Physical description

Rectangular frame with coiled metal wires on two opposite sides. Symmetrical placement of screws with connecting wires and terminals between the two sides. Removable cylindrical pin through center of top plate. Four smaller coils of wire secured to underside of top plate. Object rests on ends of three screw feet, two forward and one rear.

Inscriptions & markings

Engraved at center of top plate: ' H. TINSLEY & CO. LONDON S. E.'
Engraved at lower centre of top plate: 'NO 16949'
Engraved on top of cylinder pin: 'NO 19908'
Front side of top plate engraved with: 'DEFLECTING COILS'
Engrave on center base of front side: '10 / VOLTS'
Left side of top plate label: 'NAT. PHIL. LAB. / NO 65 / UNIV. OF MELB.'
Associated label separate to object also has inscription on recto: 'Schering & / Schmidt / Galvanometer' and upside down on verso: 'A. C / [r] [e] [...] Gold[l]ing / p.p. 245' (writing unclear)
