Air Flow Guage

From the Collection of Maldon Vintage Machinery Museum Inc Vincents Road Maldon Victoria

Description
Comprises two calibrated cylinders mounted on a board for measuring inches of water.
Gauges measure air velocity.
Cylinders are of steel with calibrations on aluminium casings.
Flexible tubes are connected to reservoirs at the back of the mounting board, one black rubber the other red plastic.
A reference barometer is mounted at the bottom right hand corner of the backing board.
Reservoirs at the rear are of metal, coloured blue.
Size
L 80 x H 44 x W 10 cm
Object Registration
VMVM 117
Keywords
instruments, air flow
When Made
Estimated pre 1970
