help of a crane. It is also used on sailing vessels as part of the rigging, help to raise and lower the ropes and sails.Block; two sheave wooden rope block with ring and becket. It features a Closed Spelter Socket (CSS). Rings are galvanised metal. There is a compliance plate attached with an inscription. It was once owned by a government body, as indicated by the 'up-arrow" symbol.Compliance plate: stamped twice "CS" [Closed Spelter] and "↑"flagstaff hill, warrnambool, shipwreck coast, flagstaff hill maritime museum, flagstaff hill maritime village, lifting equipment, stevedoring, rope block, rigging block, sailing equipment, css, closed spelter socket -
Flagstaff Hill Maritime Museum and Village
Equipment - Block, Late 19th to early 20th century
... of the rigging required to set the sails on a wind-powered vessel ...A sailing block is single or multiple pulleys with one or more sheaves that are enclosed in an assembly between cheeks or chocks. In use, a block is fixed to the end of a line, to a spar, or a surface. A rope line is reeved through the sheaves, and maybe through one or more matching blocks at the far end, to make up what's known as a tackle. The purchase of a tackle refers to its mechanical advantage. In general, the more sheaves in the blocks that make up a tackle, the higher its mechanical advantage. The matter is slightly complicated by the fact that every tackle has a working end where the final run of rope leaves the last sheave. More mechanical advantage can be obtained if this end is attached to the moving load rather than the fixed end of the tackle. Various types of blocks are used in sailing. Some blocks are used to increase mechanical advantage and others are used simply to change the direction of a line. A ratchet block turns freely when a line is pulled in one direction but does not turn in the other direction, although the line may slip past the sheave. This kind of block makes a loaded line easier to hold by hand and is sometimes used on smaller boats for lines like main and jib sheets that are frequently adjusted. A single, large, sail-powered warship in the mid-19th century required more than 1,400 blocks of various kinds and sizes.A historic item from an old sailing vessel from the late 19th to early 20th century, unfortunately. It represents part of the rigging required to set the sails on a wind-powered vessel.A two sheave wood sailing block with metal hook and becket. One sheave missing. flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, block, sailing block, two-sheave block, 2 sheave wood block, marine technology, sailing equipment, rigging, rigging block -
Flagstaff Hill Maritime Museum and Village
Equipment - Rope Block, Early-to-mid 20th century
... . Its an example of rigging equipment in use from the early ...A block and tackle is a simple but highly effective lifting device, thought to have been invented by Archimedes. These systems were used extensively for construction in the ancient world, and continue to be used today for a variety of applications, especially at sea, where non-motorized lifting systems are highly useful. A basic block and tackle includes a single fixed pulley or block, and at least one additional pulley, linked with rope, to form a complete set. Depending on the size of the load being lifted, additional sets may be used to further distribute the weight.This wooden two-sheave block is part of a ship's rigging. Its an example of rigging equipment in use from the early-to-mid 20th century and an example of the evolution of rigging equipment since the 17th century.Block; two sheave wooden tackle block with metal rollers and a large metal hook. It has a compliance plate on the side with an inscription. Stamped inside a lozenge; "2 ↑ CS" flagstaff hill museum, flagstaff hill village, shipwreck coast, flagstaff hill, block & tackle, rope, lifting heavy weights, ship rigging, cargo lifiting, rope block, marine technology, ship equipment, rigging, two sheave block -
Flagstaff Hill Maritime Museum and Village
Equipment - Sling Hooks
Sling hooks are used in ship's rigging for cargo haulage.Sling hooks are necessary for hauling cargo. Cargo was imported to and exported from the busy Port of Warrnambool in the 19th and early 20th centuries. Sling hooks are still used today for cargo.Sling hooks; three metal ring hook each on a short length of rope and all attached to the same metal ring . flagstaff hill, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, sling hook, ring hook, rigging, cargo, haulage, cargo lifiting, maritime technology -
Flagstaff Hill Maritime Museum and Village
Functional object - Deadeye, Late 19th century to 1950s
... . An item used on sailing ships rigging this item of ships equipment ...A dead eye is a part of a vessel’s rig On board sailing ships, dead eyes were used in three different areas. Traditionally dead eyes are made of wood but they have different forms according to where they were used in the vessel rigging. The most common type of dead-eye is flat, with three holes and was used to tension the shrouds, the heavy lines which steadied the masts on each side. Each shroud had a dead eye at the lower end, which corresponded to a similar dead eye attached to the side of the ship. The two were connected with a rope called a lanyard, which was used to tighten the assembly. The stays, heavy lines running forward from the masts, were also tensioned with dead eyes. These are much larger and rectangular, with four or six holes. The third type of dead-eye was a two-holed version attached to an eye at the end of the parallel, which tied a yard to the mast. The loose ends of the parallel rope passed through the dead eye and then down to the deck, making it possible to tighten or slacken the parallel from the deck so that the yard could be more easily manoeuvred. It was especially important for the mizzen yard, which had to be shifted from one side of the mast to the other when tacking the ship.An item used on sailing ships rigging this item of ships equipment and its use has been used from the beginning of the invention of sailing ships going back to ancient times. Its use on sailing vessels had not changed in design or use until they went out of fashion and steamships took their place.Circular wooden ships rigging dead eye with three holes Noneflagstaff hill, warrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, sailing vessel rigging, dead eye, sailing equipment -
Flagstaff Hill Maritime Museum and Village
Equipment - Rigging
... Warrnambool great-ocean-road Rigging Equipment Fore Rigging or Shrouds ...The shrouds or fore-rigging are a part of the standing rigging on a sailing ship. They are used in pairs on each side of a ship to help hold the masts in place and to aid the sailors who climb the rigging. They are part of the basic framework for the sails. Larger vessels may have two or three pairs, and some ships may have upper and lower shrouds. The upper shrouds would be fixed to a protruding structure on the top of the masts so that they hung from the right angle. The ropework skills of the sailmaker would be used to create the shrouds, choosing fibres with properties suitable for the job at hand and creating the triangular shape carefully. Deadeyes and ropes were then used to attach the shrouds to the ship's structure.This shroud is an example of a part of the standing rigging of a sailing ship. Shrouds were used in pairs on larger sailing vessels to help hold the masts in place and give access to adjustable rigging such as sails.Fore Rigging or Shrouds, made from rope fibres. This shroud includes the upper and lower wooden deadeyes. They are part of a ship's rigging. flagstaff hill, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, shroud, fore-rigging, ropework, sailing ship rigging, standing rigging, natural fibres, sailmakers, handmade, deadeye, knot making -
Flagstaff Hill Maritime Museum and Village
Equipment - Rigging
... Warrnambool great-ocean-road Rigging Equipment Fore Rigging or Shrouds ...The shrouds or fore-rigging are a part of the standing rigging on a sailing ship. They are used in pairs on each side of a ship to help hold the masts in place and to aid the sailors who climb the rigging. They are part of the basic framework for the sails. Larger vessels may have two or three pairs, and some ships may have upper and lower shrouds. The upper shrouds would be fixed to a protruding structure on the top of the masts so that they hung from the right angle. The ropework skills of the sailmaker would be used to create the shrouds, choosing fibres with properties suitable for the job at hand and creating the triangular shape carefully. Deadeyes and ropes were then used to attach the shrouds to the ship's structure.This shroud is an example of a part of the standing rigging of a sailing ship. Shrouds were used in pairs on larger sailing vessels to help hold the masts in place and give access to adjustable rigging such as sails.Fore Rigging or Shrouds, made from rope fibres. This shroud includes the upper and lower wooden deadeyes. They are part of a ship's rigging.flagstaff hill, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, shroud, fore-rigging, ropework, knot making, sailing ship rigging, standing rigging, natural fibres, sailmakers, handmade, deadeye -
Flagstaff Hill Maritime Museum and Village
Functional object - Porthole Frame, Russell & Co, Ca. 1886
... -19th century ship’s rigging equipment. The object is also ...This restored porthole frame was recovered from the wreck of the Falls of Halladale at Peterborough Victoria. The Falls of Halladale- The ship was an iron-hulled, four-masted barque, used as a bulk carrier of general cargo. She left New York in August 1908 bound for Melbourne and Sydney. In her hold was general cargo consisting of roofing tiles, barbed wire, stoves, oil, benzene, and many other manufactured items. After three months at sea and close to her destination, a navigational error caused the Falls of Halladale to be wrecked on a reef off the Peterborough headland on the 15th of November, 1908. The captain and 29 crew members survived, but her cargo was largely lost, despite two salvage attempts in 1908-09 and 1910. The Court of Marine Inquiry in Melbourne ruled that the foundering of the ship was entirely due to Captain David Wood Thomson's navigational error, not too technical failure of the Clyde-built ship. The Falls of Halladale was built in1886 by Russell & Co., at Greenock shipyards on the River Clyde, Scotland for Wright, Breakenridge & Co of Glasgow. She was one of several designs of the Falls Line of ships named after waterfalls in Scotland. The company was founded between 1870- 1873 as a partnership between Joseph Russell, Anderson Rodger, and William Todd Lithgow. During 1882-92 Russell & Co. standardised designs sped up their building process so much that they could build 271 ships during that time. The Falls of Halladale had a sturdy construction built to carry maximum cargo and was able to maintain full sail in heavy gales, one of the last of the 'windjammers' that sailed the Trade Route. She and her sister ship, the Falls of Garry, were the first ships in the world to include fore and aft lifting bridges. Previously, heavily loaded vessels could have heavy seas break along the full length of the deck, causing serious injury or even death to those on deck. The new, raised catwalk-type decking allowed the crew to move above the deck in stormy conditions. This artefact is important as it is an example of the materials and design of late-19th century ship’s rigging equipment. The object is also significant for its association with the historic sailing ship Falls of Halladale, wrecked in local waters in the early 20th century. The clipper ship Falls of Halladale shipwreck is of historical significance and is listed on the Victorian Heritage Register, No. S255. She was one of the last ships to sail the Trade Routes. She was one of the first vessels to have fore and aft lifting bridges. The vessel is an example of an International Cargo Ship's remains and represents aspects of Victoria’s shipping industry. Porthole frame; cast brass circular frame with several fixing holes, and hinged frame for holding the glass window. The frame has two screw dogs and a solid hinge. The porthole frame has been recondition and the layer of concretion has been removed. The porthole frame was recovered from the wrecked FALLS OF HALLADALE.flagstaff hill, warrnambool, maritime village, maritime museum, shipwreck coast, great ocean road, falls of halladale, shippwreck, shipwreck artefact, porthole, pprthole frame, ship's window, ship construction, shipwreck, peterborough, 1908 shipwreck, peterborough shipwreck, russell & co., greenock, wright breakenridge & co. glasgow, clipper ship -
Flagstaff Hill Maritime Museum and Village
Functional object - Deadeye, Late 19th century to 1950s
... . An item used on sailing ships rigging this item of ships equipment ...A dead eye is a part of a vessel’s rig On board sailing ships, dead eyes were used in three different areas. Traditionally dead eyes are made of wood but they have different forms according to where they were used in the vessel rigging. The most common type of dead-eye is flat, with three holes and was used to tension the shrouds, the heavy lines which steadied the masts on each side. Each shroud had a dead eye at the lower end, which corresponded to a similar dead eye attached to the side of the ship. The two were connected with a rope called a lanyard, which was used to tighten the assembly. The stays, heavy lines running forward from the masts, were also tensioned with dead eyes. These are much larger and rectangular, with four or six holes. The third type of dead-eye was a two-holed version attached to an eye at the end of the parallel, which tied a yard to the mast. The loose ends of the parallel rope passed through the dead eye and then down to the deck, making it possible to tighten or slacken the parallel from the deck so that the yard could be more easily manoeuvred. It was especially important for the mizzen yard, which had to be shifted from one side of the mast to the other when tacking the ship.An item used on sailing ships rigging this item of ships equipment and its use has been used from the beginning of the invention of sailing ships going back to ancient times. Its use on sailing vessels had not changed in design or use until they went out of fashion and steamships took their place.Circular wooden ships rigging dead eye with three holes Noneflagstaff hill, warrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, sailing vessel rigging, dead eye, sailing equipment -
Churchill Island Heritage Farm
Functional object - Pulley
... in sailing vessel's rigging churchill island farm equipment ...Used in sailing vessel's riggingSingle sleeve wooden pulley with small metal attachments.churchill island, farm equipment -
Ballarat Tramway Museum
Manual, Seashore Trolley Museum and Kennebunkport USA, "Seashore Museum Maintenance Manual - Electrical", c1970
... braking equipment, trucks and rigging. Has an appendix and index... breaks, car resistors, traction braking equipment, trucks ...Manual - 176 quarto pages + light grey covers Electrical" on a cover pages. with a red comb binding. Prepared by Donald G Curry of the Seashore Electric Railway, 17/6/1962. Document has table of contents: Covers Painting, Roof repairs, body repairs, inspections, Lubrication, Traction Motor Maintenance, controllers, hand operated circuit breaks, car resistors, traction braking equipment, trucks and rigging. Has an appendix and index. Document has been scanned. Part 1 - cover to page 17 2 - pages 18 to 40 3 - pages 41 to 66 4 - pages 67 to 100 5 - pages 101 to 132 6 - pages 132 to 159 7 - pages 160 to rear cover trams, tramways, manual, tramcar equipment, maintenance, motors, controllers, tramcars, tram bodies -
Flagstaff Hill Maritime Museum and Village
Equipment - Block, Ca. 19th to early-20th
This block is an example of equipment used to rig the sailing ships of the 19th and 20th centuries.One sheave wooden block with wire rope attached and covered in white canvass. Has a thimble with" D" shackle attached.flagstaff hill, flagstaff hill maritime museum and village, warrnambool, maritime museum, maritime village, great ocean road, shipwreck coast, block, rigging, mechanical block -
Ballarat Tramway Museum
Drawing, State Electricity Commission of Victoria (SECV), "Brake Rigging Brill Maximum Traction Truct No. 22E", 4/1955
... rigging and equipment. tramcars Brill 22E Pony axles axles Axle ...Set of three drawings related to the Brill 22E Maximum Traction trucks: 1 - "Brake Rigging Brill Maximum Traction Truct No. 22E" - showing the dimensions of the levers and pivot points. For the relevant Geelong drawing T1647 see item 8044 2 - "Standard Pony Axle" - traced from MMTB drawing R3755 3 - "Pony Axle Box" - traced from MMTB drawing R1112 and dated in ink 28-4-1955Yields information about Brill 22E brake rigging and equipment.Set of three Drawings - dyeline print on plain paper with a brass clip in the top right hand corner.tramcars, brill 22e, pony axles, axles, axle boxes, brake rigging, ballarat, geelong, drawings -
Flagstaff Hill Maritime Museum and Village
Tool - Hook, Mid-20th century
... Maritime Village lifting hook maritime equipment lifting equipment ...A cast iron hook was made for lifting heavy loads in a marine or warehouse environment. The hook would be attached to the end of a chain or rope around a heavy load such as a pallet or container. The other end may have been joined to a pulley or crane for lifting and moving it around. The inscription on the hook shows the SWL or Safe Working Load as 3 Ton. The SWL was used in the industry for many years to rate safe loads but it is no longer used to identify the maximum capacity of equipment. In 2002 the Australian Standard AS 1418 for Cranes, Hoists and Winches changed, and the term Safe Work Load was changed to Rated Capacity, which was defined differently.The hook represents the equipment needed on a ship or at a port, railyard, transport depot or warehouse in the 19th and 20th centuries to move cargo and loads. The inscription of SWL on the hook is significant for its use as a guide for many years to work out the weight of the load the hook could safely hold. However, time and experience have led to a change in Australian Standards and the load is now measured by another formula that gives the load's Rated Capacity.Hook; large iron hook with a ring formed in the top. Inscription stamped into the metal and indicates that the Safe Working Load (SWL) for the hook to lift is 3 Ton.Marked "ani" "SWL 3TON"warrnambool, shipwreck coast, flagstaff hill, flagstaff hill maritime museum, flagstaff hill maritime village, lifting hook, maritime equipment, lifting equipment, warehousing, cargo, loads, rigging, marine technology, swl, safe working load, 3 ton, rated capacity, load limit -
Flagstaff Hill Maritime Museum and Village
Equipment - Rope Block, Mid to Late 19th
... ship equipment Rope Block Sail Rigging None Wooden closed ...A sailing block is single or multiple pulleys with one or more sheaves that are enclosed in an assembly between cheeks or chocks. In use, a block is fixed to the end of a line, to a spar, or a surface. A rope line is reeved through the sheaves, and maybe through one or more matching blocks at the far end, to make up what's known as a tackle. The purchase of a tackle refers to its mechanical advantage. In general, the more sheaves in the blocks that make up a tackle, the higher its mechanical advantage. The matter is slightly complicated by the fact that every tackle has a working end where the final run of rope leaves the last sheave. More mechanical advantage can be obtained if this end is attached to the moving load rather than the fixed end of the tackle. Various types of blocks are used in sailing. Some blocks are used to increase mechanical advantage and others are used simply to change the direction of a line. A ratchet block turns freely when a line is pulled in one direction but does not turn the other direction, although the line may slip past the sheave. This kind of block makes a loaded line easier to hold by hand, and is sometimes used on smaller boats for lines like main and jib sheets that are frequently adjusted. A single, large, sail-powered warship in the mid-19th century required more than 1,400 blocks of various kinds and sizes. An item from an old sailing vessel from the late 19th to early 20th century, unfortunately, the item cannot be identified as to what vessel it belonged to. It does however give an insight into a piece of sailing equipment that's design is still in use today on pleasure sailing craft. Wooden closed spelter double rope block with two pully's between sheaves, block has metal frame around outside of the sheaves and 4 metal pins, 2 each side of the frame at top and 2 at bottom, joining the sheaves together. The shaft between the sheaves is also wooden. Remnants of orange and black paint on outside of block. Shafts are chipped, wood has borer holes. (NOTE: Block was rediscovered after relocating objects to new storage area)Noneflagstaff hill, warrnambool, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, sailing ship, pulley, block, sheave, ship equipment, rope block, sail rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Rope Block, After 1950
A block and tackle is a simple but highly effective lifting device, thought to have been invented by Archimedes. These systems were used extensively for construction in the ancient world, and continue to be used today for various applications, especially at sea, where non-motorised lifting systems are highly useful. A basic block and tackle includes a single fixed pulley or block, and at least one additional pulley, linked with rope, to form a complete set. Depending on the size of the load being lifted, additional sets may be used to further distribute the weight.A mid-twentieth example of a wooden block that shows advances in the design of the marine block compared to late 19th century blocks, with hook and pin and its compliance plate meeting the marine standards of the time.Two sheave rope block; two metal sheaves in polished wooden block with a metal inner pin with a ring on top and a bucket on the bottom. Rectangle carved into one cheek with inscriptions on the attached compliance plate with inscriptions. Stamped within a lozenge: "2 ↑ CS"flagstaff hill museum, flagstaff hill village, shipwreck coast, flagstaff hill, block & tackle, rope, lifting heavy weights, ship rigging, cargo lifiting, two sheave block, compliance plate, marine technology -
Flagstaff Hill Maritime Museum and Village
Equipment - Snatch Block, First quarter of the 20th century
A snatch block is a heavy-duty pulley inside a metal casing. It is primarily designed for handling heavy goods, working as a pulley point that can redirect the course of a winch line. Snatch blocks are also used to increase the lifting or pulling capacity of wire hoists and winches. There is no history or manufacturing provenance currently available.The subject item at this time cannot be associated with an historical event, person or place, provenance is unknown, item is believed to have been produced in the first quarter of the 20th century.Snatch block, metal, one sheave, with a large hook that has a hole drilled through its tip.flagstaff hill, warrnambool, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, snatch block, metal snatch block, lifting gear, rope pully, marine technology, ship rigging -
Flagstaff Hill Maritime Museum and Village
Equipment - Block, Late 19th to early 20t century
... marine technology marine equipment lifting equipment ship rigging ...Pair of two sheave wood blocks; the top block has wooden sheaves and metal straps with bolt thimble, and the lower block has an external metal strap with a forged one-piece ring on top and metal sheaves.flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, 2 sheave wood block, wood block, block, marine technology, marine equipment, lifting equipment, ship rigging, rigging, sailing ship
