During construction of the railway in 1901 a ballast siding was originally opened 4.5 km south of Barongarook but the ballast proved inferior and a new ballast siding was opened 4 km south of Gellibrand to provide material for track construction. A spur siding, with points facing Beech Forest and a capacity for six trucks, was cut into the side of a slope. Above this was erected a loading bin and chute. This stone was of durable quality so the siding continued in commission after 1902 for periodic track re-ballasting. By the mid-1920s Victoria Railways found it more economic to use ballast from elsewhere so the siding was closed by 1925 and the rails lifted.B/W. Gellibrand Ballast Siding loading ballast down the slope, with five workmen watching at the base.gellibrand; ballast; railways;

In 1902 a ballast siding was opened 4 km south of Gellibrand to provide materials for track construction. A spur siding with a capacity for six trucks was cut into the side of a slope. Above this was erected a loading bin and chute. The stone proved to be of durable quality so the siding continued after 1902 for periodic track re-ballasting works. The points were set for the main line and spiked shut when the siding was not in use. By the mid-1920s the Victorian Railways found it more economic to use ballast from Penshurst, so the siding was closed by 1925 and the rails lifted.B/W. Gellibrand ballast pit siding at 19 miles (30.6 km) south of Colac. gellibrand; gellibrand siding; railways;

In 1902 a ballast siding was opened 4km south of Gellibrand to provide materials for track construction. A spur siding, with points facing Beech Forest and a capacity for six trucks, was cut into the side of a slope. Above this was erected a loading bin and chute. The stone proved to be of durable quality so the siding continued in commission after 1902 for track re-ballasting work. By the mid-1920s Victorian Railways found it more economic to use ballast from Penshurst, so the siding was closed by 1925 and the rails lifted.Photograph; B/W. Gellibrand Ballast Loading Sitegellibrand; ballast; railways; siding;

Digital Imagesyarra river melbourne docklands, yarra river, dock, docklands, shipping, port, channel, water, ship, ballast

Produced as a souvenir from the ballast of two Japanese Midget submarines sunk during attacks on Sydney Harbour in WWII. This souvenir was produced to raise funds for the RAN relief fund and King George's Fund For Sailors. It was sold as a souvenir as part of a touring exhibition around the country accompanying a composite midget submarine constructed of the two sunken vessels raised from Sydney Harbour.The souvenir submarine has tangible connections to the Japanese Midget Submarines sunk during attacks on Sydney Harbour in 1942. It is historically significant for its links to defending Australia and for its connections to tourism and fund raising relating to war time efforts.A small lead model submarine made from a 2 piece mould produced from the ballast of two submarines sunk during attacks on Sydney Harbour in 1942."Made from Ballast Jap Midget Sub" "Sunk in Sydney Harbour May 31 1942"wwii, imperial japanese navy, sydney harbour attack, midget submarine, souvenirs wwii, ran relief fund, king george's fund for sailors

Colour slide of BTPS volunteers laying ballast using the trolley to move the ballast. In the background are trams 27 and 14. Photo by David Frost, Jan. 1974Yields information about the construction of the trackwork at the BTPS Depot.Colour Slide - Kodak cardboard mount.In ink "laying ballast on the final part of the depot fan"tramways, btps, depot fan, trackwork, railway trolley

Small lead model Japanese midget submarine made from the ballast of two submarines sunk during the raid on Sydney Harbour in May 1942.Wording on both sides of model: “Made from ballast Jap midget sub sunk in Sydney Harbour in May 31 1942”military history - souvenirs/navy, handcraft - trench art, submarine

NNN - BALLAST HOPPER, This vehicle was built by the Tasmanian Govt. Railways in 1954 and classified QG. A number were obtained by the Puffing Billy Railway for use on ballast trains but to date, only two have been converted. When the first of these was converted for 2’6” gauge operation it kept the Tasmanian QG but with the addition of an N prefix, and also kept its Tasmanian number of 3. However, to follow traditional V.R. practice, in June 2003 it was reclassified to NNN and numbered 1 as the nearest counterpart on the V.R. was the broad-gauge NN. A second one, numbered 2, has since been converted. 1 NNN - Bogie Ballast Hopper Truck Service History Built 1954 Tasmanian Railways - QR 3 - Bogie Ballast Hopper Truck converted from a 3ft 6 inch (1,068 mm) gauge ex Tasmanian Railways ballast wagon by the Puffing Billy railway. Coupled Length 20 feet 0 inches (6100 mm) Weight 6 tons Capacity 10 tons Number Built Not known In use 1 To be restored 3 Puffing Billy Service History or Notes Historic - Tasmanian Government Railways - 3 QG Bogie Ballast Hopper Truck Puffing Billy Railway - Track maintenance Vehicle - NNN - Bogie Ballast Hopper Truck1 NNN - Bogie Ballast Hopper Truck made of Steel and metal1NNNpuffing billy, pbr, rolling stock , 1 nnn bogie ballast hooper truck, tasmanian government railways, 3 qg bogie ballast hopper truck

NNN - BALLAST HOPPER, This vehicle was built by the Tasmanian Govt. Railways in 1954 and classified QG. A number were obtained by the Puffing Billy Railway for use on ballast trains but to date, only two have been converted. When the first of these was converted for 2’6” gauge operation it kept the Tasmanian QG but with the addition of an N prefix, and also kept its Tasmanian number of 18. However, to follow traditional V.R. practice, it was reclassified to NNN and numbered 2 as the nearest counterpart on the V.R. was the broad-gauge NN. A second one, numbered 1, was also converted. and was reclassified to NNN in June 2003 2 NNN - Bogie Ballast Hopper Truck Service History Built 1954 Tasmanian Railways - QR 18 - Bogie Ballast Hopper Truck converted from a 3ft 6 inch (1,068 mm) gauge ex Tasmanian Railways ballast wagon by the Puffing Billy railway. Coupled Length 20 feet 0 inches (6100 mm) Weight 6 tons Capacity 10 tons Number Built Not known In use 1 To be restored 3 Puffing Billy Service History or Notes Historic - Tasmanian Government Railways - 18 QG Bogie Ballast Hopper Truck Puffing Billy Railway - Track maintenance Vehicle - NNN - Bogie Ballast Hopper Truck2 NNN - Bogie Ballast Hopper Truck made of Steel and metal2NNNpuffing billy railway, pbr, rolling stock , 2 nnn bogie ballast hopper track, tasmanian government railways, 18 qg bogie ballast hopper truck

The construction and opening of the Orbost railway was a major event in the development of Orbost and East Gippsland, resulting in huge development of farming and timber industries. This railway functioned between 1916 until 1987. This photograph/postcard shows a train involved in the construction of the line, in a ballast pit, at Newmerella, near Orbost c.1915. Note: this is a better quality photograph than 2696.1This photograph/postcard is significant because it relates to the construction of the Bairnsdale-Orbost railway line.A b/w photograph on a postcard showing a steam train and wagons in an earth cutting, and a number of workmen in the foreground, along with a railway line.At the bottom of the postcard: Ballast Pit, Orbost - W S Vogt, Bairnsdalerailway, orbost-bairnsdale railway, orbost

Black and white print of VR locomotives Y158 and Y159 on a ballast train crossing over the tram track at Royal Park with W6 989 on a route 68 on the Royal Park Line. Photo by John Dare, 22/8/1983.On rear in ink "Y158, Y159 on ballast train at Royal Park as tram No. 989 bound for West Coburg crosses beneath on 22/5/1983 / John Dare"trams, tramways, royal park, west coburg, vr, tram 989

Hand crushed ballast made by Australian POW's for the Japanese during WWIIGreyish type of granite rock. Silver engraved plate on front.Australian - Thai chamber of commercepow, railway, ballast

Found by Allan Meiers (grandson) at SLV in 2004 when researching the settlement at Ballast ground'Fishermen's Bend, an old-time settlement near Port Melbourne', from page 12 Weekly Times 27 Oct 1906. Four photos of the settlement at the Ballast Ground and John MEIERS (John MYERS), a veteran fisherman fishermans bend, domestic life, industry - fishing, johann meiers, john myers

Found by Allan Meiers (grandson) at SLV in 2004 when researching the settlement at Ballast ground'Fishermen's Bend, an old-time settlement near Port Melbourne', from page 12 Weekly Times 27 Oct 1906. Four photos of the settlement at the Ballast Ground and John MEIERS (John MYERS), a veteran fisherman fishermans bend, domestic life, industry - fishing, johann meiers, john myers

Black and white copy negative obtained by Wal Jack of V 214, towing two trailers, undertaking ballasting operations on the Royal Park tram line, 1925.trams, tramways, v class, royal park, ballast, trailers, tram 214

Black and white photograph of MMTB Ballast Motor No. 11 and trailer at Hawthorn Depot in the 1930's. The tram is loaded with sleepers. Photograph and details of the tramcar are given on pages 70 and 72 of Destination City, 4th Edition. Photograph from Ray Pearson Collection.Yields information about the the MMTB Ballast Motor and the sidings at Hawthorn Depot.Black and white photograph with notes on rear.On rear of both photographs "11 and Ballast Trailer, Hawthorn 1930's" and "B.T.P.S. Sales" in top and bottom left hand corners respectively in red ink.trams, tramways, melbourne, mmtb, hawthorn, ballast motor, work trams, tram 11

Colour slide, Kodak, white cardboard of one of the MMTB Ballast Trailers at the Essendon Aerodrome airport terminus siding. Has the shelter in the background. 9/1/1960. Keith's notes - Ballast trailer (resurrected and reconditioned), Essendon Aerodrome terminus. Slide Number K(q)(283)Extensive handwriting on rear in ink and that it was photographed at 1/125 f5.6.trams, tramways, essendon aerodrome, essendon airport, ballast wagons, shelters

Yields information about the appearance of the depot building soon after completion of the construction and prior to the relocation of the tramcars.Set of three Black and white photographs of the depot fan early 1974 and during the construction of No. 3 road extension, ski jump for tramcar inspection later on. Taken after the ballasting of the depot fan. .1 - No. 26 on three road - after the ballasting of the depot fan and the installation of the overhead. .2 - Lifting and packing 3 road extension .3 - dittotrams, tramways, depot fan, btps, operations, tram 26

Yields information about the appearance of BTM tram No. 661 in 1960, the use of X2 on the Point Ormond line and the reconstruction of the Glenhuntly Road level crossing at Elsternwick during 1960. Black and white photographs of the depot fan late 1973 showing progress in ballasting the fan and area being cleaned up. Three trams in the depot with doors open. Agfa paper with date stamp "?.12.73" trams, tramways, depot fan, btps, operations, trackwork

A ganger, Frank Woosman, is digging ballast near a railway gangers' trolley.Out on the track. Colac-Beech Forest-Crowes Railway. c.1940colac; beech forest; crowes; frank woosman; gangers' trolley; railway;

Wooden bung removed from the steam tug wattle. Found in the bilges of the vessel in the concrete ballast.At an unknown time the bung was used to plug a leak in the hull and concreted over. Uncovered during restoration of forward starboard section of the hull.Circular wooden bung enclosed in a small section of green canvas with fragments of concrete attachedwattle, wooden bung, canvas, restoration

This lead ingot was donated to Flagstaff Hill Maritime Village in January 2015 by local residents who discovered the ingot in their garden after they purchased the property about 12 months ago The LOCH ARD cargo manifest lists “Pig lead 50 tons” comprising “944 pig and 37 rolls”. Subsequent classification has rendered this section of cargo as “Lead Ballast”. This could be true. The international price per ton of lead ore plunged from a high point of £17 in 1853 to a low of £8 in 1882. The cheaper price of lead at the time of the vessel’s loading in early 1878 may have meant it was considered as an alternative to other ballast material (traditionally stone) for the journey to Melbourne. Loch Line ships generally returned to Britain laden with Australian wool. Even though wool bales were “screwed in” to the hold to less than half their “pressed weight”, they still made an awkwardly light cargo for the passage around the Horn. The concentrated weight of lead pigs along the keel line would help steady and centre the ship, and perhaps the artefacts in this case were to be retained for this purpose, rather than being sold on to the ready colonial market. However this is conjecture. Demand for building materials in the gold and wool rich Colony of Victoria was high in the 1870s, and much of the LOCH ARD cargo was intended for the Melbourne International Exhibition in 1880, which was another example of buoyant economic conditions. In the nineteenth century lead was valued for its density (high ratio of weight to volume), flexibility (relative softness for working into shape), and durability (corrosion resistant and waterproofing properties). It was used for pipes and water tanks, roof flashing and guttering, window sealing and internal plumbing. Many large private residences and new public buildings were at planning or construction stage in the colony during this period. The LOCH ARD lead ingots could equally have been destined for this ready market. HISTORY OF THE LOCH ARD The LOCH ARD belonged to the famous Loch Line which sailed many ships from England to Australia. Built in Glasgow by Barclay, Curdle and Co. in 1873, the LOCH ARD was a three-masted square rigged iron sailing ship. The ship measured 262ft 7" (79.87m) in length, 38ft (11.58m) in width, 23ft (7m) in depth and had a gross tonnage of 1693 tons. The LOCH ARD's main mast measured a massive 150ft (45.7m) in height. LOCH ARD made three trips to Australia and one trip to Calcutta before its final voyage. LOCH ARD left England on March 2, 1878, under the command of Captain Gibbs, a newly married, 29 year old. She was bound for Melbourne with a crew of 37, plus 17 passengers and a load of cargo. The general cargo reflected the affluence of Melbourne at the time. On board were straw hats, umbrella, perfumes, clay pipes, pianos, clocks, confectionary, linen and candles, as well as a heavier load of railway irons, cement, lead and copper. There were items included that intended for display in the Melbourne International Exhibition in 1880. The voyage to Port Phillip was long but uneventful. At 3am on June 1, 1878, Captain Gibbs was expecting to see land and the passengers were becoming excited as they prepared to view their new homeland in the early morning. But LOCH ARD was running into a fog which greatly reduced visibility. Captain Gibbs was becoming anxious as there was no sign of land or the Cape Otway lighthouse. At 4am the fog lifted. A man aloft announced that he could see breakers. The sheer cliffs of Victoria's west coast came into view, and Captain Gibbs realised that the ship was much closer to them than expected. He ordered as much sail to be set as time would permit and then attempted to steer the vessel out to sea. On coming head on into the wind, the ship lost momentum, the sails fell limp and LOCH ARD's bow swung back. Gibbs then ordered the anchors to be released in an attempt to hold its position. The anchors sank some 50 fathoms - but did not hold. By this time LOCH ARD was among the breakers and the tall cliffs of Mutton Bird Island rose behind the ship. Just half a mile from the coast, the ship's bow was suddenly pulled around by the anchor. The captain tried to tack out to sea, but the ship struck a reef at the base of Mutton Bird Island, near Port Campbell. Waves broke over the ship and the top deck was loosened from the hull. The masts and rigging came crashing down knocking passengers and crew overboard. When a lifeboat was finally launched, it crashed into the side of LOCH ARD and capsized. Tom Pearce, who had launched the boat, managed to cling to its overturned hull and shelter beneath it. He drifted out to sea and then on the flood tide came into what is now known as LOCH ARD Gorge. He swam to shore, bruised and dazed, and found a cave in which to shelter. Some of the crew stayed below deck to shelter from the falling rigging but drowned when the ship slipped off the reef into deeper water. Eva Carmichael had raced onto deck to find out what was happening only to be confronted by towering cliffs looming above the stricken ship. In all the chaos, Captain Gibbs grabbed Eva and said, "If you are saved Eva, let my dear wife know that I died like a sailor". That was the last Eva Carmichael saw of the captain. She was swept off the ship by a huge wave. Eva saw Tom Pearce on a small rocky beach and yelled to attract his attention. He dived in and swam to the exhausted woman and dragged her to shore. He took her to the cave and broke open case of brandy which had washed up on the beach. He opened a bottle to revive the unconscious woman. A few hours later Tom scaled a cliff in search of help. He followed hoof prints and came by chance upon two men from nearby Glenample Station three and a half miles away. In a state of exhaustion, he told the men of the tragedy. Tom returned to the gorge while the two men rode back to the station to get help. By the time they reached LOCH ARD Gorge, it was cold and dark. The two shipwreck survivors were taken to Glenample Station to recover. Eva stayed at the station for six weeks before returning to Ireland, this time by steamship. In Melbourne, Tom Pearce received a hero's welcome. He was presented with the first gold medal of the Royal Humane Society of Victoria and a £1000 cheque from the Victorian Government. Concerts were performed to honour the young man's bravery and to raise money for those who lost family in the LOCH ARD disaster. Of the 54 crew members and passengers on board, only two survived: the apprentice, Tom Pearce and the young woman passenger, Eva Carmichael, who lost all of her family in the tragedy. Ten days after the LOCH ARD tragedy, salvage rights to the wreck were sold at auction for £2,120. Cargo valued at £3,000 was salvaged and placed on the beach, but most washed back into the sea when another storm developed. The wreck of LOCH ARD still lies at the base of Mutton Bird Island. Much of the cargo has now been salvaged and some was washed up into what is now known as LOCH ARD Gorge. Cargo and artefacts have also been illegally salvaged over many years before protective legislation was introduced. One of the most unlikely pieces of cargo to have survived the shipwreck was a Minton porcelain peacock - one of only nine in the world. The peacock was destined for the Melbourne International Exhibition in 1880. It had been well packed, which gave it adequate protection during the violent storm. Today, the Minton peacock can be seen at the Flagstaff Hill Maritime Museum in Warrnambool. From Australia's most dramatic shipwreck it has now become Australia's most valuable shipwreck artefact and is one of very few 'objects' on the Victorian State Heritage Register. The shipwreck of the LOCH ARD is of State significance ― Victorian Heritage Register S417 Flagstaff Hill’s collection of artefacts from LOCH ARD is significant for being one of the largest collections of artefacts from this shipwreck in Victoria. It is significant for its association with the shipwreck, which is on the Victorian Heritage Register (VHR S417). The collection is significant because of the relationship between the objects, as together they have a high potential to interpret the story of the LOCH ARD. The LOCH ARD collection is archaeologically significant as the remains of a large international passenger and cargo ship. The LOCH ARD collection is historically significant for representing aspects of Victoria’s shipping history and its potential to interpret sub-theme 1.5 of Victoria’s Framework of Historical Themes (living with natural processes). The collection is also historically significant for its association with the LOCH ARD, which was one of the worst and best known shipwrecks in Victoria’s history. Lead ingots (sometimes referred to as ‘lead ballast’ or ‘lead pigs), salvaged from the wreck of the LOCH ARD. Grey metal bars with flat base, rising in a curved moulded shape to form a smooth rounded upper face. The imprint of the maker runs along the upper surface in clearly legible capital lettering (height 3cm). Durable and heavy, with some marine staining, but in good condition. Stamped along curved surface, within oval border, "PONTIFEX & WOOD LONDON."flagstaff hill, warrnambool, shipwrecked coast, flagstaff hill maritime museum, maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, loch line, loch ard, captain gibbs, eva carmichael, tom pearce, glenample station, mutton bird island, loch ard gorge, lead pigs, lead ingots, lead ballast, pontifex and wood, london, lead smelters

Tender document - MMTB - 7 sheets - some pre-printed and some typed with hand written notes titled "Supply and Delivery of Blue Stone Screenings and 1.5 inch metal", for Contract No. 107. Stapled along the left hand side. Only the first page and the schedule of Prices have been scanned. Has the Conditions of tendering, contract etc. \ Total material to be tendered for was 4050 tons, to be delivered to either Burley, Hawthorn, Camberwell, Tooronga or Malvern railway sidings at the rate of a total 345 tons per week. Authorised by S. Dix, 12/1/1921.trams, tramways, ballast, tenders, trackwork, track repairs

The photo shows a group of six men standing in front of a rail mounted arc-welding plant at night. The tracks are open ballasted, possibly Dandenong Road.Yields information about the arc welding plant of the PMTT c1916.Black and white photo mounted on heavy grey card with notes on the rear.One rear in ink "The first arc-welding plant Prahran & Malvern Tramways Trust about 1916. W E ? 3rd from the left"tramways, pmtt, welding, track maintenance

Black and white photograph of a long line up of trams in the storage roads at Preston workshops, including works tram No. 20, and ex VR54 with visitors looking at them. Taken by Chris Phillips during a tour 9/2/1969. Ballast wagon No. 24, and possibly the tram behind is the sleeper carrier tram.On the rear in red ink "VR 54 Preston Workshops 9/2/69"trams, tramways, mmtb, preston workshops, vr, tram 54, tram 20, tram 24

Negative of cable tram crossing from Queensbridge Road into Market St after passing under the railway underpass, along Flinders St. In the background is a the bridge with a Tait train crossing, a work or ballast train on the bridge and the signal gantry. There is a policeman on point duty. The cable tram has the destination of Collins St.trams, tramways, cable trams, flinders st, market st, collins st, railways

Black and white negative, by Wal Jack, of W2 572 (West Preston, route 11) and Scrubber Tram No. 10 and a ballast trailer in the yard at South Melbourne depot - c1960, though the yellow flashing lights on the roof line may indicate a later photo. In the background is a MMTB works vehicle, the Shrine of Remembrancetrams, tramways, south melbourne depot, w2 class, scrubber tram, work trams, west preston, route 11, tram 572, tram 10

Black and white negative by Wal Jack of Ballast car 11, U211 and 209 waiting scrapping at Preston Workshops The car numbers were detailed in the album held by the Ballarat Tramway Museum. Photo undated - see also Reg Item 5289. Could be 19-1-41 or 13-10-40.trams, tramways, preston workshops, u class, scrapped trams, stored trams, work trams, tram 211, tram 11, tram 209
