Showing 19 items
matching flat wick lamp
-
Warrnambool and District Historical Society Inc.
Domestic object - Lantern - household
... flat wick lamp...This is a typical example of a flat wick domestic paraffin... This is a typical example of a flat wick domestic paraffin lamp used ...This is a typical example of a flat wick domestic paraffin lamp used in households prior to the introduction of electricity.A flat-wick lamp is a simple type of paraffin lamp, which burns paraffin drawn up through a wick by capillary action. A flat-wick lamp has a fuel tank (fount), with the lamp burner attached. Attached to the fuel tank, four prongs hold the glass chimney, which acts to prevent the flame from being blown out and enhances a thermally induced draft. The glass chimney needs a "throat", or slight constriction, to create the proper draft for complete combustion of the fuel; the draft carries more air (oxygen) past the flame, helping to produce a smokeless light, which is brighter than an open flame would produce. The wick holder has holes around the outer edges. When the lantern is lit and a chimney is attached, the thermally induced draft draws air through these holes and passes over the top of the wick. This has a cooling effect and keeps the wick from over heating. The lamp burner has a flat wick, made of cotton. The lower part of the wick dips into the fount and absorbs the paraffin; the top part of the wick extends out of the wick tube of the lamp burner, which includes a wick-adjustment mechanism. Adjusting how much of the wick extends above the wick tube controls the flame. The wick tube surrounds the wick and ensures that the correct amount of air reaches the lamp burner. Adjustment is usually done by means of a small knob operating a cric, which is a toothed metal sprocket bearing against the wick. If the wick is too high, and extends beyond the burner cone at the top of the wick tube, the lamp will produce smoke and soot (unburned carbon). When the lamp is lit, the paraffin that the wick has absorbed burns and produces a clear, bright, yellow flame. As the paraffin burns, capillary action in the wick draws more kerosene up from the fuel tank. All paraffin flat-wick lamps use the dead-flame burner design, where the flame is fed cold air from below, and hot air exits above. (Source: Wikipedia accessed 24 Nov 2023) This lantern has a circular heavy green glass base for holding the paraffin. The base has a 12mm green glass handle. There is a small clear glass chimney with a fluted upper edge and some bubbles in the glass. The metal burner and wick holder has four metal prongs to hold the glass chimney in place. The round metal wick winder is functioning. There is a small amount of residual paraffin in the base. The flat wick is made of cotton.There are no markings to indicate the manufacturer.paraffin lamp, flat wick lamp, domestic lantern -
Coal Creek Community Park & Museum
Equipment - Lamp, Kerosene
... flat-wick lamp... Korumburra gippsland lantern flat-wick lamp hurricane lamp lighting ...Slightly rusty oil lamp. No painted areas, all bare metal.- LANORA - LANORA AUSTRALIAlantern, flat-wick lamp, hurricane lamp, lighting device, kerosene lamp -
Orbost & District Historical Society
lamp, C T Ham Mfg Co, 1920's - 1950's
... This "hurricane lantern," is a flat-wick lamp made... gippsland This "hurricane lantern," is a flat-wick lamp made ...This "hurricane lantern," is a flat-wick lamp made for portable and outdoor use. They had a strong glass shade which would protect flames from sudden drafts. It seems that the glass on this item is not the original one.This item is an important example of the early technology of artificial light. It has historical significance in demonstrating lighting devices used before the widespread use of electricity.A metal "hurricane" lamp which has a glass shade. This is a portable oil lantern which has an oil tank on the bottom that forms the base of the lamp. The tank has a door for filling (missing), it also houses the wick and knob that increases or decreases the length of the wick. It has a carrying handle attached to each side of the metal frame.On the base - No 6(?) CLIPPERlighting lantern -
City of Moorabbin Historical Society (Operating the Box Cottage Museum)
Lights, paraffin lamp c1950, c1950
... A flat-wick lamp is a simple type of kerosene lamp, which... that produced by an open flame. The lamp burner has a flat wick, usually ...A flat-wick lamp is a simple type of kerosene lamp, which burns kerosene drawn up through a wick by capillary action. A flat-wick lamp has a fuel tank (fount), with the lamp burner attached. Four prongs hold the glass chimney, which acts to prevent the flame from being blown out and enhances a thermally induced draft. The glass chimney needs a "throat," or slight constriction, to create the proper draft for complete combustion of the fuel; the draft carries more air (oxygen) past the flame, helping to produce a smokeless light which is brighter than that produced by an open flame. The lamp burner has a flat wick, usually made of cotton. The lower part of the wick dips into the fount and absorbs the kerosene; the top part of the wick extends out of the wick tube of the lamp burner, which includes a wick-adjustment mechanism. Adjusting how much of the wick extends above the wick tube controls the flame. The wick tube surrounds the wick, and ensures that the correct amount of air reaches the lamp burner. Adjustment is usually done by means of a small knob operating a toothed, metal sprocket bearing against the wick. A paraffin lamp with a green metal base to hold fuel with a side screw to adjust wick length. An opaque white glass shield sits in a metal frame attached to base* moorabbin, bentleigh, cheltenham, pioneers, early settlers, market gardeners, lights, lamps, paraffin, oil lamps -
City of Moorabbin Historical Society (Operating the Box Cottage Museum)
Lights, Victorian kerosene banquet lamp, c1900
... . There are three types of kerosene lamp: traditional flat wick, central...This kerosene, flat wick, banquet lamp has a clear glass.... There are three types of kerosene lamp: traditional flat wick, central ...The kerosene lamp is a type of lighting device that uses kerosene as a fuel. Kerosene lamps have a wick or mantle as light source, protected by a glass chimney or globe; lamps may be used on a table, or hand-held lanterns may used for portable lighting. There are three types of kerosene lamp: traditional flat wick, central draught (tubular round wick), and mantle lamp. The screws on the side adjust the flame and hence the strength of the flame produced. Prior to the introduction of gas and electricity these lamps provided lighting in all householdsPioneers and early settlers in Moorabbin Shire relied on kerosene lamps for lighting their homes after sunset.This kerosene, flat wick, banquet lamp has a clear glass shade chimney with a frilled rim, a reservoir of plain yellow glass and a metal engraved base . 1 side screw to adjust the flamelights, early settlers, pioneers, market gardeners, moorabbin, brighton, bentleigh, cheltenham. lamps, kerosene, paraffin, oil -
City of Moorabbin Historical Society (Operating the Box Cottage Museum)
Domestic object - Lights, kerosene lamp, blue glass, Unrecorded, c1900
... of light after sunset. This lamp, uses a flat wick immersed...A flat wick kerosene lamp. The knob protruding... sunset. This lamp, uses a flat wick immersed in kerosene or oil ...Early Settlers used candles and lamps as their source of light after sunset. This lamp, uses a flat wick immersed in kerosene or oil, contained in the bulbous reservoir, with a side screw to adjust the flame enclosed in a glass, open top shield.A flat wick kerosene lamp. The knob protruding to the right adjusts the wick, and hence the flame size. This lamp has a plain blue glass shade -chimney with a fluted rim, blue glass geometrically engraved reservoir and a circular brass base early settlers, pioneers, market gardeners, moorabbin, brighton, bentleigh, ormond, mckinnon, lighting, lamps, kerosene, paraffin, oil -
Port of Echuca
Domestic object - Kerosene Lamp
Hand-held kerosene lamps were introduced in the late 1800s for lighting homes prior to the introduction of electricity. This lamp was used in the Bridge Hotel during early European settlement and migration to the area.This lamp is the only example of domestic lighting within the collection. It belongs to the objects relating to the interpretation of Echuca's Bridge Hotel, built by European founder Henry Hopwood.Ornate pressed metal base (4 sided) with floral design. Featuring a ribbed blue glass fuel fount, a four-pronged metal carrier (that would hold a flat cotton wick) with small circular knob (a mechanism for adjusting the wick) and a bulbous clear glass chimney with decorative scalloped edge.lamp, glass, blue glass, kerosene, flat wick, 1800s -
Flagstaff Hill Maritime Museum and Village
Equipment - Kerosene Lamp, Bef. 08-02-1984
The kerosene lamp was one of the most common oil lamps used and was manufactured until the 1980s. This lamp appears to be a modern reproduction of an earlier optional wall-mounted kerosene lamp. The lamp has been produced as an example of a 19th and early 20th-century marine kerosene navigation lamp. Marine lamp; portside metal kerosene lamp with two flat sides, and a curved front. The front has a red ridged glass lens insert and the name "port" is inscribed on a fixed brass plaque. A round chimney is on top of the lid and it has a catch. The fuel tank and wick can be removed through the base. The metal appears to be electroplated.Inscribed on the plaque; "PORT"warrnambool, shipwreck coast, flagstaff hill, flagstaff hill maritime museum, flagstaff hill maritime village, lamp, ship lamp, port lamp, marine lamp, navigation lamp, port, lantern, kerosene lamp, marine technology, ship light, portable lamp -
Flagstaff Hill Maritime Museum and Village
Functional object - Lamp, Bradley & Hubbard, 1900-1919
One of the most common centre draft kerosene lamps one can find in the USA and Canada is the Rayo. Large and sturdy, simple to use, but also notorious for being a fuel hog. This lamp was made by Bradley and Hubbard Metalworks in Chicago also Bradley and Hubbard made the “Perfection” brand lamps that look like the Rayo and are pretty much the same lamp with all parts interchangeable. The Rayo was given away to customers for free as a promotional item by the Standard Oil Company. The lamp’s huge appetite for fuel meant a hefty increase in sales of kerosene for the company and increased profits. The Rayo is a classic centre draft lamp that uses a widely available tubular wick that measures 62mm flat. It employs a simple and reliable mechanism for securing wicks in the burner along with a brass tube with many small teeth at its end. The tube is attached to the toothed rack that’s moved up and down by the adjuster knob.This type of lamp was used in most households and on rural properties before the introduction of electricity and is an early example of a promotional. The lamp was given away to customers of Kerosene oil as a means of increasing the Standard Oil Company sales of Kerosene during the late19th to early 20th century.Lamp of metal without shade. Mantle burner, plated light metal base. Ornate shade holder. Broken glass.Marked "Rayo Junior"flagstaff hill, warrnambool, flagstaff hill maritime museum, shipwreck coast, flagstaff hill maritime village, great ocean road, lamp, mantle lamp, metal lamp, lighting, oil lamp, bradley & hubbard -
Flagstaff Hill Maritime Museum and Village
Domestic object - Lamp, Bradley & Hubbard, Early 20th century
One of the most common centre draft kerosene lamps one can find in the USA and Canada is the Rayo. Large and sturdy, simple to use, but also notorious for being a fuel hog. This lamp was made by Bradley and Hubbard Metalworks in Chicago also Bradley and Hubbard made the “Perfection” brand lamps that look like the Rayo and are pretty much the same lamp with all parts interchangeable. The Rayo was given away to customers for free as a promotional item by the Standard Oil Company. The lamp’s huge appetite for fuel meant a hefty increase in sales of kerosene for the company and increased profits. The Rayo is a classic centre draft lamp that uses a widely available tubular wick that measures 62mm flat. It employs a simple and reliable mechanism for securing wicks in the burner along with a brass tube with many small teeth at its end. The tube is attached to the toothed rack that’s moved up and down by the adjuster knob. This type of lamp was used in most households and on rural properties before the introduction of electricity and is an early example of a promotional. The lamp was given away to customers of Kerosene oil as a means of increasing the Standard Oil Company sales of Kerosene during the late19th to early 20th century.Kerosene Lamp, side lifting arm to light.Inscribed "Rayo" and "Made in the USA"flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill-maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, kerosene lamp, lighting, hurricane lamp, storm lamp, rayo ltd -
Flagstaff Hill Maritime Museum and Village
Functional object - Lamp, Probably second half of 19th century
... oil lamp. This lamp had a broad flat wick held between two... the Argand oil lamp. This lamp had a broad flat wick held between two ...OIL LAMPS Oil had been burnt in lamps at least since the Palaeolithic age, and the cheapest light fittings used in Victorian homes had changed little since then, with a simple wick protruding from a small container of whale oil or vegetable oil. However, much brighter and more sophisticated lamps had emerged late in the 18th century, the most important being the Argand oil lamp. This lamp had a broad flat wick held between two metal cylinders to form a circular wick, with air drawn through it and around it. This in itself was a revolutionary idea, but its inventor, Aimé Argand also discovered that by placing a tube or 'chimney' over the flame, the hot gases from the flame rose rapidly creating a draught and drawing air in from below. Fanned by a draught from both inside and outside the circular wick, the poor spluttering flame of early lamps was transformed into a bright, efficient light source (see illustration). The one disadvantage for the Argand oil lamp and its many imitators in the early Victorian period was that the best oil then available, colza, was so thick and viscous that it had to be fed to the wick either by gravity from a reservoir above, or pumped up from below. Most colza oil lamps have a reservoir often shaped like a classical urn to one side which in some fittings obstructed the light. The Sinumbra lamp got around the problem by having a circular reservoir around the base of the glass light shade. One of the most significant improvements of the Victorian period was the introduction of paraffin. Patented in 1850, the price of the new fuel fell dramatically following the discovery of oil in Pennsylvania, USA. As paraffin was much lighter than colza the reservoir could be placed below the flame, enabling many new designs of light fittings. One of the most successful paraffin lamps was the Duplex burner introduced in 1865 which had two wicks side by side and, like the Argand lamp, a clear glass chimney with air drawn from below. Most lamps also had a larger shade around the chimney often of opaque glass to diffuse the light. The shades or diffusers provided an opportunity for decoration, and a variety of shapes, colours and patterns were used. The amount of light which can be produced by a wick is limited by the surface area of the wick and the amount of fuel and air able to reach it. As fuel burns at the tip of the wick only. The gas mantle, on the other hand, provides a much larger three-dimensional surface, and is far more effective as a result. Invented by Carl Aur von Wesbach in 1885, the incandescent mantle was the last major breakthrough in oil and gas lighting of the period, before both succumbed to electric lighting. The mantle consists of a skirt of silk or cotton impregnated with a non-inflammable mixture (thorium and cerium), suspended over a fierce flame. When first ignited, the cotton burns away leaving fine, brittle filaments of non-combustible material in its place which glow white hot or 'incandescent'. The mantle works best with either gas or a fine mist of paraffin produced by a pressurised reservoir which is still widely used in camping lamps today, producing a bright, warm light to rival an electric bulb. https://www.buildingconservation.com/articles/lighting/lighting.htm http://www.artandarchitecture.org.uk/stories/lighting/lighting4.html#:~:text=Oil%20had%20been%20burnt%20in,whale%20oil%20or%20vegetable%20oil.An item of great importance in any home before gas or electricity was available.Kerosene lamp, ceramic, with metal top and wick. Has handle at side and floral hand painting around the body. Glass cover. Metalwork is rusty.Noneflagstaff hill, warrnambool, flagstaff-hill, flagstaff-hill-maritime-museum, maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, oil lamp, heating, lighting, ceramics -
Flagstaff Hill Maritime Museum and Village
Functional object - Anchor Lamp, Bef. 09-02-1984
The kerosene lamp was one of the most common oil lamps used and was manufactured until the 1980s. An anchor lamp like the lamps in this pair would be raised on the highest ship mast at night to signal other seafarers that the ship was at anchor or sailing at night. The metal loops on opposing sides of the lamp could hold a pair of rods or ropes. and be used to raise the lamp.The lamp is made to the design of a 19th and early 20th-century kerosene anchor lamp carried as essential marine equipment and used as a signal lamp on sailing ships. Lamps; a pair of cylindrical kerosene anchor lamps. Each has a flat back, a hinged door, a metal handle and two metal loops or guides fixed on each side. The glass window is convex and inside the lamp is a wick in an enamel wick holder.brass lamp, lamp, anchor kerosene lamp, kerosene lamp, marine equipment, marine lamp, navigation, light, ship light, ship lamp, lantern, maritime, nautical, safety lamp -
City of Moorabbin Historical Society (Operating the Box Cottage Museum)
Lights, Victorian kerosene banquet lamp, c1900
... . There are three types of kerosene lamp: traditional flat wick, central.... There are three types of kerosene lamp: traditional flat wick, central ...The kerosene lamp is a type of lighting device that uses kerosene as a fuel. Kerosene lamps have a wick or mantle as light source, protected by a glass chimney or globe; lamps may be used on a table, or hand-held lanterns may used for portable lighting. There are three types of kerosene lamp: traditional flat wick, central draught (tubular round wick), and mantle lamp. The side screws adjust the length of the wick and hence the strength of the flame / light produced. Prior to the introduction of gas and electricity these lamps provided light in households after sunset.Prior to the introduction of gas and electricity these lamps provided light after sunset for the early settlers, as they established their farms and businesses, in Moorabbin Shire.A Victorian kerosene banquet lamp, with a gilded metal quad footed base, cranberry glass oil reservoir with geometric patterns, original etched, yellow, glass globe shade and clear glass chimney. There are 2 side screws for adjusting the flame.early settlers. pioneers, follett w, moorabbin, bentleigh, brighton, ormond, market gardeners, kerosene, paraffin, lights, lamps, candles -
City of Moorabbin Historical Society (Operating the Box Cottage Museum)
Lights, kerosene chamber lamp, 19thC
... . There are three types of kerosene lamp: traditional flat wick, central.... There are three types of kerosene lamp: traditional flat wick, central ...The kerosene lamp is a type of lighting device that uses kerosene as a fuel. Kerosene lamps have a wick or mantle as light source, protected by a glass chimney or globe; lamps may be used on a table, or hand-held lanterns may used for portable lighting. There are three types of kerosene lamp: traditional flat wick, central draught (tubular round wick), and mantle lamp. The side screws adjust the length of the wick and hence the strength of the flame/light produced. Prior to the introduction of gas and electricity these lamps were used for lighting in all households after sunsetPioneers and early settlers relied on kerosene lamps for lighting their homes after sunset.A 19th Century kerosene chamber lamp, with clear, plain glass shade and reservoir, circular metal base and 1 side screw for adjusting the flameearly settlers, pioneers, market gardeners, moorabbin, brighton, bentleigh, ormond, cheltenham, candles, lights, lamps, kerosene, paraffin, oil -
Flagstaff Hill Maritime Museum and Village
Domestic object - Lamp, Bradley & Hubbard, Early 20th century
One of the most common centre draft kerosene lamps one can find in the USA and Canada is the Rayo. Large and sturdy, simple to use, but also notorious for being a fuel hog. This lamp was made by Bradley and Hubbard Metalworks in Chicago also Bradley and Hubbard made the “Perfection” brand lamps that look like the Rayo and are pretty much the same lamp with all parts interchangeable. The Rayo was given away to customers for free as a promotional item by the Standard Oil Company. The lamp’s huge appetite for fuel meant a hefty increase in sales of kerosene for the company and increased profits. The Rayo is a classic centre draft lamp that uses a widely available tubular wick that measures 62mm flat. It employs a simple and reliable mechanism for securing wicks in the burner along with a brass tube with many small teeth at its end. The tube is attached to the toothed rack that’s moved up and down by the adjuster knob. This type of lamp was used in most households and on rural properties before the introduction of electricity and is an early example of a promotional. The lamp was given away to customers of Kerosene oil as a means of increasing the Standard Oil Company sales of Kerosene during the late19th to early 20th century.Kerosene Lamp, side lifting arm to light.Inscribed "Rayo" and "Made in the USA"flagstaff hill, warrnambool, shipwrecked-coast, flagstaff-hill-maritime-museum, shipwreck-coast, flagstaff-hill-maritime-village, kerosene lamp, lighting, hurricane lamp, storm lamp, rayo ltd -
Coal Creek Community Park & Museum
Large tallow lamp
8469.1 - Tall truncated cone with a small flat hinged disc lid, bent wire handle and long tapering spout with cotton wick present. -
Coal Creek Community Park & Museum
Small tallow lamp
8467.1 - Small tallow lamp, truncated cone with bent wire handle, simple flat disk lid and long near cylindrical spout. It appears to still retain cotton wick in the end of its spout. -
Andrew Ross Museum
Table Lamp
... and font, brass gallery,double flat wick. Table Lamp ...Kerosene table lamp, pink glass base and font, brass gallery,double flat wick. -
Wodonga & District Historical Society Inc
Functional object - Slush lamp for examining and oiling train engines, c. late 1800s to early 1900s
The slush lamp is thought to have been used for examining and oiling train engines.The slush lamp has local significance as it was donated by a resident of Wodonga. It also has historic significance as an example of an object made by upcycling in the c. late 19th century and early 20th century.The slush lamp consistis of a rectangular grey metal body with soldered edges with a flat handle at one end, a fibrous textile wick protruding from a long spout at the other end, and a cork inserted in the opening on the top surface to secure the fuel used. Slush lamps are defined as "improvised lights made from a container of fat and a wick", originating in the mid-19th century. slush lamp, slush lamps, improvised lamps
