Historical information

Schematics and details of Navy ships manufactured during WW2. First HMAS YARRA which was a Yarra Class sloop, commissioned Jan 1936 and sunk by Japanese on 4th March 1942.
Second ship was HMAS WARRAMUNGA, a Tribal Class Destroyer Commissioned No. 42 and scrapped Jan 1963.

Physical description

1. Drafting drawing of HMAS YARRA March 1941 from side profile and top down profile on white paper stapled to cardboard. Includes description of all details of ship.
2, Drafting drawing of HMAS WARRAMUNGA March 1943 with side profile and top down profile.

Inscriptions & markings

1. Headed 'HMAS YARRA March '41: Scale 1 inch = 16 feet.
2. Headed 'HMAS WARRAMUNGA" March '43: Scale 1 inch = 24 feet.
