Photograph - Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo, c1993

  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.

    Air Survey Squadron - Army Survey Regiment, Bendigo. c1993. .1) - Zeiss (Jena) Stecometer, SPR Kim Baker. .2) - Wild PUG4 point transfer device, CPL Paul Bouton.

  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.

    Air Survey Squadron - Army Survey Regiment, Bendigo. c1993. .3) to .4) - Wild PUG4 point transfer device, L to R: CPL Darren Scott, CPL Paul Bouton.

  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.

    Air Survey Squadron - Army Survey Regiment, Bendigo. c1993. .5) to .6) - CPL Doug Willis. .7) - WO2 Noel ‘Macca’ McNamara.

  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.

    Air Survey Squadron - Army Survey Regiment, Bendigo. c1993. .8) - SGT Barry Miller.

  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.
  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.
  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.
  • Aerotriangulation Production – Army Survey Regiment, Fortuna, Bendigo. c1993.

Historical information

This is a collection of eight photographs of Air Survey Squadron personnel operating aerotriangulation equipment at the Army Survey Regiment at Fortuna, Bendigo, c1993. PUG4 devices were used by technicians to stereoscopically view the photography containing the survey control points and the mapping aerial photography. The Control points were transferred from the control photography to the mapping diapositives of aerial photography by drilling their locations into the photographic emulsion. The Zeiss (Jena) Stecometer analytic stereocomparator for air photography shown in photo .1P was introduced at Air Survey Squadron in 1963. Wild PUG4 point transfer devices shown in photos .2P to .4P were introduced in c1968 superseding the PUG2 devices. See item 6195.19P for more photos and descriptions of Air Survey Squadron personnel and aerotriangulation equipment.

Physical description

This is a set of eight photographs of Air Survey Squadron personnel operating aerotriangulation equipment at the Army Survey Regiment at Fortuna, Bendigo, c1993. The photographs were on 35mm negative film and were scanned at 96 dpi. They are part of the Army Survey Regiment’s Collection.
.1) - Photo, black & white, c1993, Zeiss (Jena) Stecometer, SPR Kim Baker.
.2) - Photo, black & white, c1993, Wild PUG4 point transfer device, CPL Paul Bouton.
.3) to .4) - Photo, black & white, c1993, Wild PUG4 point transfer device, L to R: CPL Darren Scott, CPL Paul Bouton.
.5) to .6P) - Photo, black & white, c1993, CPL Doug Willis.
.7) - Photo, black & white, c1993, WO2 Noel ‘Macca’ McNamara.
.8) - Photo, black & white, c1993, SGT Barry Miller.

Inscriptions & markings

.1P to .8P - There are no annotations.
