Rowland Diffraction Grating & Goniometer

From the Collection of The Ed Muirhead Physics Museum Level 2, The School of Physics, David Caro Building (192) Corner of Elgin and Swanston Streets The University of Melbourne Parkville VIC

Diffraction grating of 14,437 lines/inch x 3 1/4 inch. Set in goniometer. “The grating is a ruling of 14,437 lines/inch by Rowland, on a concave spherical speculum mirror of 4-1/2 inch aperture and 10 ft radius. First order dispersion is 5.5 A per mm.” (see RTW Bigham: ‘Concave Roland Grating: Eagle Mounting” in ‘Inspection of New Wing’; Appendix B5 , Vol 2 of Laby :CollectedPapers. The remnants of the Eagle Mounting, featuring a 4 inch tube x 10 ft long, presently uncatalogued, lies on the roof of a display cabinet in the PSB basement open cage-store.
H20 x Diameter 20
Object Registration
diffraction grating, rowland & goniometer
Historical information
Speculum metal blanks made by John H. Brashear(1840-1920) from John Hopkins University in Baltimore, Diffraction Grating made by Prof. H.A. Rowland, [School of Physics, University of Melbourne.] No known publications using the Eagle mounting. May have been used exclusively for practical work in Physics III.
When Made
Made By
Kirkpatrick & Co., London
Inscriptions & Markings
Kirkpatrick & Co., London
Last updated
3 Mar 2017 at 10:10AM
