Produced by the SECV to document the Inner Joggle Plates.
Yields information regarding the dimensions of the Inner Joggle Plates for BSS No 1 & No 1C to 102lb BHP & 102lb BHP to BSS No 1 & No 1C.
SEC drawing number VW4/4, "Inner Joggle Plates. BSS No 1 & No 1C to 102lb BHP & 102lb BHP to BSS No 1 & No 1C. Tramways.". Drawn 06/1955. Beige paper copy of original dyeline print.
Copy of original.
