Aircraft Recognition Model - Model Aircraft


From the Collection of B-24 Liberator Memorial Restoration Australia Inc Corner Farm Rd & Princes Highway Werribee Victoria

Description: Small bakelite British Airspeed Oxford aircraft, coloured black matt, uncluding hole for suspension and mobility.
Size: Wing span 22cm x 14cm L
Object Registration: 0224
Historical information: Created to supply training & recognition of friendly/enemy aircraft.
When Made: 1941-1945
Significance: Expanded the skills of recognition for air crew, ground crew and defence activities.
Inscriptions & Markings: Airspeed Oxford E9-2189 D^D DLTDC
Last updated: 31 Jul 2018 at 10:17AM

Flying Log Book - Flight Log- Liberator Flights

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Plastic covered ring binder,A4 plastic sheet covered photocopied paper.

Historical information

R.M. Beattie qualified as a B24-Liberator pilot on9/05/1944 until he was KIA 2/07/1945.

Inscriptions & Markings

Flight Log Book- Liberator Flights, Flt. Lt. Roy McBeattie 404228 DFM

Preview View Page

Aero Engine Valve Assembly - Aircraft Radial Engine Valve

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Valve fitted with spring and porcelain valve head.Slight bend in valve stem due to impact damage.

Historical information

Item was found at a Japanese aircraft crash site on Nauru Island 1975

Significance

Indicate Japanese manufacturing level during WW11. The porcelain head on the valve is unusual and difficult to match to steel.

Inscriptions & Markings

None

Preview View Page

Bomb Release Quadrant- Scale Model

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Quarter circle quadrant with operating levers and security bracket. Body is dark green with two red operating handles.

Historical information

After an eight year international search for a complete bomb quadrant to fit the B24- Liberator fuselage it was decided to create a replica. This scale mode was used to prove the methodology.

Significance

This scale model allowed us to manufacture a full size complete working replica.This replica is now installed in the B24-Liberator and completes the operational system.

Preview View Page

Bomb Release Quadrant - Partial Bomb Release Quadrant

B-24 Liberator Memorial Restoration Australia Inc, Werribee

The item has 50% of it's body missing.Quadrant base and operative lever.Quarter circle casting with operating handle attached,base is squared off with rivets attaching both parts.

Historical information

Created for the purpose of bomb delivery from B-24 Liberator aircraft. The item was originally fitted to RAAF Liberator 72-176. During salvage and disposal operations it was damaged losing 50% of the body. The item was used as a reference to manufacture a complete example.

Significance

An example of late 1930's engineering practice in an endeavour to modernise aircraft technology.

Inscriptions & Markings

Bomb doors, 32-F-7523 (part number) three times, closed, open, safe, select.

Preview View Page

Oral History - Arthur Cambell Williams History

B-24 Liberator Memorial Restoration Australia Inc, Werribee

A4 perspex covered, bound typed copy

Historical information

Arthur Williams was in the RAAF from13/10/1940 until April 1946 and was a radar operator between February 1945 and April 1946.

Significance

The oral history of Arthur Williams is of historical significance because it provides a first hand account of the individual's experience during WW11 as a member of the RAAF who trained at Tocumwal.He saw active service in the Pacific conflict from Leyburn and Morotai as a radar operator on a B24 Liberator supporting Z Force.

Inscriptions & Markings

Black printed Arthur Cambell Williams History on grey paper with fancy black border

Preview View Page

Untitled

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Large bakelite B17 Flying Fortress aircraft, coloured matt black, including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew, ground crew and defence activities.

Inscriptions & Markings

"Flying Fortress" Boeing B17E.E9-2324 DS^D DLTDC

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Small bakelite Spitfire Mk 5 aircraft, coloured matt black, including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft

Significance

Expanded the skills of recognition for air crew, ground crew and defence activities.

Inscriptions & Markings

"Spitfire" Mk.V. Trop. E9-2275 D^D DC LTD

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Small bakelite Curtiss "Helldiver" aircraft model coloured matt black, including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew, ground crew and defence activities.

Inscriptions & Markings

Curtiss SB2C-1 E9-2349 D^D DLTDC.

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Medium bakelite Japanese Nakajima Kate aircraft, coloured black including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew. ground crew and defence activities.

Inscriptions & Markings

NAKA T-97 NTB June '42.

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Medium bakelite German Junkers 88 aircraft model, coloured black including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft

Significance

Expanded the skills of recognition for air crew, ground crew and defence activities.

Inscriptions & Markings

German Junkers 88. 9.42

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Small bakelite P38 Lightning aircraft model, coloured black including hole for suspension and mobility.

Historical information

Created to supply recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew,ground crew and defence activities.

Inscriptions & Markings

P-38, US July 42

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Large bakelite Consolidated 31 aircraft model coloured black.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew,ground crew and defence activities.

Inscriptions & Markings

"Consolidated31" E9-2994 D^D DLtdC

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Small bakelite CAC Boomerang aircraft model, coloured black.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for ground crew, air crew and defence activities.

Preview View Page

Aircraft Recognition Model - Model Aircraft

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Small bakelite P39 Aircobra Aircraft, coloured black matt including hole for suspension and mobility.

Historical information

Created to supply training and recognition of friendly/enemy aircraft.

Significance

Expanded the skills of recognition for air crew, ground crew and defence activities.

Inscriptions & Markings

P-39 June 42 US

Preview View Page

Log Book - Obserevers Air Gunners And W/T Operators Flying Log Book

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Rectangular blue linen bound cover book

Historical information

C. G. Ashcroft qualified as a 1st Engineer on B-24 Liberator aircraft in March 1944

Inscriptions & Markings

G C Ashcroft 32827 Flying Officer

Preview View Page

Flying Log Book - Royal Australian Air Force Flying Log Book

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Leather covered Log Book

Significance

Log book was issued to W O Isaacs who qualified as a pilot on Airspeed Oxford, Anson and Liberator aircraft.

Inscriptions & Markings

Royal Australian Air Force. Flying Log Book. Name Isaacs M.G.

Preview View Page

Helmet and Goggles

B-24 Liberator Memorial Restoration Australia Inc, Werribee

Leather helmet with suede lining, under chin strap, earphone inlets with snap locked flaps. Metal framed goggles with leather surrounds, adjustable rubber strap and split glass lenses.

Significance

These goggles and helmets were issued to flying recruits for learning to fly biplanes.

Inscriptions & Markings

Made in England Patent. R51067 scratched into metal.

Preview View Page

Computer True Air Speed

B-24 Liberator Memorial Restoration Australia Inc, Werribee

2 black discs printed with luminous paint with plastic indicator, used for calculating true air speed.

Historical information

Standard crew issue for pilots and flight engineers

Significance

Equipment supplied crew with a computer to calculate true airspeed.

Inscriptions & Markings

COMPUTER. TRUE AIRSPEED. A.C. TYPE G-1 A list of 4 instructions for use. Spec. No. 27367-A, MFG.DWG. No. 42D531, Order No.42-18049-P GENERAL LUMINESCENT CORPORATION, CHICAGO

Preview View Page

Graviscope - Graviscope for Liberator

B-24 Liberator Memorial Restoration Australia Inc, Werribee

2 Circular plastic manual computing discs with black print on a white background with areas for calculating Centre of gravity, Armament, Bomb loadings,Fuel, oil,Crew, Miscel., Oxygen and Camera. Clear plastic protractor with string attached. Enclosed in a leather envelope.

Historical information

Standard crew issue for pilots and flight engineers.

Significance

The equipment supplied air crew with a computer to calculate individual aircraft's weight and balance.

Inscriptions & Markings

GRAVISCOPE FOR LIBERATOR. MODEL B24J, L AND M. MANUFACTURED BY MELB. >W&G< AUST. R.A.A.F IDENT NO G6B/2396

Preview View Page
