Vickers Machine Gun Clinometer MkIV, 1940

Untitled image

Reuse this media

Can you reuse this media without permission? No (with exceptions, see below)

Conditions of use

All rights reserved

This media item is licensed under "All rights reserved". You cannot share (i.e. copy, distribute, transmit) or rework (i.e. alter, transform, build upon) this item, or use it for commercial purposes without the permission of the copyright owner. However, an exception can be made if your intended use meets the "fair dealing" criteria. Uses that meet this criteria include research or study; criticism or review; parody or satire; reporting news; enabling a person with a disability to access material; or professional advice by a lawyer, patent attorney, or trademark attorney.

Attribution

Please acknowledge the item’s source, creator and title (where known)

Have a question? Contact Montmorency/Eltham RSL Sub Branch

Historical information

Used in WWII

Significance

Used in WWII

Physical description

Clinometer Mk IV: Vickers Machine gun brass and steel. Used for sighting long range fire or a fixed fire line of fire for a Vickers .303 inch machine gun. The top of the clinometer contains a spirit level and at each end there is a brass and steel winder that can depress or elevate the clinometer from minus twenty degrees to plus twenty degrees. The brass scale is graded in five degree units. At the bottom of the clinometer is two brass lugs and a brass steel spring loaded small plate, used for attachment to a Vickers machine gun. Serial number 809.

Inscriptions & markings

The front face plate has markings: DEP DEGs and ELEV DEGs. The scale is marked in one degree increments numbered in five D degree increments to the left, and five E increments to the right. The left winder is marked from zero to fifty degrees in ten D degree increments. The right winder is marked from zero to fifty degrees in ten E degree increments. The rear face is marked: 1940, the letters TS inside a circle, and No 809. It also has CLINOMETER SIGHT (MARK IV) markings.
