Equipment - HELIOGRAPH TRIPOD, Heliograph Tripod Legs, c. 1940 - 1945

Historical information

Tripods similar to this were used in both WW1 and WW2. Note: Item 6482 is a Heliograph that was mounted onto a tripod such as this when it was used for surveying.

Physical description

Tripod with wooden legs painted in jungle green. The legs are attached to the apex with tarnished brass fittings, each secured with brass screws. Metal reinforcing plates protect the pointed end of each leg. A brass plate sits at the apex with a threaded rod positioned to allow the attachment of a heliograph or signal light. A khaki webbing shoulder strap for carrying the item is secured to one of the legs. At the bottom end of the strap is a webbing loop used to secure the tripod legs when closed.

Inscriptions & markings

Stamped on one wooden leg: '15629'
Stamped on the top plate: 'D(upwards arrow)D, 0 with an upwards arrow through it, 3(upwards arrow)0'
Stamped on one brass leg fitting: 'STAND LAMP OR HELIO A MKlll'
